Piper Malibu Meridian PA-46-500TP User manual

PART NUMBER 767-005 April 15, 2007
1A1
AIRPLANE MAINTENANCE MANUAL
CARD 1 OF 9
PA-46-500TP
(S/N’s 4697001 and UP)
PIPER AIRCRAFT, INC.

1A2
Published by
Technical Publications
© Piper Aircraft, Inc.
2926 Piper Drive
Vero Beach, Florida 32960
U.S.A.
Member
General Aviation
Manufacturers Association

PAGE 1
Apr 15/07
AEROFICHE EFFECTIVITY
1A3
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL
AEROFICHE REVISION STATUS
Revisions to this Maintenance Manual 767-005 issued July 01, 2000 are as follows:
Revision Publication Date Aerofiche Card Effectivity
ORG000701 July 1, 2000 All
PR010219 February 19, 2001 1
PR010515 May 15, 2001 1
PR011201 December 1, 2001 1, 3, & 4
PR030306 March 6, 2003 1, 2, 3, 4, 5, 6, & 7
PR040109 January 9, 2004 1, 2, 3, 5, 6, & 7
PR041231 December 31, 2004 1, 2, 3, 4, 5, 6, & 7
CR061130 November 30, 2006 1, 2, 3, 4, 5, 6, 7, 8, & 9
CR070415* April 15, 2007 1, 2, 3, 4, 5, 6, 7, 8, & 9
* COMPLETE REVISION OF MAINTENANCE MANUAL 767-005
Revisions appear in all nine Aerofiche Cards. Accordingly, discard your
entire existing aerofiche card set and replace it with this set dated
04/15/07.
Consult the Customer Service Information Aerofiche (P/N 1753-755) for current revision dates for this
manual.

PAGE 2
Apr 15/07 AEROFICHE EFFECTIVITY 1A4
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL
THIS PAGE INTENTIONALLY BLANK

PAGE 1
Apr 15/07
INTRO - LIST OF EFFECTIVE PAGES
1A5
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL
INTRODUCTION
LIST OF EFFECTIVE PAGES
CHAPTER
SECTION PAGE DATE
Intro-List of 1 Apr 15/07
Effective Pages 2 Apr 15/07
Intro-Table of Contents 1 Apr 15/07
2 Apr 15/07
Introduction 1 Apr 15/07
2 Apr 15/07
3 Apr 15/07
4 Apr 15/07
5 Apr 15/07
6 Apr 15/07
7 Apr 15/07
8 Apr 15/07
9 Apr 15/07
10 Apr 15/07
11 Apr 15/07
12 Apr 15/07
13 Apr 15/07
14 Apr 15/07
15 Apr 15/07
16 Apr 15/07
Index 1 Apr 15/07
2 Apr 15/07
3 Apr 15/07
4 Apr 15/07
5 Apr 15/07
6 Apr 15/07
7 Apr 15/07
8 Apr 15/07
9 Apr 15/07
10 Apr 15/07
11 Apr 15/07
12 Apr 15/07
CHAPTER
SECTION PAGE DATE

PAGE 2
Apr 15/07 INTRO - LIST OF EFFECTIVE PAGES
THIS PAGE INTENTIONALLY BLANK
1A6
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL

PAGE 1
Apr 15/07
1A7 INTRO - CONTENTS
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL
TABLE OF CONTENTS
SUBJECT SECTION PAGE GRID NO.
INTRODUCTION
Instructions for Continued Airworthiness 1 1A9
General 1 1A9
Effectivity 2 1A10
Serial Number Explanation 2 1A10
Assignment of Subject Material 2 1A10
Pagination 2 1A10
Aerofiche Effectivity 3 1A11
Identifying Revised Material 3 1A11
Indexing 3 1A11
List of Effective Pages 3 1A11
Warnings, Cautions, and Notes 3 1A11
Accident/Incident Reporting 3 1A11
Supplementary Publications 4 1A12
PIPER Publications 4 1A12
Vendor Publications 4 1A12
Chapter/Section Index Guide 11 1A19
INDEX
Index 1 1B1

PAGE 2
Apr 15/07 1A8
INTRO - CONTENTS
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL
THIS PAGE INTENTIONALLY BLANK

