Planet GS-6320 Series User manual

L3 Multiple Gigabit + 2-/4-Port 10G SFP+
Managed Switch
GS-6320 LCD Switch Series
Quick Installation Guide

Table of Contents
1. Package Contents ....................................................................................... 3
2. Requirements ............................................................................................. 4
3. Terminal Setup ........................................................................................... 5
3.1 Logging on to Console ......................................................................... 6
 3.2 ConguringIPAddress......................................................................... 6
4. Starting Web Management .......................................................................... 9
 4.1 LoggingintotheManagedPoESwitch .................................................. 9
 4.2 SavingCongurationviaWeb ..............................................................11
5. RecoveringBacktoDefaultConguration.....................................................13
6. LCD Touch Screen......................................................................................14
7. Customer Support .....................................................................................16

3
1. Package Contents
Thank you for purchasing PLANET L3 Multiple Gigabit + 2-/4-Port 10G SFP+
ManagedSwitchwithLCD.Thedescriptionofthismodelisshownbelow:
ModelName PoEPorts 10GSFP+ 10GRJ45 PoE
Budget
Power
Input
GS-6320-24UP2T2XV 24-Port802.3bt 2 2 600W AC/DC
“Managed PoE Switch” is used as an alternative name in this Quick Installation
Guide.
Open the box of the Managed PoE Switch and carefully unpack it. The box should
containthefollowingitems:
zTheManagedPoESwitch
zQuickInstallationGuide
zRJ45toRS232Cable
zRubberFeet
zTwoRack-mountingBracketswithAttachmentScrews
zPowerCord
zSFPDust-proofCapx2
If any of these pieces are missing or damaged, please contact your dealer
immediately; if possible, retain the carton including the original packing material,
andusethemagaintorepacktheproductincasethereisaneedtoreturnittous
for repair.

4
2. Requirements
zWorkstations running Windows 10/XP/2003/Vista/7/8/2008, MAC OS X or later,
Linux,UNIX,orotherplatformsarecompatiblewithTCP/IPprotocols.
zWorkstationsareinstalledwithEthernetNIC(NetworkInterfaceCard)
zSerialPortConnection(Terminal)
 The above Workstations come with COM Port (DB9) or USB-to-RS232
converter.
 The above Workstations have been installed with terminal emulator, such as
HyperTerminalincludedinWindowsXP/2003.
 Serial cable -- one end is attached to the RS232 serial port, while the other
endtotheconsoleportoftheManagedPoESwitch.
zEthernetPortConnection
 Networkcables--Usestandardnetwork(UTP)cableswithRJ45connectors.
 The above PC is installed with Web browser and JAVA runtime environment
plug-in.
Note
It is recommended to use Internet Explorer 8.0 or above to access
the Managed PoE Switch. If the Web interface of the Managed PoE
Switch is not accessible, please turn off the anti-virus software or
firewallandthentryitagain.

5
3. Terminal Setup
To congure the system, connect a serial cable to a COM port on a PC or
notebookcomputerandtoRJ45typeofserialportoftheManagedPoESwitch.
Managed Switch
PC / Workstation
with
Terminal Emulation Software
Serial Port
RS232 to RJ45 Cable
Console Port
RJ45
Figure 3-1: Managed PoE Switch Console Connectivity
A terminal program is required to make the software connection to the Managed
PoESwitch.
1. Run terminal program on the OS.
2.When the following screen appears, make sure that the COM port should be
conguredas:
Baud:115200
Databits:8
Parity:None
Stopbits:1
Flowcontrol:None
Figure 3-2: COM Port Conguration

6
3.1 Logging on to Console
Once the terminal is connected to the device, power on the Managed PoE Switch,
and the terminal will display “running testing procedures”. Then, the following
message asks to log in user name and password. The factory default user name
andpasswordareshownasfollowsandtheloginscreeninFigure3-3appears.
Username:admin
Password:admin
Figure 3-3: Managed PoE Switch Console Login Screen
The user can now enter commands to manage the Managed PoE Switch. For a
detaileddescriptionofthecommands,pleaserefertothefollowingchapters.
Note
1.For security reason, please change and memorize the new pass-
wordafterthisfirstsetup.
2.Only accept command in lowercase letter under console inter-
face.
3.2 ConguringIPAddress
TheManagedPoESwitchisshippedwithdefaultIPaddressshownbelow.
IPAddress:192.168.0.100
SubnetMask:255.255.255.0

7
To check the current IP address or modify a new IP address for the Switch, please
usetheproceduresasfollows:
Show the current IP Address
1.Atthe“#”prompt,enter“show ip interface brief”.
2.ThescreendisplaysthecurrentIPaddressasshowninFigure3-4.
Figure 3-4: IP Information Screen
 Conguring IP Address
3.At the “#” prompt, enter the following command and press <Enter> as shown
inFigure3-5.
Switch#congure terminal
Switch(cong)#interface vlan 1
Switch(cong-if-vlan)#ip address 192.168.1.100 255.255.255.0
The previous command would apply the following settings for the Managed PoE
Switch.
IPAddress:192.168.1.100
SubnetMask:255.255.255.0
Figure 3-5: Conguring IP Address Screen
4.Repeatstep1tocheckiftheIPaddresshaschanged.

