Pioneer KFDH075UW User manual

Technical Manual
Split System , Cooling Only
KODH
TMES--2013
KFDH
075-200
075, 100
125,150,200
075, 100
125,150

Contents
Features ……………..…………..…………..………….. 1
Product Nomenclature …………..…………..……… 1
2
2
Refrigeration Schematic Diagram ………..…………
Operating Range ……………..…………..………..
Specification ……………..…………..…………… 3
Performance Table ………..…………..…………… 4-5
Fan Performance Curve .......................................... 6
Fan Performance Table .......................................... 7
Sound Data ....................................................... 8
Unit Dimension ........................................................ 9,10
11
Installation
Indoor unit installation .....................................
12,13
Outdoor unit installation .. ...............................
14
Refrigerant piping connection .......................
14-16
Refrigerant & Charging ..................................
17-18
31
Electrical Wiring ..............................................
Controller Operation
Service and Maintenance .....................................
32
Trouble Shooting ....................................................
1 stage controller ............................................. 19-21
2 stage controller .............................................. 22-29
Phase Protector ............................................ 30

FeaturesFeatures
█General
–Fabricated with a rigid galvanized steel casing.
–Single skin galvanized steel casing with 10mm thickness,
25 kg/m3 high-density non-flammable PE insulation for the indoor unit.
█Motor
–The single phase motor is consisted with hermetic aluminum alloy casing
and permanently lubricated ball bearing.
- The motor has class B insulation ; with internal thermal protection.
– Motor lead-out wires are with sleeve, providing protection against damage
–The 3 phase motor has Class F insulation, with IP55 protection index
█Drain Pan
–The drain pan is 45~50mm depth with 1.0mm thickness galvanized steel
c/w internal epoxy polyester resin coating.
–The drain pan is sloped towards the drain pipe with a 2 deg. gradient.
–The drain pan has one 3/4-inch to 1-1/4-inch male pipe thread (BT) connection.
– The standard insulation material is 10mm thickness, 25kg /m density PE foam.
3
█Flat type design which allows maximum utilization of storage and container loading.
Modular design allows minimum space for site installation.
█All condensing units are supplied with scroll compressor, which is high in energy efficiency
and quiet in operation.
Product Nomenclature
123456789
K F D H 1 2 5 U W
Outdoor
1- 4 KFDH - Ducted Fan Coil Unit
KODH - Outdoor Unit
5-7 Nominal Capacity - MBH
8-9 Generation
150 - 150,000 Btu/hr
100 - 100,000 Btu/hr 200 - 200,000 Btu/hr
075 - 75,000 Btu/hr
125 - 125,000 Btu/hr

Refrigeration Schematic DiagramRefrigeration Schematic Diagram
Operation LimitOperation Limit
Dry bulb Wet bulb
TXV
(field installed)
Sight
glass Filter
drier
Scroll
Compressor
Access
Valve
Access
Valve
High Pressure
Switch
Low Pressure
Switch
Heat Exchanger (Outdoor)
Heat Exchanger (Indoor)
Discharge
Cooling Operation
** For working conditions below 20 deg C head pressure control shall be installed
(Eg , Fan speed Controller , Field installed)
Caution:
Ambient temperature deg C
Indoor
Maximum 35 21
Minimum 19 14
Outdoor
Maximum 43 -
Minimum 20**

