Phocos Any-Grid PSW-B-5KW-230/48V Operating manual

Pure Sine Wave Battery Inverter Charger with MPPT Solar Charge Controller PSW-B-5KW-230/48V User and Installation Manual English For further languages see Für weitere Sprachen siehe Pour autres langues voir Para otros idiomas ver 对于其他语言请参阅 www.phocos.com

www.phocos.com 1 | Page 1.0 Introduction ................................................................................................................................................... 2
2.0 Important Safety Information ....................................................................................................................... 2
3.0 Regulatory Information ................................................................................................................................. 3
4.0 Overview......................................................................................................................................................... 4
Functional Overview .......................................................................................................................................................................... 4
Product Overview ................................................................................................................................................................................ 5
5.0 Installation ..................................................................................................................................................... 6
Package Contents ................................................................................................................................................................................ 6
Mounting the Unit ............................................................................................................................................................................... 6
Battery Connection ............................................................................................................................................................................. 7
AC Input and AC Output Connection .......................................................................................................................................... 8
PV Connection ...................................................................................................................................................................................... 9
Final Assembly .................................................................................................................................................................................... 10
6.0 Operation ..................................................................................................................................................... 11
Inverter Power ON/OFF ................................................................................................................................................................... 11
Display and Control Module .......................................................................................................................................................... 12
Display Symbols ................................................................................................................................................................................. 13
Device Operation Settings ............................................................................................................................................................. 14
Screen Views of Current Values .................................................................................................................................................... 20
Operating Mode Description ........................................................................................................................................................ 23
7.0 Cleaning and Maintenance .......................................................................................................................... 25
Every Month ......................................................................................................................................................................................... 25
Every 6 Months ................................................................................................................................................................................... 26
8.0 Fault Reference Codes.................................................................................................................................. 27
9.0 Warning Codes ............................................................................................................................................. 28
10.0 Troubleshooting........................................................................................................................................... 29
11.0 Specifications ............................................................................................................................................... 30
Grid Mode ............................................................................................................................................................................................. 30
Off-Grid Mode ..................................................................................................................................................................................... 31
Battery Charging ................................................................................................................................................................................ 32
General ................................................................................................................................................................................................... 33
12.0 Warranty ....................................................................................................................................................... 34
Conditions ............................................................................................................................................................................................ 34
Liability Exclusion .............................................................................................................................................................................. 34

