Planmeca ProMax User manual

Planmeca ProMax®
Cephalostat
user's manual
EN
10033034

Table of contents
1 Introduction.................................................................................................................................................1
2 Switching X-ray unit on...............................................................................................................................2
3 Main parts...................................................................................................................................................3
3.1 General view of cephalostat............................................................................................................. 3
3.2 Patient supports................................................................................................................................4
3.3 Patient positioning controls...............................................................................................................4
3.4 Emergency stop button.....................................................................................................................6
4 Preparations for exposure.......................................................................................................................... 7
4.1 Preparing X-ray unit..........................................................................................................................7
4.1.1 Attaching cephalometric patient supports............................................................................ 7
4.1.2 Removing 2D or 3D patient supports................................................................................... 9
4.2 Additional preparations on X-ray units with Dimax sensor............................................................. 10
4.2.1 Removing sensor from C-arm............................................................................................ 10
4.2.2 Attaching Dimax sensor to cephalostat..............................................................................13
4.3 Additional preparations on 3D X-ray units......................................................................................15
4.4 Preparing Planmeca Romexis........................................................................................................15
4.5 Preparing patient............................................................................................................................ 16
5 Cephalometric exposure...........................................................................................................................17
5.1 Selecting program.......................................................................................................................... 17
5.2 Selecting patient size......................................................................................................................17
5.3 Patient positioning in lateral projection...........................................................................................18
5.4 Patient positioning in posteroanterior or anteroposterior projection............................................... 21
5.5 Patient positioning in submental-vertex projection......................................................................... 25
5.6 Patient positioning in Waters’ view.................................................................................................26
5.7 Patient positioning in AP Towne projection.................................................................................... 27
5.8 Patient positioning in oblique projection......................................................................................... 28
5.9 Positioning in hand exposure......................................................................................................... 30
5.10 Adjusting exposure values for current exposure............................................................................ 31
5.11 Selecting Dynamic Exposure Control (DEC).................................................................................. 32
5.12 Adjusting DEC density....................................................................................................................33
5.13 Taking an exposure........................................................................................................................33
User's manual Planmeca ProMax

The manufacturer, assembler and importer are responsible for the safety, reliability and
performance of the unit only if:
- installation, calibration, modification and repairs are carried out by qualified
authorised personnel
- electrical installations are carried out according to the appropriate requirements such
as IEC 60364
- equipment is used according to the operating instructions.
Planmeca pursues a policy of continual product development. Although every effort is
made to produce up-to-date product documentation this publication should not be
regarded as an infallible guide to current specifications. We reserve the right to make
changes without prior notice.
COPYRIGHT PLANMECA
Publication Number 10033034 Revision 11
Release Date 20 November 2018
Table of contents
Planmeca ProMax User's manual

1 Introduction
This manual describes how to operate the Planmeca ProMax Cephalostat.
The Planmeca ProMax Cephalostat is used to position the patient’s head
accurately for taking X-ray images of the skull. The device can also be used
for taking hand images for bone age studies.
The cephalostat is attached to a 2D or 3D Planmeca ProMax X-ray unit. The
X-ray unit has a separate manual. Refer to the User’s Manual of the X-ray
unit for any general information about the X-ray unit.
NOTE
This manual is valid for Planmeca ProMax software version 3.9.6 or later.
This software version is compatible with Planmeca Romexis software
version 5.2.1.R or later. To check the software version of your X-ray unit,
select Settings > About > 4100 Component Information > ProMax SW
version.
Make sure that you are fully acquainted with the appropriate radiation
protection measures and these instructions before you use the X-ray unit.
NOTE
The X-ray unit may be used by health care professionals only.
1 Introduction
User's manual Planmeca ProMax 1

2 Switching X-ray unit on
The on / off switch is located on the underside of the stationary column top.
NOTE
To prolong the lifetime of your X-ray unit, always switch the X-ray unit off
when it is not in active use.
2 Switching X-ray unit on
2 Planmeca ProMax User's manual

3 Main parts
3.1 General view of cephalostat
1. Height adjusting button
2. Head support plate
3. Rotation scale
4. Nasal positioner
5. Dimax sensor
6. Ear posts
(see section "Patient supports" on page 4)
7. Release lever on ear post holder (patient’s left ear)
8. Collimator
3 Main parts
User's manual Planmeca ProMax 3

3.2 Patient supports
1. Ear post for patient’s left ear (marked with letter L)
2. Ear post for patient’s right ear (marked with letter R)
3. Positioning cones
4. Nasal positioner
5. Hand imaging support
3.3 Patient positioning controls
The patient positioning controls are located above the touch screen.
The up and down buttons are used to adjust the cephalostat to suit the
height of the patient.
The cephalostat moves slowly at first, then faster.
NOTE
If for some reason either of the buttons gets stuck during operation, you can
stop the up / down movement by pressing any of the other control buttons or
the positioning joystick. This is a safety measure that guarantees that the
up / down movement can be stopped in an emergency.
3 Main parts
4 Planmeca ProMax User's manual