PAGE 1
Apr 15/07
INTRODUCTION
1A9
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL
INTRODUCTION
1. Instructions for Continued Airworthiness
WARNING: INSTRUCTIONS FOR CONTINUED AIRWORTHINESS (ICA) FOR ALL NON-PIPER
APPROVED STC INSTALLATIONS ARE NOT INCLUDED IN THIS MANUAL. WHEN A
NON-PIPER APPROVED STC INSTALLATION IS INCORPORATED ON THE AIRPLANE,
THOSE PORTIONS OF THE AIRPLANE AFFECTED BY THE INSTALLATION MUST BE
INSPECTED IN ACCORDANCE WITH THE ICA PUBLISHED BY THE OWNER OF THE
STC. SINCE NON-PIPER APPROVED STC INSTALLATIONS MAY CHANGE SYSTEMS
INTERFACE, OPERATING CHARACTERISTICS AND COMPONENT LOADS OR
STRESSES ON ADJACENT STRUCTURES, THE PIPER PROVIDED ICA MAY NOT BE
VALID FOR AIRPLANES SO MODIFIED.
The PIPER PA-46-500TP Malibu Meridian Maintenance Manual constitutes the Instructions for
Continued Airworthiness as required by Federal Aviation Regulations (FAR) Part 23, Appendix G.
Chapter 4 contains the Airworthiness Limitations section (4-00-00) and the Inspection Program is in
Chapter 5 (5-20-00).
2. General
This publication is prepared in accordance with the General Aviation Manufacturers Association (GAMA)
Specification No. 2, with respect to the arrangement and content of the System/Chapters within the
designated Chapter/Section-numbering system.
WARNING: USE ONLY GENUINE PIPER AIRCRAFT PARTS OR PIPER AIRCRAFT APPROVED
PARTS OBTAINED FROM PIPER APPROVED SOURCES, IN CONNECTION WITH THE
MAINTENANCE AND REPAIR OF PIPER AIRPLANES.
Genuine PIPER parts are produced and inspected under rigorous procedures to insure airworthiness
and suitability for use in PIPER airplane applications. Parts purchased from sources other than PIPER,
even though identical in appearance, may not have had the required tests and inspections performed,
may be different in fabrication techniques and materials, and may be dangerous when installed in an
airplane.
Additionally, reworked or salvaged parts or those parts obtained from non-PIPER approved sources,
may have service histories which are unknown or cannot be authenticated, may have been subjected to
unacceptable stresses or temperatures or may have other hidden damage not discernible through
routine visual or nondestructive testing. This may render the part, component or structural assembly,
even though originally manufactured by PIPER, unsuitable and unsafe for airplane use.
PIPER AIRCRAFT, INC. expressly disclaims any responsibility for malfunctions, failures, damage or
injury caused by use of non-PIPER approved parts.
NOTE: PIPER AIRCRAFT, INC. expressly reserves the right to supersede, cancel and/or declare
obsolete any part, part numbers, kits or publication that may be referenced in this manual
without prior notice.
Any question concerning the care of your airplane, be sure to include the airplane serial number in any
correspondence.

