Phrozen Shuffle 2019 User manual

Phrozen Shuffle 2019 / Shuffle Lite User Guide
Thank you for purchasing Phrozen products!
CONTENTS
• Phrozen Shuffle 2019/Lite Printer * 1 pc
• Resin Vat with Cover and Preinstalled FEP film *1 set
• Phrozen Printing Toolkits Box
o Plastic Scraper * 1 pc
o Metal Scraper * 1 pc
o Funnel * 1 pc
o Gloves * 1 set
o AC Power Cord * 1 pc
※If you have any missing component or problems, please contact the
Phrozen team directly

BEFORE YOU START…
• Plug-in AC Power Cord and turn on the button.

Phrozen OS will be ready in 45 secs.

CALIBRATION
Z-axis calibration is an essential process to make your 3D prints successfully
printed with good quality, please do start your printing process after a proper
Z-axis calibration.
Step 1è Take off the resin vat
and make sure no objects on the
LCD.
S Step 2è Put 1 piece of A4 paper
on the LCD platform.

Step 4è Click 【Z-AXIS】button to start the calibration process.
Step 5è Click the manual dot icon at the right side.

Step 6è Loosen 4 screws on both sides of the build platform.
Ø Tips Gently pull the build platform to see if it’s moveable and well-loosened.

Step 7è Click 【NEXT】, kindly wait the build platform down to the BOTTOM.
Step 8è Tighten the screws with slightly pressing the build platform to make
sure the A4 paper is still and IMMOVABLE.

Step 9è Click 【DONE】, kindly wait the build platform back to the top.

UPLOARD PRINTING FILES
USB connection method:
Step 1
è
Make sure the printing file in your USB has been sliced to .phz or .zip
format.
Ø Tips Please name your printing file with ONLY EN ALPHABET.
Step 2
è
Insert your USB into the socket at the back of the printer.
Step 3
è
Click 【PLATES】.
Step 4
è
Click USB icon at the top of the screen.

Step 5
è
Choose your printing file to start uploading process.
Step 6
è
The file will be displayed on the PLATES screen

Step 7
è
After entering the preview screen, please double check the file you
are going to print and click √.
Step 8
è
Before starting to print, please make sure that there is no object
around the stage and resin tank to avoid the LCD panel being crushed.

Printing
●Pour in resin
Ø Tip 1 Always wear gloves, goggles, long-sleeved clothing during your
printing process.
Ø Tip 2 Resin is a kind of chemical material, if feeling any uncomfortable
during using it or, moreover, accidently eating it, please go to the nearest
medical unit asap for further help.
Ø Tip 3 Always wash out completely if any contact between resins and your
body, furthermore, if feeling any uncomfortable, please go to the nearest
medical unit asap for further help.
Ø Tip 4 KEEP THE RESIN SAFELY AWAY FROM CHILDREN.
Ø Tip 5 Please shake the resin properly before using it.
Ø Tip 6 Kindly keep the resin capacity below 1/2 height of the resin vat.
Ø Tip 7 Always stir the vat-stored resin properly before starting your printing
process.
Ø Tip 8 Make sure there’s NO OBJECT ON THE LCD OR IN RESIN VAT except
resin.
Ø Tip 9 Kindly keep your printing environment under 25°C.
Ø Tip 10 If refilling resins is required during printing process, please refill the
resin during the UV light off with platform raising-up.
Ø Tip 11 Always clean the resin immediately if it spills out.

Shutdown
Step 1
è
Touch the screen operation: click SETUP.
Step 2
è
After clicking, follow the instruction below:
Step 3
è
① Setup→ ② Shutdown→ ③ √→ ④ Please turn off the Power
Switch

AFTER PRINTING PROCESS
PLEASE KINDLY FOLLOW THE ENVIRONMENT PROTECTION RULES
IN YOUR LOCAL AREA WHILE YOU DO THE CLEANING PROCESS
AFTER PRINTING.
1. Clean Your Prints
Step 1
è
Take off your print slightly from the build platform with metal
scraper.
Ø Tips Always wear gloves and be aware of any danger operations with
the metal scraper.
Step 2
è
Clean your prints by Phrozen Wash/IPA/95% alcohol until no resin
on your print.
Ø Tips Phrozen Washè https://reurl.cc/8lOv0o
Ø Tips Ultra-sonic Clearè https://reurl.cc/Gklj43
Step 3
è
Post cure your print by Phrozen Cure/405nm UV light.
Ø Tips Phrozen Cureè https://reurl.cc/NaEQQq
2. Tidy Up Your 3D Printer
(a) Safely shutdown your Phrozen 3D printer
Ø Tip ALWAYS SHUTDOWN YOUR 3D PRINTER FIRST before you
clean the build platform & resin vat for avoiding static electricity
damaging your printer.
(b) Clean the build platform
Step 1
è
Take off your print slightly from the build platform with metal
scraper.
Ø Tips Always wear gloves and be aware of any danger
operations with the metal scraper.
Step 2
è
Clean your build platform by Phrozen Wash/IPA/95% alcohol
until no resin on the platform.
Step 3
è
Dry the model by placing it in a cool place more than 30
minutes.
(c) Clean the resin vat
Step 1
è
Store your used resin with a whole black, well-sealed bottle in a
dark and cool place.

Ø Tip 1 Funnel, filter paper and plastic scraper will be the
helpful toolkits to store your resins.
Ø Tip 2 Always keep new resin and used resin stored in
separated container.
Step 2
è
Clean your resin vat by Phrozen Wash/IPA/95% alcohol until
no resin on the resin vat.

PZSlice Pro Software Operation
1.Basic setting
Step 1
è
Machine type
Step 2
è
Select layer thickness (*advice 50um)
Step 3
è
select『Apply』
Step 4
è
Choose language

2.Import file
Step 1
è
Select the upper left file icon
Step 2
è
Choose the file to import
※Mobile window: The middle mouse button can move the screen, and the
right mouse button can rotate the screen in 3D.

3. Hollow setup
Step 1
è
Select the icon- Support mode
Step 2
è
Choose advanced function
Step 3
è
Adjust the height of the base to 1mm
Step 4
è
Hollow out

4. Adjust the support type to the bracket type
Step 1
è
Generate all
Step2
è
Support type

5.Check the internal support function
Internal support function - for example, the model itself has a base, the automatic
support is the support between the base and the platform; if the inner support is
selected, the following place will be added.
