Planet VCG-1500WG-LTE User manual

User’s Manual of VCG-1500WG-LTE
1
VCG-1500WG-LTE
Vehicle 4G LTE Cellular Wireless
Gateway with 5-Port 10/100TX

User’s Manual of VCG-1500WG-LTE
2
Trademarks
Copyright © PLANET Technology Corp. 2018.
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no
warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for
a particular purpose. PLANET has made every effort to ensure that this User's Manual is accurate; PLANET disclaims liability
for any inaccuracies or omissions that may have occurred.
Information in this User's Manual is subject to change without notice and does not represent a commitment on the part of
PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User's Manual. PLANET makes
no commitment to update or keep current the information in this User's Manual, and reserves the right to make improvements to
this User's Manual and/or to the products described in this User's Manual, at any time without notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate your comments and
suggestions.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the Instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be
required to take adequate measures.
Energy Saving Note of the Device
This power required device does not support Standby mode operation. For energy saving, please remove the power cable to
disconnect the device from the power circuit. In view of saving the energy and reducing the unnecessary power consumption, it
is strongly suggested to remove the power connection for the device if this device is not intended to be active.
WEEE Warning
To avoid the potential effects on the environment and human health as a result of the presence of hazardous
substances in electrical and electronic equipment, end users of electrical and electronic equipment should
understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted
municipal waste and have to collect such WEEE separately.
Revision
PLANET VCG-1500WG-LTE User's Manual
Model: VCG-1500WG-LTE
Revision: 1.0 (July, 2018)
Part No: EM-VCG-1500WG-LTE _v1.0

User’s Manual of VCG-1500WG-LTE
3
TABLE OF CONTENTS
1. INTRODUCTION....................................................................................................................6
1.1 Packet Contents ...........................................................................................................................................6
1.2 Product Description.....................................................................................................................................7
1.3 How to Use This Manual..............................................................................................................................9
1.4 Product Features........................................................................................................................................10
1.5 Product Specifications ..............................................................................................................................12
2. INSTALLATION ................................................................................................................... 14
2.1 Hardware Description ................................................................................................................................14
2.1.1 Vehicle Gateway Front and Rear Panels.............................................................................................................14
2.1.2 LED Indications ...................................................................................................................................................15
2.1.3 Power Inputs........................................................................................................................................................16
2.1.4 SIM Card Installation ...........................................................................................................................................17
2.1.5 Antenna Installation .............................................................................................................................................18
2.1.6 RJ45-DB9F Instruction ........................................................................................................................................18
2.2 Mounting Installation .................................................................................................................................19
3. QUICK CONFIGURATION...................................................................................................20
3.1 Inserting SIM Card into Gateway’s SIM Card Slot...................................................................................20
3.2 Connecting Antennas ................................................................................................................................20
3.3 Connecting LAN 2 Port of Gateway with PC ...........................................................................................20
3.4 Logging in to the Vehicle Gateway...........................................................................................................20
3.5 LED and System Status.............................................................................................................................20
4. BASIC CONFIGURATION ...................................................................................................22
4.1 WAN Configuration ....................................................................................................................................22
4.2 PPPoE Configuration.................................................................................................................................24
4.3 LAN Configuration .....................................................................................................................................24
4.4 Wi-Fi Configuration....................................................................................................................................26
4.5 DHCPD Configuration................................................................................................................................28

User’s Manual of VCG-1500WG-LTE
4
4.6 Dynamic Domain Name Server (DDNS) Configuration...........................................................................28
4.6.1 PLANET DDNS ............................................................................................................................................29
4.7 Keep Alive ...................................................................................................................................................32
5. ADVANCED CONFIGURATION .......................................................................................... 34
5.1 IP Table Filter ..............................................................................................................................................34
5.1.1 IP Filter Rule Configuration..................................................................................................................................35
5.1.2 MAC Filter Configuration .....................................................................................................................................37
5.2 NAT/DMZ Configuration.............................................................................................................................39
5.3 Router Configuration .................................................................................................................................40
5.4 VPN Configuration .....................................................................................................................................42
5.4.1 GRE.....................................................................................................................................................................42
5.4.2 PPTP...................................................................................................................................................................43
5.4.3 IPSEC..................................................................................................................................................................45
5.4.4 L2TP....................................................................................................................................................................46
6. System Management..........................................................................................................48
6.1 Time Management......................................................................................................................................48
6.2 User Management ......................................................................................................................................48
6.3 System Status.............................................................................................................................................49
6.4 Software Upgrade.......................................................................................................................................50
6.5 System Debug ............................................................................................................................................50
7. Internet Access Management............................................................................................ 52
7.1 Captive Portal .............................................................................................................................................52
7.2 WiFidog Configure .....................................................................................................................................53
7.3 Application Filtering...................................................................................................................................54
7.4 Follower.......................................................................................................................................................55
7.5 Battery Power Feature Config...................................................................................................................55
7.6 GPS Function..............................................................................................................................................56
8. Other Configurations .........................................................................................................59