www.phocos.com 2 | Page 1.0 Introduction Dear customer, thank you for choosing this quality Phocos product. The Any-Grid™ PSW-B pure sine wave battery inverter / charger series has numerous outstanding features and use-cases such as:  Function as purely Off-Grid inverter for applications with no AC power source  Function as solar enabled (optional) uninterruptible power supply (UPS) functionality for intermittent or unstable AC sources  Function as grid-connected or AC-generator-connected inverter to reduce energy demand from the AC source by prioritizing solar and / or battery power, thus saving energy costs  Integrated MPPT solar charge controller means no external charge controller is required  Battery charging from an AC source such as the public power grid or a genset  Compatibility with multiple battery types including lead-acid (gel, AGM and liquid electrolyte) and lithium-based batteries such as LiFePO4 (as no battery management system communication is possible, ensure the battery can function without external communication before use)  Both neutral (N) and live (L) wires of the AC input are automatically disconnected (break-before-make relays) from the AC output when the Any-Grid PSW-B operates in Off-Grid mode  Grid feed-in is technically not possible as this device is not grid-interactive. It never operates in parallel to the AC source. It either uses the AC source to power loads directly from it (the inverter is not running at this time, the unit is acting purely as a load) in Grid mode. Or, in Off-Grid mode, the integrated inverter module is running, but isolated from the AC source on both neutral (N) and live (L) wires through air gaps.  All-in-one unit allows simple and fast installation, and easy configuration  Optional accessory: Phocos Any-Bridge™ IoT Gateway (sold separately) to connect to the PhocosLink Cloud from anywhere with any internet-capable device via its web browser This manual describes the assembly, installation, operation, maintenance and troubleshooting of this unit. 2.0 Important Safety Information SAVE THESE INSTRUCTIONS: This manual contains important instructions for model PSW-B-5KW-230/48V that shall be followed during installation and maintenance of the unit. Read and save this manual for future reference. WARNING: The installation of this unit may only be undertaken by qualified personnel with appropriate training. High voltages in and around the unit can cause serious injury or death. This unit must be installed in accordance with rules and regulations at the site of installation. CAUTION: A battery can present a risk of electrical shock, burning from high short-circuit current, fire or explosion from vented gasses. Observe proper precautions. WARNING: This unit must be connected to a permanent grounded wiring system. Be sure to comply with local requirements and regulations when installing this unit. BATTERY TYPE: Suitable for use with lead-acid (gel, AGM and liquid electrolyte) and lithium-based batteries such as LiFePO4. OVERCURRENT PROTECTION FOR BATTERY: Install an overcurrent protection device with a minimum of 1000A interrupt rating as close as possible to the battery terminal. Select a device rated for 1.25 times the nominal current rating of the inverter / charger . An overcurrent protection device must be purchased separately. 1. Before using the unit, read all instructions and cautionary markings on this unit, the batteries, the solar modules, any connected loads. 2. Please do not disassemble or attempt to repair Phocos products. This unit does not contain user serviceable parts. Damage to the warranty seal will lead to a loss of warranty of the product and can lead to injury. 3. To reduce risk of electric shock, disconnect all wirings before attempting any maintenance or cleaning. Switching off the unit is not sufficient, turn off and / or disconnect all connections to the unit. 4. For safe operation of this unit, please adhere to appropriate cable size requirements in this manual.

www.phocos.com 3 | Page 5. Usage of insulated tools around the unit is strongly recommended. Be very cautious when working with uninsulated metal tools on or around batteries. They can short-circuit batteries or other electrical parts and could cause an explosion and / or injury. 6. Strictly follow the installation procedure when connecting or disconnecting AC or DC terminals. Please refer to the “Installation” section of this manual for details. 7. Appropriate fuses or breakers are required near the battery supply and AC input and AC output of this unit. 8. WARNING: It is highly recommended and legally required in many countries to install a Type B residual current device (RCD) between the AC output of the unit(s) and the AC loads to protect humans from hazardous electric shock due to faulty AC wiring, faulty loads or a potential inverter fault. Only in Off-Grid mode, the neutral (N) and ground (PE) of the AC output are automatically bridged inside the Any-Grid to ensure the RCD’s functioning if the AC installation is wired correctly as a TN-S or TN-C-S earthing system. In a TN-C-S installation the bridge between neutral (N) and ground (PE) must be between the public grid and AC input of the Any-Grid to ensure that there is never more than one bridge between N and PE. This unit is not designed to be operated in environments where an RCD is present between this unit and the AC source. 9. Never allow any AC or DC connections to be short-circuited. Do not connect to the mains when the battery input is short-circuited. 10. Only qualified service persons may service this device. If errors persist after following the “Troubleshooting” section in this manual, please send this unit back to a local Phocos dealer or service center for maintenance. 11. WARNING: Only solar panels are acceptable for use which do not require positive grounding as only grounding of the negative PV cables is allowed, if necessary. Grounding of the PV module frame is permitted and frequently required by local law. The MPPT solar charge controller is not galvanically isolated from the battery, but is isolated from the inverter. The battery is galvanically isolated from the inverter, therefore the battery positive or negative terminal may be grounded if required. 12. CAUTION: It is highly recommended to use a surge arrester, also named surge protective device (SPD) near the PV input terminals of this unit. This is to prevent damage to the unit from lightning, thunderstorms or other voltage surges on the PV cables. The max. DC operating voltage of the SPD must be between 145 and 160 Vdc. For example the
Citel DS240-110DC is suitable. 13. CAUTION: It is highly recommended to use a surge arrester, also named surge protective device (SPD) near the AC input terminals of this unit, if the AC input is used. This is to prevent damage to the unit from lightning, thunderstorms or other voltage surges on the AC input conductors (for example coming from the public grid). The max. AC operating voltage of the SPD must be between 275 and 300 Vac for 230 Vac models. For example, the
Citel DS41S-230 (for most public grids or generators, higher protection) or Citel DS41S-320 (for public grids with large voltage swings, lower protection) are suitable. When using with a 110 ~ 127 Vac AC source the SPD must have a max. AC operating voltage between 140 and 150 Vac. For example, the
Citel DS41S-120 is suitable. 3.0 Regulatory Information This product is CE and RoHS (Restriction of Hazardous Substances) compliant. Please find the CE declaration at www.phocos.com. This product is manufactured in an ISO 9001 (quality management) and ISO 14001 (environmental management) certified facility. This equipment is suitable for use in non-hazardous locations only. This is a class A device: in a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. RoHS

