Planet WPG-100 User manual

Wireless Presentation Gateway
WPG-100
Quick Installation Guide Version 1.0
Thanks for your purchase our wireless presentation gateway. WPG-100 is
an easy installation, convenient operation and user friendly projecting
device. It turns your current Projector into a high-end Projector. With the
WPG-100 your Projector become a wireless device and PC/Notebooks
will be easier to project screen to Projector.Package Content
1 x WPG-100
1 x CD Disk (User’s Guide included)
5V DC Power adapter
Quick Installation Guide
Wall mount kit
Quick Start
1) Connect projector VGA cable to WPG-100 box VGA connector and turn
on projector power.
2) Turn on WPG-100.
• When Projector shows the default menu on the screen as below, it
indicates the WPG-100 is ready now.
3) Make sure your PC LAN port or WLAN interface is enabled already, and
connect your PC with WPG-100 (wireless default SSID is WPG-100).
4) Open your browser and enter the WPG-100 IP address to get in
WPG-100 web home page.
• The default IP address of WPG-100 is 192.168.1.10. If you have modified
the IP address, you can refer to the IP address shown on the left-down
corner of projector screen.
5) Please select “Download” option and press “Login” button. The Password is
empty.

2011-E60010-000
6) You will see a file download dialog box appear, press “Run” to execute
the installation program.
7) After install the program, WPG-100 shortcut will come out on the
desktop.
8) If there is any firewall, please make sure your personal firewall has allow
WPG-100 software to pass through.
9) Enter the LOGIN CODE and press “OK”.
• You can see the login code on the projector screen
10) Click the “Play” button to start projection!
