Philips HomeRun Aqua 7000 Series User manual

Aqua
HomeRun
Vacuum & Mop Robot
Aqua
Vacuum & Mop Robot
7000 Series

XU7000
XU7000
XU7000
2
8 9
26
12
11 18
19
1413
10
4
1
35
15
16 17
21
24
25
7
6
37
36
38
39
34
33
35
29
45
42
43
XU7100
20
40
41
27
28
32
31
30
22
44
23
XU7100
46

English 6
Čeština 42
Dansk 78
Deutsch 114
Eesti 152
Español 188
Français 227
Hrvatski 265
Italiano 301
Latviešu 339
Lietuviškai 376
Magyar 413
Nederlands 451
Norsk 489
Polski 525
Português 563
Română 601
Shqip 638
Slovenščina 676
Slovensky 712
Srpski 749
Suomi 785
Svenska 821
Türkçe 857
Ελληνικά 893
Български 894
Македонски 933
Русский 972
Українська 1011

English
6English
Contents
Introduction ______________________________________________________________________________ 6
Product overview __________________________________________________________________________ 6
Sensor overview____________________________________________________________________________ 7
Before first use_____________________________________________________________________________ 7
Preparing for use___________________________________________________________________________ 8
Audible signals_____________________________________________________________________________ 13
How your robot works ______________________________________________________________________ 13
Using your robot ___________________________________________________________________________ 18
Cleaning and maintenance __________________________________________________________________ 21
User interface signals and their meaning ______________________________________________________ 32
Reset/restore the robot _____________________________________________________________________ 34
Replacement ______________________________________________________________________________ 34
Warranty and support ______________________________________________________________________ 36
Disposal and recycling ______________________________________________________________________ 37
Troubleshooting ___________________________________________________________________________ 37
Introduction
Congratulations on your purchase of a Philips HomeRun Vacuum and Mop robot
7000 Series Aqua! To get the most out of your robot and access all the advanced
functions you can download and install the Philips HomeRun robot app. You can
also find support videos and frequently asked questions in the app.
Read the separate safety booklet carefully before you use the machine for the
first time and save it for future reference.
Product overview
1 Dust bin
2 Washable filter
3 Lid of the washable filter
4 Filter lock
5 Filter lid lock
6 Dust bin empty lid
7 Release buttons of the dust bin
8 On/off button
9 Home button
10 Reset button
11 Top cover
12 Bumper
13 Vacuum inlet
14 Air outlet
15 Water tank
16 Release button of the water tank
17 Water inlet
18 Main brush
19 Brush cover
20 Release buttons of the brush cover
21 Main wheels

7
English
22 Front caster wheel
23 Charging contact points (robot)
24 Side brush
25 Mop pad holder
26 Washable mop pad (2x)
27 Power cord (XU7000)
28 (Charging) station (XU7000)
29 IR signal window (XU7000)
30 Charging contact points (station)
31 Power cord socket
32 Placemat (XU7000)
33 Dust bag (2x) (XU7100)
34 Canister lid
35 Dust bag compartment
36 Auto-Empty station (XU7100)
37 Indicator light
38 IR signal window
39 Ramp
40 Auto-Empty inlet
41 Auto-Empty air outlet
42 Charging contact points (station)
43 Exhaust vent
44 Brush cleaning tool
45 Power cord socket
46 Power cord (XU7100)
Sensor overview
1
5
3 4
6
7 7
77
7 7
6
6
6
6
6
6
6
2 2
1 360° laser navigation (LiDAR)
2 Collision sensor (2x)
3 Infrared signal receiver to find the station
4 Infrared signal emitter to communicate with the station
5 3D ToF sensor to detect and avoid small obstacles in front of the robot (120°)
6 ToF-sensor to detect and avoid small obstacle around the robot (8x)
7 Anti-drop sensor (6x)
Before first use
1Take the appliance out of the box and remove all packaging.
2Remove the protection covers.

