Planet IFT-802T User manual

10/100BASE-TX to 100BASE-FX
Industrial Media Converter
IFT-802T / IFT-802TS15 / IFT-805AT
User's Manual

Trademarks
Copyright © PLANET Technology Corp. 2015.
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp.
All other trademarks belong to their respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware will
work properly in all environments and applications, and makes
no warranty and representation, either implied or expressed,
with respect to the quality, performance, merchantability, or
tness for a particular purpose.
PLANET has made every effort to ensure that this User’s Manual
is accurate; PLANET disclaims liability for any inaccuracies or
omissions that may have occurred.
Information in this User’s Manual is subject to change without
notice and does not represent a commitment on the part of
PLANET. PLANET assumes no responsibility for any inaccuracies
that may be contained in this User’s Manual. PLANET makes no
commitment to update or keep current the information in this
User’s Manual, and reserves the right to make improvements
to this User’s Manual and/or to the products described in this
User’s Manual, at any time without notice.
If you nd information in this manual that is incorrect,
misleading, or incomplete, we would appreciate your comments
and suggestions.
FCC Warning
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
Instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own
expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this
product may cause radio interference, in which case the user
may be required to take adequate measures
WEEE Warning
To avoid the potential effects on the environment and
human health as a result of the presence of
hazardous substances in electrical and electronic
equipment, end users of electrical and electronic
equipment should understand the meaning of the crossed-out
wheeled bin symbol. Do not dispose of WEEE as unsorted
municipal waste and have to collect such WEEE separately.
Revision
PLANET 10/100BASE-TX to 100BASE-FX Industrial Media
Converter User's Manual
For Models: IFT-802T, IFT-802TS15, IFT-805AT
Revision: 1.1 (June, 2015)
Part No: EM-IFT-80xT_v1.1 (2350-AH1140-001)

Table Of Contents
1. Introduction ..................................................................... 5
1.1 Package Contents....................................................... 5
1.2 How to Use This Manual ............................................. 5
1.3 Product Features ........................................................ 6
1.4 Product Specications................................................. 7
2. Installation ................................................................... 10
2.1 Product Description .................................................. 10
2.1.1 Media Converter Front Panel ........................... 12
2.1.2 LED Indicators............................................... 12
2.1.3 Media Converter Upper Panel.......................... 14
2.1.4 Wiring the Power Inputs................................. 14
2.1.5 Wiring the Fault Alarm Contact ....................... 15
2.2 Mounting Installation ................................................ 16
2.2.1 Installing DIN-Rail Mounting ........................... 17
2.2.2 Wall-mount Plate Mounting ............................. 19
3. Applications ................................................................... 20
3.1 Installation Steps ..................................................... 20
4. Media Converter Operation .............................................. 22
4.1 Learning.................................................................. 22
4.2 Forwarding & Filtering .............................................. 22
4.3 Store-and-Forward ................................................... 22
4.4 Auto-negotiation ...................................................... 23
5. Troubleshooting .............................................................. 24
Appendix A: Networking Connection ..................................... 26
A.1 Media Converter’s RJ45 Pin Assignments..................... 26
A.2 RJ45 Cable Pin Assignments ...................................... 26
A.3 Fiber Optical Cable Connection Parameter ................... 27

5
1.Introduction
1.1 Package Contents
Check your package for the following parts:
● 10/100BASE-TX to 100BASE-FX Industrial Media Converter x 1
● User’s Manual x 1
● DIN Rail Kit x 1
● Wall Mount Kit x 1
● Screws x 1 (set)
If any of these are missing or damaged, please contact your
dealer immediately; if possible, retain the carton including the
original packing material, and use them again to repack the
product in case there is a need to return it to us for repair.
1.2 How to Use This Manual
This Industrial Media Converter User Manual is structured
as follows:
Chapter 2 Installation
The chapter explains the feature, functionality and the physical
installation of the Industrial Media Converter.
Chapter 3 Application
The chapter explains the Industrial Media Converter application.
Chapter 4 Media Converter operation
The chapter explains the Industrial Media Converter transmit
operation.
Chapter 5 Troubleshooting
The chapter explains the troubleshooting of the Industrial Media
Converter.
Appendix A
This chapter contains cable information of the Industrial Media
Converter.

