Pioneer CT-F10 Building instructions
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2000
c
Component Model Service manual Remarks
STEREO CD TUNER XC-F10 RRV2319
STEREO POWER AMPLIFIER M-F10 RRV2321
SPEAKER SYSTEM S-F10-LRW RRV2330
STEREO CASSETTE DECK CT-F10 RRV2308 This manual.
Type Model Power Requirement
CT-F10
ZVYXJ DC power supplied from other system component
CT-F10
RRV2308
1. SAFETY INFORMATION ...................................... 2
2. EXPLODED VIEWS AND PARTS LIST................ 3
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM .... 8
4. PCB CONNECTION DIAGRAM.......................... 14
5. PCB PARTS LIST ............................................... 18
6. ADJUSTMENT .................................................... 20
CONTENTS 7. GENERAL INFORMATION ................................ 25
7.1 DIAGNOSIS................................................. 25
7.1.1 DISASSEMBLY ...................................... 25
7.1.2 POWER ON SEQUENCE ...................... 26
7.2 PARTS ......................................................... 27
7.2.1 IC ............................................................ 27
8. PANEL FACILITIES AND SPECIFICATIONS .... 28
T–ZZR JUNE 2000 Printed in Japan
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
STEREO CASSETTE DECK
Remarks
÷This products are component of systems. This product does not operate normally by
itself. Please connect it to the STEREO CD TUNER XC-F10 and the STEREO POWER
AMPLIFIER M-F10 for adjustment and operation inspection.
¶This product is a system(s) component.
Be sure to connect it to the prescribed system component(s), otherwise damage may
result.
