IMPORTANT INFORMATION
ABOUT YOUR NEW NAVIGATION SYSTEM AND THIS MANUAL
• The navigation features of this product (and rear view camera option if pur-
chased) is intended solely as an aid to you in the operation of your vehicle. It is
not a substitute for your attentiveness, judgment and care when driving.
• Never use this navigation system to route to hospitals, police stations, or similar
facilities in an emergency, Please call 911.
• Do not operate this navigation system (or the rear view camera option if pur-
chased) if doing so in any way will divert your attention from the safe operation
of your vehicle. Traffic restrictions and advisories currently in force should
always take precedence over guidance given by this product. Always obey current
traffic restrictions, even if this product provides contrary advice.
• Certain government laws may restrict the placement and use of navigation sys-
tems in your vehicle. Please comply with all applicable laws and regulations in
the installation and operation of your navigation system.
• This manual explains how to install this navigation system in your vehicle.
Operation of this navigation system is explained in the separate Operation
Manual or Hardware Manual for the navigation system.
• Do not install this product where it may (i) obstruct the driver’s vision, (ii) impair
the performance of any of the vehicle’s operating systems of safety features,
including airbags, hazard lamp buttons or (iii) impair the driver’s ability to safely
operate the vehicle. In some cases, it may not be possible to install this product
because of the vehicle type or the shape of the vehicle interior.
ENG/MASTER 96
<CRD4067A/U> 2
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 2

<CRD4067A/U> 3
English Español Deutsch Français Italiano Nederlands
IMPORTANT INFORMATION .................... 1
ABOUT YOUR NEW NAVIGATION
SYSTEM AND THIS MANUAL .............. 1
IMPORTANT SAFEGUARDS .................... 3
PLEASE READ ALL OF THESE
INSTRUCTIONS REGARDING
YOUR NAVIGATION
SYSTEM AND RETAIN THEM
FOR FUTURE REFERENCE .................... 3
Connecting the System ............................ 4
-Before installing this product
-To prevent damage
-Parts supplied
Connecting the system ...................................... 7
Connecting the power cord (1) .......................... 9
Connecting the power cord (2) ........................ 11
When connecting to separately sold power
amp .......................................................... 13
When connecting a Rear view camera ............ 15
When connecting the external video component
and the display .......................................... 16
-When using a display connected to rear video
output
Installation ................................................ 17
To guard against electromagnetic
interference .............................................. 18
Before installing .............................................. 18
Installing this product ...................................... 19
-Installation notes
-Parts supplied
-DIN Front/Rear-mount
-DIN Front-mount
-DIN Rear-mount
Installing the GPS antenna .............................. 23
-Installation notes
-Parts supplied
-When installing the antenna inside the vehi-
cle (on the rear shelf)
-When installing the antenna outside the vehi-
cle (on the body)
After Installing this Product.................... 26
2
ENG/MASTER 96
Contents
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 3

<CRD4067A/U> 4
ENG/MASTER 96
IMPORTANT SAFEGUARDS
3
PLEASE READ ALL OF THESE INSTRUCTIONS REGARDING YOUR
NAVIGATION SYSTEM AND RETAIN THEM FOR FUTURE REFERENCE
1. Read this manual fully and carefully before installing your navigation system.
2. Keep this manual handy for future reference.
3. Pay close attention to all warnings in this manual and follow the instructions care-
fully.
4. This navigation system may in certain circumstances display erroneous informa-
tion regarding the position of your vehicle, the distance of objects shown on the
screen, and compass directions. In addition, the system has certain limitations,
including the inability to identify one-way streets, temporary traffic restrictions
and potentially unsafe driving areas. Please exercise your own judgment in the
light of actual driving conditions.
5. As with any accessory in your vehicle’s interior, the navigation system should not
divert your attention from the safe operation of your vehicle. If you experience
difficulty in operating the system or reading the display, please make adjustments
while safely parked.
6. Please remember to wear your seat belt at all times while operating your vehicle.
If you are ever in an accident, your injuries can be considerably more severe if
your seat belt is not properly buckled.
Do not attempt to install or service your navigation system by yourself.
Installation or servicing of the navigation system by persons without training and
experience in electronic equipment and automotive accessories may be dangerous
and could expose you to the risk of electric shock or other hazards.
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 4