6
1.3 Product Features
Physical Port
IFT-802T
• 1-Port 10/100BASE-TX RJ45
• 1-Port 100BASE-FX interface for up to 2km (Multi-mode
ber 62.5/125μm / 50/125μm)
IFT-802TS15
• 1-Port 10/100BASE-TX RJ45
• 1-Port 100BASE-FX interface for up to 15km (Single mode
ber 9/125μm)
IFT-805AT
• 1-Port 10/100BASE-TX RJ45
• 1-Port 100BASE-FX SFP slot (Distance depends on SFP
module)
Industrial Design
• Slim type IP30 metal case
• -40°C~75°C operating temperature
• DIN rail and wall-mount design
• 12 to 48V DC, redundant power with polarity reverse
protect function and connective removable terminal block
for master and slave power
• Supports EFT 6KV DC protection for power line
• Supports 6KV DC Ethernet ESD protection
Data Communication
• Complies with the IEEE 802.3, IEEE 802.3u Fast Ethernet
standard
• Auto-MDI/MDI-X detection and auto-negotiation with
half-duplex / full-duplex modes for 10 /100BASE-TX RJ45
port

7
• Store-and-Forward switching architecture
• Features Store-and-Forward mode with wire-speed ltering
and forwarding rates
• Prevents packet loss with back pressure (half-duplex) and
IEEE 802.3x pause frame ow control (full-duplex)
• Supports packet size of up to 1522bytes
• CSMA/CD protocol
• Automatic source address learning and aging
1.4 ProductSpecications
Product IFT-802T IFT-802TS15 IFT-805AT
Hardware Specications
10/100BASE-TX
Port 1 RJ45 Auto-MDI/MDI-X port
100BASE-FX Port 1 SC Interface 1 SFP Slot
Fiber Port Type SC / Multi-mode SC / Single mode
Vary on
module
Cable Distance 2km 15km
Optical
Frequency 1310nm 1310nm
Launch Power
(dBm)
Max: -14
Min: -20
Max: 0
Min: -20
Receive
Sensitivity (dBm) -32 -32
Maximum Input
Power (dBm) -14 0
Dimensions
(W x D x H) 135mm x 85mm x 32mm

8
Weight 430g
Installation DIN rail kit and wall-mount ear
Maximum Frame
Size Packet size of 1522bytes
Flow Control Back pressure for half duplex, IEEE 802.3x
pause frame for full duplex
Enclosure IP-30 slim-type metal case
LED Indicator
System:
• Power 1 (green)
• Power 2 (green)
• Fault (green)
1 x copper port:
• 10/100 (green)
• LNK/ACT(green)
1 x 100FX port:
• 100 (green)
• LNK/ACT (green)
Power Input 12 to 48V DC redundant power with polarity
reverse protection function
Power
Consumption 3 watts / 10BTU (maximum)
Protection ESD (Ethernet): 6KV DC
Surge (Power): 6KV DC
Operating
Temperature -40~75 degrees C
Operating
Humidity 5~90% non-condensing
Storage
Temperature -40~85 degrees C
Storage Humidity 5~90% non-condensing

9
Speed
Twisted-pair:
• 10/20Mbps for half / full-duplex
• 100/200Mbps for half / full duplex
Fiber-optic:
• 200Mbps for full-duplex
Network Cables
10/100BASE-TX:
• 2-pair UTP Cat. 3, 4, 5 (100 meters, max.)
• EIA/TIA-568 100-ohm STP (100 meters, max.)
100BASE-FX:
• IFT-802T: Multi-mode optic ber 62.5/125μm /
50/125μm (2km)
• IFT-802TS15: Single mode optic ber 9/125μm
(15km)
• IFT-805AT: SFP Slot (depending on SFP
module)
Standards Conformance
Emissions FCC Class A, CE Class A
Standards
Compliance
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX / 100BASE-FX
IEEE 802.3x ow control and back pressure
Stability Testing
IEC60068-2-32 (free fall)
IEC60068-2-27 (shock)
IEC60068-2-6 (vibration)