User’s Manual of VCG-1500WG-LTE
5
8.1 Activation Mode..........................................................................................................................................59
8.2 Bandwidth Management............................................................................................................................62
8.3 Connecting Device (MAC Address Binding) ...........................................................................................63
8.4 Other Configurations .................................................................................................................................64
8.5 Timing Restart ............................................................................................................................................65
8.6 DTU Configuration .....................................................................................................................................66
Appendix: FAQs .....................................................................................................................68

User’s Manual of VCG-1500WG-LTE
6
1. INTRODUCTION
Thank you for purchasing PLANET Vehicle 4G LTE Cellular Gateway. Please refer to the table list below for the models used in
Europe and the U.S.:
Model Name
4G LTE
Wi-Fi
FDD
TDD
VCG-1500WG-LTE-EU
B1/B3/B5/B7/B8/B20
B38/B40/B41
ETSI
VCG-1500WG-LTE-US
B1-5/7/8/13/17-20
-
FCC
“Vehicle Gateway” is used as an alternative name in this user’s manual.
1.1 Packet Contents
Open the box of the Vehicle Gateway and carefully unpack it. The box should contain the following items:
VCG-1500WG-LTE x 1
Quick Installation Guide x 1
4G LTE Antenna x 1
2.4G Wi-Fi Antenna x 2
GPS Antenna x 1
Ethernet Cable x 1
Console Cable x 1
Mounting Kit x 1
Power Kit x 1
Antenna Dust Cap x 4
Copper Dust Cap x 6
If any item is found missing or damaged, please contact your local reseller for replacement.

User’s Manual of VCG-1500WG-LTE
7
1.2 Product Description
Internet of Vehicles via 4G LTE Vehicle Gateway
PLANET VCG-1500WG-LTE is a reliable, secure and high-bandwidth communications Vehicle Gateway for demanding mobile
applications and IoVdeployments. It features 4G LTE (Long Term Evolution), wireless AP, five Ethernet ports (4 LAN and 1
WAN), GPS,VPN technology and bandwidth management bundled in a mountable metal case to establish a public network
connection and allow passengers to access Internet.
High-performance 4G LTE
The VCG-1500WG-LTE is able to reach a download (DL) speed of up to 100Mbps and an upload (UL) speed of 50Mbps. The
Vehicle Gateway also supports multi-band connectivity including LTE FDD, TDD, HSDPA, WCDMA and GSM for a wide range
of applications.
Wireless Access Point
With an integrated 802.11n Wireless Access Point, the gateway supports data rate up to 300Mbps and is also compatible with
2.4GHz 802.11b/g/n equipment. The Wireless Protected Access (WPA-PSK/WPA2-PSK) and Wireless Encryption Protocol
(WEP) features enhance the level of transmission security and access control over Wireless LAN.
GPS Included
The VCG-1500WG-LTE is equipped with one convenient feature and that is GPS (global positioning system). It is a positioning
system based on a network of satellites that continuously transmit necessary data. More signals transmitted from more satellites
can triangulate its location on the ground, meaning any location can be easily tracked anytime.
Cost-effective VPN Solution
The VCG-1500WG-LTE provides a complete data security and privacy feature for access and exchange of sensitive data. The
full VPN capability of the VCG-1500WG-LTE including built-in PPTP, LT2P, and IPSec VPN client functions with
DES/3DES/AES encryption and MD5/SHA-1 authentication makes the shared connection more secure and flexible. The IPSec
VPN also makes the private tunnel over Internet more secure for enterprises doing business transactions.
Dual TF Cards for Wi-Fi Advertising Contents
The VCG-1500WG-LTE provides dual TF cards and the capacity of each card is up to 128GB. The TF cards can store
thousands of advertising data and movie files. The administrator is able to upload these files to TF cards via FTP locally.
Besides, through the CMS (central management system), administrator is able to upload and maintain these files remotely.
The device will display advertising contents when users access to the Wi-Fi after authentication.
Superior Management Functions
For networking management features, the VCG-1500WG-LTE provides such functions as DMZ, QoS, Wifidog and SNMP, as
well as full secure functions including Network Address Translation (NAT) and IP/URL/MAC filtering. The VCG-1500WG-LTE
has 4G and WAN connection failover characteristics, which can automatically switch over to the redundant, stable WAN
connection to keep users always online without missing any fascinating moments.