8
 Store current switch conguration
5.Atthe“#”prompt,enterthefollowingcommandandpress<Enter>.
# copy running-cong startup-cong
Figure 3-6: Saving Current Conguration Command Screen
If the IP is successfully congured, the Managed PoE Switch will apply the new IP
addresssetting immediately. You canaccess theWebinterface ofthe ManagedPoE
SwitchthroughthenewIPaddress.
Note
If you are not familiar with the console command or the related
parameter, enter “help” anytime in console to get the help
description.

9
4. Starting Web Management
The following shows how to start up the Web Management of the Managed
PoE Switch. Note the Managed PoE Switch is congured through an Ethernet
connection. Please make sure the manager PC must be set to the same IP subnet
address.
Forexample,thedefaultIP address oftheManagedPoESwitchis192.168.0.100,
then the manager PC should be set to 192.168.0.x (where x is a number
between1and254,except100),andthedefaultsubnetmaskis255.255.255.0.
PC / Workstation with Web Browser
192.168.0.x
Managed Switch
RJ45/UTP Cable
IP Address: 192.168.0.100
Figure 4-1: IP Management Diagram
4.1 Logging in to the Managed PoE Switch
1.Use Internet Explorer 8.0 or above Web browser and enter IP address
https://192.168.0.100 (the factory default IP address or the one that you
havejustchangedinconsole)toaccesstheWebinterface.
2.When the following dialog box appears, please enter the default user name and
password “admin” (or the password you have changed via console). The login
screeninFigure4-2appears.
DefaultIPAddress:192.168.0.100
DefaultUsername:admin
DefaultPassword:admin
Figure 4-2: Login Screen

10
3.Afterenteringthepassword,themainscreenappearsasFigure4-3shows.
Figure 4-3: Web Main Screen of Managed PoE Switch
4.The Switch Menu on the left of the Web page lets you access all the commands
andstatisticstheManagedPoESwitchprovides.
Figure 4-4: Switch Menu
Now, you can use the Web management interface to continue the Switch
management. Please refer to the user manual for more.
Note
If you are not familiar with Switch functions or the related param-
eter, press “Help icon” anytime on the Web page to get the help
description.

11
4.2 SavingCongurationviaWeb
To save all applied changes and set the current conguration as a startup
conguration, the startup-conguration le will be loaded automatically across a
system reboot.
1. Click Maintenance > Open Switch Maintenance on the left page > Press
Save Startup Cong.

12
2. Or you can press the “Save Conguration” button.
3. Press the “Save Conguration” button to save.

13
5.RecoveringBacktoDefaultConguration
IP address has been changed or admin password has been forgotten –
To reset the IP address to the default IP address “192.168.0.100” or reset the
login password to default value, press the hardware-based reset button on the
rear panel for about 10 seconds. After the device is rebooted, you can log in the
managementWebinterfacewithinthesamesubnetof192.168.0.xx.
115200, N, 8, 1
Console
GS-6320-24UP2T2XV
2
1
4
3
SYS
AC
DC
Ring
Reset
ACT1000 LNK
ACT10/100 LNK
bt PoE
af/at PoE
Smart LCD
Reset
Figure 5-1: GS-6320 LCD Series Reset Button

14
6. LCD Touch Screen
The Managed PoE Switch has a 2.4-inch color LCD touch screen with management
functions.TaptheLCDtouchscreentowaketheLCDtouchscreen.
Figure 6-1: Waking the LCD Touch Screen
ThefactorydefaultLCDcongurationsareshownasfollows.
DefaultLCD:Enable
DefaultTouchScreen:Enable
DefaultBacklightTimeout:Enable
DefaultBacklightTimeoutTime:300
DefaultReadOnlyMode:Disable
DefaultScreen:Main Menu
DefaultTimeInterval:10
DefaultColorScheme:Dark
DefaultPinNumber:1234

15
You can use the Web management interface and click LCD, and then LCD
ManagementtochangetheLCDconguration.
Please refer to the user’s manual for more.

16
7. Customer Support
Thank you for purchasing PLANET products. You can browse our online FAQ
resourceandUser’s ManualonPLANET Website rsttocheck ifitcould solve your
issue.Ifyouneed moresupportinformation, pleasecontactPLANET switchsupport
team.
PLANETonlineFAQs:
http://www.planet.com.tw/en/support/faq.php?type=1
Switchsupportteammailaddress:
[email protected]
GS-6320LCDSeriesUser’sManual:
https://www.planet.com.tw/en/support/downloads?method=category&c1=lan-
switches&p=&type=3
(Please select your switch model name from the drop-down menu of Product
Model.)
