Planet FGSW-2620 User manual

24-Port 10/100Mbps + 2-Port
Gigabit Ethernet Switch
FGSW-2620
User’s Manual

Trademarks
Copyright © PLANET Technology Corp. 2007.
Contents subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other
trademarks belong to their respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware will work
properly in all environments and applications, and makes no warranty
and representation, either implied or expressed, with respect to
the quality, performance, merchantability, or tness for a particular
purpose.
PLANET has made every effort to ensure that this User’s Manual is
accurate; PLANET disclaims liability for any inaccuracies or omissions
that may have occurred.
Information in this User’s Manual is subject to change without notice
and does not represent a commitment on the part of PLANET. PLANET
assumes no responsibility for any inaccuracies that may be contained in
this User’s Manual. PLANET makes no commitment to update or keep
current the information in this User’s Manual, and reserves the right
to make improvements to this User’s Manual and/or to the products
described in this User’s Manual, at any time without notice.
If you nd information in this manual that is incorrect, misleading, or
incomplete, we would appreciate your comments and suggestions.

FCC Warning
This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with
the Instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product may
cause radio interference, in which case the user may be required to
take adequate measures.
WEEE Warning
To avoid the potential effects on the environment and
human health as a result of the presence of hazardous
substances in electrical and electronic equipment, end users
of electrical and electronic equipment should understand the
meaning of the crossed-out wheeled bin symbol. Do not
dispose of WEEE as unsorted municipal waste and have to collect such
WEEE separately.
Revision
PLANET 24-Port 10/100Mbps+ 2-Port Gigabit Ethernet Switch User's
Manual
FOR Model: FGSW-2620
Rev: 3.0 (October, 2007)
Part No: 2010-A50060-001

TABLE OF CONTENTS
1. Introduction ............................................................................... 5
1.1 Package Contents ................................................................ 5
1.2 How to Use This Manual ..................................................... 5
1.3 Product Features ................................................................. 6
1.4 Product Specications .......................................................... 7
2. Installation................................................................................. 8
2.1 Product Description.............................................................. 8
2.1.1 Product Overview ........................................................ 8
2.1.2 FGSW-2620 Front Panel............................................... 8
2.1.3 LED Indicators ............................................................ 9
2.1.4 FGSW-2620 Rear Panel...............................................10
2.2 Installing a FGSW-2620 ......................................................10
2.2.1 Desktop Installation....................................................10
2.2.2 Rack Mounting ...........................................................11
3. Switch Operation .......................................................................14
3.1 Address Table.....................................................................14
3.2 Learning ............................................................................14
3.3 Forwarding & Filtering.........................................................14
3.4 Store-and-Forward..............................................................14
3.5 Auto-Negotiation ................................................................15
4. Troubleshooting .........................................................................17
Appendix A Networking Connection .................................................18
A.1 Switch‘s RJ-45 Pin Assignments...........................................18
A.2 RJ-45 cable Pin Assignments ...............................................19

5
1. Introduction
1.1 Package Contents
Check the contents of your package for following parts:
● 24-Port 10/100Mbps+ 2-Port Gigabit Ethernet Switch x1
● User's manual x1
● Power cord x1
● Two Rack-Mounting Brackets with Attachment Screws x1
If any of these are missing or damaged, please contact your dealer
immediately, if possible, retain the carton including the original packing
material, and use them against to repack the product in case there is a
need return to it to us for repairing.
1.2 How to Use This Manual
This 24-Port 10/100Mbps+ 2-Port Gigabit Ethernet Switch Us-
ers’ Manual is structured as follows:
● Section 2, Installation
It explains the functions of Switch and how to physically install the
FGSW-2620.
● Section 3 Switch operation
It explains the Switch operation of FGSW-2620.
● Section 4 Troubleshooting
It contains troubleshooting guide of FGSW-2620.
● Appendix A
It contains cable information of FGSW-2620.
In the following section, the term “Switch” means the Switch, i.e.
FGSW-2620; term of “switch” can be any third part switches.

6
1.3 Product Features
● Comply with the IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE
802.3z Gigabit Ethernet standard
● 24-Port 10/100Mbps Fast Ethernet ports
● 2 10/100/1000Mbps ports
● Each Switching ports support auto-negotiation-10/20, 100/200Mbps,
1000/2000Mbps supported
● Auto-MDI/MDI-X detection on each RJ-45 port
● Prevents packet loss with back pressure (half-duplex) and IEEE
802.3x PAUSE frame ow control (full-duplex)
● High performance Store and Forward architecture, broadcast storm
control, runt/CRC ltering eliminates erroneous packets to optimize
the network bandwidth
● 4K MAC address table, automatic source address learning and ageing
● 2.5Mbits embedded memory for packet buffers
● 19-inch rack mount size
● EMI standards comply with FCC Class A, CE

7
1.4 Product Specications
Product FGSW-2620
Hardware Specication
Ports 24 10/100Base-TX RJ-45 Auto-MDI/MDI-X
ports
Gigabit ports 2 10/100/1000Mbps ports
Switch Processing
Scheme Store-and-Forward
Throughput (packet
per second) 6.54Mpps
Switch fabric 8.8Gbps
Address Table 4K entries
Share data Buffer 2.5Mbits
Flow Control Back pressure for half duplex, IEEE 802.3x
Pause Frame for full duplex
Dimensions 440 x 120 x 44 mm (1U height)
Weight 1.57 kg
Power Requirement 100~240 VAC, 50~60 Hz
Power Consumption
/ Dissipation 23.1 watts / 78 BTU
Temperature Operating: 0~50 degree C
Storage: -40~70 degree C
Humidity Operating: 5% to 90%, Storage: 5% to 90% (Non-
condensing)
Standards Conformance
Regulation
Compliance FCC Part 15 Class A, CE
Standards
Compliance
IEEE 802.3 (Ethernet)
IEEE 802.3u (Fast Ethernet),
IEEE 802.3x (Full-duplex ow control)

8
2. Installation
This section describes the functionalities of FGSW-2620 components
and guides how to install it on the desktop or shelf. Basic knowledge
of networking is assumed. Please read this chapter completely before
continuing.
2.1 Product Description
The PLANET FGSW-2620 provides 24 10/100Mbps Fast Ethernet ports
with 2 10/100/1000Mbps ports (port 25/26). The two Gigabit ports can
be 1000Base-T for 10/100/1000Mbps; the distance can be extended
from 100 meters (TP). The Switch with non-blocking backplane
and simplies the task of upgrading your LAN to cater for increased
bandwidth demand.
2.1.1 Product Overview
PLANET FGSW-2620 is Ethernet Switch with 24 RJ-45 10/100Mbps
ports. The Switch also provides up to two 10/100/1000Mbps ports for
cost effective high-performance network connectivity. With its 8.8Gbps
non-blocking switch fabric, the Switch can also provide a local, high
bandwidth, Fast Ethernet network for your departmental backbone.
This Switch also supports store-and-forward forwarding scheme to
ensure low latency and high data integrity, eliminates unnecessary
trafc and relieves congestion on critical network paths. With an
intelligent address recognition algorithm, Switch could recognize up to
8K different MAC address and enables ltering and forwarding at full
wire speed.
2.1.2 FGSW-2620 Front Panel
Figure 2-1 shows front panel of FGSW-2620.
Figure 2-1 FGSW-2620 Front Panel

9
2.1.3 LED Indicators
System
LED Color Function
PWR Green Lights to indicate that the Switch is powered on.
Per 10/100Mbps port
LED Color Function
LNK/ACT Green
Lights: to indicate the link through that port is
successfully established.
Blink: indicate that the Switch is actively sending
or receiving data over that port.
10/100 Orange
Steady Lights: to indicate the port is run at
100Mbps.
Blinking Slowly: to indicate the port is run at
10Mbps.
Per 10/100/1000Base-T port
LED Color Function
LNK/ACT Green
Lights: to indicate the link through that port
is successfully established.
Blink: indicate that the Switch is actively
sending or receiving data over that port.
10/100/1000 Green
Steady Lights: indicate the port is operating
at 1000Mbps.
Blinking Slowly: to indicate the port is run
at 100Mbps.
Off: to indicate the port is run at 10Mbps.

10
2.1.4 FGSW-2620 Rear Panel
The rear panel of the Switch indicates an AC inlet power socket, which
accepts input power from 100 to 240VAC, 50-60Hz. Figure 2-2 shows
Rear panel of the Switch.
Figure 2-2 Rear Panel of FGSW-2620
Power Notice:
1. The device is a power-required device, it means, it will not work till it
is powered. If your networks should active all the time, please con-
sider using UPS (Uninterrupted Power Supply) for your device. It will
prevent you from network data loss or network downtime.
2. In some area, installing a surge suppression device may also help
to protect your Switch from being damaged by unregulated surge or
current to the Switch or the power adapter.
2.2 Installing a FGSW-2620
This part describes how to install your Ethernet Switch and make
connections to the Switch. Please read the following topics and perform
the procedures in the order being presented.
To install your Switch on a desktop or shelf, simply complete the
following steps.
2.2.1 Desktop Installation
To install a Switch on a desktop or shelf, simply complete the following
steps:
Step1: Attach the rubber feet to the recessed areas on the bottom
of the Switch.
Step2: Place the Switch on a desktop or shelf near an AC power
source.

11
Step3: Keep enough ventilation space between the Switch and the
surrounding objects.
Note
When choosing a location, please keep in mind the
environmental restrictions discussed in Chapter 1, Section
4, Specification.
Step4: Connect your Switch to network devices
A.Connect one end of a standard network cable to the 10/100
RJ-45 ports on the front of the Switch.
B. Connect the other end of the cable to the network devices
such as printer servers, workstations or routers…etc.
Note
Connection to the Switch requires UTP Category 5 network
cabling with RJ-45 tips. For more information, please see
the Cabling Specification in Appendix A.
Step5: Supply power to the Switch.
A.Connect one end of the power cable to the Switch.
B. Connect the power plug of the power cable to a standard wall
outlet then power on the Switch.
When the Switch receives power, the Power LED should remain solid
Green.
2.2.2 Rack Mounting
To install the Switch in a 19-inch standard rack, follow the instructions
described below.
Step1: Place your Switch on a hard at surface, with the front panel
positioned towards your front side.

12
Step2: Attach a rack-mount bracket to each side of the Switch with
supplied screws attached to the package. Figure 2-3 shows
how to attach brackets to one side of the Switch.
Figure 2-3 Attaching the brackets to the Switch
Caution:
You must use the screws supplied with the mounting brackets. Damage
caused to the parts by using incorrect screws would invalidate your
warranty.
Step3: Secure the brackets tightly.
Step4: Follow the same steps to attach the second bracket to the
opposite side.

13
Step5: After the brackets are attached to the Switch, use suitable
screws to securely attach the brackets to the rack, as shown
in gure 2-4.
Figure 2-4 Mounting the Switch in a Rack
Step6: Proceed with the steps 4 and steps 5 of section 2.2.1 Desk-
top Installation to connect the network cabling and supply
power to your Switch.

14
3. Switch Operation
3.1 Address Table
The Switch is implemented with an address table. This address table
composed of many entries. Each entry is used to store the address
information of some node in network, including MAC address, port
no, etc. This information comes from the learning process of Ethernet
Switch.
3.2 Learning
When one packet comes in from any port, the Switch will record the
source address, port no. And the other related information in address
table. This information will be used to decide either forwarding or
ltering for future packets.
3.3 Forwarding & Filtering
When one packet comes from some port of the Ethernet Switching,
it will also check the destination address besides the source address
learning. The Ethernet Switching will lookup the address-table for the
destination address. If not found, this packet will be forwarded to all
the other ports except the port, which this packet comes in. And these
ports will transmit this packet to the network it connected. If found,
and the destination address is located at different port from this packet
comes in, the Ethernet Switching will forward this packet to the port
where this destination address is located according to the information
from address table. But, if the destination address is located at the
same port with this packet comes in, then this packet will be ltered.
Thereby increasing the network throughput and availability.
3.4 Store-and-Forward
Store-and-Forward is one type of packet-forwarding techniques. A
Store-and-Forward Ethernet Switching stores the incoming frame in

15
an internal buffer, do the complete error checking before transmission.
Therefore, no error packets occurrence, it is the best choice when a
network needs efciency and stability.
The Ethernet Switch scans the destination address from the packet-
header, searches the routing table provided for the incoming port
and forwards the packet, only if required. The fast forwarding makes
the switch attractive for connecting servers directly to the network,
thereby increasing throughput and availability. However, the switch is
most commonly used to segment existence hubs, which nearly always
improves overall performance. An Ethernet Switching can be easily
congured in any Ethernet network environment to signicantly boost
bandwidth using conventional cabling and adapters.
Due to the learning function of the Ethernet switching, the source
address and corresponding port number of each incoming and outgoing
packet are stored in a routing table. This information is subsequently
used to lter packets whose destination address is on the same
segment as the source address. This connes network trafc to its
respective domain, reducing the overall load on the network.
The Switch performs "Store and forward" therefore, no error packets
occur. More reliably, it reduces the re-transmission rate. No packet loss
will occur.
3.5 Auto-Negotiation
The STP ports on the Switch have built-in “Auto-negotiation”. This
technology automatically sets the best possible bandwidth when a
connection is established with another network device (usually at Power
On or Reset). This is done by detect the modes and speeds at the
second of both device is connected and capable of, both 10Base-T and
100Base-TX devices can connect with the port in either Half- or Full-
Duplex mode. 1000Base-T can be only connected in Full-duplex mode.

16
If attached device is: 100Base-TX port will set to:
• 10Mbps, no auto-negotiation 10Mbps
• 10Mbps, with auto-negotiation 10/20Mbps (10Base-T/Full-Duplex)
• 100Mbps, no auto-negotiation 100Mbps
• 100Mbps, with auto-
negotiation
100/200Mbps (100Base-TX/Full-
Duplex)

17
4. Troubleshooting
This chapter contains information to help you solve issues. If the
Ethernet Switch is not functioning properly, make sure the Ethernet
Switch was set up according to instructions in this manual.
The per port LED is not lit
Solution: Check the cable connection of the FGSW-2620.
Performance is bad
Solution: Check the speed duplex mode of the partner device. The
FGSW-2620 is run at Auto-negotiation mode and if the
partner is set to half duplex, then the performance will be
poor.
Per port LED is lit, but the trafc is irregular
Solution: Check that the attached device is not set to dedicate full
duplex. Some devices use a physical or software switch to
change duplex modes. Auto-negotiation may not recognize
this type of full-duplex setting.
Why the Switch doesn’t connect to the network
Solution: Check per port LED on the switch. Try another port on the
Switch Make sure the cable is installed properly Make sure
the cable is the right type Turn off the power. After a while,
turn on power again.

18
Appendix A Networking Connection
A.1 Switch's RJ-45 Pin Assignments
1000Mbps, 1000Base T
Contact MDI MDI-X
1BI_DA+ BI_DB+
2BI_DA- BI_DB-
3BI_DB+ BI_DA+
4BI_DC+ BI_DD+
5BI_DC- BI_DD-
6BI_DB- BI_DA-
7BI_DD+ BI_DC+
8BI_DD- BI_DC-
10/100Mbps, 10/100Base-TX
RJ-45 Connector pin assignment
Contact
MDI
Media Dependant
Interface
MDI-X
Media Dependant
Interface -Cross
1 Tx + (transmit) Rx + (receive)
2 Tx - (transmit) Rx - (receive)
3 Rx + (receive) Tx + (transmit)
4, 5 Not used
6 Rx - (receive) Tx - (transmit)
7, 8 Not used

19
A.2 RJ-45 cable Pin Assignments
The standard RJ-45 receptacle/connector
There are 8 wires on a standard UTP/STP cable and each wire is color-
coded. The following shows the pin allocation and color of straight cable
and crossover cable connection:
Figure A-1: Straight-Through and Crossover Cable
Please make sure your connected cables are with same pin assignment
and color as above picture before deploying the cables into your
network.