<CRD4067A/U> 5
English Español Deutsch Français Italiano Nederlands
4
ENG/MASTER 96
Connecting the System
• Pioneer does not recommend that you install your navigation system yourself. We
recommend that only authorized Pioneer service personnel, who have special train-
ing and experience in mobile electronics, set up and install this product. NEVER
SERVICE THIS PRODUCT YOURSELF. Installing or servicing this product and
its connecting cables may expose you to the risk of electric shock or other hazards,
and can cause damage to the navigation system that is not covered by warranty.
• If you decide to perform the installation yourself, and have special training and
experience in the mobile electronics installations, please carefully follow all of the
steps in the Installation Manual.
• Secure all wiring with cable clamps or electrical tape. Do not allow any bare wiring
to remain exposed.
• Do not directly connect the yellow lead of this product to the vehicle battery. If the
lead is directly connected to the battery, engine vibration may eventually cause the
insulation to fail at the point where the wire passes from the passenger compart-
ment into the engine compartment. If the yellow lead’s insulation tears as a result
of contact with metal parts, short-circuiting can occur, resulting in considerable
danger.
• It is extremely dangerous to allow the GPS antenna cable to become wound around
the steering column or shift lever. Be sure to install this product, its cables, and
wiring away in such a way that they will not obstruct or hinder driving.
• Make sure that the cables and wires are routed and secured so they will not inter-
fere with or become caught in any of the vehicle’s moving parts, especially the
steering wheel, shift lever, parking brake, sliding seat tracks, doors, or any of the
vehicle’s controls.
• Do not route wires where they will be exposed to high temperatures. If the insula-
tion heats up, wires may become damaged, resulting in a short circuit or malfunc-
tion and permanent damage to this product.
• Do not cut the GPS antenna cable to shorten it or use an extension to make it
longer. Altering the antenna cable could result in a short circuit or malfunction.
• Do not shorten any leads. If you do, the protection circuit (fuse holder, fuse resister
or filter, etc.) may fail to work properly.
• Never feed power to other electronic products by cutting the insulation of the
power supply lead of the navigation system and tapping into the lead. The current
capacity of the lead will be exceeded, causing overheating.
• The black lead is ground. Please ground this lead separately from the ground of
high-current products such as power amps.
Do not ground more than one product together with the ground from another
product. For example, you must separately ground any amplifier unit away from
the ground of this product. Connecting grounds together can cause a fire and/or
damage the products if their grounds became detached.
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 5

5
Connecting the System
Before installing this product
• This product is for vehicles with a 12-volt battery and negative grounding. Check the
battery voltage of your vehicle before installation.
To prevent damage
When replacing the fuse, be sure to only use a fuse of the rating prescribed on the fuse holder.
• When disconnecting a connector, pull the connector itself. Do not pull the lead, as you
may pull it out of the connector.
• This product cannot be installed in a vehicle that does not have an ACC (accessory)
position on the ignition switch.
• To avoid short-circuiting, cover the disconnected lead with insulating tape. It is especial-
ly important to insulate all unused speaker leads, which if left uncovered may cause a
short circuit.
• Attach the connectors of the same color to the corresponding colored port, i.e., blue con-
nector to the blue port, black to black, etc.
• Refer to the owner’s manual for details on connecting the power amp and other units,
then make connections accordingly.
• Since a unique BPTL circuit is employed, do not directly ground the ≠side of the
speaker lead or connect the ≠sides of the speaker leads together. Be sure to connect the
≠side of the speaker lead to the ≠side of the speaker lead on this product.
• If the RCA pin jack on this product will not be used, do not remove the caps attached to
the end of the connector.
• When connecting the blue lead to the auto antenna and using the auto antenna function,
the vehicle’s antenna can be stowed by following the instructions below.
– In the INITIAL menu, select “RADIO” for “AUTO ANTENNA” and change the
source from radio to another source
– Turn the source off
– Turn off the ignition switch (ACC OFF)
For more detailed information on changing the “AUTO ANTENNA” mode, refer to
“Switching the auto antenna setting” in the Operation Manual.
No ACC positionACC position
O
N
S
T
A
R
T
O
F
F
A
C
C
O
N
S
T
A
R
T
O
F
F
• To avoid shorts in the electrical sys-
tem, be sure to disconnect the (–)
battery cable before beginning
installation.
ENG/MASTER 96
<CRD4067A/U> 6
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 6