www.phocos.com 4 | Page 4.0 Overview Functional Overview This pure sine wave battery inverter charger with solar charge controller (MPPT) can provide power to connected loads by utilizing PV power, AC power and battery power. Most connections are optional, but there must be at least one power source (AC or PV) and battery connected: Fig. 1: System Overview This unit has one each of the following power connections: battery, PV, AC input, AC output. The unit is designed to provide continuous power from PV / battery or an AC source, depending on the set priority. Independently, the priority for charging the battery can be set (the battery can only be charged from AC when the unit is not working in Off-Grid mode). The switching time between Grid (also valid when an AC generator is used) and Off-Grid modes is only 10 milliseconds (typical). In Grid mode the unit can pass AC power from the AC source to AC loads. PV power is only charged into the battery in this mode. In Off-Grid mode the AC loads are supplied by PV power and if not sufficient, also by the battery via the inverter. It is not possible to power AC loads with PV power and power for the AC source at the same time, only to switch back and forth between these sources. The pure sine wave AC output and the surge power capability (twice the continuous power rating) assure all types of AC loads can be powered. Ensure that the peak power requirement of the loads is below the surge power capability of this inverter.
PV Panels (optional)
Battery
AC
Loads
Public Grid (optional)* AC Generator (optional)*
Phocos Any
-
Grid™ PSW
-
B
Battery Inverter Charger
* Any
-
Grid™ accepts one AC input,
no grid feed-in possible

www.phocos.com 5 | Page Product Overview Fig. 2: Product Overview 1. LCD screen 2. Inverter status indicator 3. Charging indicator 4. Fault indicator 5. Function buttons 6. AC output on/off switch (solar charging still functions when the AC output is powered off) 7. AC input terminals (public grid or AC generator connection) 8. AC output terminals (load connection) 9. PV terminals 10. Battery terminals 11. Resettable circuit breaker 12. USB communication port 13. RS-232 communication port CAUTION: Using any other cable or interface than the one provided for RS-232 on RS-232 communication port 13 (such as an Ethernet device), or a device explicitly compatible with the PSW-B, is likely to damage the Any-Grid PSW-B and / or the connected device. Such damage is not covered under warranty.

www.phocos.com 6 | Page 5.0 Installation Package Contents Before installation, please inspect the unit to ensure nothing inside the package is damaged. Package contents:  Any-Grid PSW-B unit  This manual  RS-232 cable (SUB-D to RJ-45)  Strain relief for battery cables with two screws  Strain relief for solar / PV cables with two screws  Two cable ties for use with strain reliefs Mounting the Unit Before connecting all wirings, please take off the bottom cover by removing two screws as shown below and carefully sliding the cover down. (Fig. 3). Fig. 3: Removal of bottom cover Fig. 4: Minimum distance to other objects WARNING: Only mount this unit on concrete or another solid non-combustible surface capable of securely holding the weight of the unit.  Install this inverter at eye level to ensure legibility of the display  Ensure the ambient temperature is between -10 ~ 50 °C, 14 ~ 122 °F at all times  Avoid excessively dusty environments  The unit is designed for vertical installation on a solid wall  Ensure a minimum distance to other objects and surfaces as shown in Fig. 4 to guarantee sufficient heat dissipation and to have enough space for removing wires.  Install in a room where noise is not an issue as the unit has fans for cooling Install the unit by using two M4 or M5 screws (Fig. 5) appropriate for the weight of the unit and wall material, use wall plugs. This bottom cover must remain removed for the rest of this “Installation” chapter until instructed otherwise. Fig. 5: Mounting holes