3. Effectivity
This maintenance manual is effective for PA-46-500TP Malibu Meridian airplane serial numbers
4697001 and up. This encompasses the following model years:
NOTE: The following information is provided as a general reference only.
Model Year Serial Numbers Model Year Serial Numbers
4. Serial Number Explanation
Example:
5. Assignment of Subject Material
This publication is divided into industry standard, three element, numeric subject groupings as follows:
A. System/Chapter - The various groups are broken down into major systems such as Environmental
Systems, Electrical Power, Landing Gear, etc. They are assigned a number, which becomes the first
element of the standardized numbering system. Thus, the element “28” of the number 28-40-01
refers to the chapter “Fuel”. Everything concerning the fuel system will be covered in this chapter.
B. Sub-System/Section - The major systems/chapters of an airplane are broken down into
subsystems. These sub-systems are identified by the second element of the standard numbering
system. The element “40” of the number 28-40-01 concerns itself with the indicating section of the
fuel system.
C. Unit/Subject - The individual units within a sub-system/section may be identified by the third
element of the standard numbering system. The element “01” of the number 28-40-01 is a subject
designator. This element is assigned at the option of the manufacturer and is normally zeroed out by
PIPER.
Refer to paragraph 14, Chapter/Section Index Guide, for a complete breakdown and list. The material is
arranged in ascending numerical sequence.
6. Pagination
The Chapter - Section (i.e. - 28-40-00) numbering system (explained above) forms the primary page
numbering system for this manual. Within each Section, pages are numbered consecutively beginning
with Page 1 (i.e. - 28-40-00, Page 1). Additionally, the aerofiche grid numbering system (explained
below) is also used to indicate location within the manual.
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL
PAGE 2
Apr 15/07 INTRODUCTION 1A10
2000 4697001 thru 4697037
2001 4697038 thru 4697119, and
4697121, 4697123, & 4697125
2002 4697120, 4697122, 4697124,
and 4697126 thru 4697141,
and 4697143, and
4697145 thru 4697147
2003 4697142, 4697144, and
4697148 thru 4697173
2004 4697174 thru 4697197
2005 4697198 thru 4697215
2006 4697216 thru 4697282
2007 4697283 and up
46 97 001
TYPE CERTIFICATE DESIGNATION
MODEL CODE
97 = PA-46-500TP MALIBU MERIDIAN
SEQUENCE NUMBER

PAGE 3
Apr 15/07
INTRODUCTION
1A11
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL
7. Aerofiche Effectivity
A. The General Aviation Manufacturers Association (GAMA) have developed specifications for
microfiche reproduction of aircraft publications. The information compiled in this Aerofiche
Maintenance Manual will be kept current by revisions distributed periodically. These revisions will
supersede all previous revisions and will be complete Aerofiche card replacements and shall
supersede Aerofiche cards of the same number in the set. The “Aerofiche Effectivity” page at the
front of this manual lists the current revision for each card in this set.
B. Conversion of Aerofiche alpha/numeric grid code numbers:
First number is the Aerofiche card number.
Letter is the horizontal row reference per card
Second number is the vertical column reference per card.
Example: 2J16 = Aerofiche card number two, row J, column 16.
C. To aid in locating information, the following is provided at the beginning of each aerofiche card:
(1) A complete Introduction containing the Chapter/Section Index Guide for all fiche in this set.
(2) A complete subject Index for all fiche in this set.
8. Identifying Revised Material
A revision to a page is defined as any change to the printed matter that existed previously.
Revisions, additions and deletions are identified by a vertical line (i. e. - change bar) along the left-
hand margin of the page opposite only that portion of the printed matter that was changed.
A change bar in the left-hand margin opposite the footer (i.e. - chapter/section/subject, page
number and date), indicates that the text was unchanged but the material was relocated to a
different page.
Example.
NOTE: Change bars are not used in the title pages, list of effective pages, or index.
9. Indexing
An alphabetically arranged subject Index follows this introduction to assist the user in locating desired
information. In addition, each System/Chapter begins with an individual Table of Contents.
10. List of Effective Pages
Each System/Chapter has a List of Effective Pages preceding the Table of Contents to identify the
effective revision date for each page in that chapter.
11. Warnings, Cautions and Notes
These adjuncts to the text are used to highlight or emphasize important points when necessary.
WARNINGS call attention to use of materials, processes, methods, procedures or limits which must be
followed precisely to avoid injury or death to persons. CAUTIONS call attention to methods and
procedures which must be followed to avoid damage to equipment. NOTES call attention to methods
which make the job easier. Warnings and Cautions shall be located directly above and Notes directly
beneath the text and be in line with the paragraphs to which they apply.
12. Accident/Incident Reporting
To improve our Service and Reliability system and aid in Piper’s compliance with FAR 21.3, knowledge
of all incidents and/or accidents must be reported to Piper immediately. To expedite and assist in
reporting all incidents and accidents, Piper Form 420-01 has been created. See Service Letter 1041 for
latest revision. This procedure is to be used by all Dealers, Service Centers and Repair Facilities.