SpecificationSpecification
General Data
Note:-
1. All specifications are subjected to change by the manuf acturer without prior notice
2. Nominal cooling capacity are based on the below conditions:-
a) Entering air temp 27 deg C DB and 19 deg C WB.
b) Entering outdoor temperature 35deg C
3.**. Charging level based on 7m copper tube connection, actual charge level shall be based on site installation.
KFDH075UW KFDH100UW KFDH125UW KFDH150UW KFDH200UW
KODH075UW KODH100UW KODH125UW KODH150UW KODH200UW
Btu/h
75,000 98,000 120,000 150,000 200,000
W
22,000 29,000 36,000 44,000 59,000
kcal/h
19,000 25,000 31,000 38,000 51,000
W
7,760 9,900 11,790 17,020 21,660
A
15.6 19.1 21.9 33.8 41.0
V/Ph /H z
2 stage
L/s (cfm)
1 140 (2400) 1511 (3200) 1889 (4000) 2266 (4800) 3022 (6400)
Pa
100 100 150 150 150
dB-A
56 57 58 61 62
Height mm
549 549 885 885 885
Length mm
1502 1502 1640 1640 1894
Depth mm
761 761 1040 1040 1040
Height mm
559 559 881 881 881
Length mm
1399 1399 1546 1546 1799
Depth mm
756 756 1057 1057 1057
kg
91 100 179 187 212
mm (in)
25 (1") 25 (1") 25 (1") 25 (1") 32 (1-1/4")
cfm
5500 5500 5500 8000 11000
Sound Pressure Level dB-A
66 67 67 70 70
Height mm
1085 1085 1085 1372 1085
Width mm
985 985 985 985 985
Depth mm
1220 1220 1220 1220 2250
kg
165 170 200 310 340
Liquid mm (in)
12.7 / 1/2 15.88 / 5/8 15.88 / 5/8 15.88 / 5/8 15.88 / 5/8
Suction mm (in) 28.6 / 1 1/8 28.6 / 1 1/8 34.9 / 1 3/8 34.9 / 1 3/8 28.6 / 1 1/8
Refrigerant Charge ** kg
5.6 6.5 9.4 12 6.5 x 2
MODEL
Indoor Unit
Outdoor Unit
380~415V/3Ph/50Hz
NOMINAL COOLING CAPACITY
NOMINAL INPUT POWER
NOMINAL RUNNING CURRENT
POWER SUPPLY
380~415V/3Ph/50Hz
INDOOR UNIT
Control
Air Flow
External Static Pressure
Sound Pressure Level
Unit Dimension
Unit Dimension,
Double Skin
Unit Weight
Condensate Drain Pipe
OUTDOOR UNIT
Air Flow
Unit
Dimension
Weight
Connection
(Braze Type)
1 stage
1 stage
Ins ulation /
Diameter X Length mm
Index of Protection; Ins ulation
Power Source (V/Ph//Hz)
Capacitor μF
10 + 10 12 + 12 - - -
Rated Running Curre A
2.0 + 2.0 2.0 + 2.0 3.4 4.7 6.2
Rated Output Power W
250 + 250 315 + 315 1500 2200 3000
Tube Material, Size mm (in)
FinMaterial,Thickness mm
Face Area
m
2
(ft
2
)
3 X 14 4 X 14 3 X 14 4 X 14 4 X 14
Dimension (LxWxt):
Qty
mm
Type of Discharge Throw
Vertic al Ve rti cal Vertic al Ve rti cal Vertica l
Scroll Scroll Scroll Scroll Scroll
Lock Rotor Amp A
95 125 128 198 2 x 125
Rated Running Current A11.7 16.2 16.9 25 2 x 16.2
Input Power W
6500 8520 9550 12600 2 x 8520
1 1 1 1 2
Diameter mm (in)
660 (26) 660 (26) 660 (26) 760 (30) 660 (26)
Index of Protection; Ins ulation
IP55; F IP55; F IP55; F IP55; F IP55; F
Rated Running Current A1.4 1.4 1.4 4 2X1.4
Rated Output Power W
550 550 550 1500 2x550
Rated Input Power W
670 670 670 2000 2x670
Tube Material, Size mm (in)
FinMaterial,Thickness mm
Face Area
m2 1.67 1.67 1.67 2.16 3.37
1 X 18 2 x12 2 x 18 2 x 18 2 x 12
381 X 474
1
DIDW Fwd Curve ; Belt ; Galvabond Steel
PE / 10mm
Polyester , Saiver Blue (Ext)/ Bare GI (Int)
GI
Induction Motor; 1 ; 4P
IP20; F
220~240V/1Ph/50Hz
0.54 (5.8)
Was hable Alu Frame Filter / G3
Cu 9.52 (3/8")
Alu m in um , 0.1 1
2
380~415V/3Ph/50Hz
IP54; F
Was hable Alu Frame Filter / G3
GI ; Polyes ter ; Saiver Blue & Silk Grey
738 x 456 x 46 x 3,
738 x 264 x 46 x 1 (200 only)
Propellar/ Direct / Metal
Cu, S.I.G.C. ,9.52 (3/8")
Alu m in um , 0,1 1
INDOOR UNIT
Casing
Mate ri a l
Coating/ Colour
Fan
Type / Drive / Material
Qty
Capacitor Run Motor, 2, 4P
241 X 241
Coil
Fan Motor
Type, Qty, Poles
1.01 (10.9)
Row, FPI
Filtration
Type
420 x 420 x 21 x 3
OUTDOOR UNIT
Material/Coating/ Colour
Compressor
Compressor Type
Fan
Type/ Drive/ Material
Casing
Qty
Fan Motor
Coil
Row , FPI
DIDW Centrifugal Fwd Curve ;
Component Data

