Planet IGS-10020PT User manual

Industrial L2+ 8-Port Gigabit 802.3af/at PoE
+ 2-Port 100/1000X SFP Managed Switch
IGS-10020PT/IGS-10020HPT
Quick Installation Guide

Table of Contents
1. Package Contents ....................................................................................... 3
2. Requirements ............................................................................................. 4
3. Wiring the Power Inputs.............................................................................. 5
4. Terminal Setup ........................................................................................... 7
4.1 Logging on to the Console.................................................................... 8
4.2 ConguringIPAddress......................................................................... 9
5. Starting Web Management .........................................................................12
5.1 LoggingintotheIndustrialManagedPoE+Switch ................................12
5.2. SavingConguration...........................................................................16
6. RecoveringBacktoDefaultConguration.....................................................18
7. Customer Support .....................................................................................19

3
1. Package Contents
Thank you for purchasing PLANET L2+ Industrial Managed Gigabit PoE Switch,
such as IGS-10020PT and IGS-10020HPT. The descriptions of these models are as
follows:
IGS-10020PT/
IGS-10020HPT:
Industrial8-Port10/100/1000T802.3af/atPoE+2-Port
100/1000XSFPManagedSwitch
“Industrial Managed PoE+ Switch” mentioned in this Quick Installation Guide
referstotheabovemodels.
Open the box of the Industrial Managed PoE+ Switch and carefully unpack it. The
boxshouldcontainthefollowingitems:
zTheIndustrialManagedPoE+Switchx1
zQuickInstallationGuidex1
zDIN-railKitx1
zWallMountingKitx1
zDB9 to RJ45 Interface RS232 Console Cable x 1
zDust Cap (Please refer to the table below.)
RJ45 Dust Cap SFPDustCap
IGS-10020PT/IGS-10020HPT: 9 2
If any item is found missing or damaged, please contact your local reseller for
replacement.

4
2. Requirements
zWorkstations running Windows XP/2003/Vista/7/8/10/2008, MAC OS X or later,
Linux,UNIX,orotherplatformsarecompatiblewithTCP/IPprotocols.
zWorkstationsareinstalledwithEthernetNIC(NetworkInterfaceCard)
zSerial Port Connection (Terminal)
The above Workstations come with COM Port (DB9) or USB-to-RS232
converter.
The above Workstations have been installed with terminal emulator, such as
HyperTerminalincludedinWindowsXP/2003.
 Serial cable -- one end is attached to the RS232 serial port, while the other
endstotheRJ45consoleportoftheIndustrialManagedPoE+Switch.
zEthernetPortConnection
 Networkcables--Usestandardnetwork(UTP)cableswithRJ45connectors.
 The above PC is installed with Web browser and JAVA runtime environment
plug-in.
Note
It is recommended to use Internet Explorer 8.0 or above to access
the Industrial Managed PoE+ Switch. If the Web interface of the
Industrial Managed PoE+ Switch is not accessible, please turn off
theanti-virussoftwareorfirewallandthentryitagain.

5
3. Wiring the Power Inputs
TheUpper Panel of theIndustrial ManagedPoE+Switchindicates aDCinlet power
socketandconsistsofoneterminalblockconnectorwithin6contacts.Pleasefollow
the steps below to insert the power wire.
1.Insert positive/negative DC power wires into Contacts 1 and 2 for Power 1, or
Contacts5and6forPower2.
zIGS-10020PT:48V~56VDC
Input DC 48~56V
DC1 DC2
Fault
DI1 DO0 DO1DI0 GNDGND
1A@24V
Figure 3-1: IGS-10020PT Upper Panel
zIGS-10020HPT:DC12~48V
DI1 DO0 DO1DI0 GNDGND
1A@24V
Input DC 12-48V
DC1 DC2
Fault
Figure 3-2: IGS-10020HPT Upper Panel

6
2.Tightenthewire-clampscrewsforpreventingthewiresfromloosening.
1 2 3 4 5 6
V1+ V1- V2+ V2-
Power 1 Power 2
Positive(+)Pin Negative(-)Pin
IGS-10020PT/IGS-10020HPT Pin1/5 Pin2/6
Note
The wire gauge for the terminal block should be in the range from
12to24AWG.