13. Supplementary Publications
The following publications/sources provide servicing, overhaul and parts information for the
PA-46-500TP airplane and its various components. Use them to supplement this manual.
A. Piper Publications:
(1) Parts Catalog - P/N 767-004
(2) Progressive Inspection Manual (100 hour) - P/N 767-009
B. Vendor Publications:
WARNING: FAILURE TO CONSULT APPLICABLE VENDOR PUBLICATION(S), WHEN
SERVICING OR INSPECTING VENDOR EQUIPMENT INSTALLED IN PIPER
AIRCRAFT, MAY RENDER THE AIRCRAFT UNAIRWORTHY.
(1) AIR CONDITIONING COMPRESSOR:
Vendor: Sanden International (USA), Inc. PH: - [phone]
601 South Sanden Blvd. FAX: - [phone]
Wylie, Texas 75098
http://www.sanden.com/
(2) AIR CONDITIONING EVAPORATORS AND BLOWERS:
Vendor: Enviro Systems, Inc. PH: - [phone]
P.O. Box 1404
Seminole, Oklahoma 74868
(3) ALTERNATOR:
Vendor: Electro Systems, Inc. PH: - [phone]
Airport Complex
P. O. Box 273
Fort Deposit, Alabama 36032
http://www.kellyaerospace.com/index.htm/
(4) ALTERNATOR CONTROL UNIT:
Vendor: Lamar
(See Generator Control Unit)
(5) AUTOPILOT:
Vendor: S-TEC Corporation PH: - [phone]
One S-TEC Way
Mineral Wells, Texas 76067-9236
http://www.s-tec.com
Instructions for
Continued Airworthiness: S-TEC System 550 Flight Director/Autopilot with Trim,
Yaw Damper and Altitude Selector Alerter - Part No. 81532P
Instructions for
Continued Airworthiness: Meggitt Avionics / S-TEC MAGIC 1500 Flight Director/Autopilot
- Part No. 81640P
PAGE 4
Apr 15/07 INTRODUCTION 1A12
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL

PAGE 5
Apr 15/07
INTRODUCTION
1A13
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL
(6) BATTERIES:
(a) AIRCRAFT MAIN:
Vendor: Concorde Battery Corp. PH: - [phone]
2009 San Bernardino Road
West Covina, CA 91790
http://www.concordebattery.com
Maintenance Manual
Supplement: Manual M1 - Supplement for Concorde Valve Regulated
Lead-Acid Main Battery
(b) STANDBY ATTITUDE INDICATOR EMERGENCY POWER SUPPLY:
Vendor: BFGoodrich Avionics Systems, Inc. PH: - [phone]
5353 52nd Street, SE
P.O. Box 873
Grand Rapids, MI 49588-0873
http://www.bfgavionics.com/
Service Letter: SL-120A, or latest revision,
PS-834 Battery Charging and Capacity Testing.
(7) BRAKES AND WHEELS:
Vendor: Parker Hannifin Corp PH: - [phone]
Aircraft Wheel and Brake Division
1160 Center Road
Avon, Ohio 44011
http://www.parker.com/cleveland/Universe/book.pdf
(8) DEICER SYSTEM:
Vendor: BFGoodrich Aerospace PH: - [phone]
De-Icing and Specialty Systems FAX: - [phone]
1555 Corporate Woods Parkway
Uniontown, Ohio 44685-8799
http://www.bfg-ips.com/
(9) ELECTRONIC FLIGHT INSTRUMENT SYSTEM (EFIS):
Vendor: Meggitt Avionics, Inc. PH: - [phone]
10 Ammon Drive FAX: - [phone]
Manchester, NH 03103-7406
http://www.meggittavi.com/
or Avidyne Corporation PH - [phone]
55 Old Bedford Road
Lincoln, MA 01773
http://www.avidyne.com/index.htm
Instructions for Continued Airworthiness (Avidyne):
Primary Flight Display
and Magnetometer/OAT: Document No. AVPFD-174
Multifunction Display: Document No. AVMFD-167