Performance TablePerformance Table
TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW )
15 24.4 15.1 22.9 13.7 21.4 12.4 19.7 10.8 18.4 9.7 16.6 8.0
16 24.7 13.8 23.3 12.7 21.8 11.5 20.2 10.2 19.0 9.3 17.2 7.9
16 24.7 18.4 23.3 17.2 21.8 16.1 20.2 14.8 19.0 13.8 17.2 12.4
17 25.0 17.1 23.6 16.2 22.3 15.3 20.7 14.2 19.6 13.3 17.9 12.3
18 25.3 15.9 24.0 15.2 22.7 14.5 21.2 13.6 20.2 13.1 18.6 12.2
19 25.6 14.6 24.4 14.1 23.2 13.6 21.8 13.0 20.8 12.7 19.3 12.1
20 25.9 13.3 24.7 13.0 23.6 12.6 22.2 12.1 21.2 11.9 19.8 11.5
18 25.3 20.3 24.0 19.7 22.7 19.0 21.1 18.1 20.2 17.6 18.6 16.8
19 25.6 19.2 24.4 18.7 23.2 18.2 22.0 17.5 20.8 17.2 19.3 16.7
20 25.9 17.9 24.7 17.5 23.6 17.2 22.2 16.6 21.2 16.5 19.8 16.0
21 26.2 16.6 25.1 16.3 23.9 16.1 22.6 15.6 21.7 15.5 20.3 15.1
22 26.5 15.4 25.4 15.1 24.3 14.9 23.0 14.5 22.1 14.5 20.8 14.2
23 26.8 14.1 25.7 13.9 24.7 13.8 23.4 13.4 22.5 13.5 21.2 13.3
24 27.1 12.8 26.1 12.7 25.0 12.6 23.8 12.4 22.9 12.5 21.7 12.4
20 25.9 20.2 24.7 19.8 23.6 19.5 22.2 18.9 21.2 18.8 19.8 18.3
21 26.2 18.9 25.1 18.6 23.9 18.3 21.6 17.8 21.7 17.8 20.3 17.4
22 26.5 17.6 25.4 17.4 24.3 17.2 23.0 16.8 22.1 16.7 20.8 16.5
23 26.8 16.4 25.7 16.2 24.7 16.1 23.4 15.7 22.5 15.7 21.2 15.6
24 27.1 15.1 26.1 15.0 25.0 14.9 23.8 14.6 22.9 14.7 21.7 14.6
27
30
43
20
24
20
25
30
35
40
ID DB'C
ID W B 'C
Outdoor DB C
TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW )
15 29.7 17.5 28.0 16.1 26.3 14.7 24.3 13.1 22.8 11.9 20.6 10.1
16 31.3 16.9 29.4 15.5 27.4 14.1 25.3 12.6 23.5 11.4 21.1 9.7
16 31.3 22.5 29.4 21.3 27.4 19.9 25.3 18.3 23.5 17.1 21.1 15.5
17 33.0 22.0 30.8 20.6 28.6 19.3 26.2 17.8 24.1 16.7 21.5 15.1
18 34.6 21.3 32.1 20.0 29.7 18.7 27.1 17.3 24.8 16.2 21.9 14.7
19 36.2 20.6 33.5 19.4 30.8 18.2 28.7 16.7 25.5 15.7 22.3 14.2
20 37.8 19.9 35.0 18.7 32.2 17.5 29.1 16.1 26.5 15.0 23.1 13.5
18 34.6 27.1 32.1 25.8 29.7 24.5 27.1 23.0 24.8 22.0 21.9 20.4
19 36.2 26.4 33.5 25.2 30.8 23.9 29.0 23.2 25.5 21.5 22.3 20.0
20 37.8 25.7 35.0 24.5 32.2 23.2 29.1 21.8 2.8 20.8 23.1 19.3
21 39.4 25.0 36.5 23.8 33.6 22.5 30.5 21.0 27.8 20.0 24.3 18.5
22 40.9 24.3 38.1 23.0 35.1 21.7 31.9 20.3 29.1 19.1 25.5 17.6
23 42.7 23.7 39.6 22.3 36.5 21.0 33.3 19.5 30.4 18.3 26.7 16.7
24 44.3 23.0 41.1 21.6 38.0 20.2 34.6 18.7 31.7 17.5 27.9 15.9
20 37.8 28.6 35.0 27.4 32.2 26.1 29.1 24.7 26.5 23.7 23.1 22.2
21 39.4 27.9 36.5 26.6 33.6 25.4 30.5 23.9 27.8 22.9 24.3 21.3
22 41.0 27.2 38.1 25.9 35.1 24.6 31.9 23.1 29.1 22.0 25.5 20.5
23 42.7 26.5 39.6 25.2 36.5 23.9 33.3 22.4 30.4 21.2 26.7 19.6
24 44.3 25.9 41.1 24.5 38.0 23.1 34.6 21.6 31.7 20.4 27.9 18.8
27
30
43
20
24
20
25
30
35
40
ID DB'C
ID W B 'C
Outdoor DB C
TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW )
15 39.3 22.8 36.7 20.9 34.1 19.0 31.4 16.9 29.0 15.2 26.0 12.9
16 41.0 20.6 38.2 19.0 35.4 17.4 32.4 15.7 29.7 14.3 26.4 12.4
16 41.0 27.8 38.2 26.3 35.4 24.7 32.4 22.9 29.7 21.6 26.4 19.7
17 42.7 25.6 39.6 24.4 36.6 23.2 33.3 21.7 30.5 20.7 26.8 19.2
18 44.4 23.4 41.1 22.5 37.8 21.6 34.3 20.5 31.2 19.9 27.2 18.8
19 46.1 21.2 42.6 20.6 39.0 20.1 35.7 19.4 31.9 19.0 27.6 18.4
20 47.9 18.9 44.2 18.6 40.5 18.3 36.6 17.8 33.1 17.7 28.7 17.3
18 44.4 30.6 41.1 29.8 37.8 28.9 34.3 27.8 31.2 27.1 27.2 26.1
19 46.1 28.4 42.6 27.9 39.0 27.3 36.0 26.9 31.9 26.3 27.6 25.6
20 47.9 26.2 44.2 25.9 40.5 25.5 36.6 25.0 33.1 24.9 28.7 24.5
21 49.6 23.9 45.9 23.8 42.2 23.6 38.3 23.2 34.7 23.3 30.3 23.1
22 51.4 21.7 47.6 21.7 43.9 21.6 39.9 21.4 36.4 21.6 31.9 21.6
23 53.1 19.4 49.3 19.6 45.5 19.7 41.6 19.6 38.0 19.9 33.4 20.1
24 54.9 17.2 51.0 17.5 47.2 17.7 43.2 17.8 39.6 18.3 35.0 18.6
20 47.9 29.8 44.2 29.5 40.5 29.2 36.6 28.7 33.1 28.5 28.7 28.2
21 49.6 27.6 45.9 27.4 42.2 27.2 38.3 26.9 34.7 26.9 30.3 26.7
22 51.4 25.3 47.6 25.3 43.9 25.3 39.9 25.1 36.4 25.2 31.9 25.0
23 53.1 23.1 49.3 23.2 45.5 23.3 41.6 23.2 38.0 23.6 33.4 23.7
24 54.9 20.8 51.0 21.1 47.2 21.4 43.2 21.4 39.6 21.9 35.0 22.2
27
30
43
20
24
20
25
30
35
40
ID DB'C
ID W B 'C
Outdoor DB C
MODEL : 075
MODEL : 100
MODEL : 125
4