User’s Manual of VCG-1500WG-LTE
8
User-friendly and Secure Management
For efficient management, the VCG-1500WG-LTE is equipped with console, web and Wifidog management interfaces. With the
built-in web-based management interface, the VCG-1500WG-LTE offers an easy-to-use, platform independent management
and configuration facility. The VCG-1500WG-LTE supports Wifidog and it can be managed via the CMS for remote
management and Wi-Fi advertising.

User’s Manual of VCG-1500WG-LTE
9
1.3 How to Use This Manual
This User Manual is structured as follows:
Section 2, INSTALLATION
The section explains the functions of the Vehicle Gateway and how to physically install the Vehicle Gateway.
Section 3, QUICK CONFIGURATION
The section contains the procedure of installing hardware and accessing the Web UI.
Section 4, BASIC CONFIGURATION
The section explains how to manage the Vehicle Gateway by Web interface.
Section 5,ADVANCED CONFIGURATION
The chapter explains how to set up the advanced function of the Vehicle Gateway.
Section 6,SYSTEM MANAGEMENT
The chapter explains how to troubleshoot the Vehicle Gateway.
Section 7,INTERNET ACCESS MANAGEMENT
The chapter explains how to set up remote management and advertising.
Section 8,OTHER CONFIGURATIONS
The chapter explains related functions of the Vehicle Gateway.
Appendix A
The section contains FAQ information of the Vehicle Gateway.

User’s Manual of VCG-1500WG-LTE
10
1.4 Product Features
Physical Port
■4 10/100BASE-TX RJ45 LAN ports, auto-negotiation, auto MDI/MDI-X
■1 10/100BASE-TX RJ45 WAN port, auto-negotiation, auto MDI/MDI-X
■1 4G LTE 2.3 dBi antenna
■2 2.4G Wi-Fi 2dBi antennas
■1 GPS antenna
■1SIM card slot
■1console port
■2TF card slots to save files for Wi-Fi advertising
Cellular Interfaces
■Supports multi-band connectivity with FDD LTE/ TDD LTE/ WCDMA/ GSM/ LTE Cat4
■Built-in SIM and broadband backup for network redundancy
■One detachable antenna for 4G LTE connectiion
■LED indicators for connection status (3G/4G)
Wi-Fi Interfaces
■Complies with IEEE802.11b/g/n 2.4GHz
■Two detachable antennas for wireless connection
■64/128-bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK (TKIP/AES encryption)
■LED indicators for status
Case and Installation
■IP30 aluminum case
■Mounting brackets for vehicles
■Power requirement: 6~32V DC
■Supports 15KV DC Ethernet ESD protection
■-25 to 65 degrees C operating temperature
Advanced Features
■Supports demilitarized zone (DMZ)
■Supports VPN client, including GRE, PPTP, IPSec, L2TP
■Supports NAT port mapping function, such as SNAT and DNAT
■Supports Static Routing to display current routing information of the gateway
■Supports QoS for bandwidth management
■Supports Dynamic DNS and PLANETDDNS
■Supports WAN connection types: DHCP client, static IP and PPPoE client
■Secures network connection
IP filter
URL filter
MAC filter

User’s Manual of VCG-1500WG-LTE
11
Management
■Gateway management interfaces
- Console/Telnet Command Line interface
- Web management
■Gateway Maintenance
- Firmware upload via HTTP, and TFTP
- Restore or Reset button for reset to factory default
- Dual images
■SNTP (Simple Network Time Protocol)
■System log
■System tool, such as ping and trace
■Configuration backup and restore
■Supports CMS and Wifidog for remote management, and Wi-Fi advertising