(10) EMERGENCY LOCATOR TRANSMITTER:
Vendor: Artex Airccraft Supplies PH: - [phone]
14405 Keil Road NE
Aurora, Oregon 97002
http://www.artex.net/
(11) ENGINE:
Vendor: Pratt & Whitney Canada, Inc. PH: US/CAN - [phone]
1000 Maire-Victorian Blvd. INTL - [phone]
Longueuil, Quebec
Canada J4G 1A1
http://www.pwc.ca/www/en_pwc/index2.asp
Maintenance Manual: Pratt & Whitney Turboprop Gas Turbine Engine
- Maintenance Manual (PT6A-38/-40-/41/-42/-42A)
P/N 3021442
(12) ENGINE FIRE WARNING SYSTEM:
Vendor: Meggitt
(See Electronic Flight Instrument System)
(13) ENGINE INSTRUMENT DISPLAY SYSTEM (EIDS):
Vendor: Meggitt
(See Electronic Flight Instrument System)
(14) ENVIRONMENTAL CONTROL SYSTEM (ECS):
Vendor: Enviro Systems, Inc.
(See Air Conditioning Evaporators and Blowers)
(15) FIRE EXTINGUISHER (PORTABLE):
Vendor: H3R Inc. PH: - [phone]
43 Magnolia Ave # 4
San Francisco, California 94123-2911
http://www.h3r.com/index.htm
(16) FORCE APPLICATOR KIT:
Vendor: Safe Flight Instrument Corp. PH: - [phone]
20 New King Street
White Plains, New York 10602
(17) FUEL BOOST PUMP:
Vendor: Parker Hannifin Corp. PH: - [phone]
Airborne Division
711 Taylor Street
Elyria, Ohio 44035
http://www.parker.com/cleveland/Universe/book.pdf
(18) FUEL FILTER ASSEMBLY:
Vendor: Pall Aeropower Corp. PH: - [phone]
5775 Rio Vista Drive
Clearwater, Florida 33760-3114
http://www.pall.com
PAGE 6
Apr 15/07 INTRODUCTION 1A14
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL

PAGE 7
Apr 15/07
INTRODUCTION
1A15
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL
(19) GENERATOR CONTROL UNIT:
Vendor: Lamar Technologies Corp. PH: - [phone]
14900 - 40th Ave. N.E.
Marysville, WA 98271
http://www.lamartech.com/
(20) GROUND BLOWER:
Vendor: Electro-Mech Inc.
2600 S. Custer
Wichita, Kansas
(21) GEAR LOCKING ACTUATORS, NOSE GEAR DOOR ACTUATOR, HYDRAULIC PUMP,
AND ALL HYDRAULIC COMPONENTS:
Vendor: Frisby Aerospace PH: - [phone]
4520 Hampton Rd. FAX: - [phone]
Clemmons, NC 27012
http://frisbyaerospace.com/
(22) HI-LOK FASTENERS AND TOOLS:
Vendor: Hi-Shear Corporation PH: - [phone]
2600 Skypark Drive
Torrance, California 90509
(23) LIGHTS - NAVIGATION, STROBE, AND STANDBY/MAP LIGHTS:
Vendor: Whelen Engineering Co. Inc. PH: - [phone]
Route 145, Winthrop Rd. FAX - [phone]
Chester, Connecticut 06412
http://www.whelen.com/
(24) NAVIGATION, COMMUNICATIONS, AND GPS (NAV/COM/GPS):
Vendor: Gamin International PH: - [phone]
1200 East 151ST Street
Olathe, KS 66062
http://www.Gamin.com
(25) OXYGEN SYSTEM:
Vendor: Scott Aviation PH - [phone]
2225 Erie Street
Lancaster, New York 14086
http://www.scottaviation.com/
Maintenance Manual: Operating and Maintenance Instructions,
EROS, Quick Donning Mask-Regulator MC-10-[ ]-[ ] Series,
P/N 4NUT0045A
(26) PRESSURIZATION SAFETY AND OUTFLOW VALVE, CONTROLLER VALVE:
Vendor: AlliedSignal Aerospace PH - [phone]
Aerospace Equipment Systems FAX: - [phone]
2525 W. 190th Street
Torrance, CA 90504
http://www.alliedsignalaerospace.com/aerospace/