Performance TablePerformance Table
TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW )
15 49.0 28.7 45.7 26.3 42.4 23.9 38.9 21.3 35.9 19.1 31.9 16.3
16 51.0 25.9 47.4 24.0 43.9 22.1 40.1 20.0 36.7 18.3 32.4 16.1
16 51.0 34.8 47.4 32.9 43.9 31.0 40.1 28.9 36.7 27.2 32.4 25.0
17 53.1 32.0 49.2 30.6 45.3 29.2 41.2 27.6 37.5 26.4 32.9 24.8
18 55.1 29.1 50.9 28.3 46.7 27.4 42.4 26.3 38.4 25.6 33.4 24.6
19 57.2 26.3 52.7 25.9 48.1 25.6 43.8 25.0 39.2 24.8 33.8 24.4
20 59.2 23.5 54.6 23.4 50.0 23.3 45.2 23.0 40.8 23.1 35.2 23.0
18 55.1 38.1 50.9 37.2 46.7 36.3 42.4 35.2 38.4 34.5 33.5 33.5
19 57.2 35.2 52.7 34.9 48.1 34.5 44.0 34.2 39.2 33.7 33.8 33.3
20 59.2 32.4 54.6 32.3 50.0 32.2 45.2 31.9 40.8 32.1 35.2 32.0
21 61.3 29.5 56.7 29.6 52.0 29.7 47.2 29.5 42.8 29.8 37.2 29.9
22 63.4 26.7 58.7 26.9 54.1 27.1 49.2 27.1 44.8 27.6 39.2 27.8
23 65.5 23.8 60.8 24.2 56.1 24.6 51.3 24.7 46.8 25.3 41.2 25.8
24 67.6 21.0 62.9 21.5 58.2 22.0 53.3 22.3 48.8 23.1 43.1 23.7
20 59.2 36.8 54.6 36.8 50.0 36.7 45.2 36.4 40.8 36.5 36.4 36.4
21 61.3 34.0 56.7 34.1 52.0 33.4 47.2 34.0 42.8 34.3 37.2 34.4
22 63.4 31.1 58.7 31.4 54.1 31.6 49.2 31.6 44.8 32.0 39.2 32.3
23 65.5 28.3 60.8 28.6 56.1 29.0 51.3 29.2 46.8 29.8 41.2 30.2
24 67.6 25.4 62.9 25.9 58.2 26.5 53.3 26.8 48.8 27.5 43.1 28.2
27
30
43
20
24
20
25
30
35
40
ID DB'C
ID W B 'C
Outdoor DB C
TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW ) TC (kW ) SC (kW )
15 56.4 31.9 53.7 30.0 51.0 28.2 48.0 26.1 45.5 24.5 42.2 22.3
16 61.6 31.0 57.9 29.0 54.3 27.1 50.4 24.9 47.0 23.2 42.6 20.8
16 61.6 41.7 57.9 39.8 54.3 37.8 50.4 35.6 47.0 33.9 42.6 31.5
17 66.7 40.9 62.2 38.8 57.6 36.7 52.8 34.4 48.5 32.6 43.0 30.1
18 71.9 40.0 66.4 37.8 60.9 35.6 55.2 33.2 50.0 31.3 43.4 28.7
19 76.3 39.1 70.6 36.8 64.2 34.5 58.8 32.0 51.4 30.0 43.8 27.2
20 82.2 38.3 75.2 35.8 68.2 33.4 60.9 30.8 54.1 28.6 45.7 25.7
18 71.9 50.7 66.4 48.5 60.9 46.4 55.2 44.0 50.0 42.0 43.4 39.4
19 77.0 49.9 70.6 47.6 64.2 45.3 59.0 44.2 51.4 40.7 43.8 37.9
20 82.2 49.0 75.2 46.6 68.2 44.1 60.9 41.5 54.1 39.3 45.7 36.4
21 87.4 48.1 80.0 45.5 72.5 43.0 64.8 40.2 57.6 37.9 48.6 34.8
22 92.6 47.2 84.7 44.5 76.8 41.8 68.7 38.9 61.1 36.4 51.6 33.2
23 97.9 46.4 89.5 43.5 81.2 40.7 72.7 37.6 64.5 35.0 54.5 31.5
24 103.1 45.5 94.3 42.5 85.5 39.5 76.6 36.3 68.0 33.5 57.5 29.9
20 82.2 54.3 75.2 51.9 68.2 49.5 60.9 46.9
54.1
44.7 45.7 41.8
21 87.4 53.5 80.0 50.9 72.5 48.3 64.8 45.6 57.6 43.2 48.6 40.1
22 92.6 52.6 84.7 49.9 76.8 47.2 68.7 44.3 61.1 41.8 51.6 38.5
23 97.9 51.7 89.5 48.9 81.2 46.0 72.7 43.0 64.5 40.3 54.5 36.9
24 103.1 50.9 94.3 47.9 85.5 44.9 76.6 41.7 68.0 38.9 57.5 35.3
27
30
43
20
24
20
25
30
35
40
ID DB'C
ID W B 'C
Outdoor DB C
MODEL : 150
MODEL : 200
5