<CRD4067A/U> 7
English Español Deutsch Français Italiano Nederlands
6
ENG/MASTER 96
• Never connect speakers with an output rating of less than 50 W channel or impedance
outside of the 4 ohms to 8 ohms specifications to your navigation system. Connecting
speakers with output and/or impedance values other than those noted here may result in
the speakers catching fire, emitting smoke, or becoming damaged.
• When the ignition switch is turned on (ACC ON), a control signal is output through the
blue/white lead. Connect to an external power amp’s system remote control terminal
(max. 300 mA 12 V DC). The control signal is output through the blue/white lead, even
if the audio source is switched off.
• When an external power amp is being used with this system, be sure not to connect the
blue lead to the amp’s power terminal. Likewise, do not connect the blue lead to the
power terminal of the auto antenna. Such connection could cause excessive current drain
and malfunction as well as damage to the auto antenna of the vehicle.
Parts supplied
RCA connector
GPS antennaExtension lead
(for speed signal)
Extension lead
(for reverse signal)
ConnectorPower cordThis product
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 7

<CRD4067A/U> 8
7
Connecting the System
ENG/MASTER 96
Connecting the system
Blue
Blue
*1
Hide-away XM tuner
(GEX-P10XMT)
(sold separately)
Light gray
5 m (16 ft. 5 in.)
GPS antenna
Blue
IP-BUS cable
(supplied with XM tuner)
Black
*2
Black
Black
XM DATA cable
(supplied with XM tuner)
•When combining this product with GEX-P10XMT
(sold separately), this connection must be required.
•When installing the XM tuner in the trunk, etc.,
the optional cable (e.g. CD-600DC) (sold separately)
is required.
Black
Antenna jack
WIRED REMOTE IN
Please see the Instruction Manual for
the Wired Remote Control Adapters (sold separately).
Power cord
RCA connector
This product
Note:
The XM tuner will not receive XM Radio
service when you drive outside of the XM’s
coverage area. When the XM tuner is not
used, connect the IP-BUS cable*1 directly
to this product*2.
☞ See Page 9 to 12.
☞ See Page 13 to 16.
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 8

8
ENG/MASTER 96
English Español Deutsch Français Italiano Nederlands
<CRD4067A/U> 9
Multi-CD player
IP-BUS cable
(sold separately)
Blue
Hide-away TV tuner
(e.g. GEX-P5700TV)
(sold separately)
AV-BUS cable
(supplied with TV tuner)
IP-BUS cable
(supplied with TV tuner)
Black
Black
• To avoid the risk of accident and the potential
violation of applicable laws, this product
should never be used while the vehicle is being
driven except for navigation purposes. And,
also Rear Displays should not be in a location
where it is a visible distraction to the driver.
• In some countries or states the viewing of
images on a display inside a vehicle, even by
persons other than the driver, may be illegal.
Where such regulations apply, they must be
obeyed, and this product’s rear video output
features should not be used.
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 9

9
Connecting the System
ENG/MASTER 96
<CRD4067A/U> 10
Connecting the power cord (1)
Fuse (10 A)
Yellow
To terminal always supplied
with power regardless of
ignition switch position.
Red
To electric terminal controlled
by ignition switch (12 V DC)
ON/OFF.
Black (ground)
To vehicle (metal) body.
Orange/white
To lighting switch terminal.
Fuse resistor
Fuse resistor
With a 2 speaker system, do not connect
anything to the speaker leads that are not
connected to speakers.
White
White/black
Gray
Gray/black
Green
Green/black
Violet
Violet/black
Front speaker Front speaker
Left Right
+
≠
+
≠
+
≠
+
≠
Note:
When a subwoofer is connected to this product instead
of a rear speaker, change the rear output setting in
the Initial Setting. (Refer to the Operation Manual.)
The subwoofer output of this product is monaural.
Rear speaker
or Subwoofer
Rear speaker
or Subwoofer
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 10

<CRD4067A/U> 11
10
ENG/MASTER 96
English Español Deutsch Français Italiano Nederlands
For information on other leads
Blue
To Auto-antenna relay control terminal.
If the vehicle has a glass antenna, connect to
the antenna booster power supply terminal
(max. 300 mA 12 V DC).
This product
Note:
Audio source will be set to mute or attenuate,
while the voice guidance of the navigation
will not be muted or attenuated. For details,
see the Operation Manual.
Note:
When connecting the blue lead to the auto antenna and using
the auto antenna function, the vehicle’s antenna can be stowed
by following the instructions below.
- In the INITIAL menu, select “RADIO”for “AUTO
ANTENNA”and change the source from radio to another
source
- Turn the source off
- Turn off the ignition switch (ACC OFF)
For more detailed information on changing the “AUTO
ANTENNA”mode, refer to “Switching the auto antenna
setting”in the Operation Manual.
Yellow/black
If you use equipment with a mute function (e.g.
cellular telephones), connect that equipment to the
Audio Mute lead. If not, keep the Audio Mute
lead free of any connections.
Note:
Cords for this product and those for other products
may be different colors even if they have the same
function. When connecting this product to another
product, refer to the supplied manuals of both prod-
ucts and connect cords that have the same function.
☞ See Page 11.
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 11