PAGE 8
Apr 15/07 INTRODUCTION 1A16
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL
(27) PROPELLER:
Vendor: Hartzell Propeller Inc. PH - [phone]
One Propeller Place FAX - [phone]
Piqua, OH 45356-2634
http://www.hartzellprop.com/index2.htm
Overhaul Instructions: Manual No. 143
Aluminum Blade
Inspection, Repair,
and Overhaul Instructions: Manual No. 133
Propeller Owner’s
Manual and Logbook: Manual No. 149
(28) PROPELLER GOVERNOR AND PROPELLER OVERSPEED GOVERNOR (I.E. - HTG):
Vendor: Woodward Governor Company PH - [phone]
Aircraft Engine Systems
Attn: Supervisor, Product Support
One Woodward Way
P.O. Box 405
Rockton, Illinois 61072-0405
http://www.woodward.com/AES/
Overhaul Instructions: Manual No. 61-20-15 (60045)
(29) WEATHER RADAR, RDR - 2000:
Vendor: Honeywell
One Technology Center
23500 W. 105th Street, M/D #45
Olathe, KS 66061-1950
http://www.bendixking.com
Maintenance Manual: Bendix/King ART 2000
P/N 006-05332-0001
Installation and
Maintenance Manual
with Instructions for Bendix/King KMD 850 MFD
Continued Airworthiness P/N 006-20000-0000
(30) RADIO COOLING BLOWER:
Vendor: Troll Avionics, Inc. PH - [phone]
4200 Encino Lane
Ventura, CA 93001
(31) STARTER/GENERATOR:
Vendor: Aircraft Parts Corp. PH - [phone]
100 Corporate Drive
Holtsville, NY 11742
http://www.apcmfg.com
(32) VACUUM REGULATOR:
Vendor: Parker Hannifin Corp.
(See Fuel Boost Pump)

PAGE 9
Apr 15/07
INTRODUCTION
1A17
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL
THIS PAGE INTENTIONALLY BLANK

PAGE 10
Apr 15/07 INTRODUCTION 1A18
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL
THIS PAGE INTENTIONALLY BLANK

INTRODUCTION
1A19
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL
PAGE 11
Apr 15/07
14. Chapter/Section Index Guide
NOTE: The following GAMA Specification No. 2 standard chapters are not included in this Maintenance
Manual: 36, 38, 49, 53, 54, 60, 73, 78, 80, 81, 83, and 95. These chapters are omitted because
the subject system is either: not installed in these airplanes; adequately covered in vendor or
other manuals; or, for ease of use, has been combined with another chapter.
CHAPTER SECTION TITLE GRID NO.
4 AIRWORTHINESS LIMITATIONS 1C1
00 Airworthiness Limitations
5 TIME LIMITS/MAINTENANCE CHECKS 1C9
00 General
10 Time Limits
20 Scheduled Maintenance Checks
30 Special Inspections
50 Unscheduled Maintenance Checks
6 DIMENSIONS AND AREAS 1F15
00 General
7 LIFTING AND SHORING 1G9
10 Jacking
8 LEVELING AND WEIGHING 1G17
10 Weighing
20 Leveling
9 TOWING AND TAXIING 1H5
00 General
10 Towing
20 Taxiing
10 PARKING AND MOORING 1H17
10 Parking
20 Mooring
11 PLACARDS AND MARKINGS 1I5
20 Exterior Placards and Markings
30 Interior Placards and Markings
12 SERVICING 1K1
00 General
10 Replenishing
20 Scheduled Servicing

INTRODUCTION 1A20
PIPER AIRCRAFT, INC.
PA-46-500TP, MALIBU MERIDIAN
MAINTENANCE MANUAL
PAGE 12
Apr 15/07
CHAPTER SECTION TITLE GRID NO.
20 STANDARD PRACTICES - AIRFRAME 2C1
00 General
21 ENVIRONMENTAL SYSTEMS 2D1
00 General
20 Distribution
30 Pressurization Control
40 Heating
50 Cooling
60 Temperature Control
22 AUTOFLIGHT 2G15
10 Autopilot
23 COMMUNICATIONS 2I1
00 General
50 Audio Integrating
60 Static Discharging
24 ELECTRICAL POWER 2IJ1
00 General
30 DC Generation
40 External Power
50 Electrical Load Distribution
25 EQUIPMENT/FURNISHINGS 3C1
10 Flight Compartment
20 Passenger Compartment
50 Cargo Compartments
60 Emergency
26 FIRE PROTECTION 3D1
10 Detecting
20 Extinguishing
27 FLIGHT CONTROLS 3D15
00 General
10 Aileron and Tab
20 Rudder and Tab
30 Elevator and Tab
50 Flaps