Fan Performance CurveFan Performance Curve
ESP (Pa)
350
300
250
200
150
100
50
KFDH075UW - 250Watt X 2
AIR FLOW CMH (CFM)
Low
Medium
High
Fan Speed
700 (400)
1350 (800) 2050 (1200) 2700 (1600) 3400 (2000) 4100 (2400) 4750 (2800)
ESP (Pa)
350
300
250
200
150
100
50
KFDH100UW - 350Watt X 2
AIR FLOW CMH (CFM)
1350
(800)
2050 (1200) 2700 (1600) 3400 (2000) 4100 (2400) 4750 (2800) 5450 (3200) 3600
400

Fan Performance TableFan Performance Table
100 751 1.5 85 160 SPZ/ 1
200 867 1.5 100 160 SPZ/ 1
300 976 2.2 118 180 SPZ/ 1
400 1078 2.2 118 160 SPZ/ 1
450 1170 3125 160 SPZ/ 1
100 810 2.2 90 160 SPZ/ 1
150 859 2.2 100 160 SPZ/ 1
200 911 2.2 118 180 SPZ/ 1
300 1010 3125 180 SPZ/ 1
400 1103 4140 180 SPZ/ 1
100 826 395 160 SPZ/ 1
200 920
3
118 180 SPZ/ 1
300 1010 3125 180 SPZ/ 1
400 1098 4140 180 SPZ/ 1
100 826 3140 224 SPZ/ 1
200 920
3
150 224 SPZ/ 1
300 1010 3160 224 SPZ/ 1
400 1098 4170 224 SPZ/ 1
100 903 3140 224 SPZ/ 1
150 944 4140 224 SPZ/1
200 984 4150 224 SPZ/1
300 1063 4160 224 SPZ/1
400 1140 5.5 170 224 SPZ/ 2
100 953 4150 224 SPZ/ 1
200 1027 4160 224 SPZ/ 1
300 1100 5.5 170 224 SPZ/ 2
(5400)
(5400)
ESP
Pa
Model
Air Flow
(CFM)
CMH
Motor
Power
Pulley Size
(Motor)
Pulley Size
(Blower) Type /Qty
KFDH150UW
100 712 1.5 80 160 SPZ/ 1
200 841 1.5 90 150 SPZ/ 1
300 958 1.5 90 140 SPZ/ 1
400 1064 2.2 100 140 SPZ/ 1
500 1161 2.2 112 140 SPZ/ 1
100 751 1.5 80 150 SPZ/ 1
150 802 1.5 80 140 SPZ/ 1
200 867 1.5 90 150 SPZ/ 1
300 976 2.2 100 150 SPZ/ 1
400 1078 2.2 112 150 SPZ/ 1
450 1126 3125 160 SPZ/ 1
100 756 1.5 80 150 SPZ/ 1
200 800 1.5 90 150 SPZ/ 1
300 890 2.2 95 150 SPZ/ 1
400 992 2.2 100 150 SPZ/ 1
KFDH125UW
(3400)
(4000)
(4400)
(4000)
(4800)
(7000)
(6400)
9200
9200
5800
6800
7500
6800
8200
11900
10900
Blower
rpm
KFDH200UW
Standard Point , ESP

