Planet NMC-360V-12 User manual

Renewable Energy Management Controller
with LCD Touch Screen
NMS-360V
Quick Installation Guide

Table of Contents
1. Package Contents ....................................................................................... 3
2. Hardware Description .................................................................................. 4
 2.1 PhysicalSpecications.......................................................................... 5
2.2 Product Features ................................................................................. 7
 2.3 Specications ...................................................................................... 8
3. Deployed Devices Monitored via NMS-360V Controller ...................................... 10
4. WiredNetworkConguration ......................................................................12
5. Entering into the Web Management.............................................................13
6. Setup Wizard ............................................................................................14
Further Information ........................................................................................16

3
1. Package Contents
Thank you for purchasing PLANET Universal Network Management Controller.
PLANET NMS-360V comes in two sizes as described below:
NMS-360V-12 Renewable Energy Management Controller with 12" LCD Touch
Screen
NMS-360V-10 Renewable Energy Management Controller with 10" LCD Touch
Screen
Package Contents:
zThe NMS-360V Controller x 1
zQuick Installation Guide x 1
zAdapter with Power Cord x 1
zInstallation Kit x 1
If any item is found missing or damaged, contact your local reseller for
replacement.

4
2. Hardware Description
LAN Port
USB PortAudio Line Out
HDMI
COM 1 COM 2
SW
+
-
9-36V DC IN
Power Indicator

5
2.1 PhysicalSpecications
Model NMS-360V-10 NMS-360V-12
Dimensions (W x D x H) 285 x 49 x 189 mm 319 x 51.7 x 245 mm
Weight 2 kg 2.9 kg
NMS-360V-10 (10” Panel)
NMS-360V-12 (12” Panel)

6
VESA Mounting
The NMS-360V series is designed to be VESA-mounted as shown in the picture.
Just carefully place the LCD stand on the back of the controller and tighten the
given screws to secure the mounting.
Panel Mounting
There are eight holes located along the four sides of the NMS-360V. Insert the
clamp from the four sides and tighten them with the nuts provided.

7
2.2 Product Features
Network Devices Management
Dashboard Providingtheat-a-glanceviewofsystem,power,trac,
and device event statuses.
Device List Providing devices status overview and managed function.
Setup Wizard Easy to use step-by-step guidance.
Node Discovery Management is carried out once a BSP-360-powered device
is detected.
App-like Device
Viewing
App-like devices that are compliant with SNMP, MQTT, and
Smart Discovery.
Event Table The status of system can be reported via event alarm.
Alarm System E-mail alerts for the administrator via the SMTP server.
Device Provisioning EnablingBSP-360tobeconguredandupgradedatthe
same time.
Site Map Real-time site map of BSP-360 and IP cams on the user-
denedmaptooptimizeenergydeployment.
Remote PoE control Real-timeremotePoEon/otorebootconnected devices.
User Control Allowingon-demandaccountcreationanduser-dened
access policy.
Scalability FreesystemupgradeandBSP-360rmwarebulkupgrade
capability.
Maximum Scalability 1 site map, 512 nodes, 2048 managed IP cameras.
Network Management Characteristics
zBuilt-in DHCP Server
zBuilt-in RADIUS Server
zSSL secure access
zWeb-based GUI management interface
zSNMP v1, v2c, and v3 management
zSupports PLANET DDNS/Easy DDNS

8
2.3 Specications
Product
NMS-360V-10 NMS-360V-12
Renewable Energy Management Controller with LCD
Touch Screen
Platform
Form Factor Panel Mount, VESA 100 x 100
PhysicalSpecications
I/O Interface
2 10/100/1000BASE-T Gigabit Ethernet RJ45 ports
2 USB 3.0 ports
(They cannot be used at the same time.)
1 Audio Line Out (reserved)
1 HDMI interface
2 DB-9 COM1,COM2 (reserved)
1 3-pin DC power input terminal
12-pinconnectorforpoweron/obutton(reserved)
Storage 2.5” 32G SATA3 HDD
Touch LCD Size 10.1” TFT-LCD 12.1” TFT-LCD
Touch Type Resistive Touch Window Projected Capacitive Touch
Display Resolution 1280 x 800 1024 x 768
Display Luminance (cd/m²) 350 500
Display Viewing Angle
(H°/V°) 160(H) / 160(V) 160(H) / 140(V)
Display Contrast 800:1 700:1
Display Backlight Lifetime
(hrs) 40,000 hrs 30,000 hrs
Light Transmission (%) Resistive Touch Window: over 80%
Projected Capacitive Touch: over 90%
Enclosure Aluminum Die-casting Chassis
Power Requirements
DC IN 9~36V
60W adapter 12V 5A with terminal block
AC 100~240V, 2.0A, 60~50Hz.
Environment&Certication
IP Rating IP66-rated front bezel
Temperature Operating: 0 ~ 50 degrees C
Storage: -30 ~ 70 degrees C
Humidity 10 ~ 90% relative humidity (non-condensing)
MTBF (Hours) 100,000
Network Management
Number of Managed Devices 512 BSP-360 units