www.phocos.com 7 | Page Battery Connection WARNING: The installation of this unit may only be undertaken by qualified personnel with appropriate training. High voltages in and around the battery and unit can cause serious injury or death. This unit must be installed in accordance with rules and regulations at the site of installation. WARNING: Choose a suitable battery fuse as outlined in the chapter “Important Safety Information”, section “OVERCURRENT PROTECTION FOR BATTERY”. WARNING: Ensure the battery cables are sized according to the table below. Inadequate battery cables can cause excessive heat or fire during operation. Recommended battery cable cross-section, battery size and fuse / DC circuit breaker rating: Battery cable cross-section 35 mm², AWG 2 Min. battery capacity (lead-based) 200 Ah Battery discharge current capability 140 Adc cont., 280 Adc surge (5s) Fuse / breaker rating 175 Adc, min. 63 Vdc Steps to connect the battery: 1. WARNING: Ensure the battery cables are not yet connected to the battery and that the battery fuse is removed or battery circuit breaker is open. CAUTION: Ensure none of the cable insulation is jammed into the terminal. Remove 18 mm / 0.7 in of insulation from the ends of the battery conductors to be installed on the inverter unit. 2. It is recommended to securely crimp ferrules onto these exposed cable ends if using stranded wires. 3. Fasten the strain relief plate under the battery terminals marked “+ BATTERY -” with the two included screws: Fig. 6: Battery cable strain relief installation 4. Connect the other end of the battery conductors to the battery. Ensure the polarity of the battery terminals on the Any-Grid match the battery polarity. 5. Now insert the inverter-side wires of the battery into the inverter battery terminals, ensuring correct polarity. Tighten the inverter battery terminals with a torque of 2 Nm (1.5 lbf⋅ft). CAUTION: Reverse polarity connection to the battery may damage the unit. CAUTION: Over-tightening the terminal nuts can cause damage to the terminal, under-tightening can cause a loose connection and excessive heat during operation, make sure to use the prescribed torque. Fig. 7: Battery connection

www.phocos.com 8 | Page 6. Fix the conductors to the strain relief with an included cable tie: Fig. 8: Battery cable strain relief AC Input and AC Output Connection WARNING: Before connecting an AC source to the AC input of the Any-Grid, install an AC circuit breaker between the Any-Grid and AC input power source. This will ensure the inverter can be securely disconnected during maintenance and fully protected from over current of AC input. Make sure the breaker is open / off for the rest of the installation procedure until instructed otherwise. WARNING: Ensure that the installation has adequate grounding and connect the protective earth (PE) terminals to this ground as instructed below. Failure to do so can cause serious injury or death once the unit is powered up or the AC source is activated via its breaker. WARNING: Ensure the AC cables are sized according to the table below. Inadequate AC cables can cause excessive heat or fire during operation. CAUTION: Do not connect an AC source to the “AC OUT” labelled terminal of the unit as this will destroy the unit. Only connect it to the “AC IN” labeled terminal. CAUTION: Only AC sources with a neutral may be used connected. Using AC sources with two phases on an Any-Grid PSW-B instead, will cause damage. Recommended AC cable cross-section and AC circuit breaker rating: AC input and output cable cross-section 6 ~ 10 mm², AWG 7 ~ AWG 10 Circuit breaker rating 40 Aac, ≥ 280 Vac if operated with 220 ~ 240 Vac source or ≥ 140 Vac if operated with 110 ~ 127 Vac source Steps to connect the AC source and AC loads: 1. WARNING: Ensure the battery cable fuse is removed or breaker is secured in the open position. WARNING: Ensure the AC source breaker is secured in the open position and there is no voltage on the conductors before continuing. 2. Remove 10 mm / 0.4 in of insulation for the six AC conductors (neutral “N”, live “L” and protective earth “PE” for the AC source and loads). 3. It is recommended to securely crimp ferrules onto these exposed cable ends if using stranded wires. 4. Insert the “PE” protective conductor from the AC source first into the corresponding AC input terminal and tighten with a torque of 1.2 Nm (0.9 lbf⋅ft). Repeat for the neutral “N” and live “L” conductors of the AC source. Fig. 9: AC Input connection