Sound DataSound Data
Sound Pressure LevelSound Pressure Level
125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz
High 51 50 48 48 43 38 31 51 47
Medium 48 46 45 45 39 33 26 48 44
Low 45 43 42 39 35 29 23 44 38
High 53 51 50 49 44 41 34 53 48
Medium 49 46 48 46 40 35 27 50 45
Low 464343413530244540
57 52 54 52 48 48 45 56 51
56 53 59 48 45 46 38 57 57
56 52 61 51 45 43 39 60 58
KFDH125UW
KFDH150UW
KFDH200UW
NC
KFDH
075UW
KFDH
100UW
Model Connection 1/1 Octave Sound Pressure Level (dB, ref 20uPa) Overall
(dBA)
Sound pressure measuring point is 1.4m below the unit surface.
(unit is ducted with 3m discharge air duct)
Sound Pressure LevelSound Pressure Level
125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz
66 61
67 63
64
64 62 54 48.5 39
KODH100UW
67.5
KODH075UW
6568 66 63 55.5 49 41
6670 66 63 56 50 41 67 63
72 68 66.5 66 60 53.5 44 70 65
74 68 68 66.5 60 52.5 43.5 70 66
KODH125UW
KODH150UW
KODH200UW
NCModel 1/1 Octave Sound Pressure Level (dB, ref 20uPa) Overall
(dBA)
Sound pressure measuring point is 1.4m from corner of the unit.

Unit DimensionUnit Dimension
Model :
KFDH075/100UW
Model :
KFDH125,150,200UW
476
C
Control
Box
20 A
B
20
885
35
412
255
773
850 130
38
745 38
74
Drain Pipe 1”
φ15
1502
20
53 1268 81
20
396
1402
973
297
80
562
71 437
60 761
605 96
25
214 40
Model 125,150 200
A 1600 2854
B 1541 1975
C 1376 1630

Unit DimensionUnit Dimension
Model :
KODH075/100/125/150UW
Liquid line (75: 1/2 ”, 100/125/150 : 5/8” )
Gas line (75/100 : 1 1/8” ; 125/150 : 1 3/8” )
Control Box
Wiring Hole Liquid line
Gas line
Condenser
Control Box
Wiring Hole Liquid line
Gas line
Condenser
Model :
KODH200UW
Liquid line ( 5/8” )
Gas line ( 1 “)
1/8
75/100/125 1000 1085
150 1287 1372
Model

Indoor unit InstallationIndoor unit Installation
Installing indoor unit
Unit suspension
• Use the hanging rods to hang the unit through the holes provided. Strength of
hanging rods must be ble to support the total weight of the unit.
• Add isolator, absorber , if necessary , to minimize the vibration transmission
to the ceiling.
Drain pipe
• Drain pipe shall be properly installed for the drainage for the drainge
of condensate water.
• Trap shall be installed (See figure)
• Make sure no leak at the connecting joint.
Trap
• Insulate the drain pipe to avoid water condensation.
Service space
Min. 800mm
• Make sure sufficient space for service and
maintenance (see figure).
• Select a location where air can be distributed to all corners of the room.
• Make sure no obstruction to return and dischage air.
• Avoid installation at the following location:
- area where flamable gas may leak or generated.
- places where unit is frequently exposed to corrosive gas, or acidic solutions.
Warning:
•The unit must be securely installed on structure that can sustain its weight.

Condensing unit InstallationCondensing unit Installation
• In order to optimize capacity, unit shall be installed as recommended requirements :-
a) Allow sufficient space around the unit, to avoid the recirculation of the hot discharge air.
b) Ensure no obstruction air flow into or out of the unit.
c) The location which is well ventilated
d) A place which protected from direct sunlighght, use an awning for protection , if necessary.
e) A place where the hot air discharge and operating sound level will not annoy the neighbours.
f) A place must not be susceptible to dust or oil mist, or other corrosive chemicals
Caution: If the condensing unit is operated in an atmosphere containing oils (including
machine oils), salt (coastal area), sulphide gas (near hot spring, oil refinery plant), corrosive
chemicals etc may lead to failure of the unit.
Installation Space and Clearance
Orientation 1 2 X KODH075 to 150
Orientation 2 2 X KODH075 to 150, 1 X KODH 200
Orientation 3 4X KODH075 to 150, 2 X KODH 200
5NITINMM

Condensing unit InstallationCondensing unit Installation
Unit Lifting
Holes at the unit base are for the lifting purpose.
The length of the belt shall be adjust properly,
in order to prevent the imbalance of the unit when lifting
Unit Support
Slab/ curb
Absorber
Unit shall be placed on a secured base, on slab ,
curb or steel frame
Absorber should be installed to absorb the
unit vibration during operation.
Belt shall be used for lifting the unit, properly tied the
belt to the holes , use shackles to tighten the belt.
Make sure the belt strenght is able to withstand the unit
weight.