User’s Manual of VCG-1500WG-LTE
12
1.5 Product Specifications
Product
VCG-1500WG-LTE
Hardware Specifications
Copper Ports
4 LAN 10/100BASE-TX RJ45 auto-MDI/MDI-X ports
1 WAN 10/100BASE-TX RJ45 auto-MDI/MDI-X port
Console
1 x RS232-to-RJ45 serial port (115200, 8, N, 1)
SIM Interface
1 SIM card slot with mini SIM card tray
Cellular Antenna
1 2dBi external antenna with SMAconnector for LTE
Wi-Fi Antenna
2 2dBi external antennas with SMAconnectors for 2.4GHz
GPS Antenna
1 28dB gain external antennas with SMA connectors for GPS -3m
USB Interface
1 USB 2.0 for external storage
TF Card Interface
2 TF card for storing thousands of advertising data (max. capacity up to 128G for each)
Connector
Standard 4-pin vehicle power jack for power input
Reset Button
> 5 sec: Factory default
ESD Protection
15KV DC
Enclosure
IP30 metal case
Installation
Mounting brackets for vehicles
LED
System:
PWR (Red)
Ethernet Interfaces (Port1-4 and WAN Port):
LNK (Green)
ACT (Orange)
LTE SIM and Signal :
3G/4G (Blue)
Wi-Fi (Blue)
Internet (Blue)
Dimensions (W x D x H)
168 x 104 x 25 mm (not including antenna and connector)
Weight
537g (not including antenna)
Power Requirements –
DC
6~32V DC, 1.5A
Power Consumption
3 watts/10.23 BTU
Multi Band Supports
EU Model
FDD LTE B1/B3/B5/B7/B8/B20 (2100/1800/850/2600/900/800)
TDD LTE B38/B40/B41 (2600/2300/2500)
WCDMA B1/B5/B8 (2100/850/900)
GSM/EDGE B3/B8 (1800/900)
US Model
FDD LTE B2/B4/B12 (1900/AWS1700/700)
WCDMA B2/B4/B5 (1900/AWS1700/850)
LTE Data Rate
20MHz bandwidth: 100Mbps (DL), 50Mbps (UL)
Wireless Specifications
Standard
IEEE 802.11 b/g/n 2.4GHz
Wireless Mode
Access Point
Operating Channels
FCC: 1~11, ETSI: 1~13
Encryption Security
64-/128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK

User’s Manual of VCG-1500WG-LTE
13
Data Rate
Up to 300Mbps
Transmission Distance
Up to 150 meters
*The estimated transmission distance is based on the theory.
The actual distance will vary in different environments
Advanced Functions
VPN
GRE, PPTP, IPSec, L2TP
QoS
Bandwidth management
WAN Connection Type
PPPoE, Static, DHCP client
Wifidog
Wifi authentication and advertising
Secure Network
IP filter
URL filter
MAC filter
Other
Supports demilitarized zone (DMZ)
Supports NAT port mapping function, UPnP
Supports Dynamic DNS
Management
Basic Management
Interfaces
Console, Telnet, Web browser
Standards Conformance
Regulatory Compliance
CE, FCC
Standards and Protocols
Compliance
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x flow control and back pressure
RFC 768 UDP
RFC 791 IP
RFC 792 ICMP
RFC 5321 SMTP
RFC 2068 HTTP
RFC 1939 POP3
RFC 854 TELNET
RFC 959 FTP
Environment
Operating
Temperature: -25 ~ 65 degrees C
Relative Humidity: 95% (non-condensing)
Storage
Temperature: -40 ~ 85 degrees C
Relative Humidity: 95% (non-condensing)

User’s Manual of VCG-1500WG-LTE
14
2. INSTALLATION
This section describes the hardware features and installation of the Vehicle Gateway. For easier management and control of the
Vehicle Gateway, familiarize yourself with its display indicators and ports. Front panel illustrations in this chapter display the unit
LED indicators. Before connecting any network device to the Vehicle Gateway, please read this chapter completely.
2.1 Hardware Description
2.1.1 Vehicle Gateway Front and Rear Panels
The front panel provides the monitoring of the Vehicle Gateway’s simple interfaces. Figure 2-1 shows the front panel of the
Vehicle Gateway.
The rear panel provides the most of the connectors in the gateway. Figure 2-2 shows the rear panel of the Vehicle Gateway.
Figure 2-2 Rear Panel
Figure 2-1 Front Panel

User’s Manual of VCG-1500WG-LTE
15
Reset Button
On the rear of the VCG-1500WG-LTE, the reset button is designed to reset the Vehicle Gateway to factory default.
Figure 2-3 Reset Button of VCG-1500WG-LTE
Reset Button
Function
> 5 sec: Factory Default
Reset the Vehicle Gateway to Factory Default configuration.
Vehicle Gateway will then reboot and load the default settings
shown below:
Default username: admin
Default password: admin
Default IP address: 192.168.1.1
Subnet mask: 255.255.255.0
2.1.2 LED Indications
The front and real panels’LEDs indicate instant status related to system power, Wi-Fi, 4G and Internet. It helps monitor and
troubleshoot when needed.
System
LED
Color
Function
PWR
Red
Lights
Indicates the system is working properly.
Wi-Fi
Blue
Lights
Indicates the Wi-Fi is working. The Wi-Fi is enabled by default.
3G
Blue
Lights
Indicates the SIM card is detected via 3G
4G
Blue
Lights
Indicates the SIM card is detected via 4G.
Internet
Blue
Lights
Indicates the system is connecting to the Internet.
10/100BASE-TX Port Interfaces (LAN Port-1 to Port-4, WAN)
LED
Color
Function
Ethernet
Green
Blinking
LNK, indicates that the link is successfully established
Orange
Blinking
ACT, indicates that the port is operating at 100Mbps