Pink (CAR SPEED SIGNAL INPUT)
The mobile navigation system is connected here to detect the distance
the vehicle travels. Always connect the vehicle’s speed detection
circuit or the ND-PG1 speed pulse generator, sold separately. Failure
to make this connection will increase errors in the location display.
IMPROPER CONNECTION MAY RESULT IN SERIOUS
DAMAGE OR INJURY INCLUDING ELECTRICAL SHOCK,
AND INTERFERENCE WITH THE OPERATION OF THE
VEHICLE’S ANTILOCK BRAKING SYSTEM, AUTOMATIC
TRANSMISSION AND SPEEDOMETER INDICATION.
LIGHT GREEN LEAD AT POWER
CONNECTOR IS DESIGNED TO DETECT
PARKED STATUS AND MUST BE
CONNECTED TO THE POWER SUPPLY SIDE
OF THE PARKING BRAKE SWITCH.
IMPROPER CONNECTION OR USE OF THIS
LEAD MAY VIOLATE APPLICABLE LAW
AND MAY RESULT IN SERIOUS INJURY OR
DAMAGE.
Light green
Used to detect the ON/OFF status of the parking brake. This lead
must be connected to the power supply side of the parking brake
switch. If this connection is made incorrectly or omitted, certain
functions of your navigation system will be unusable.
•It is strongly suggested that the speed pulse wire be connected
for accuracy of navigation and better performance of interlock.
•If the speed pulse wire is unavailable for some reason, it is
recommended that the pulse generator (ND-PG1) be used.
Notes:
•The position of the speed detection circuit and the position of the
parking brake switch vary depending on the vehicle model. For
details, consult your authorized Pioneer dealer or an installation
professional.
•Even when the light green lead and the pink lead are connected
correctly, a message indicating improper connection is shown until
sensor initialization has completed.
11
Connecting the System
ENG/MASTER 96
<CRD4067A/U> 12
Connecting the power cord (2)
Connection method
Clamp the parking brake
switch power supply side lead.
Clamp firmly with
needle-nosed pliers.
Power supply side
Ground side
Parking brake switch
Speed detection circuit lead
Vehicle injection
computer
Connector
Pass the extension cord
and the lead for the
speed detection circuit
through this hole.
Clamp firmly
with needle-
nosed pliers.
Close the cover.
Connection method
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 12

<CRD4067A/U> 13
Be sure to use only the supplied extension lead. Use of another
lead could cause fire, smoke and/or damage this product.
12
ENG/MASTER 96
English Español Deutsch Français Italiano Nederlands
Note:
Cords for this product and those for other products
may be different colors even if they have the same
function. When connecting this product to another
product, refer to the supplied manuals of both prod-
ucts and connect cords that have the same function.
Power cord
Violet/white (REVERSEGEAR SIGNAL INPUT)
This is connected so that the navigation system can
detect whether the vehicle is moving forwards or
backwards. Connect the violet/white lead to the
lead whose voltage changes when the shift lever is
put in reverse. Unless connected, the sensor may
not detect your vehicle traveling forward/backward
properly, and thus the position of your vehicle
detected by the sensor may be misaligned from the
actual position.
Note: When you use the ND-PG1 speed pulse
generator (sold separately), please make sure
to connect this lead.
When you use a rear view camera, please make
sure to connect this lead. Otherwise you cannot
switch to rear view camera picture.
☞ See Page 15.
Connection method
Clamp the reversing lamp lead.
Clamp firmly with
needle-nosed pliers.
Reversing
lamp lead
Fuse resistor
Check the position of your vehicle’s
reversing lamp (the one that lights up
when the shift lever is in reverse [R])
and find the reversing lamp lead in the
trunk.
This product
Extension lead
(for reverse signal)
Extension lead (for speed signal)
For information on other leads
5 m (16 ft. 5 in.)
☞ See Page 9.
5 m (16 ft. 5 in.)
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 13