Unit InstallationUnit Installation
Field Copper Tubing Connection
To ensure satisfactory operation and performance, the following points should be noted for the field
tubing arrangements of the complete refrigerant cycle.
a) Liquid loops or oil traps must be provided according to the position of the outdoor and the indoor
units (depending on whether the indoor unit is above or below the outdoor unit).
b) Field supplied filter drier must be installed as close to the expansion valve(s) of the indoor
unit (evaporator) as possible.
c) Field supplied sight glass must be assembled and mounted next to filter dryer.
d) Pipe size shall be followed as listed in page
When the pipe is too long, the required refrigerant quantity increases, both the capacity and
reliability of compressor will drop.
Maximum tube length and Maximum number of Bends
,,
When the number of bends increases, refrigerant flow resistance increases, thus lowering the cooling
capacity; the excessive pressure drop might eventually cause the failure of compressor.
If height difference of evaporator and condenser is excessive, this will retard the compressor oil return
and affecting the compressor efficiency
Cautions: All units installation length
Max elevation 20M
Max total equivalent length 35M
Max bends 8
For operation safety, accumulator is recommended to be added for any installation more than 30m in
len
g
th
length
Field Charging & Refrigerant Handling
Scroll compressors have a very high volumetric efficiency and quickly pump a deep vacuum if there is
insufficient refrigerant in the system or if refrigerant is added too slowly. Low suction pressure will lead
to high discharge temperatures.
This process will casue the scrolls are not being well-lubricated eventually leads to high friction
between the scroll flanks and tips and generates additional heat.
This will cause damage to scroll bearing which can occur in less than one minute. But the failure might
occur only in later of time after charging.
Other typical field charging problems include undercharging, overcharging, moisture or air in the
system etc. In time each one of these problems can cause compressor failure.
Equipment
Minimal equipments are required for field charging. to do a satisfactory job is :
Set of service gauges Hoses , Vacuum pump, Charging Cylinder
Scales Thermometer Vacuum gauge
Always choose the shortest piping path with minimum bends.
• Both indoor and outdoor are brazed connection.
Warning:
• Make sure there is no flammable gas at the surrounding before the brazing work started.
• DO NOT charge in flammable gas.
Caution:
• During the preparation, piping shall be properly covered to avoid the containmination of the system.


Unit InstallationUnit Installation
Charging Hose
Most field-charging is done using standard service hoses. Hoses are made in different colors with
different working pressures and with different leak rates but the most important point is the presence
or absence of hoses
This slows evacuation and vapor charging dramatically. In most cases the Shredder depressor can
be removed but it is simpler to have one set of hoses with and one set without Shredder depressors
Hose selection is important depending whether the system is being evacuated or charged. Charging
liquid from the cylinder into the liquid line should be carried out using an open hose connected to an
unrestricted fitting. This will reduce charging time.
The proper refrigerant charge should follow the volume as recommended by manufacturer , addtional
charge for extended length installation can follow general guideline below.
If the installer cannot find the correct charge but the system must be started, refrigerant should be
carefully added to the system until reasonable sub-cooling is measured in the liquid line and reasonable
suction superheat is measured at the compressor suction. Suction and discharge pressures must be
monitored carefully during the charging process.
Additional Chage
Based on liquid pipe size per meter length:
Liquid line size kg
1/2” 0.10
5/8” 0.17
3/4” 0.26
7/8” 0.37
Above is the recommendation, actual charge level may be different due to the different application
and ambient condition.
Refrigerant R410A : special precaution
R410A is HFC refrigerant which has Zero Ozone Depletion Potential (ODP = 0). The working
pressure of this refrigerant is 1.6 times higher than refrigerant (R22), thus proper installation /
servicing is essential
i) Characteristic
Mixture of composition by weight : R32(50%) and R125(50%)
R410A liquid and vapor components have different compositions when the fluid evaporates or
condenses. Hence, when leak occurs and only vapor leaks out, the composition of the refrigerant
mixture left in the system will change and subsequently affect the system performance.
It is NOT recommended to add new refrigerant to leaked system.
System shall be evacuated thoroughly and recharging with liquid refrigerant (original mixture
composition of R410A ).
Polyol-ester (POE) oil is used as lubricant for R410A compressor. As the water will react with POE
oil and become acid.Extra precaution must be taken to avoid exposing the R410A system to moist air.
How much refrigerant?