10
2.Installation
This section describes the functionalities of the Industrial Media
Converter’s components and guides you how to install it on the
desktop. Basic knowledge of networking is assumed. Please read
this chapter completely before continuing.
In the following section, the term “Industrial Media
Converter” means the IFT-802T / 802TS15 / 805AT.
2.1 Product Description
The IFT-80xT is an industrially-hardened media converter
specially designed to operate under the environment
temperature range of -40 to 75°C. The IFT-80xT is highly
reliable and stable when operating in the harsh environment.
The IFT-80xT provides high level of immunity to electromagnetic
interference and heavy electrical surges typical of environments
found on plant oors or in curb side trafc control cabinets.
The IFT-80xT is packaged in a compact, IP30 standard metal
that allows either DIN or panel mounting for efcient use of
cabinet space. The media converter provides an integrated
power supply with a wide range of voltages (12 to 48V DC)
for worldwide operability or dual-redundancy, reversible
polarity, and 24V DC and 48V DC power supply inputs for high
availability applications requiring dual or backup power inputs.
The IFT-80xT provides one 10/100BASE–TX optic-ber SC/SFP
interface and one 100BASE-FX optic-ber SC/SFP interface. It
provides multi-mode or single-mode 100BASE-FX SC interface
and 100BASE-FX SFP slot. The ber transmit distance of the
IFT-802T can be 2km while that of the IFT-802TS15 is 15km
and that of the IFT-805AT varies depending on SFP module.
With Fast Ethernet SFP interface, the IFT-805AT is highly

11
reliable and exible to extend the distance from 2km to 60km,
depending on the MFB family Fast Ethernet SFP modules.
MFB family Fast Ethernet SFP module comes with one of the
following models. The following list the available modules for the
IFT-805AT
Fast Ethernet SFP Module List
Model Interface Fiber Connector and Distance
MFB-FX SFP-Port
100BASE-FX Module
LC, Multi-Mode (1310nm)
-2km (-0~50°C)
MFB-F20 SFP-Port
100BASE-FX Module
LC, Single Mode (1310nm) –
20km (-0~50°C)
MFB-F40 SFP-Port
100BASE-FX Module
LC, Single Mode (1310nm) –
40km (-0~50°C)
MFB-F60 SFP-Port
100BASE-FX Module
LC, Single Mode (1310nm) –
60km (-0~50°C)
MFB-FA20 SFP-Port
100BASE-BX Module
LC WDM, Single Mode
(TX:1310nm, RX:1550nm) -
20km (-0~50°C)
MFB-FB20 SFP-Port
100BASE-BX Module
LC WDM, Single Mode
(TX:1550nm, RX:1310nm) -
20km (-0~50°C)
MFB-TFX SFP-Port
100BASE-FX Module
LC, Multi-Mode (1310nm)
-2km (-40~75°C)
MFB-TF20 SFP-Port
100BASE-FX Module
LC, Single Mode (1310nm) –
20km (-40~75°C)
* Models with the last two numbers indicate the maximum
distance in km.

12
2.1.1 Media Converter Front Panel
Figure 2-1 & 2-2 & 2-3 show a front panel of Industrial Media
Converter.
P1 P2 FAULT
100Base-FX
IFT-802T
LNK/ACT
100
100
LNK/ACT
RX
TX
10/100Base-TX
P1 P2 FAULT
100BASE-FX
IFT-802TS15
LNK/ACT
100
100
LNK/ACT
RX
TX
10/100BASE-TX
P1 P2 FAULT
100Base-FX
IFT-805AT
LNK/ACT
100
100
LNK/ACT
10/100Base-TX
Figure 2-1 IFT-
802T Front Panel
Figure 2-2 IFT-
802TS15 Front Panel
Figure 2-3 IFT-
805AT Front Panel
2.1.2 LED Indicators
System
LED Color Function
P1 Green Lit: Indicates power 1 has power.
P2 Green Lit: Indicates power 2 has power.
FAULT Green Lit: Indicates either power 1 or power 2
has no power.

