Phoenix Contact RAD-ISM-900-DATA-BD User manual

RAD-ISM-900-DATA-BD
RAD-ISM-900-RS232-BD
PHOENIX CONTACT • P.O. Box 4100 • Harrisburg, PA 17111 • Phone: [phone] • Fax: [phone]
1
Features
• DIN-rail mountable
• All-in-one Master, Slave and Store-and-Forward
Repeater/Slave
• GUI and DIP switch configuration
• Remote diagnostics avaiable via second port on radios,
and terminal windows in the GUI
• Dry contact LINK output as well as voltage output for
quick and easy field RSSI wiring
• 1 watt transmit power
• Class I, Div. 2 approved for hazardous area installation
(UL, CUL, and CSA approved)
Description
The RAD-ISM-900-RS232-BD is a radio transceiver that
allows two-way communications via RS-232. The RAD-
ISM-900-DATA-BD is a radio transceiver that allows
two-way communications via RS-232, RS-485 and RS-
422. Modbus RTU and Allen Bradley DF1 protocols are
supported with assured communications in both radios,
which are programmed using the RAD-LINK software. Up
to 254 remote locations can be accessed by one Master
transceiver. The RAD-ISM-900 transceivers can be used on
the license-free 902-928MHz band and proven Frequency
Hopping Spread Spectrum technology designed for use in
high frequency environments.
Applications
• SCADA systems
• PC/PLC/RTU interface
• Pump controls
• Tank level/pressure/temperature monitoring
• Water/Wastewater
• Petro-chem
Quick Start Guide 1945B September 2006
Figure 1. RAD-ISM-900-DATA-BD
p/n 2867131
Figure 2. RAD-ISM-900-RS232-BD
p/n 2867555
INSPIRING INNOVATIONS
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12967-Phoenix-Contact-2867131-Radio-900-MHz-Serial-Data-Radio.aspx

The information given herein is based on data believed to be reliable, but Phoenix
Contact makes no warranties expressed or implied as to its accuracy and
assumes no liability arising out of its use by others.This publication is not to be
taken as a license to operate under, or recommendation to infringe, any patent.
Headquarters, U.S.
Technical Service
Headquarters, Canada
Technical Service
PHOENIX CONTACT
P.O. Box 4100
Harrisburg, PA 17111-0100
Phone: [phone]
717-944-1300
Fax: [phone]
Email: inf[email protected]
Website: www.phoenixcon.com
Phone: [phone]
PHOENIX CONTACT Ltd.
235 Watline Avenue
Mississauga, Ontario L4Z 1P3
Phone: [phone]
Fax: [phone]
Phone: [phone]
2
Data Sheet 1945B
RAD-ISM-900-DATA-BD
RAD-ISM-900-RS232-BD
Engineering Specifications
General Specifications
Power 9 to 30 VDC required
Power Consumption Average: 2.5 Watts
Peak: 4.1 Watts
Reverse Wiring Protection Ye s
Wiring Connections (DATA-BD) RS-232 port: DB9 female
RS-485/422 port: screw-type terminals; 12-24AWG
Wiring Connections (RS232-BD) RS-232 port: DB9 female
Diagnostic port: 6-pin mini-DIN
Mounting 35mm DIN-rail mount
Dimensions (DATA-BD) (LxWxH) 3.9" x 0.88" x 4.5" (99mm x 22.5mm x 114.5mm)
Dimensions (RS232-BD) (LxWxH) 2.9" x 0.88" x 4.2" (75mm x 22.5mm x 107.5mm)
Case Material Plastic
Weight 5.5 oz (175 grams)
Temperature Range -40°C to 70°C (-40°F to 158°F)
Environmental Rating NEMA 1 (equivalent to IP 30)
Approvals Class I, Div. 2 Groups A,B,C,D; UL and CSA (pending)
LED Indicators RF: glows solid when RF link is established
TX: flashes when data is being transmitted
RX: flashes when data is being received
Communication Interface
Protocols MODBUS RTU or AB DF1 half-duplex
Interface (DATA-BD) RS-232 and RS-485/422
(2-wire or 4-wire half-duplex)
Interface (RS232-BD) RS-232
Baud Rates 1,200 to 38,400 baud
Data Format Asynchronous - 7 data, even parity or 8
data, no parity; 1 stop bit
Flow Control RTS/CTS or non
Radio Specifications
Range 600 to 1,000 feet (180 to 305m) in-plant
(obstructed); 4 to 5 miles (6 to 8km) LOS
wit Omni antenna; 20+ miles (32+km)
LOS with Yagi antenna
Frequency 902 to 928MHz
Transmit Power 1 Watt
Channel Hopping FHSS - 256 channels
Bit Error Rates 10e-6 BER at -106dBm wihtout error
correction
Rx Sensitivity <-110dBm
Unit ID 16-bit coding of each transceiver group
Antenna Connector MCX (female)
FCC ID (USA) IA9FHOEM900
ISC (Canada) 1338104550A
