Planet LRP-822CS User manual

Multi-port Coax + 2-port 10/100/1000T + 2-port
100/1000X SFP Long Reach PoE over Coaxial
Managed Switch
LRP-822CS / LRP-1622CS
Quick Installation Guide

Table of Contents
1. Package Contents ....................................................................................... 3
2. Requirements ............................................................................................. 4
3. Terminal Setup ........................................................................................... 5
4. Logon to the Console .................................................................................. 6
5. ConguringIPAddressviatheConsole ........................................................ 7
6. SavingtheCongurationviatheConsole...................................................... 9
7. Starting Web Management .........................................................................10
8. Starting Long Reach PoE Communication .....................................................12
9. SavingCongurationviatheWeb ...............................................................16
10.RecoveringBacktoDefaultConguration ....................................................17
11. Customer Support.....................................................................................18

3
1. Package Contents
ThankyouforpurchasingPLANET Multi-portCoax +2-port 10/100/1000T+ 2-port
100/1000XSFPLongReachPoEoverCoaxialManagedSwitch.
Thedescriptionofthismodelisshownbelow:
LRP-822CS 8-portCoax+2-port10/100/1000T+2-port100/1000XSFP
LongReachPoEoverCoaxialManagedSwitch
LRP-1622CS 16-portCoax+2-port10/100/1000T+2-port100/1000XSFP
LongReachPoEoverCoaxialManagedSwitch
“LRP Managed Switch” is used as an alternative name in this Quick Installation
Guide.
Open the box of the LRP Managed Switch and carefully unpack it. The box should
containthefollowingitems:
zTheLRPManagedSwitchx1
zQuickInstallationGuidex1
zRubberFeetx4
zPowerCordx1
zRS232toRJ45ConsoleCablex1
zSFPDustCapx2
zBNCFemaleDustCapx8(LRP-822CS)
zBNCFemaleDustCapx16(LRP-1622CS)
zWarningStickerx8(LRP-822CS)
zWarningStickerx16(LRP-1622CS)
zRack-mountAccessoryKitx1
If any item is found missing or damaged, please contact your local reseller for
replacement.

4
2. Requirements
zWorkstations running Windows XP/2003/Vista/7/8/2008, MAC OS X or later,
Linux,UNIX,orotherplatformsarecompatiblewithTCP/IPprotocols.
zWorkstationsareinstalledwithEthernetNIC(NetworkInterfaceCard)
zSerial Port Connection(Terminal)
 The above Workstations come with COM Port (DB9) or USB-to-RS-232
converter.
 The above Workstations have been installed with terminal emulator, such as
HyperTerminalincludedinWindowsXP/2003.
 Serial cable -- one end is attached to the RS232 serial port, while the other
endtotheconsoleportoftheLRPManagedSwitch.
zEthernet Port Connection
 Networkcables--Usestandardnetwork(UTP)cableswithRJ45connectors.
 The above PC is installed with Web Browser and JAVA runtime environment
plug-in.
Note
It is recommended to use Internet Explore 8.0 or above to access
the LRP Managed Switch. If the Web interface of the LRP Managed
Switch is not accessible, please turn off the anti-virus software or
firewallandthentryitagain.

5
3. Terminal Setup
To congure the system, connect a serial cable to a COM port on a PC or
notebook computer and to the RJ45 type of the console port of the LRP Managed
Switch.
Managed Switch
PC / Workstation
with
Terminal Emulation Software
Serial Port
RS232 to RJ45 Cable
Console Port
RJ45
Figure 3-1: LRP Managed Switch Console Connectivity
A terminal program is required to make the software connection to the LRP
ManagedSwitch.
1. Run terminal program on the OS.
2.When the following screen appears, make sure that the COM port should be
conguredas:
zBaud :115200
zDatabits :8
zParity :None
zStopbits :1
zFlowcontrol :None
Figure 3-2: COM Port Conguration

6
4. Logon to the Console
Once the terminal is connected to the device, power on the LRP Managed Switch,
and the terminal will display “running testing procedures”. Then, the following
message asks to log-in user name and password. The factory default user name
andpasswordareshownasfollows,andtheloginscreeninFigure4-1appears.
Username:admin
Password:admin
Figure 4-1: LRP Managed Switch Console Login Screen
The user can now enter commands to manage the LRP Managed Switch. For a
detaileddescriptionofthecommands,pleaserefertothefollowingchapters.
Note
1.For security reason, please change and memorize the new
passwordafterthisfirstsetup.
2.Only accept command in lowercase letter under console
interface.