User’s Manual of VCG-1500WG-LTE
16
2.1.3 Power Inputs
The 4-pin power connector on the rear panel of Vehicle Gateway is used for one DC power input. The power input range is from
6 to 32V DC. In the power kit, VCG-1500WG-LTE provides one power adapter and one power cable with 4-pin female power
jack. Please follow the steps below to insert the power wire.
1.Plug the 4-pin female power jack of the power cable into the power connector.
Figure 2-4: Plugging in the Power Input
2. Connecting power adapter with power cable.
Figure 2-5: Connecting Power Cable with Power Adapter
Except for the power adapter, the power cable also reserves two bare wires with positive
and negative poles so that the user can connect to the battery of the car.

User’s Manual of VCG-1500WG-LTE
17
2.1.4 SIM Card Installation
1. SIM Card Drawer and Eject Button
Figure 2-6: SIM Card Slot and Ejector
2. Inserting and Removing SIM Card
(1) Before inserting or removing the SIM card, ensure that the power has been turned off and the power connector has
been removed from Vehicle Gateway.
(2) Press the ejector button with a paper clip or suitable tool to eject the SIM card from the drawer.
(3) Insert the SIM card with the contacts facing down and align it properly into the drawer. Make sure your direction of
SIM card and put it into the tray.
(4) Slide the drawer back and lock it in place.
A mini card with LTE and WCDMA subscription.
Please make sure the direction first. When pulling into the SIM tray without putting the correct
direction, the tray will be stuck inside.
Please turn off Vehicle Gateway before removing the SIM card.

User’s Manual of VCG-1500WG-LTE
18
2.1.5 Antenna Installation
After SIM card installation, please connect 4G antenna, GPS antenna and Wi-Fi antennas to connectors and ensure these
antennas are fixed properly. Without installing antennas, it will affect the performance or can not receive the signal.
2.1.6 RJ45-DB9F Instruction
This Gateway supports RS232 asynchronous communication serial interface and adopts RJ45. Serial interface is mainly used
to configure control or configured to be DTU function.
Com/line: RS232 asynchronous communication serial interface
Shown below are the signal definitions of the RJ45-DB9F serial communication interfaces:
RJ45
DB9F
1
8
2
6
3
2
4
1
5
5
6
3
7
4
8
7
The signal definitions of the DB9F serial communication interface shown below::
PIN
RS232 Signal
Name
Description
Direction related to
DTU
1
DCD
carrier wave
signal check
Output
2
RXD
receive data
Output
3
TXD
send data
Input
4
DTR
data
terminal ready
Input
5
GND
power reference
ground
6
DSR
data
device ready
Output
7
RTS
request to send
Input
8
CTS
data device gets
ready to receive
data
Output

User’s Manual of VCG-1500WG-LTE
19
2.2 Mounting Installation
This section describes how to install your Vehicle Gateway and make connections to the Vehicle Gateway. To install your
Vehicle Gateway on a desktop or shelf, simply complete the following steps.
Step 1: Screw the brackets on the Vehicle Gateway.
Step 2: Place the Vehicle Gateway in the car where you need to install it, and then lock the screws.

User’s Manual of VCG-1500WG-LTE
20
3. QUICK CONFIGURATION
This chapter explains the procedure that you can install and configure the Gateway in a short time. Besides, it also contains
information about port connection options.
3.1 Inserting SIM Card into Gateway’s SIM Card Slot
3.2 Connecting Antennas
3.3 Connecting LAN 2 Port of Gateway with PC
Please connect the gateway and PC to the same switch. The default IP address of LAN 2 port is 192.168.1.1 and the port
number is 9999. In the PC, please make sure the manager PC must be set to the same IP subnet address.
For example, the default IP address of the gateway is 192.168.1.1, then the manager PC should be set to 192.168.1.x (where x
is a number between 2 and 254), and the default subnet mask is 255.255.255.0
Figure 3-3-1 Web Management
3.4 Logging in to the Vehicle Gateway
Use Internet Explorer 8.0 or above Web browser and enter default IP address http://192.168.1.1:9999 to access the Web
interface.
After entering the http://192.168.1.1:9999 the following dialog box will appear. Please enter the default user name and password
“admin”.
3.5 LED and System Status
When the gateway is working properly, the LED status should display as shown below:
