Planet 85M Powerline Ethernet PL-201-KIT User manual

PL-201-KIT
With PLANET powerline communication products, the power outlets are
no longer to be viewed as power receptacles only but can also be the
network connection point. The PL-201 is a Powerline to Ethernet Bridge
with a RJ-45 Ethernet interface which directly connects to your computer’s
network card. Through the multiple outlets in the building, the PL-201
allows you to use the existing electrical wiring to build the network
connection in the entire household or office without the clutter of messy
wiring. It is no need of using Ethernet cable but simply pulg the PL-201
into the outlets anywhere in the house or office to share the network.
The PL-201 offers customers high speed up to 85Mbps data rate through
powerline. In addition, the PL-201 features 56-Bit DES data encryption
that improves the security and reliability and protects the data leaked by
anyone else.
Data Sheet
1
Key Features
HomePlug Powerline Specification 1.0 Turbo compliant•
Up to 85Mbps data rate on the powerline•
Connects 10/100 Ethernet network to Powerline network•
56-bit DES encryption to ensure data security and reliability•
Direct attached to power outlets•
Up to 200 meters between powerline nodes•
Throughout the whole house, just use your power circuit to•
access the Internet or PC network
Orthogonal Frequency Division Multiplexing for high data•
reliability in noisy media conditions
85M Powerline Ethernet Bridge – Two Devices Included
Applications
PLANET provides several types of powerline products to meet
various demands. As illustrated in the topology, a notebook with
a built-in Ethernet can connect to the PL-201 freely and roam in
the house. Apply an ADSL modem or broadband router to one of
the Powerline to Ethernet bridges, and all computers can share the
Internet connection. With the PLANET Powerline products, no messy
network cables and additional switches are required at home and
users can entirely enjoy home networking from now on.
PL-201
ADE-4400
PL-420
Ethernet85M Powerline
PL-420
PL-201
Internet

PL-201-KIT
Data Sheet
2
Specification
Ordering Information
PL-201-KIT-EU 85M Powerline Ethernet Bridge KIT (Two Devices Pack, EU type)
PL-201-KIT-UK 85M Powerline Ethernet Bridge KIT (Two Devices Pack, UK type)
01-09 C-PL-201-KIT
PLANET reserves the right to change specications without prior notice. All brand names and trademarks are property of
their respective owners. Copyright © 2009 PLANET Technology Corp. All rights reserved.
PLANET Technology Corporation
11F, No. 96, Min Chuan Road, Hsin Tien, Taipei, Taiwan, R.O.C.
Tel: [phone] Fax: [phone]
Email: [email protected] www.planet.com.tw
VoIP Gateway: vip.planet.com.tw
Product 85M Powerline Ethernet Bridge – Two Devices Included
Model PL-201-KIT
Standard
HomePlug Powerline Specification 1.0 Turbo compliant
IEEE802.3 10 Base-T
IEEE802.3u 100 Base-TX
Ports One RJ-45 port
Speed UP to 85Mbps
Encryption 56-bits DES encryption
LED Power, Ethernet, Data
Powerline Frequency Band 4Mhz to 21Mhz
Dimension (W x D x H) EU : 105 x 72 x 60 mm
UK : 105 x 72 x 70 mm
Weight 130g
Certifications FCC, CE
Operating Temp. 0~50 Degree C
Operating Humidity 10~95% (non-condensing)
Input Voltage 100V~240V AC, 50~60Hz
