Pifco P28053 User manual

MODEL P28053
700W Dual Cyclonic
Vacuum Cleaner
YOUR SAFETY & INSTRUCTION MANUAL
PLEASE READ CAREFULLY
Need help?
For advice, spares & returns.
Call: [phone]
8:30am to 6:00pm Monday - Friday
Visit: www.pifco.co
www.pifco.co

2
Customer support team: [phone]
Technical data
Description: Dual Cyclonic Vacuum
Model: P28053
Battery Charger
Frequency: 220-240V ~50/60Hz
Product Rating: 700W
Documentation
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
RK Wholesale LTD Quality Assurance, United Kingdom
Warranty
This product is guaranteed for 12 months from the date of original purchase. If any defect arises
due to faulty materials of workmanship, the faulty products must be returned to the place of
purchase. Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RK Wholesale LTD has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.

3
www.pifco.co
WARNING:
This appliance is double insulated. Do not connect any wire to the earth terminal.
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the
mains lead of this
appliance may not
correspond with the
coloured markings
identifying the terminals
in your plug, please
proceed as follows:
The wires in the mains
lead are coloured in accordance with the
following code:
Blue neutral [N] Brown live [L]
Plug Fitting Details (Where Applicable).
The wire coloured blue is the neutral and must
be connected to the terminal marked [N] or
coloured black.
The wire coloured brown is the live wire and
must be connected to the terminal marked [L]
or coloured red.
On no account must either the brown or
the blue wire be connected to the [EARTH]
terminal .
Always ensure that the cord grip is fastened
correctly.
The plug must be fitted with a fuse of the same
rating already fitted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualified electrician who
will be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug fitted to the mains lead and
should the fuse need replacing, you must use
an ASTA approved one (conforming to BS 1362
of the same rating).
If in doubt, consult a qualified electrician who
will be pleased to do this for you.
If you need to remove the plug – disconnect
it from the mains – and then cut it off of the
mains lead and immediately dispose of it in a
safe manner. Never attempt to reuse the plug
or insert it into a socket outlet as there is a
danger of an electric shock.

4
Customer support team: [phone]
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and seek advice
from the manufacturer, its
service agent or a similarly
qualified person.
• DO NOT let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• DO NOT carry the appliance
by the power cord.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer apart
from those supplied with
this product. DO NOT use
extension cords with the
appliance.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.
• Switch off at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• Switch off and unplug before
fitting or removing tools/
attachments, after use and
before cleaning.
• Close supervision is
necessary when any
appliance is used by or near
children.
• Children should not play with
the appliance.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards
involved.
• Cleaning and user
maintenance should not
be undertaken by children
without supervision.
• Take care when any appliance
is used near pets.
• Not suitable for carpets with
long fibres as the bristles will
damage the fibres.
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:

5
www.pifco.co
• Keep the vacuum cleaner
moving over the carpet
surface at all times to avoid
damaging the carpet fibres.
• DO NOT use this product
for anything other than its
intended use.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• This appliance is for
household use only.
• DO NOT use the appliance
outdoors.
• Keep hair, loose clothing,
fingers and all body parts
away from moving parts.
• DO NOT use to pick up
flammable liquids such as
gasoline or use in an area
where they might be present.
• DO NOT use the appliance
without the dust container
filter in place.
• DO NOT pick up anything
that is burning or smoking
such as cigarettes, matches
or hot ashes.
• Use extra care when cleaning
on stairs.
• Use only manufacturer’s
recommended accessories.
• DO NOT pull cord, use cord
as a handle, close a door on
cord, or pull cord around
sharp edges or corners.
• DO NOT run vacuum cleaner
over the cord. Keep cord
away from heated surfaces.
• This product is fitted with
a thermal cut-out, which
will activate if the motor
overheats due to blocked
air inlets. If the appliance
cuts out, allow it to cool for
1 hour, then empty the dust
container and clean all of the
filters.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team.
HIGH VOLTAGE ROTATING PARTS

6
Customer support team: [phone]
What’s in the box & details:
Instruction Manual
1. Motor Speed Adjustment
2. Filter Lid
3. Filter/Dust Cup
4. Suction Hose
5. Suction Hose Connection
6. Floor Brush
7. Telescopic Tube
8. Automatic Cord Rewind
9. ON/OFF Foot Switch
10. Crevice Tool with Brush
Before your first use:
1. Remove the product from the box.
2. Remove any packaging from the product.
3. Please retain all packaging until you have checked and counted all the parts and the contents
against the parts list.
Dispose of the packaging in a responsible manner.
2
38
9
7
1
6
4
510

7
www.pifco.co
Assembly and disassembly of the
vacuum tube:
1. To assemble, insert the vacuum tube into
the air intake opening. Push the vacuum
tube in until it locks in place .
2. To disassemble, disconnecting the
appliance from the mains socket.
3. Press the lugs either side of the
connector and remove the vacuum tube.
Assembling the telescope tube and
accessories:
1. Remove the telescope tube from the
hand grip.
2. Set the telescope tube to the correct
length.
3. Push the telescope tube slider forwards
and pull out the lower part of the tube to
the length required. Then simply let go of
the slider and let it snap into place
4. Fix the floor brush to the telescope tube.
Floor brush settings:
The floor brush has 2 height settings.
• Hard floors = Brush bar extended
• Carpets = Brush bar retracted
Using your appliance:
1. Before using the appliance first roll out a
sufficient length of electric flex cable and
then plug into the mains socket.
2. The yellow mark on the electric flex cable
is the maximum length that can be safely
used and must not be exceeded.
3. To switch on the device press the foot
pedal button on the casing with your
foot.
4. To rewind the power cable, press the
button with one hand and guide the
cable with the other hand to ensure that
it does not whip causing damage.
Adjustable power feature:
This cleaner has an adjustable power
feature, enabling you to increase or decrease
the vacuum power according to your
requirements.
Note:
The vacuum cleaner comes with the
following accessories;
• A crevice tool to vacuum corners or
narrow gaps.
• A brush tool to clean delicate
surfaces.
Note:
The vacuum is suitable for everyday
cleaning of the carpet and of wooden
floors.