8English
3If you see any sign of visible damage, go to www.philips.com/support or
contact the Consumer Care Center in your country.
Install and fill the water tank
2
1
1Fill the water tank. Use the water inlet.
Note: Make sure that the outside of the water tank is dry.
Note: Do not use cleaning detergents.
2
1
2Insert the water tank in the correct location.
Preparing for use
Install the robot and the station
Tips for choosing the best location for installing the station:
-Do not place the station in bright sunlight or under furniture. This will block
the infrared signal that helps the robot find its way back to the station.
-Install the station on a level surface against a wall.
-Install the station on a hard floor.
-Do not place the station near stairs or a heating source (radiator).
-Install in a location with good WiFi coverage.
To install the station:
1Install the station within the correct dimensions for placement.
-Model XU7100 -Model XU7000
-
0.5m
0.5m
1.5m
-
0.5m
0.5m
1.5m

9
English
Note: Keep 0.5 meters of space on the sides of the station and 1.5 meters
in front of the station.
2Connect the station to the power supply.
3Make sure that the remaining part of the power cable is well concealed
behind the station so that the robot cannot drive over it.
Note: For model XU7100 only, place the dust bag in the dust bag
compartment of the station.
Charging the robot
1Turn the robot to its correct position and put the robot on the floor in front of
the station. The water tank should be facing away from the station.
-Model XU7100 -Model XU7000
- -
2Make sure that the station is connected to the wall socket.
3Press and hold the on/off button for 3 seconds to switch on the robot.
4Press the home button. The robot drives to the correct position in the station.
-Model XU7100 -Model XU7000
-
2
1
-
2
1
5Wait until the robot is fully charged.
If the battery is empty, the robot will not drive itself to the correct position. In
this case, follow the next steps:
1Turn the robot to its correct position and put the robot on the floor in front of
the station.
2Align the wheels with the tracks on the station (for model XU7100) or align
the charge contacts of the robot with the charge terminals of the station (for
model XU7000).
3Push the robot in and let the wheels go in the tracks (for model XU7100) or
put the robot with the charge contacts on the charge terminals of the station
(for model XU7000).

10 English
Model XU7100 Model XU7000
-
1
2
-
1
2
Note: Make sure that the robot is in its correct position and starts to
charge. The lights in the two buttons on the robot flash slowly. If the battery
is empty, it may take a while before the robot indicates that it is charging.
4Wait until the robot is fully charged.
Note: Make sure the robot is fully charged before you use it for the first
time.
Note: When the robot is charging, the lights in the two buttons on the robot
will flash slowly.
Note: For model XU7100 only, the white LED on the station also lights up to
indicate that the robot is charging.
Note: For model XU7100 only, after the battery is fully charged, the white LED
on the station will light up continuously, meaning the robot is now in standby
mode.
Download the app, register, and connect to Wi-Fi
App content
You can operate the robot with the Philips HomeRun robot app. The app allows
you to manage your robot and offers help and support:
1How-to-use videos.
2Full user manual.
3FAQs.
4Contact Consumer Care.
5Create a map of your home.
6Select which rooms to clean.
7Choose between different cleaning modes and settings for each room.
8View the status of the cleaning run in real time and see the battery level.
9Receive notifications and alerts.
10 Schedule a cleaning run.
11 See the maintenance status and find replacement parts .
12 Connect your robot with a digital voice assistant to operate it via voice
commands.

11
English
Downloading the app
1Scan the QR code on the cover of this user manual or on the package of the
robot.
Or:
Search for 'Philips HomeRun robot app' in the Apple App Store or one of the
Android App Stores.
2Download and install the app.
3Follow the instructions in the app.
Registering a personal account
You can register a personal account and benefit from the following advantages:
-Control the robot from more than one device, e.g. a smart phone and tablet,
or add multiple users in the household.
-Save back-up of important data like customized cleaning plans for your
home.
-Connect your robot with a smart home speaker.
Note: If you change your phone and you don't have an account, then you'll
lose all customized cleaning plans.
Important: Philips values and respects your privacy. A link to our privacy notice
can be found in the app before registering.
Setting up the Wi-Fi connection
Before you begin: make sure that the robot and your mobile device have
good Wi-Fi coverage.
1Press the 'Add robot' button in the app and follow the instructions.
2Select the model of your robot.
-Model XU7100 -Model XU7000