There is an additional height adjusting button on the underside of the
cephalostat. The cephalostat moves up or down depending on which side
the button is pressed.
NOTE
Be careful that the X-ray unit does not hit the ceiling when you press the up
button. The maximum height can be adjusted to suit offices with a low
ceiling, contact your service technician for help.
NOTE
Make sure that there is no object under the X-ray unit when you press the
down button. If something is in danger of becoming trapped, release the
button immediately to stop the movement. Clear any obstruction before
pressing the button again.
NOTE
The column movement stops automatically if the emergency stop plate at
the bottom is pressed upwards. Clear any obstruction before moving the
column again.
NOTE
When positioning seated patients (e.g. in a wheelchair) always first move the
cephalostat down before you position the patient.
3 Main parts
User's manual Planmeca ProMax 5

3.4 Emergency stop button
The emergency stop button is located on the top of the stationary column.
Press the button to stop the X-ray unit operating in an emergency. When the
emergency stop button is pressed down, all movements of the X-ray unit are
blocked and the unit will not generate radiation. The up / down movement
will stop within a distance of 10 mm (0.4 in.).
A help message will appear on the touch screen. Guide the patient away
from the X-ray unit. Then release the emergency stop button. The X-ray unit
will automatically restart.
3 Main parts
6 Planmeca ProMax User's manual

4 Preparations for exposure
4.1 Preparing X-ray unit
4.1.1 Attaching cephalometric patient supports
The ear posts are marked with the letter L for the patient’s left ear and letter
R for the patient’s right ear.
The positioning cones contain small metal objects that are visible in the
image. They help you to identify the patient’s left and right side.
• The left ear post contains a ball.
• The right ear post contains a ring.
NOTE
Ensure that you position the ear posts the right way round.
NOTE
The nasal positioner has to point inward as shown.
4 Preparations for exposure
User's manual Planmeca ProMax 7

1. Lift the locking clip up and slide the ear post / nasal positioner as far up
as it will go.
2. Press the locking clip down to lock the ear post / nasal positioner in
place.
4 Preparations for exposure
8 Planmeca ProMax User's manual

4.1.2 Removing 2D or 3D patient supports
If the temple supports are in place, turn them down and remove all patient
supports from the patient support table.
If the support bars are in place, remove all patient supports from the patient
support table, including support bars, chin cup and adapter.
• To remove the support bars, first loosen the locking knobs and then pull
the support bars out.
4 Preparations for exposure
User's manual Planmeca ProMax 9

4.2 Additional preparations on X-ray units with Dimax sensor
If a Dimax sensor is attached to the C-arm, the sensor must be moved to the
cephalostat before you can take cephalometric exposures.
1. Remove Dimax sensor from
C-arm (see section "Removing
sensor from C-arm" on page
10)
2. Attach Dimax sensor to
cephalostat (see section
"Attaching Dimax sensor to
cephalostat" on page 13)
3. X-ray unit with Dimax sensor
4.2.1 Removing sensor from C-arm
NOTE
Do not remove the sensor during imaging process.
4 Preparations for exposure
10 Planmeca ProMax User's manual

1. Push in the C-arm electrical connector. This will disconnect the electrical
connection between the sensor and C-arm.
1. Turn the locking knob 180 degrees. This will release the locking
mechanism.
4 Preparations for exposure
User's manual Planmeca ProMax 11

2. Carefully pull the sensor out.
CAUTION
Do not drop the sensor. Planmeca limited warranty does not cover damage
which is due to misuse, e.g. dropping the sensor, neglect, or any cause
other than ordinary use.
Do not use the sensor if the shock indicator (marked in the figure) is red -
contact your service technician for help.
If you have any reason to believe that the sensor might be faulty, take a test
exposure before taking a patient exposure.
4 Preparations for exposure
12 Planmeca ProMax User's manual

4.2.2 Attaching Dimax sensor to cephalostat
1. Push the sensor onto the adapter on the cephalostat.
2. Turn the locking knob 180 degrees in order to complete the mechanical
connection.
4 Preparations for exposure
User's manual Planmeca ProMax 13

3. Push in the cephalostat electrical connector button on the other side.
This will make the electrical connection between the sensor and
cephalostat.
4 Preparations for exposure
14 Planmeca ProMax User's manual

4.3 Additional preparations on 3D X-ray units
If your X-ray unit has a non-rotating tube head, you must remove the 3D
sensor from the C-arm before you can take cephalometric exposures.
1. Non-rotating tube head:
Remove 3D sensor from C-arm
(refer to section "Removing
sensor from C-arm" on page
10)
2. Rotating tube head: No need
to remove 3D sensor
3. No joint: Tube head does not
rotate
4. Joint: Tube head rotates to
ceph position
5. 3D unit C-arm
4.4 Preparing Planmeca Romexis
First select the patient.
4 Preparations for exposure
User's manual Planmeca ProMax 15

Then select the cephalometric exposure.
Refer to the Planmeca Romexis User’s Manual for details on Romexis
functions.
4.5 Preparing patient
Ask the patient to remove any spectacles, hearing aids, dentures, hairpins,
and personal jewellery such as earrings, necklaces and piercings as these
can produce shadows or reflections in the image. The patient should also
remove any loose items of clothing (e.g. scarf, tie) that might get caught in
the arm structures of the X-ray unit.
Place a protective lead apron over the patient’s back if required.
NOTE
We recommend that you image patients with poor health in a sitting position.
4 Preparations for exposure
16 Planmeca ProMax User's manual
