USER MANUAL CL-BU-G80M-RC | 8000 LUMEN LED 3-PANEL GARAGE/UTILITY BULB
WITH MOTION SENSOR AND REMOTE CONTROL
USER MANUAL CL-BU-G80M-RC | 8000 LUMEN LED 3-PANEL GARAGE/UTILITY BULB
WITH MOTION SENSOR AND REMOTE CONTROL
CARE FOR YOUR PRODUCT:
Your product will last for many years with minimum care. Therefore, it is
essential to clean the product periodically. Use a soft, non-abrasive cloth or
a mild, non-abrasive glass cleaner. It is essential NOT to use any solvents or
harsh cleaning agents. When cleaning, make sure the power is OFF. Do
not spray liquid directly onto the product or wiring. Instead, spray or pour a
small amount into the cloth and clean the product.
CARE FOR YOUR PRODUCT:
This product has a two-year limited warranty from the date of
purchase—this guarantees against failure due to factory defects,
whether caused by materials or workmanship. The warranty is non-
transferable and only pertains to the original purchaser. Proof of
purchase is required for any repair or replacement, so please keep
your proof of purchase receipt. This warranty does not cover normal
wear and tear or damage due to misuse. Misuse of this product
includes but is not limited to:
• Using outdoors in extreme weather conditions.
• Opening the product’s housing.
• Any attempts to update, remodel or x the unit yourself.
WARNING:
YOU SHOULD ALWAYS FOLLOW BASIC PRECAUTIONS.
Read, follow, and understand all instructions and warnings before beginning any installation
of this product. Failure to do so can result in electric shock, re, or other injuries, including
death. This product should be installed following these instructions, electrical codes, and
by the National Electric Code (NED). Save this user manual for instructions and warnings for
possible future relocation and installation.
CAUTION:
• This product is not waterproof and is designed for dry and damp use only.
• Avoid environments with extreme dust and/or humidity.
• DO NOT use on radiant heated surfaces.
• DO NOT remove the lens protecting the LED.
• DO NOT use near a gas source.
• DO NOT open the product. It is NOT possible to change the LED lights or source.
• This product is not intended for use in possible explosive areas. It should never be in an
area of exposure to vapor elements.
• This product is NOT a toy and should stay out of children’s hands.
• This product is not intended for use with emergency exits.
• Dimmable only with remote.
• DO NOT use this product with a TRIAC dimmer.
TROUBLESHOOTING:
Problem Possible Cause Solution
The product does The power is o Check the power supply and make sure it is ON
not turn on Bad connection Check the wiring
Faulty switch Test and/or replace the switch
Circuit breaker Discontinue use immediately Call customer service 1-888-745-4837
trips or fuse blows Call an electrician
when light is turned on
Lumen: 8000LM
Watts: 65W
Equivalent: 500W Incandescent
LED Lifespan: 30,000 Hours
Operating Voltage: 120V
CRI: 80
Color Temp (CCT): 5000K Daylight
Base: E26 Standard Medium Edison Base
Damp Rated Yes
Operating
Temperature: -4°F to 104°F
(-20°C to 40°C)
EYES:
• DO NOT look directly at the LED lights.
• DO NOT remove the LED lights protective covering.
If you have questions or are missing parts, please contact customer service at 1-888-745-4837 If you have questions or are missing parts, please contact customer service at 1-888-745-4837
WARNING:
RISK OF ELECTRICAL SHOCK.
TO AVOID ELECTRICAL SHOCK, MAKE SURE TO TURN
OFF THE MAIN POWER SOURCE OR DISCONNECT POWER
DURING THE INSTALLATION OR SERVICE
OF THIS PRODUCT
Ballast must be bypassed if present.

USER MANUAL CL-BU-G80M-RC | 8000 LUMEN LED 3-PANEL GARAGE/UTILITY BULB
WITH MOTION SENSOR AND REMOTE CONTROL
USER MANUAL CL-BU-G80M-RC | 8000 LUMEN LED 3-PANEL GARAGE/UTILITY BULB
WITH MOTION SENSOR AND REMOTE CONTROL
INSTALLATION INSTRUCTIONS:
1. Before installing, make sure to shut the power OFF at the circuit breaker. It is highly
recommended that a surge protector is installed. If Ballast is present, it must be bypassed.
2. Remove the existing bulb by unscrewing in a counter-clockwise direction.
3. In a clockwise direction, screw in the unit. Do not overtighten as this may cause damage to the
light and/or the socket. It may be necessary to pivot each light panel down before screwing in
the unit.
4. Turn the power ON at the circuit breaker.
5. Turn the light switch ON then turn the light on from the remote. The LEDs will illuminate.
6. There are 3 adjustable light panels. Pivot each one to meet the desired light in the area. To
protect your eyes, never look directly into the LED lights even when adjusting the panels.
Remote directions:
Press the On (A) button to turn the light on
Press the O (C) button to turn the light o
Press the increase or decrease (D) buttons
to brighten or lower the light strength.
Press the Auto (B) button to set the light
into motion detection mode. Then
select the time (E) you would prefer the
light to stay on when it detections
motion (in seconds)
*Dimmable only with remote.
*DO NOT use this product with a TRIAC dimmer.
If you have questions or are missing parts, please contact customer service at 1-888-745-4837 If you have questions or are missing parts, please contact customer service at 1-888-745-4837
WARNING:
RISK OF ELECTRICAL SHOCK.
TO AVOID ELECTRICAL SHOCK, MAKE SURE TO TURN
OFF THE MAIN POWER SOURCE OR DISCONNECT POWER
DURING THE INSTALLATION OR SERVICE
OF THIS PRODUCT
ADDITIONAL WARNINGS:
• DO NOT open the product. It is NOT possible to
change the LED lights or source.
• Temperature rating is from -4OF to 104OF
• This product is designed for dry/damp use and is
not waterproof. Never use near standing water.
• This product is NOT to be used with dimmers.
Dimmers can damage the product and usage of one will void the
warranty.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.Warning: Changes
or modications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment. Note: This equipment has been tested
and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that the interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on, the user is encouraged to
try to correct the interference by one or more of the following measures: (1) Reorient or relocate the
receiving antenna. (2) Increase the separation between the equipment and receiver. (3) Connect the
equipment into an outlet on a circuit dierent from that of the receiver. (4) Consult the dealer or an
experienced radio/TV technician for help.
17-26FT