12 English
- -
You can select the model of your robot by scanning the QR code on top of
the robot, or you can look up the model number yourself on the type plate at
the back of the station.
3Install the station within the correct dimensions for placement.
3
sec
4Press and hold the on/off button and home button at the same time for three
seconds. The lights in the buttons will flash orange to indicate that the robot
is in in Wi-Fi set-up mode.
5Pair the robot with the Wi-Fi in the app.
6Click the join button if it's visible in the app to connect with the 'Philips
robot' network.
Philips HomeRun
Philips robot_XXXX
Settings
WLAN
Note: If the join button is not visible in the app, leave the app and go to
Wi-Fi under 'Settings' on your mobile device. There you can select the 'Philips
robot' network and connect to it.
If the Wi-Fi pairing fails:
-Check if you have selected the correct robot model.
-Check your Wi-Fi connection
-Check if you entered the correct Wi-Fi password
-Check if the robot is still in Wi-Fi set-up mode.
Note: You can recognize this if the lights in the two buttons on the robot
are still flashing orange.
Note: If you are unable to solve the problem, visit
www.philips.com/myrobot7000 for support information and the contact
details of Consumer Care.

13
English
Audible signals
hello
-The voice alert language of the robot can be changed from English to your
local language. To change the language, download the app and connect the
robot with the Wi-Fi, so that it can download the new language.
-The app will give alerts and reminders if the robot needs attention. This way
you'll be fully informed on the real-time status even if the robot cleans while
you're away.
Set the language of the voice alert
You can set the language of the voice alert immediately after you have
connected the robot to Wi-Fi
1Make sure that the robot is connected with the app.
2In two places in the app you can find the option to change the language of
the voice alert.
-On the same app screen where you are asked to name the robot
-Or by pressing the three lines at the top left and then choosing the Robot
settings tab.
3Then choose the language of the voice alert there.
How your robot works
Create a mapping
How mapping works
The robot drives through the rooms and the laser navigation quickly scans the
rooms to build a map of the floor.

14 English
Map Edit
In the app, you can use Map Edit to:
-Edit rooms (merge/divide rooms, name rooms) so you can customize the
cleaning routine of the robot per room.
-Set up restricted areas to specify where the robot is allowed to clean and
where it is not.
-Create a map for each floor of your home and store up to 5 maps. When you
use the appliance, it generates a new map in a new environment. If you have
maps that you use frequently and do not want to accidentally overwrite, you
can lock up to 3 maps.
Preparing the room for mapping
Before you start mapping, make sure to:
-Tidy up the area.
-Put furniture in the proper place.
-Put away loose and small obstacles.
Note: This is important to avoid permanently storing the obstacles on the
map.
-Open all in-house doors.
Important: Make sure the robot cannot get blocked during use.
Creating a map
Important: During mapping your robot will not clean.
Important: To create a map of a floor, it is very important to place the station
on the floor that you want to map because the robot must be in the station
when starting and ending the mapping. If you want to create a map of the 2nd
floor, the station must be placed there during the mapping process. Thereafter
the map of this floor can be used even if the station is on another floor.
Note: For model XU7100 only, after the robot has completed its mapping run,
the Auto-empty station will start emptying the robot. This is not an error but
normal behavior.

15
English
Tell your robot where not to clean with restricted cleaning
zones
In the app you can set up restricted areas to indicate where the robot is allowed
to clean and where it is not.
Virtual wall and No-Go zone
Create virtual walls and No-Go zones for areas you do not want the robot
to go. You can for example create virtual walls or No-Go zones to:
-Protect fragile objects. The robot cannot detect shiny, transparent (e.g. glass)
or dark obstacles or surfaces.
-Prevent the robot from getting stuck while cleaning.
Note: The robot can get stuck on high pile carpets, carpets with fringes or
or very light rugs like in the bathroom. Also the robot cannot detect cables on
the floor.
-Protect the robot.
Note: The robot should be kept away from liquids and wet areas such as
pet bowls and plant trays.
Important: virtual walls and No-Go zones should not be used to protect
against hazards.
Important: virtual walls and No-Go zones should not prevent the robot from
returning to the station.
Important: Do not use your robot outdoors. It was not designed for outdoor
use.
No-Mop zone
Create No-Mop zones to prevent the robot from mopping carpets or rugs.
You can adjust the following options in the app under 'Robot settings':
-Avoid No-Mop zones when the rest of the room is mopped.
-Only vacuum the No-Mop zone. Note that the mop can still be moist.
Gentle zone
Your robot can navigate over some furniture if need be. Don't want it to climb
over certain things? Draw a Gentle zone on your map. Your robot will roll up to
your furniture, climbing only a little, before turning away.
IMPORTANT: If you want your robot to still go into other rooms, make sure
that your Gentle zone isn't too close to a door with a threshold. Set your Gentle
zone at least 1 meter from a door with a threshold.

16 English
How your robot cleans
In the app, the following cleaning routines can be selected:
Routine Description
Regular
cleaning
Regular cleaning is intended for your normal daily cleaning routines. The robot cleans each
room according to the settings you specified and saved in the cleaning plan. If the
environment is not recognized, the robot maps the environment and simultaneously
vacuums it (the robot does not mop in this case). After completion, it returns to the station.
Custom
cleaning
Custom cleaning can be used to have the robot perform cleaning actions at unique
occasions. You can customize the cleaning routine of your robot to your wishes. You can
set the following three options.
- Room: the robot cleans one or more rooms in an order you specify.
- Zone: the robot cleans a zone in a room you specify
- Spot: the robot cleans in a square of 1.5 by 1.5 meter in a specific spot in your house
that you want to have cleaned.
Note: with spot cleaning, place the robot in the middle of the square you want the
robot to clean.
After selecting one of the above options, you can select a cleaning mode and fine-tune
your cleaning preferences and advanced settings.
Set cleaning preferences, advanced settings and cleaning order
In the app, you can select five different cleaning modes for each room. These are
standard modes that can be used in most situations. You can customize your
cleaning mode by fine-tuning cleaning preferences and advanced settings.
Cleaning modes
Mode Description
Wet & dry The robot vacuums and mops the floor at the same time. This mode is intended for
regular cleaning of hard floors.
IMPORTANT: For mopping sensitive hard floors, such as parquet
floors, set the mopping wetness level in the app to the lowest level.
Dry The robot only vacuums the floor. This mode can be used for areas that shouldn't be
mopped.
Quiet The robot cleans with minimal noise. The suction power is lowered and the voice
alerts are muted.

17
English
Cleaning modes
Intensive The robot vacuums and mops the floor at the same time and at full power. This mode
is intended for thorough cleaning of small areas.
Note that it is not recommended to clean large areas in this mode. The robot
passes the area 5 times, so the cleaning time and battery usage will increase
significantly.
Individual For this mode you can select all expert settings from scratch.
Cleaning preferences
For each cleaning mode, you can fine-tune the following cleaning preferences:
Setting Description
Suction power Change the suction power:
- Eco: for efficient cleaning with low energy consumption and low noise level.
- Normal: for regular cleaning and effective removal of fine dust on hard floors
with optimal balance between power and efficiency.
- High: for a thorough cleaning of large floors. Can clean more on a single charge
than max mode.
- Max: ideal for removing large dirt like pet hairs or crumbs. The strong suction
power removes fine dust particles hidden deep inside carpets and crevices.
Water level Determine the flow rate that is pumped from the electric water tank onto the mop:
- Off: Switch off the mopping wetness for uncoated wooden floors and carpets.
- Low: to mop a sensitive floor e.g. parquet. The combination of vacuuming and
mopping removes more fine dust than vacuuming alone.
- Middle: optimal for a regular wet & dry cleaning. The mop removes superficial
dirt and bacteria to keep your home sanitized and healthy.
- High: for an effective removal of footprints for a spotlessly clean home. It is
recommended to combine this setting with mop vibrations turned on and 5
cleaning path repetitions for an intensive cleaning.
Cleaning path
sequence
Specify the number of cleaning passes. One pass is sufficient for normal cleaning. It is
possible to program the robot to make two or even five passes for intensive cleaning
of stubborn dirt. It is recommended to select this option only for specific cleaning
areas as it impacts cleaning duration.
Advanced settings
For each cleaning mode, you can fine-tune the following advanced settings:
Setting Description
Mop vibration Turn the mop vibration on or off. The vibrations gently yet effectively scrub the floor
to loosen dirt and footprints.
Y-pattern mopping Change the mopping pattern to Y-pattern. By mopping in a Y-pattern, the robot will
leave less watermarks and traces. Note that the cleaning time will be a bit longer
than normal mopping.