7
5.ConguringIPAddressviatheConsole
TheLRPManagedSwitchisshippedwithdefaultIPaddressasfollows:
IPAddress:192.168.0.100
SubnetMask:255.255.255.0
To check the current IP address or modify a new IP address for the Switch, please
usetheproceduresasfollows:
Show the current IP address
1.Atthe“LRP-series#”prompt,enter“show ip”.
2.The screendisplaysthe currentIP address,SubnetMask andGatewayasshown
inFigure5-1.
Figure 5-1: IP Information Screen
 ConguringIPaddress
3.Atthe“LRP-series#”prompt,enter“congure”.
4.Atthe“LRP-series (cong)#”prompt,enterthefollowingcommandandpress
<Enter>asshowninFigure5-2.
LRP-series(cong)# ip address 192.168.1.100 mask 255.255.255.0
LRP-series(cong)# ip default-gateway 192.168.1.254

8
ThepreviouscommandwouldapplythefollowingsettingsfortheSwitch.
IPAddress:192.168.1.100
SubnetMask:255.255.255.0
Gateway:192.168.1.254
Figure 5-2: IP Address Screen
5.RepeatStep1tocheckiftheIPaddressischanged.
If the IP is successfully congured, the LRP Managed Switch will apply the new IP
addresssettingimmediately. Youcan accessthe Web interfaceof theLRP Managed
SwitchthroughthenewIPaddress.
Note
If you are not familiar with console command or the related
parameter,enter“?”anytimeinconsoletogetthehelpdescription.

9
6.SavingtheCongurationviatheConsole
In the switch, the running conguration le stores in the RAM. In the current
version, the running conguration sequence running-cong can be saved from the
RAMtoFLASHbywritingthecommand or copying the running-cong startup-
cong command, so that the running conguration sequence becomes the startup
congurationle,whichiscalledcongurationsave.
1.At the “LRP-series#” prompt, enter “copy running-cong startup-cong”
asshowninFigure6-1.
Figure 6-1: The Conguration Screen

10
7. Starting Web Management
The following shows how to start up the Web Management of the LRP Managed
Switch. Note the LRP Managed Switch is congured through an Ethernet
connection. Please make sure the manager PC must be set on the same IP
subnet address.
Forexample,thedefaultIPaddressoftheLRPManagedSwitchis192.168.0.100,
then the manager PC should be set at 192.168.0.x (where x is a number
between1and254,except100),andthedefaultsubnetmaskis255.255.255.0.
PC / Workstation
with Web Browser
192.168.0.x
Managed Switch
RJ45/UTP Cable
IP Address:
192.168.0.100
Figure 7-1: IP Management Diagram
Logging in to the LRP Managed Switch
1.Use Internet Explorer 8.0 or above Web browser and enter IP address
http://192.168.0.100 toaccesstheWebinterface.
2.When the following dialog box appears, please enter the default user name and
password“admin”.TheloginscreeninFigure7-2appears.
DefaultUsername:admin
DefaultPassword:admin
Figure 7-2: Login Screen

11
3.Afterenteringthepassword,themainscreenappearsasFigure7-3shows.
Figure 7-3: Web Main Screen of LRP Managed Switch
The Switch Menu on the left of the Web page lets you access all the commands
andstatisticstheLRPManagedSwitchprovides.
Figure 7-4: Switch Menu
Now, you can use the Web management interface to continue the Switch
management.
Pleaserefertotheuser’smanualformore.

12
8. Starting Long Reach PoE Communication
Thefollowingshows howtostartup theLong Reach PoE Communicationof the
LRPManagedSwitchfromWebManagement.
Note
The LRP Managed Switch is configured DISABLED Long Reach PoE
functionasdefault.
Connect the Coaxial Cable
1.Insert thecoaxial cablewith oneside beingthe75ΩBNC plugconnector intothe
LongReachEthernetcoaxialinterface.
2.Connect the other end of the cable to a device with Long Reach Ethernet
coaxial extenderinstalled.
3.TighttheBNCmaleconnectorgently.
5C2V/RG6 75Ω Coaxial Cable RJ45
PoE PT Camera
Long Reach Power over Ethernet
2
1
LRP-822CS
LRP-101CE

13
4.Enable Long Reach Power over Ethernet function for the all LRP ports from
WebUI.
5.Check the LNK LED of the Long Reach Power over Ethernet interface on the
front of the LRP Managed Switch. Ensure that the Long Reach Power over
Ethernetinterfaceisoperatingcorrectly.
Note
1.Before installation, please consider the distance and watts
value demand for PD devices. The LRP Managed Switch and
LRP Extender PoE output capacity and upload / download
performance depend on the length of coaxial cable. You can
refertomanualchapter1.5fortheinformation.
2.As there are various resistance values in the category of
RG-59/U or RG-6/U cable, the actual data rate will vary on the
qualityofthecopperwireandenvironmentalfactors.