13
10/100BASE-TX RJ45 Port
LED Color Function
10/100 Green
Lit: Indicates TP port is successfully
connecting to the network at 100Mbps.
Off: Indicates TP port is successfully
connecting to the network at 10Mbps.
LNK/ACT Green
Lit: Indicates the link through that port is
successfully established.
Blinking: Indicates TP port is actively
sending or receiving data over
that port.
100BASE-FX SC / SFP Fiber Interface
LED Color Function
100 Green Lit: Indicates ber port is successfully
connecting to the network at 100Mbps.
LNK/ACT Green
Lit: Indicates the link through that port is
successfully established.
Blinking: Indicates ber port is actively
sending or receiving data over
that port.

14
2.1.3 Media Converter Upper Panel
The upper panel of the Industrial Media Converter consists one
terminal block connector within two DC power inputs. Figure 2-4
shows the upper panel of the Industrial Media Converter.
Figure 2-4 Industrial Media Converter Upper Panel.
2.1.4 Wiring the Power Inputs
The 6-contact terminal block connector on the top panel of
Industrial Media Converter is used for two DC redundant inputs.
Please follow the steps below to insert the power wire.
1. Insert positive / negative DC power wires into Contacts 1 and
2 for Power 1 or 5 and 6 for Power 2.
V1- V1 + V2 - V2 +

15
2. Tighten the wire-clamp screws for preventing the wires from
loosening
123456
Power 1 Fault Power 2
- + - +
Note
The wire gauge for the terminal block should be
in the range of 12 to 24 AWG.
2.1.5 Wiring the Fault Alarm Contact
The fault alarm contacts are in the middle of the terminal block
connector as the picture shows below. After inserting the wires,
the Industrial Media Converter will detect the fault status of the
power failure, or port link failure (available for managed model)
and then form an open circuit. The following illustration shows
an application example for wiring the fault alarm contacts.
Insert the wires into the fault alarm contacts.

16
Note
1. The wire gauge for the terminal block should
be in the range of 12 to 24 AWG.
2. Alarm relay circuit accepts up to 30V, max. 3A
currents.
2.2 Mounting Installation
This section describes how to install the Industrial Media
Converter and make connections to it. Please read the following
steps to perform the procedures in the order being presented.
Note
In the installation steps below, this Manual uses
the IGS-801 (PLANET 8-port Industrial Gigabit
Switch) as an example. However, the steps for
PLANET Industrial Media Converter are similar.

17
2.2.1 Installing DIN-Rail Mounting
Follow the steps below for the DIN-rail mounting of the
Industrial Media Converter:
Step 1: Screw the DIN-rail on the Industrial Media Converter.
2
1
Step 2: Lightly slide the DIN-rail into the track.

18
Step 3: Make sure the DIN-rail is tightly on the track.
2
1
Step 4: To remove Industrial Media Converter from the track,
lightly lift it up.

19
2.2.2 Wall-mount Plate Mounting
To install the Industrial Media Converter on the wall, please
follow the instructions described below:
Step 1: Remove the DIN-rail from the Industrial Media
Converter; loosen the screws to remove the DIN-rail.
Step 2: Place the wall-mount plate on the rear panel of the
Industrial Media Converter.
Step 3: Use the screws to screw the wall-mount plate on the
Industrial Media Converter.
Step 4: Use the hook holes at the corners of the wall-
mount plate to hang the Industrial Media Converter
on the wall.
Step 5: To remove the wall-mount plate, reverse the steps
above.

20
3.Applications
In this section, how to install Industrial Media Converter and its
installation points are described below:
3.1 Installation Steps
Step 1: Unpack the Industrial Media Converter.
Step 2: Screw DIN-rail on the Industrial Media Converter.
Please refer to the DIN-rail Mounting section for
DIN-rail installation if the DIN-rail is not screwed on
the Industrial Media Converter. If you want to wall-
mount the Industrial Media Converter, please refer to
the Wall-mount Plate Mounting section for wall-mount
plate installation.