www.phocos.com 9 | Page 5. Attach the “PE” protective conductor of the AC output wiring to the grounding screw with an appropriate ring terminal as shown below. Insert the neutral “N” and live “L” conductors of the AC loads into the corresponding two terminals marked “AC OUT” and tighten with a torque of 1.2 Nm (0.9 lbf⋅ft). Fig. 10: AC Output connection 6. Make sure the six wires are securely connected. CAUTION: Over-tightening the terminal screws can cause damage to the terminal, under-tightening can cause a loose connection and excessive heat during operation, make sure to use the prescribed torque where defined. Ensure none of the conductor insulation is jammed between the terminal contacts. CAUTION: Ensure the polarity is correct on all wires. Failure to do so may cause damage. PV Connection WARNING: Before connecting the PV module array to the PV input of the Any-Grid, install a DC circuit breaker between each Any-Grid PV terminal pair and the PV modules. This ensures the inverter can be securely disconnected during maintenance and is protected from over-current of the PV modules. PV modules produce a dangerous voltage even at low light. Make sure the breaker is open / off for the rest of the installation procedure until instructed otherwise. WARNING: Ensure the PV cables are sized according to the table below. Inadequate PV cables can cause excessive heat or fire during operation. Recommended PV cable cross-section and DC circuit breaker rating: PV cable cross-section 6 ~ 16 mm², AWG 5 ~ AWG 10 Circuit breaker rating 60 Adc, min. 150 Vdc For selecting the correct PV module configuration, please consider the following points:  The total open circuit voltage (Uoc / Voc) of the PV module array may never exceed the values in the table below. Consider the coldest possible temperatures at the installation location together with the temperature coefficient of the PV modules used.  The total maximum power point voltage (Umpp / Vmpp) of the PV module array must be above the minimum values in the table below. Consider the hottest PV module temperatures at installation location.  The total maximum power point current (Impp / Ampp) of the PV array may not exceed the values below.  The total PV array power may not exceed the corresponding value in the table below. Max. PV voltage (Uoc) 145 Vdc Min. PV mpp voltage (Umpp) 60 Vdc Max. mpp current (Impp) 60 Adc Max. PV array power 4500 Wp Steps to connect the PV module array:

www.phocos.com 10 | Page 1. Remove 10 mm / 0.4 in of insulation from the positive and negative PV cables. 2. It is recommended to securely crimp ferrules onto these exposed cable ends if using stranded wires. 3. Fasten the strain relief plate under the PV terminals marked “+ PV IN -” with the two included screws: Fig. 11: PV cable strain relief installation 4. Insert the positive PV cable into the PV input “+” terminal and the negative PV cable into the PV input “-” terminal. CAUTION: Ensure correct polarity. Fig. 12: PV connection 5. Tighten both terminal screws with a torque of 1.6 Nm (1.2 lbf⋅ft) and make sure the two wires are securely connected. CAUTION: Over-tightening the terminal screws can cause damage to the terminal, under-tightening can cause a loose connection and excessive heat during operation, make sure to use the prescribed torque. Ensure none of the cable insulation is jammed between the terminal contacts. 6. Fix the conductors to the strain relief with an included cable tie: Fig. 13: PV cable strain relief Final Assembly After Battery, PV and AC wiring is completed, please slide the bottom cover back up on the unit and secure it by fastening the two screws as shown below.

www.phocos.com 11 | Page Fig. 14: Re-applying bottom cover 6.0 Operation Inverter Power ON/OFF Fig. 15: Load output ON/OFF button location Ensure the “ON/OFF” switch located on the right side of the unit (Fig. 15) is in the “OFF” position after the initial installation. Now activate the circuit breakers or insert the fuses to energize the various inputs and outputs in the following order (skip any that are not connected): 1. Battery 2. AC input 3. PV input 4. AC output Next, switch the “ON/OFF” (Fig. 15) button to the “ON” position to turn on the AC output and thus connected AC loads and the entire unit. If the “ON/OFF” switch is in the “OFF” position, then the unit will be completely off when there is insufficient sunlight.

www.phocos.com 12 | Page If PV modules are connected and there is sufficient PV voltage, the unit and display will wake up automatically to charge the batteries during the day. Once the PV voltage drops below the min. PV voltage threshold, the unit will again turn completely off to save energy during the night. The AC output and thus the AC loads will remain off as long as the “ON/OFF” switch is in the “OFF” position. Display and Control Module The display and control module, shown in Fig. 16, includes three LED indicators, four function buttons, and a LCD-screen, indicating the operating status and allowing the programming of settings parameters. Fig. 16: Display module buttons and indicators Indicator Description Indicator Colour Solid On / Flashing Description Green Solid On AC output powered by AC input (Grid mode) Flashing AC output powered by integrated inverter (Off-Grid mode) Green Solid On Battery is fully charged Flashing Battery is charging Red Solid On Fault mode Flashing Warning mode Function Buttons Function Button Description Escape / close Exit settings without confirming Up To last selection Down To next selection Enter To confirm/enter the selection in setting mode LCD-screen LED indicators Function buttons

www.phocos.com 13 | Page Display Symbols Fig. 17: LCD-Screen symbols Symbol Description Input Information Indicates AC input Indicates PV input Indicates input voltage, input frequency, PV voltage, PV current, PV power, charging current, charging power, battery voltage. Settings menu and Fault Information Indicates the setting menus Indicates warning and fault codes. Warning: flashing with warning code and flashing red LED. Fault: shown with fault code and solid red LED. Output Information Indicates output voltage, output frequency, load in % of nominal power, load in VA, load in Watt and discharging current. Battery Information Indicates battery level in 0 ~ 24%, 25 ~ 49%, 50 ~ 74% and 75 ~ 100% (left to right) increments in Off-Grid mode and charging status in Grid mode. In Grid mode, the battery indicator shows the following: Status Battery Voltage LCD Display All battery charging modes except Floating phase < 48 V 4 bars flash in turns 48 ~ 50 V Bottom bar constantly on and other three bars flash in turns 50 ~ 52 V Bottom two bars constantly on and other two bars flash in turns > 52 V Bottom three bars constantly on and top bar flashes

www.phocos.com 14 | Page Floating phase. Batteries are fully charged. 4 bars constantly on
In Off-grid mode, the battery indicator shows the following: Load Percentage Battery Voltage LC-Display Load > 50% < 44.4 V 0 ~ 24% 44.4 ~ 46.4 V 25 ~ 49% 46.4 ~ 48.4 V 50 ~ 74% > 48.4 V 75 ~ 100% Load < 50% 45.4 V 0 ~ 24% 45.4 ~ 47.4 V 25 ~ 49% 47.4 ~ 49.4 V 50 ~ 74% > 49.4 V 75 ~ 100%
Load Information Indicates overload Indicates load level by 0 ~ 24%, 25 ~ 49%, 50 ~ 74% and 75 ~ 100% (left to right) increments. Mode Operation Information Constantly on: AC source valid Blinking: AC source present but rejected PV input valid Load supplied by AC input AC source charger circuit is active DC to AC inverter circuit is active Alarm disabled Device Operation Settings General Settings Press for 3 seconds to enter settings mode. Press or to select between settings menus. Once selected, press to confirm the selection or to exit without confirmation.

www.phocos.com 15 | Page Settings menus Menu no. Description Selectable Option and Notes 00 Exit setting mode Escape 01 AC output source priority: Configure the priority of which power sources supply the AC output load Solar first Solar provides power to the loads as first priority. If solar power is not sufficient to power all connected loads, battery power will supply the loads simultaneously (Off-Grid mode). If no solar power is available (ex. at night), or the battery voltage reaches the setting point in settings menu 12, AC input / utility power is used exclusively. During this time any PV power available is used to charge the battery. With unavailable solar power the battery is only discharged (apart from unit self-consumption) when the AC input / utility power is unavailable (Off-Grid mode). Utility / AC input first (Default) AC input / utility will provide power to the loads as first priority (Grid mode). Solar and battery will provide power to the loads only when utility power is not available (Off-Grid mode). SBU priority “SBU” for: Solar  Battery  Utility Solar powers the loads as first priority. If solar power is not sufficient to power all connected loads, the battery will supply power to the loads simultaneously. The Any-Grid is disconnected from the grid at this time (Off-Grid mode). AC input / utility provides power to the loads (Grid mode) only when the battery voltage drops to either low-level warning voltage or the setting point in settings menu 12. In this case the loads are powered only from the AC source. Any PV power is used to charge the battery while in Grid mode.

www.phocos.com 16 | Page 02 Maximum total battery charging current of AC and solar charging combined: Max. total charging current = AC input charging current + solar charging current This setting is important to limit charging current for some battery types. 10A 60A (Default) Can be set from 10 ~ 120 Adc in 10 Adc increments. This is the battery-side DC charging current. 03 AC input voltage range In addition to wider voltage tolerance, “Appliances” setting also allows more deformed sine-waves to be accepted at the AC input compared to “UPS” mode. Appliances Accepted AC input voltage range from 90 ~ 280 Vac if settings menu 10 is set from 220 ~ 240 Vac. 80 ~ 140 Vac if settings menu 10 is set from 110 ~ 127 Vac UPS (Default) Accepted AC input voltage range from 170 ~ 280 Vac if settings menu 10 is set from 220 ~ 240 Vac. 90 ~ 140 Vac if settings menu 10 is set from 110 ~ 127 Vac 05 Battery type Settings menus 26, 27 and 29 can only be modified if “User-defined” is selected here AGM (Default) Flooded User-defined Battery charging voltages and low voltage disconnect (LVD) can be manually defined in settings menu 26, 27 and 29. 06 Automatic restart if an AC output overload occurs Restart disabled (Default) Restart enabled 07 Automatic restart when over-temperature occurs Restart disabled (Default) Restart enabled 09 AC output frequency Only relevant for Off-Grid mode 50 Hz (Default) 60 Hz

www.phocos.com 17 | Page 10 AC output voltage Defines AC output voltage in Off-Grid mode and AC input voltage limits (see settings menu 03). Any modification between 110/120/127 Vac and 220/230/240 Vac will be effective only after the inverter is restarted. 230 Vac (Default) Available values: 110, 120, 127, 220, 230 and 240 Vac. 11 Maximum AC source charging current (battery side) If settings menu 02 is smaller than this value, charging will be limited by the value in settings menu 02. 30 Adc (Default) Available values: 2 Adc and 10 ~ 60 Adc in 10 Adc increments. 12 Voltage set-point to switch from Off-Grid mode to Grid mode when “SBU priority” or “Solar first” is selected in settings menu 01. 24 Vdc (Default) 48.0 Available values: 44.0 ~ 47.0 Vdc in 1.0 Vdc increments. 13 Voltage set-point to switch from Grid mode to Off-Grid mode when selecting “SBU priority” or “Solar first” in settings menu 01. Battery fully charged 54 Vdc (Default) 54.0 Available values: “FULL” and 48.0 ~ 61.0 in 1.0 Vdc increments. The battery is considered fully charged when the float charging phase is reached. 16 Battery charger source priority Configure the priority of which power sources are used to charge the battery. The AC source can only charge the battery if in Grid, Stand-By or Fault modes. In Off-Grid mode only solar / PV power can charge the battery. It is recommended not to choose “Only Solar” if an AC source is available because the self-consumption of the Any-Grid unit is supplied from the battery. If there are long periods without sunshine (ex. snow), the unit may shut down due to low battery voltage. Instead, select “Solar first” here and 2 Adc in settings menu 11 to compensate for the self-consumption with some safety margin. Solar first Solar power will charge battery as first priority. Utility / AC source will charge battery only when solar energy is not available and the unit is in Grid mode. Utility first Utility / AC source will charge battery as first priority. Solar power will charge battery only when no AC source is available. Solar and Utility (Default) Solar power and AC input power will charge battery at the same time if the unit is in Grid mode. Only Solar Solar power will be the only battery charging source, regardless of the operating mode.