14
Remove the connected the Coaxial Cable
1.Makesurethereisnonetworkactivityanymore
2.Disable Long Reach Power over Ethernet function for the all LRP ports from
WebUI.
3.LoosetheBNCmaleconnectorgently.
4.Pulloutthecoaxialcablegently.
5C2V/RG6 75Ω Coaxial Cable RJ45
PoE PT Camera
Long Reach Power over Ethernet
1
2
LRP-822CS
LRP-101CE

15
Note
Neverpull outthecoaxial cablewithout disabledLong Reach Power
overEthernet functionfor the portfrom WebUI. Directlypulling out
the coaxial cable could damage the Long Reach Ethernet coaxial
extender and the BNC female connector of the LRP Managed
Switch.
Caution
1. The package contains warning stickers, which should be stuck on
the coaxial cable connector before using PLANET LRP-822CS /
LRP-1622CS and LRP extender. If connected with Non-PLANET
LRP series extender equipment, it might cause damage to the
equipment.
2.After LRP PoE port enabled, the center pin of the coaxial cable
iswith electricity. Donottouch centerpinor connectthis endto
anynon-PLANETLRPequipments.
Warning:
This side of connector
contains electric power. Please be
careful before plugging into
the device.
Please be reminded that the cable con
Do Not Touch
the Center Pin

16
9.SavingCongurationviatheWeb
In the LRP Managed Switch, the running conguration le stores in the RAM. In
the current version, the running conguration sequence of running-cong can be
saved from the RAM to FLASH by “Save Congurations to FLASH” function, so
that the running conguration sequence becomes the startup conguration le,
whichiscalledcongurationsave.
To save all applied changes and set the current conguration as a startup
conguration, the startup-conguration le will be loaded automatically across a
system reboot.
1. Click “Save > Save Congurations to FLASH” to login “Conguration
Manager”Page.
2. Press the “Apply”buttontosaverunningcongurationtostartupconguration.

17
10.RecoveringBacktoDefaultConguration
IP Address has been changed or admin password has been
forgotten –
To reset the IP address to the default IP Address “192.168.0.100” or reset the
login password to default value, press the hardware reset button on the front
panel for about 10 seconds. After the device is rebooted, you can login the
managementWebinterfacewithinthesamesubnetof192.168.0.xx.
1 2
345678
ACTLNK
1000
GE2
GE1
GE4
GE3
GE2
GE1
GE4
GE3
FAN 3
PWR
FAN 1
FAN 2
Alert
LRP-822CS 8-Port
Long Reach PoE + 2-Port 10/100/1000T + 2-Port 100/1000X SFP Managed Switch
Console
115200, N, 8, 1
RESET
SYS
PWR PoE In-Use
LNK
The LRP interface is
allowed to connect to
LRP Extender only.
CAUTION
Figure 10-1: LRP-822CS Reset Button
LRP-1622CS
2
1
4
3
6
5
8
7
10
9
12
11
14
13
16
15
ACTLNK
1000
LNK
GE2
GE1
GE4
GE3
GE2
GE1
GE4
GE3
FAN 1
PoE PWR
FAN 3
FAN 2
Alert
Console
115200, N, 8, 1
RESET
SYS
1 2 3
4 5 6 7 8 9 10 11 12 13 14 15 16
PWR
The LRP interface is
allowed to connect to
LRP Extender only.
CAUTION
Figure 10-2: LRP-1622CS Reset Button

18
11. Customer Support
Thank you for purchasing PLANET products. You can browse our online FAQ
resourceandUser’s ManualonPLANET Website rst tocheck ifit couldsolveyour
issue.Ifyouneed moresupport information,please contactPLANETswitchsupport
team.
PLANETonlineFAQ:
http://www.planet.com.tw/en/support/faq.php?type=1
Switchsupportteammailaddress:
[email protected]
LRP-822CS/LRP-1622CSUser’sManual:
http://www.planet.com.tw/en/support/download.php?type1=1&model=&type=3
(PleaseselectyourswitchmodelnamefromtheProductModeldrop-downmenu)
Copyright © PLANET Technology Corp. 2015.
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their
respective owners.