<CRD4067A/U> 14
13
Connecting the System
ENG/MASTER 96
When connecting to separately sold power amp
This product
Front output
(FRONT OUTPUT)
Rear output
(REAR OUTPUT)
15 cm (5–7/8 in.)
23 cm (9 in.)
Blue/white
To system control terminal of the power amp
(max. 300 mA 12 V DC).
Do not connect this lead to Auto-antenna control
terminal.
15 cm (5–7/8 in.)
For information on other cables
Subwoofer output
or non-fading output
(SUBWOOFER OUTPUT or
NON-FANDING OUTPUT)
☞ See Page 15 to 16.
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 14

14
ENG/MASTER 96
English Español Deutsch Français Italiano Nederlands
<CRD4067A/U> 15
Power amp
(sold separately)
Power amp
(sold separately)
Power amp
(sold separately)
+
≠
+
≠
+
≠
+
≠
+
≠
+
≠
System remote control
RCA cables
(sold separately)
Front speaker
Rear speaker
Subwoofer
Front speaker
Rear speaker
Subwoofer
Left Right
Perform these connections when using
the optional amplifier.
Note:
You can change the RCA output of the subwoofer depending on your subwoofer
system. (Refer to the Operation Manual.)
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 15

<CRD4067A/U> 16
When connecting a Rear view camera
When using this product with a rear view camera, automatic switching to video from a rear
view camera is possible when the gear shift is moved to REVERSE (R) position.
Rear view mode also allows you to check what is behind you while driving.
USE INPUT ONLY FOR REVERSE OR MIRROR IMAGE REAR VIEW CAMERA. OTHER USE
MAY RESULT IN INJURY OR DAMAGE.
•The screen image may appear reversed.
•The rear view camera function is to use this product as an aid to keep an eye on trailers, or backing
into a tight parking spot. Do not use this function for entertainment purposes.
•The object in rear view may appear closer or more distant than in reality.
•Please note that the edges of the rear view camera images may differ slightly according to whether
full screen images are displayed when backing, and whether the images are used for checking the
rear when the vehicle is moving forward.
15
Connecting the System
ENG/MASTER 96
Fuse resistor
5 m (16 ft. 5 in.)
15 cm (5 - 7/8 in.)
Extension lead (for reverse signal)
Violet/white
Rear view
camera
RCA cable
(sold separately)
To video output
Connect to the rear view camera. Do not connect
to any other equipment.
Brown
Note:
This product
Brawn
(REAR VIEW CAMERA IN)
Note:
It is necessary to set to “CAMERA”
in “SETUP”when connecting the
rear view camera. (For details, see the
Operation Manual)
Be sure to use only the supplied extension lead.
Use of another lead could cause fire, smoke
and/or damage this product.
About connection method
☞ See Page 11.
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 16

When connecting the external video component and the display
•It is necessary to set to “AV INPUT”or “REAR DISP”in “SET UP”when connecting
the external video component.
When using a display connected to rear video output
This product’s rear video output is for connection of a display to enable passengers in the
rear seats to watch the video source.
•NEVER install the rear display in a location that enables the driver to watch the video source while
Driving.
This product
15 cm (5 - 7/8 in.)
20 cm (7 - 7/8 in.)
To video input
External video
component
(sold separately)
RCA cables
(sold separately)
Display with
RCA input jacks
To video output
RCA cables
(sold separately)
To audio outputs
Yellow
(REAR MONITOR OUTPUT)
Yellow
(VIDEO INPUT) Red, white (AUDIO INPUT)
For information on other cables
16
ENG/MASTER 96
English Español Deutsch Français Italiano Nederlands
<CRD4067A/U> 17
Note:
The map screen navigation images output
to the rear display differ from standard
NTSC format images. Therefore, their qual-
ity will be inferior to the images that appear
on the front display.
☞ See Page 13 to 15.
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 17