www.phocos.com 18 | Page 18 General alarm control Alarm on (Default) Alarm off 19 Automatic return to default overview display screen Return to default display view (Default) The display will return to the default overview (input voltage / output voltage) if no button is pressed for approx. 1 minute. Remain at last view The display will remain at the selected view indefinitely, until another view is selected. 20 Display backlight control Backlight always on (Default) Backlight off after one minute of no button presses 22 Beeps while primary source is interrupted Alarm on (Default) Alarm off 23 Overload by-pass: When enabled, the unit will quickly switch to Grid mode if an AC output overload occurs in Off-Grid mode. It will return back to Off-Grid mode once the load power has normalized (min. timeout 10 minutes). By-pass disabled (Default) By-pass enabled 26 Boost battery charging voltage 57.6 Vdc (Default) 57.6 If “User-defined” is selected in settings menu 05, this value can be changed. Available values: 48.0 ~ 61.0 Vdc in 0.1 Vdc increments. 27 Floating battery charging voltage 55.2 Vdc (Default) 55.2 If “User-defined” is selected in settings menu 05, this value can be changed. Available values: 48.0 ~ 61.0 Vdc in 0.1 Vdc increments.

www.phocos.com 19 | Page 29 Low voltage disconnect The AC output is turned off when the battery reaches this voltage level to protect the battery from deep discharge. The low DC / battery warning voltage is 2 Vdc above this setting. This value must be set at least 4 Vdc lower than settings menu 30. 44.0 Vdc (Default) 44.0 If “User-defined” is selected in settings menu 05, this value can be changed. Available values: 37.5 ~ 54.0 Vdc in 0.1 Vdc increments. This voltage is fixed and independent of the load power level. 30 Low voltage reconnect If the AC output is turned off due to low voltage disconnect (settings menu 29), the AC output is automatically turned back on once this voltage is reached. This value must be at most 0.5 Vdc below settings menu 27, and at least 4 Vdc higher than settings menu 29. 54.7 Vdc (Default) 54.7 If “User-defined” is selected in settings menu 05, this value can be changed. Available values: 51.6 ~ 60.5 Vdc in 0.1 Vdc increments. 32 Boost battery charging duration The duration for which the boost voltage from settings menu 26 is held before the Floating phase is reached. Automatic 120 min (Default) If “User-defined” is selected in settings menu 05, this value can be changed. Available values: “Automatic” and 5 ~ 900 minutes in 5 min. increments. If “Automatic” is set, the duration of bulk phase (see chapter “Specifications”  “Battery Charging”) is multiplied by 10, with a minimum of 10 minutes and maximum of 8 hours. 33 Battery equalization Battery equalization helps prevent sulfation of lead-acid batteries and is beneficial for bringing all cells to the same voltage. Consult your battery manual to make sure the battery can withstand the higher voltages required for this purpose. This is typically the case for flooded lead-acid batteries. Enabled Disabled (Default) If “User-defined” or “Flooded” is selected in settings menu 05, this value can be changed. 34 Battery equalization voltage 59.2 Vdc (Default) 59.2 Available values: 48.0 ~ 61.0 Vdc increments.
