Pifco P28040A User manual

MODEL P28040A
Cordless, Handheld
Vacuum Cleaner
YOUR SAFETY & INSTRUCTION MANUAL
PLEASE READ CAREFULLY
Need help?
For advice, spares & returns.
Call: [phone]
8:30am to 6:00pm Monday - Friday
Visit: www.pifco.co
www.pifco.co

2
Customer support team: [phone]
Technical data
Description: Cordless Handheld Vacuum Cleaner
Model: P28040A
Battery Charger
Input: 100-240V ~50/60Hz 0.2A
Output: DC 26V 0.4
Battery: 22.2V 2000mAh
Product Rating: 150W
Documentation
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
RK Wholesale LTD Quality Assurance, United Kingdom
Warranty
This product is guaranteed for 12 months from the date of original purchase. If any defect arises
due to faulty materials of workmanship, the faulty products must be returned to the place of
purchase. Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RK Wholesale LTD has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.

3
www.pifco.co
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and seek advice
from the manufacturer, its
service agent or a similarly
qualified person.
• DO NOT let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• DO NOT carry the appliance
by the power cord.
• DO NOT use any extension
cord with this appliance.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.
• Switch off at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• Switch off and unplug before
fitting or removing tools/
attachments, after use and
before cleaning.
• Close supervision is
necessary when any
appliance is used by or near
children.
• Children should not play with
the appliance.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards
involved.
• Cleaning and user
maintenance should not
be undertaken by children
without supervision.
• Take care when any appliance
is used near pets.
• DO NOT use this product
for anything other than its
intended use.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:

4
Customer support team: [phone]
• This appliance is for
household use only.
• DO NOT use the appliance
outdoors.
• Keep hair, loose clothing,
fingers and all body parts
away from moving parts.
• DO NOT use to pick up
flammable liquids such as
gasoline or use in an area
where they might be present.
• DO NOT use the appliance
without the dust container
filter in place.
• DO NOT pick up anything
that is burning or smoking
such as cigarettes, matches
or hot ashes.
• Use extra care when cleaning
on stairs.
• Use only manufacturer’s
recommended accessories.
• DO NOT pull cord, use cord
as a handle, close a door on
cord, or pull cord around
sharp edges or corners.
• DO NOT run vacuum cleaner
over the cord. Keep cord
away from heated surfaces.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team.
HIGH VOLTAGE ROTATING PARTS

5
www.pifco.co
What’s in the box & details:
Instruction Manual
Charging Adaptor
1. Sofa Brush
2. Floor Brush
3. Rechargeable battery
4. Charging Station
5. Suction Pipe
6. Release Button
7. Power Button
8. Dust Cup
9. Dusting Brush
10. Crevice Tool
11. Extension Pipe
12. Main Connector
Before your first use:
1. Remove the product from the box.
2. Remove any packaging from the product.
3. Please retain all packaging until you have checked and counted all the parts and the contents
against the parts list.
4. Charge the rechargeable battery.
Dispose of the packaging in a responsible manner.
1
5 6 7
2
3 4
8
1110
12
9

6
Customer support team: [phone]
Charging the sweeper:
1. To charge the vacuum, remove the
rechargeable battery from the bottom of
the vacuum.
2. To remove the battery, push the battery
lock main button in, and pull.
3. Fit the battery onto the charging station.
4. Connect the charging adaptor cable to
the charging station, and then plug in at
the mains.
5. When the charger is plugged in, both
indicator lights on the charging station
will illuminate.
6. When the battery is fully charged, the red
extension indicator light will go out.
7. Switch off at the mains and unplug.
Remove the charging adaptor from the
charging station, and then remove the
battery.
8. Attach the battery to the bottom of the
vacuum.
Attaching the tools to the main body:
1. Push the main connector into the suction
pipe opening or connect the extension
pipe.
2. Push the required tool into the other end
of the main connector.
3. When using the extension pipe ensure
the end attachment is fitted securely.
When connecting the extension pipe
to the suction pipe, or the floor brush,
ensure all tabs are aligned.
Using your appliance:
1. Once the required accessories have been
attached, the vacuum is ready for use.
2. The power button is located on the
handle.
3. Push and hold the power button to use.
Cleaning and care:
In order to achieve the best performance,
empty the dust cup container and clean the
dust cup filter after each use.
1. Turn off the vacuum cleaner and remove
the charging cable.
2. Hold the vacuum over the bin or bin bag.
With one hand holding the handle, unclip
the dust cup cover to open.
3. The dust cup cover will pop open and the
dust and debris will empty into the bin.
4. To remove the filters, turn the filter
handle anti-clockwise.
5. Remove the inner filter from the outer
filter and rinse both in warm water and
then let air dry for 24 hours before
re-assembling.
6. Ensure you remove all dust and debris
from both filters. A soft bristled brush can
be used to remove any blocked dirt from
the outer filter.
7. Re-assemble when completely dry.
Storage:
• When the appliance is not in use, store in
a safe, dry place, out of reach of children.
• DO NOT store the vacuum in direct
sunlight.
Note:
Regular cleaning of the vacuum will
prolong its life.
Note:
A full charge takes approximately
4.5 Hours.

7
www.pifco.co
WARNING:
DO NOT immerse any electrical part of the appliance in water such as motor units or plugs.
Please see cleaning secon for further instrucons.
Troubleshoong:
Problem Possible Soluon
Vacuum will not work. The vacuum may have run out of charge.
Charge fully.
Vacuum will not pick-up or suction power is
weak.
The dust cup container may be full, or the
filters may require cleaning.
Empty the dust cup container and clean the
filters.
Dust is escaping from the vacuum. The filter may not be installed correctly, or the
dust cup container may be full.
Empty the dust cup container and reassemble
the filter system.
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish. You are
required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk
for access to information about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of electrical items
purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be recycled,
rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.

0419.V3
We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantasc products,
we are oering you an extra 1 year peace of mind.
*To receive your extra 1 years guarantee, register your appliance online
within 28 days of purchase by vising:
www.pifco.co
Make sure to retain your original receipt.
Should you have a problem
with your appliance or need any spare parts please call our
Customer Support Team on:
[phone]
Distributed throughout the UK by RK Wholesale LTD
