Pifco P29013 Mounting instructions

MODEL P29013
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
www.pifco.co
RECHARGEABLE
WINDOW VACUUM

2
CUSTOMER SUPPORT TEAM: [phone]
TECHNICAL DATA
Description: Rechargeable Window Vacuum
Model: P29013
Rated Voltage: 240V ~50Hz
Adaptor:
Input: 100-240V ~50/60Hz 0.2A Max
Output: DC 5V 800mA
Battery: 3.6V 1.5Ah Li-ion Battery
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
RKW Quality Assurance, United Kingdom
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RKW has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.

3
www.pifco.co
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• Please ensure that the appliance
is used on a stable, level, and
heat resistant surface.
• Do not immerse cords, plugs
or any part of the appliance in
water or any other liquid.
• Do not leave the appliance
unattended while it is operating.
• Close supervision is necessary
when any appliance is used by
or near children or pets.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved.
• Children shall not play with the
appliance.
• Cleaning and user maintenance
shall not be made by children
without supervision.
• Switch o at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• If the supply cord or appliance
is damaged, stop using the
appliance immediately and seek
advice from the manufacturer
or its service agent or a similarly
qualied person.
• Do not let the cord hang over
the edge of a table or counter or
let it come into contact with any
hot surfaces.
• The use of accessory
attachments is not
recommended by the appliance
manufacturer, apart from those
supplied with this product.
• Do not pull the plug out by the
cord as this may damage the
plug and/or the cable.
• Do not use this product for
anything other than its intended
use.
• This appliance is for household
use, but may be used outdoors
on windows only.
• Do not carry the appliance by
the power cord.

4
CUSTOMER SUPPORT TEAM: [phone]
• Do not insert objects into the air
outlets.
• Do not spray liquid from the
spray bottle directly onto
equipment containing electrical
components, such as the
interior of ovens.
• Do not place in front of or close
to radiators, heaters or res.
• Always test by wiping high
shine surfaces by wiping the
microbre cloth on a small area,
prior to using the appliance on
the surface.
• This appliance is intended for
wet pick up only. Do not use
for picking up dust or other dry
materials.
• Do not use to pick up hot ash,
ammable liquids, or any other
hot, smoking or burning objects
or glowing embers.
• Do not use to pick up hard,
sharp objects such as glass or
nails.
• Do not use any accessories or
parts that are not supplied with
the appliance.
• In the unlikely event the
appliance develops a fault,
stop using it immediately and
seek advice from the Customer
Support Team.
HIGH VOLTAGE

5
www.pifco.co
WHAT’S IN THE BOX
Instruction Manual
Spray Bottle
Microbre Cloth
Charger
1. Squeegee Vacuum Head
2. Cleaning Head Lock
3. Indicator Light
4. Power button
5. Upper tank & top cap
(cap not shown)
6. Lower tank & bottom cap
cap not shown)
7. Air outlet
8. Body
9. Charging input
10. Cloth
11. Spray Head
12. Spray Bottle
BEFORE YOUR FIRST USE:
1. Carefully remove all contents from packaging and inspect product to make sure there is no
damage.
2. Assemble the appliance as per the instructions.
3. Charge for 2.5 hours.
4. Your appliance is now ready for normal use.
Dispose of the packaging in a responsible manner.
1
2
3
4
5
6
7
8
9
10
11
12

6
CUSTOMER SUPPORT TEAM: [phone]
USING YOUR APPLIANCE
1. Fill the spray bottle with water and a small
amount of window cleaning solution.
Attach the cloth onto the spray head and
screw the spray head onto the spray
bottle.
2. Slide the squeegee vacuum head into
place on the top of the window vac. It will
click into place once secured.
Note: Always unplug the window vac from
the charger before assembly, cleaning,
maintenance or use.
3. Using the spray bottle, spray the window
and wipe any excess dirt away with the
cloth.
4. Turn the window vac on by pressing the
power button.
5. Using a vertical motion, use the window
vac from the top to the bottom of the
window, until the window is clear.
6. Hold the window vac at the bottom of the
window to suck up any excess dirty water.
7. Turn the window vac o when the dirty
water inside lls the tank.
8. Open the top cap and pour away the dirty
water.
9. If there is water in the bottom tank, open
the bottom cap and empty it to ensure no
dirty water is sprayed from the air outlet.
Note: If too much water lls the bottom tank,
the window vac will automatically shut down
and the indicator light will ash. Empty the
bottom tank and power back on to continue
use.
CHARGING
Before rst use, charge for 2.5 hours.
The window vac needs to be charged for 2.5
hours for 25 minutes of continuous use.
To charge:
1. Connect the lead from the charging
adaptor to the charging port on the back
of the window vac.
2. Plug the adaptor into a mains power
supply. The indicator light will ash to
show the battery is charging. When the
window vac is full charged the indicator
light will stop ashing and remain steadily
lit up.

7
www.pifco.co
CLEANING & CARE
• Do not immerse the main body in water.
• Always unplug the window vac from the
charger before cleaning or maintenance.
• Wash the microbre cloth in warm soapy
water and allow to air dry thoroughly.
• To clean the exterior of the window
vacuum, wipe it with a soft, damp cloth
and then allow to dry thoroughly.
• Clean the squeegee vacuum head, spray
bottle and spray head in warm soapy
water and allow to dry.
WARNING:
DO NOT IMMERSE ANY PART OF THE
APPLIANCE IN WATER
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish.
You are required to dispose of old electrical
and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk
for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to
information about the recycling of electrical
items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it
has reached the end of its life.

1017.V5
We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are oering you an extra 2 years peace of mind.
To receive your extra 2 years guarantee, register your appliance
online within 28 days of purchase by visiting.
www.pifco.co
Need help?
For advice, spares and returns.
Call:[phone]
8.30am to 6.00pm Monday-Friday
Visit: www.pifco.co
Distributed throughout the UK by RKW LTD