8
Customer support team: [phone]
Inserting batteries into the power
control area:
1. Open the battery cover.
2. Make sure that the batteries are inserted
according to their polarity as indicated.
3. Replace the battery cover.
4. Turn on the switch and all of the lights
should illuminate.
• The battery type should be AAA Battery
• Different types of batteries or new and
used batteries are not to be mixed.
Always use new batteries when replacing
them.
• Batteries are to be inserted with the
correct polarity.
• Exhausted batteries are to be removed
from regulating handle and safely
disposed of.
• If the appliance and the power control
handle are to be stored or unused for
a long period, the batteries should
be removed to prevent leakage and
corrosion.
Adjusting the power:
1. Turn on the switch. All of the lights on
the panel will illuminate.
2. Press the “-” button on the indication
label and the lights will switch off
successively as the power reduces.
3. Press the “+” button on the indication
label, the lights will turn on successively,
and the power will increase at the same
time.
4. Turn off the switch to put the appliance
into standby mode. Press the switch
again to power up the appliance again.
Note:
This vacuum sweeper works best on
smooth surfaces such as wood, ceramic,
tiles and marble. It will also perform well
on hard, short-haired carpet. It should
NOT be used on long-haired carpets as
the fibres will damage the system.
Note:
The control buttons on the handle of the
vacuum cleaner require 2 x AAA batteries
to operate. Ensure the correct type
of batteries has been inserted before
attempting to use these controls.

9
www.pifco.co
Cleaning and care:
The cyclone vacuum cleaner functions without
requiring a dust bag. Instead the dirt, dust and
particles are sucked up and channelled into
the dust container by the force of the air jet.
The air is cleaned by a washable permanent
filter (HEPA filter) in the dust container, motor
protection filter and an exhaust air filter.
Caution! Never vacuum clean without a filter
or with a damaged filter. Dust that is sucked
into the unit could force its way into the
device and damage the motor.
Emptying Dust Container:
Thanks to the transparent dust container it is
easy to see the fill level of the appliance and
whether it should be emptied.
1. Switch off the vacuum cleaner and
disconnect the plug from the mains.
Always pull on the plug, never pull on the
cable.
2. Pull the container, together with the
cleaning system, out of their anchoring
with the aid of the carrier handle on the
dust container. Then lift out the dust
container and carry it to the waste bin.
It is best to empty the container near to
where your dust receptacle is situated.
3. A push button is located on the dust
container that you can use to open and
empty it.
4. To do this, hold the dust container over
your dustbin and press on the button.
This will release the stopper. When the
dust container is full, it is a good idea to
pull a plastic bag over it and to empty it
into this bag. This helps to prevent the
spilling of dust.
5. After emptying it clean the HEPA filter
again if necessary (see also Cleaning the
HEPA filter below). After this rinse out
the dust container and wipe it dry.
6. After this push the HEPA filter cleaning
system back into position in the cyclone
vacuum cleaner until it snaps into place.
Your cyclone vacuum cleaner is now
ready for use again.
Cleaning the exhaust air filter or
HEPA filter:
The exhaust air filter or HEPA filter cleans the
air a final time before it leaves the vacuum
cleaner. You can clean the exhaust air filter or
HEPA filter as follows:
1. Switch off the vacuum cleaner and
disconnect the plug from the mains.
Always pull on the plug, never pull on the
cable.
2. Open the exhaust air grill.
3. The exhaust air filter or HEPA filter is
visible when the grill has been opened.
4. Rinse the filter or HEPA filter under cold
running water and allow dry.
5. Put the exhaust air filter or HEPA filter
back into place (or replace with a new
one)
6. Close the exhaust air filter grill.
Storage:
• When the appliance is not in use, store in
a safe, dry place, out of reach of children.
• DO NOT store the vacuum in direct
sunlight.
Note:
Keep the brushes free of fibres, hairs, and
other objects that could impede proper
functioning. Always remove the fibres
or other objects when the brushes pick
them up.

10
Customer support team: [phone]
WARNING:
DO NOT immerse any electrical part of the appliance in water such as motor units or plugs.
Please see cleaning secon for further instrucons.
Troubleshoong:
Problem Possible Soluon
Vacuum will not work. The vacuum may have run out of charge.
Charge fully.
This vacuum cleaner is equipped with a motor
protective thermostat. If for some reason
your vacuum overheats, the thermostat will
automatically turn the suction motor off.
Should this occur, allow it to cool for 1 hour,
then empty the dust container and clean all of
the filters.
Vacuum will not pick-up or suction power is
weak.
The dust container may be full, or the filters
may require cleaning.
Empty the dust container and clean the filters.
Check to make sure the Brush roller is clear of
fibres.
Dust is escaping from the vacuum. The filter may not be installed correctly, or
the dust container may be full. Empty the dust
container and reassemble the filter system
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish. You are
required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk
for access to information about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of electrical items
purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be recycled,
rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.

11
www.pifco.co
Notes
P28053

0219.V3
We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantasc products,
we are oering you an extra 2 year peace of mind.
*To receive your extra 2 years guarantee, register your appliance online
within 28 days of purchase by vising:
www.pifco.co
Make sure to retain your original receipt.
Should you have a problem
with your appliance or need any spare parts please call our
Customer Support Team on:
[phone]
Distributed throughout the UK by RK Wholesale LTD