9
Auto Discovery Supports PLANET BSP-360
Dashboard Providing the at-a-glance view of system, power,
trac,systemstatisticsanddeviceeventstatuses
Device List Providing devices status overview and managed
function
Setup Wizard Easy-to-use step-by-step guidance
Node Discovery Management is carried out once a BSP-360-powered
device is detected
App-like Device Viewing App-like devices that are compliant with SNMP,
MQTT, and Smart Discovery
Event Table The status of system can be reported via event
alarm
Alarm System E-mail alerts for the administrator via the SMTP
server
Device Provisioning EnablingBSP-360tobeconguredandupgradedat
the same time
Site Map Real-time site map of BSP-360 and IP cams on the
user-denedmaptooptimizeenergydeployment
Remote PoE control Real-timeremotePoEon/otorebootconnected
devices
User Control Allowing on-demand account creation and user-
denedaccesspolicy
Scalability FreesystemupgradeandBSP-360rmwarebulk
upgrade capability
Backup/Restoration Providessystemandprolebackup/restoration
Network Services
Network
DDNS Supports PLANET DDNS/Easy DDNS
DHCP Built-in DHCP Server for auto IP assignment to APs
Management Console; Telnet; SSL;Web browser (Chrome is
recommended); SNMP v1, v2c, v3
Discovery Supports SNMP, ONVIF and PLANET Smart Discovery
Maintenance
Backup System backup and restore to local or USB HDD
Reboot Provides system reboot manually or automatically
per power schedule
Diagnostic Provides IPv4/IPv6 ping and trace route
Standards Conformance
Regulatory Compliance CE, FCC
Standards Compliance
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab Gigabit 1000BASE-T
[Remarks] Only support BSP-360 V2 version.

10
3. Deployed Devices Monitored via NMS-360V Controller
Prior installation
The NMS-360V is used to centrally manage a large number of BSP-360s(V2).
Therefore,youneed toupgradethe BSP-360(V2)rmwarebeforeusingNMS-360V.
Please download and use the latest BSP-360(V2) rmware from the website so
that setting can be completed smoothly.
The NMS-360V incorporated in a workstation or PC can monitor the BSP-360s
compliant with the MQTT Protocol, SNMP Protocol, ONVIF Protocol and
PLANET Smart Discovery utility.
Follow the steps below to set up the NMS-360V and BSP-360(V2) accordingly.
Step 1. Connect the devices, NMS-360V Controller and your computer, to the
same network.
PC / Workstation with
Web Browser 192.168.1.x
192.168.1.x
Managed AP
IP Camera
192.168.1.x
PoE
PoE
NMS-360V
Default IP: 192.168.1.100
BSP-360
192.168.1.x
Step 2. BSP-360: Log in to the Switch’s Web User Interface and enable the
SNMP and NMS controller functions.



11



12
4.WiredNetworkConguration
Acomputerwithwired Ethernetconnectionis requiredfortherst-timeconguration
of the NMS-360V Controller.
PC / Workstation with
Web Browser 192.168.1.x
RJ45/UTP Cable
NMS-360V
IP Address: 192.168.1.100
1. Go to “Control Panel-> Network and Sharing Center-> Change Adapter
Settings”.
2. Double-click “Local Area Connection”.
3. Select “Internet Protocol version 4 (TCP/IPv4)” and click “Properties”.
4. Select “Use the following IP address” and then click the “OK” button twice
to save the conguration. For example, the default IP address of the NMS-
360V Controller is 192.168.1.100, then the manager PC should be set to
192.168.1.x (where x is a number between 1 and 254, except 100), and the
default subnet mask is 255.255.255.0.

13
5. Entering into the Web Management
Default IP Address: 192.168.1.100
Default Management Port: 8888
Default Username: admin
Default Password: admin
Launch the Web browser (Google Chrome with seamless mode is recommended.)
and enter the default IP address “https://192.168.1.100:8888”. Then, enter the
default username and password shown above to log on to the system.
*The secure login with SSL (HTTPS) prex is required.
After logging on, connect the NMS-360V Controller to the managed network to
centrally control PLANET managed devices.

14
6.SetupWizard
1. Account Modication: Set a new account and password for security.
2. IP Conguration Setting: Set the NMS-360V’s IP into the same local network
segment.

15
3. Devices Discovery: Search the managed devices and add to list. (Finish Wizard)
4. If added devices are successful, you can see them in Device List /
Management page.

FurtherInformation
The above steps introduce the simple installations and congurations of the NMS-
360VController.Forfurther congurations ofPLANETNMS, please refer totheuser
manual, which can be downloaded from the website.
PLANET online FAQs:
http://www.planet.com.tw/en/support/faq
Support team mail address:
[email protected]
User’s Manual:
https://www.planet.com.tw/en/support/downloads?&method=keyword&keyword=N
MS-360V&view=3#list
If you have further questions, please contact the local dealer or distributor where
you purchased this product.