Unit InstallationUnit Installation
Charging Hose
Refrigerant R410A : special precaution
ii) Check List Before Installation / Servicing
• Tubing -Refrigerant R410A is more easily affected by dust or moisture compared with R22, make sure to
temporarily cover the ends of the tubing prior to installation
• Compressor oil - No additional charge of compressor oil is permitted.
• Tools - Tools used for R410A only (must not be share with other refrigerant)
Gauge manifold and charging hose ,Refrigerant cylinder/charging cylinder
Vacuum pump c/w adapter, Refrigerant recovery machine etc
iii) Handling and Installation Guidelines
Like R22 systems, the handling and installation of R410A system are closely similar. All precautionary
measures; such as ensuring no moisture, no dirt or chips in the system, clean brazing using nitrogen, and
thorough leak check and vacuuming are equally important requirements. However, due to its hydroscopic
POE oil, additional precautions must be taken to ensure optimum and trouble-free system operation.
a) During installation or servicing, avoid prolong exposure of the internal part of the refrigerant system to
moist air. Residual POE oil in the piping and components can absorb moisture from the air.
b) Ensure that the compressor is not expose to open air for more than the recommended time specified by
its manufacturer (typically less than 10 minutes). Removed the seal-plugs only when the compressor is
about to be brazed.
c) The system should be thoroughly vacuumed to 1.0 Pa ( 700mmHg) or lower. This vacuuming level is
more stringent than R22 system so as to ensure no incompressible gas and moisture in the system.
d) When charging R410A, ensure that only liquid is being withdrawn from the cylinder or can. This is to
ensure that only the original composition of R410A is being delivered into the system. The liquid
composition can be different from the vapor composition.
e) Normally, the R410A cylinder or can is being equipped with a dip-pipe for liquid withdrawal. However, if
the dip-pipe is not available, invert the cylinder or can so as to withdraw liquid from the valve at the
bottom.

Electrical WiringElectrical Wiring
• Entire unit wiring diagram.
Caution:
• Field-installed wirings must comply with local codes and regulations. Voltage tolerance should
be kept at rated voltage ±10%.
• Check if the main power supply matches the nameplate rating before installation takes place.
• Each air-conditioning unit should be installed with independent circuit breaker (Field installed)
• Unit must be properly GROUNDED.
a.
b.
c.
d.
e.
Power supply
Circuit Breaker (field supply)
Power supply wiring for unit
indoor unit
outdoor unit
Wired remote controller
f.
Unit interconnecting wire
b
ch
PE
d
g.
Earthh.
f
aa
b
ch
PE
e
g
Note:
75/100 c
No. of wire
CC CX
LP
CC
CX
TB2 (C)
Blue
Brown
Brown
15
OLP
95 96
OLP
MF2
CC
MC
(1) (2) (3)
CH
HP PP
PP
Fuse 3.15A
TB1
L3
L1
L2
N
E
LIVE
COMP
X1X2X3
HIMED
LOW
HANDSET
N1
N2
TR
TR
ID COIL SENSOR ROOM SENSOR
H
LM
TB3 (C)
TB3
L
N
MF1-1 MF1-2
PE
h
h
g
b
bc
L
c
TIM
HIGH
LOW
MED
TEMP
AUTO DRY
FAN MODE
COOL
ON/OF F
f
Wiring Diagram : KFDH/KODH 75,100
200 g

Electrical WiringElectrical Wiring
CC CX
LP
CC
CX
TB2 (C)
Blue
Brown
Brown
15
OLP
95 96
OLP
MF2
CC
MC
(1) (2) (3)
CH
HP PP
PP
Fuse 3.15A
TB1
L3
L1
L2
N
E
h
g
bc
TIM
HIGH
LOW
MED
TEMP
AUTO DRY
FAN MODE
COOL
ON/OF F
FAN
HEAT
MF1
IFC
LIVE
COMP
X1
X2X3
HI
MED
LOW
HANDSET
N1
N2
TR
TR
TB3 (C)
ID COIL SENSOR ROOM SENSOR
IFC OLPF
TB3
L3
L1
L2
N
PE
bc
h
OLP
95
96
Wiring Diagram : KFDH/KODH125/150
f
Fuse 3.15A
bc
Wiring Diagram : KFDH/KODH200 (2 stage)
DI 12
COMP1 COMP2 INDOOR
LIVE
NEUTRAL
TR
DI 02
DI 06
12V COM
DI 04
CH1
CH2
TB4 (A)
(1C)
TB3(1)
TB3(A)
TB3(2)
(1)
(2)
TB4(2C)
CC2
WHITE
RED
BLACK
TB1
L3
L1
L2 MC2
MC1
CC2
CC1 OLP1
OLP2
N
Neutral
OFC
pp
MF1
IDF OLPF
TB2
L3
L1
L2
N
IFC
CC1
CC2
PP
OLP2 LP2
HP2
OLP1 LP1
HP1
TB3(1C)
TB3(2C)
CC1
OUTDOOR
OLPOF
OLPF
MF2
MF3
OFC
CC1
CC2
CIRCUIT
BREAKER
h
g
g
TIM
HIGH
LOW
MED
TEMP
AUTO DRY
FAN MODE
COOL
ON/OF F
FAN
HEAT
f
• Recommended field installed minimum wire size (90deg C insulation).
Model 75 100 125 150 200
Indoor
Outdoor
Indoor
Outdoor 5 × 4
Interconnecting, No x 0.75mm2 5 x
380V/3ph/50Hz ~N
Power Suppy 220V/1ph/50Hz ~N 380V/3ph/50Hz ~N
Supply
No. × size (mm2) 5× 6 5× 8
5× 1.5
5× 1.5
1 x