17
Installation
•Pioneer does not recommend that you install or service your navigation sys-
tem yourself. Installing or servicing this product may expose you to risk of
electric shock or other hazards. Refer all installation and servicing of your
navigation system to authorized Pioneer service personnel.
•Never install this product in places, or in a manner that where:
* It could injure the driver or passengers if the vehicle stops suddenly.
* It may interfere with the driver’s operation of the vehicle, such as on the
floor in front of the driver’s seat, or close to the steering wheel or shift
lever.
•Make sure there is nothing behind the dashboard or paneling when drilling
holes in them. Be careful not to damage fuel lines, brake lines, electronic
components, communication wires or power cables.
•When using screws, do not allow them to come into contact with any electri-
cal lead. Vibration may damage wires or insulation, leading to a short circuit
or other damage to the vehicle.
•To ensure proper installation, use the supplied parts in the manner specified.
If any parts other than the supplied ones are used, they may damage internal
parts of this product or they may work loose and the product may become
detached.
•It is extremely dangerous to allow the GPS antenna lead to become wound
around the steering column or shift lever. Be sure to install this product in
such a way that it will not obstruct driving.
•Make sure that leads cannot get caught in a door or the sliding mechanism of
a seat, resulting in a short circuit.
•Please confirm the proper function of your vehicle’s other equipment follow-
ing installation of the navigation system.
•Certain government laws may prohibit or restrict the placement and use of
this system in your vehicle. Please comply with all applicable laws and regu-
lations regarding the use, installation and operation of your navigation sys-
tem.
•Do not install this product where it may (i) obstruct the driver’s vision, (ii)
impair the performance of any of the vehicle’s operating systems or safety
features, including airbags and hazard lamp buttons or (iii) impair the dri-
ver’s ability to safely operate the vehicle.
ENG/MASTER 96
<CRD4067A/U> 18
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 18

•Install this product between the driver’s seat and front passenger seat so that
it will not be hit by the driver or passenger if the vehicle stops quickly.
•Never install this product in front of or next to the place in the dash, door, or
pillar from which one of your vehicle’s airbags would deploy. Please refer to
your vehicle’s Owner’s Manual for reference to the deployment area of the
frontal airbags.
•Do not install this product in a place where it will impair the performance of
any of the vehicle’s operating systems, including airbags and headrests.
To guard against electromagnetic interference
•In order to prevent interference, set the following items as far as possible from this prod-
uct, other cables or leads:
- TV antenna and antenna lead
- FM, AM antenna and its lead
- GPS antenna and its lead
In addition you should lay or route each antenna lead as far as possible from other antenna
leads.
Do not bind them together, lay or route them together, or cross them.
Such electromagnetic noise will increase the potential for errors in the location display.
Before installing
•Consult with your nearest dealer if installation requires the drilling of holes or other mod-
ifications of the vehicle.
•Before making a final installation of this product, temporarily connect the wiring to con-
firm that the connections are correct and the system works properly.
•Do not install this product in a position where the opening of the LCD panel is obstruct-
ed by any obstacles, such as the shift lever. Before installing this product, be sure to
leave sufficient space so that the LCD panel does not obstruct the shift lever when it is
fully opened. This may cause interference with the shift lever, or a malfunction of the
mechanism of this product.
18
ENG/MASTER 96
English Español Deutsch Français Italiano Nederlands
<CRD4067A/U> 19
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 19

19
Installation
Installing this product
Installation notes
•Do not install this product in places where it may become subject to high temperatures
or humidity, such as:
* places close to a heater, vent or air conditioner.
* places exposed to direct sunlight, such as on top of the dashboard.
* places that may be splashed by rain, for example close to the door.
•Install this product in an area strong enough to bear its weight. Choose a position where
this product can be firmly installed, and install it securely.
If this product is not securely installed, the current location of the vehicle cannot be dis-
played correctly.
•Install this product horizontally on a surface within 0 degrees to 30 degrees tolerance. If
the installation angles on the left and right sides exceed 5 degrees, the allowable range
can be increased to 10 degrees by making corrective adjustments. (Refer to “Correcting
the installation angle”in the Operation Manual.) If connection of the pink lead (CAR
SPEED SIGNAL INPUT) is omitted, the angles on the left and right sides are allowable
to within five degrees. Improper installation of the unit with the surface tilted more than
these tolerances increases the potential for errors in the location display, and might oth-
erwise cause reduced display performance.
•The cords must not cover up the area shown in the figure below. This is necessary to
allow the amplifiers and navigation mechanism to heat dissipate freely.
•The semiconductor laser will be damaged if it overheats, so don’t install this product
anywhere hot —for instance, near a heater outlet.
Do not cover this area.
If the angle exceeds five degrees,
please make corrective adjustments.
ENG/MASTER 96
<CRD4067A/U> 20
CRD4067A_U_inst_001_027_US 10/24/05 19:49 Page 20