18 English
Setting Description
Carpet boost Turn the carpet boost on or off. The robot automatically increases the suction power
when it has driven onto a carpet or rug. It is recommended to enable this setting.
However, you can disable it for rooms where no disturbance is wanted.
Using your robot
Preparing for a cleaning run
Before you start the robot on its cleaning run:
MAX
60 °C
-Pre-wet the mop for optimal results.
2
1
-Attach the washable mop pad to the mop pad holder.
IMPORTANT: The mop pad holder cannot be removed and when using the
robot, the washable mop pad must always be attached to the mop pad
holder, even if you use the robot without mopping. This is to prevent damage
to the floor and the mop holder during use.
-Remove all cables, wires and cords from the floor to prevent the robot from
getting entangled in them.

19
English
-Open all in-house doors.
Start your first cleaning program via the app (see H.)
Start
1Open the app.
2Select the cleaning program: Regular cleaning or Custom cleaning.
3Press the 'start' icon.
Note: If the battery level is too low, cleaning cannot start. Wait until the robot
is sufficiently charged before you start a cleaning run.
Stop
1Press the Pause icon in the app. The robot stops.
2Press the Start icon again. The robot continues.
3Press the Home & charge icon. The robot goes back to the station.
Using the robot without the app
Note: For an optimal experience, we recommend using the app.
Without the app, you can use the two buttons on the robot to operate it:
-On/off button
-Long press (3s) to turn the robot on and off.
-Short press to start cleaning or to pause cleaning. Press again to resume
cleaning.
-Home button
-Short press (when the robot is not cleaning): the robot will find the station
and charge.
-Short press while cleaning: the robot will stop cleaning. Short press again:
the robot returns to the station to charge.

20 English
-Short press when the robot is driving back to the station: the robot will
pause returning to the station. Press again to let it drive back to the
station.
When operating the robot manually, it will vacuum and mop. However, if the
water tank is empty it won't mop.
Your robot's cleaning pattern
1
2
3
The robot cleans the home in a structured way. The robot cleans room by room
and always starts by cleaning the edges of the room first before covering the
remaining surface.
Note: If cleaning is completed within 10 minutes, the area will be cleaned
twice. This is an extra touch up to improve cleaning results.
Returning to the station
1 2
3
E D
A
F
B
C
After the robot has completed its cleaning run, the robot will automatically drive
back to the station to recharge.
Note: When the robot is docked it will withdraw power to keep the battery
performance optimal. However, the energy consumption is limited.
Note: For model XU7100 only, the station will also vacuum the dust bin of the
robot empty. The dust is then collected in the dust bag of the station.
Auto recharge and resume
When the battery runs low (<20%) while cleaning, the robot automatically
returns to the station to recharge. After the battery has been charged, the robot
continues where it has left off.

21
English
Cleaning and maintenance
When to do maintenance
Item Cleaning Replacement
Washable mop pad After every use 3-6 months
Main brush Monthly 6-12 months
Washable filter Monthly 3-6 months
Side brush Monthly 6-12 months
Main wheels & universal
wheel
Monthly -
360° laser navigation
(LiDAR) sensor
Monthly -
Sensors:
- Collision sensor (2x)
- Infrared signal receiver
to find the station
- Infrared signal emitter
to communicate with
the station
- 3D ToF sensor to detect
and avoid small
obstacles in front of
the robot (120°)
- ToF-sensor to detect
and avoid small
obstacle around the
robot (8x)
- Anti-drop sensor (6x)
Monthly -
Charging contacts robot
and station
Monthly -
Sensors to detect
placement of dust bin and
water tank
6 months -
Dustbin (XU7000) Empty the dustbin after
each use
-

22 English
Dust bag in Auto-empty
station (XU7100)
- When the orange LED on the auto-empty station
flashes indicating that de dust bag is full.
Cleaning the washable mop pad
1Push the water tank release button.
2Pull the water tank out of the robot.
1
2
3Pull the washable mop off the velcro material.
4Slide the straight side of the washable mop out of the slot.
MAX
60 °C
MAX
60 °C
5Rinse and clean the washable mop pad with water or wash it in the washing
machine.