7
4. Terminal Setup
To congure the system, connect a serial cable to a COM port on a PC or
notebook computer and to RJ45 type serial (console) port of the Industrial
Managed PoE+ Switch. The console port of the Industrial Managed PoE+ Switch is
DCE already, so that you can connect the console port directly through PC without
theneedofnullmodem.
PC/Workstation
with
Terminal emulation software
RJ45 to DB9 RS232 Cable
Serial Port
IP Address:
192.168.0.100
IGS Industrial Managed Switch
Figure 4-1: Industrial Managed PoE+ Switch Console Connectivity
A terminal program is required to make the software connected to the Industrial
Managed PoE+ Switch. Windows’ Hyper Terminal program may be a good choice.
TheHyperTerminalcanbeaccessedfromtheStartmenu.
1. Click START, then Programs, AccessoriesandthenHyper Terminal.
2.When the following screen appears, make sure that the COM port should be
conguredas:
Baud:115200
Parity:None
Data Bits: 8
Stop Bits: 1
FlowControl:None  
Figure 4-2: COM Port Conguration

8
4.1 Logging on to the Console
Once the terminal has been connected to the device, power on the Industrial
ManagedPoE+Switchandtheterminalwilldisplay“runningtestingprocedures”.
Note
The following console screen is based on the IGS-10020HPT.
The display of the IGS-10020PT is the same as that of the IGS-
10020HPT.
When the following dialog box shown in Figure 4-3 appears, please enter the
factorydefaultusername“admin”andpassword“admin”.
Username:admin
Password:admin
Figure 4-3: Console Login Screen
Note
1.For security reason, please change and memorize the new pass-
wordafterthisfirstsetup.
2.Only accept command in lowercase letter under console inter-
face.

9
4.2 ConguringIPAddress
The Industrial Managed PoE+ Switch is shipped with default IP address shown
below:
IPAddress:192.168.0.100
Subnet Mask: 255.255.255.0
To check the current IP address or modify a new IP address for the Industrial
ManagedPoE+Switch,pleaseusetheprocedureasfollows:
Display of the current IP Address
1.Atthe“#”prompt,enter“show ip interface brief”.
2.ThescreendisplaysthecurrentIPaddressshowninFigure4-4.
Figure 4-4: IP Information Screen

10
CongurationoftheIPAddress
3.At the “#” prompt, enter the following command and press <Enter> as shown
inFigure4-5.
The previous command would apply the following settings for the Industrial
ManagedPoE+Switch.
IPAddress:192.168.1.100
Subnet Mask: 255.255.255.0
Figure 4-5: Conguring IP Address Screen
4.Repeatstep1tocheckiftheIPaddresshaschanged.

11
Storethecurrentswitchconguration
5.Atthe“#”prompt,enterthefollowingcommandandpress<Enter>.
#copyrunning-congstartup-cong
Figure 4-6: Saving Current Conguration Command Screen
If the IP is successfully congured, the Industrial Managed PoE+ Switch will apply
the new IP address setting immediately. You can access the Web interface of the
IndustrialManagedPoE+SwitchthroughthenewIPaddress.
Note
If you are not familiar with the console command or the related
parameter, enter “help” anytime in console to get the help
description.

12
5. Starting Web Management
The following shows how to start up the Web Management of the Industrial
Managed PoE+ Switch. Note the Industrial Managed PoE+ Switch is congured
through an Ethernet connection. Please make sure the manager PC must be set to
the same IP subnet address.
For example, the default IP address of the Industrial Managed PoE+ Switch is
192.168.0.100, then the manager PC should be set to 192.168.0.x (where x
is a number between 1 and 254, except 100), and the default subnet mask is
255.255.255.0.
IP Address: 192.168.0.x
IP Address: 192.168.0.100
IGS Industrial Switch
RJ45/UTP-Cable
Figure 5-1: IP Management Diagram
5.1 Logging in to the Industrial Managed PoE+ Switch
1.Use Internet Explorer 8.0 or above for Web browser and enter IP address
http://192.168.0.100 (the factory-default IP address) to access the Web
interface.
2.When the following dialog box appears, please enter the default user name
“admin”andpassword“admin”(orthepasswordyouhavechangedbefore)as
showninFigure5-2.
DefaultIPAddress:192.168.0.100
DefaultUserName:admin
DefaultPassword:admin
Figure 5-2: Web Login Screen

13
Note
Thefollowingweb screenbased onIGS-10020HPT willbe thesame
asthatofIGS-10020PT.
3.Afterenteringthepassword,themainscreenappearsasshowninFigure5-3.
Figure 5-3: Web Main Screen of Industrial Managed PoE+ Switch
The Switch Menu on the top of the Web page lets you access all the commands
and statistics the Industrial Managed PoE+ Switch provides. The Switch Menu
always contains one or more buttons, such as “System”, “Switching”, “QoS”,
“Security”,“PoE”,“Ring”,“ONVIF”and“Maintenance”.
Figure 5-4: Switch Menu
Figure 5-5: Switch Menu -- System

14
Figure 5-6: Switch Menu – Switching
Figure 5-7: Switch Menu -- QoS
Figure 5-8: Switch Menu -- Maintenance

15
Figure 5-9: Switch Menu -- Security
Figure 5-10: Switch Menu -- PoE
Figure 5-11: Switch Menu – Ring

16
Figure 5-12: Switch Menu – ONVIF
Note
If you are not familiar with Switch functions or the related param-
eter, press “Help icon” anytime on the Web page to get the help
description.
Now, you can use the Web management interface to continue the Switch
management or manage the Switch by console interface.
Pleaserefertotheuser’smanualformore.
5.2.SavingConguration
To save all applied changes and set the current conguration as a startup
conguration on the Web user interface, the startup-conguration le will be
loadedautomaticallyacrossasystemreboot.
1. Click the Save icon on the top Switch Menu bar.
Figure 5-13: Save Cong -- Hot Key
2. Press the “SaveConguration” button.

17
3. Or the other way to save the setting is to Click Maintenance, Save Startup
Cong.
Figure 5-14: Save Cong -- Maintenance

18
6.RecoveringBacktoDefaultConguration
To reset the IP address to the default IP address “192.168.0.100” and the
user password to factory default mode (default password is admin), press the
hardware-based reset button on the front panel for about 10 seconds. After the
device is rebooted, you can login the management Web interface within the same
subnet of 192.168.0.xx and default password. Be noted that all the previous
setupswillbedisappearedafterthefactorydefaultresetismade.
9
LNK/ACT1000LNK/ACT1000
10
Console
115200,N,8,1
P1 P2
Ring R.O.
FAULT
910
100/1000X SFP
RESET
LNK
ACT
LNK ACT
PoE-in-Use
Figure 6-1: IGS-10020PT/IGS-10020HPT Reset Button

19
7. Customer Support
Thank you for purchasing PLANET products. You can browse our online FAQ
resourceon PLANET website rst tocheck if itcould solve yourissue. Ifyou need
moresupportinformation,pleasecontactPLANETswitchsupportteam.
PLANETonlineFAQs:
http://www.planet.com.tw/en/support/faq
Switchsupportteammailaddress:
[email protected]
IGS-10020PT/IGS-10020HPTUser’sManual:
https://www.planet.com.tw/en/support/downloads?method=category&c1=industrial-
ethernet&p=&type=3
