PLANMECA INTRA X-RAY UNIT
MOBILE BASE
INSTALLATION INSTRUCTIONS
1. Attach the generator back plate to the column with eight M6x16 DIN 912 screws (1) using the 5mm
Allen key. Attach the handle to the generator back plate with two M10x40 DIN 912 screws (2) using the
8mm Allen key.
mobile_intra1.eps
1
2
Column
Generator back plate
Handle
COPYRIGHT PLANMECA 2004-05
PUBLICATION NUMBER 10006705 version
3

PLANMECA INTRA X-RAY UNIT
2/8 Planmeca Intra Mobile base Installation instructions
2. Place the column e.g. onto the mobile base package so that the generator back plate is horizontal (1).
Attach the wheel assemblies to the base plate with the M10x40 DIN 912 screws using the 8mm Allen
key (2). Place the base plate onto the package as shown on the figure below. Rotate the column holder
(located in the column) so that the base plate can be attached to the column (base plate’s and column’s
screw holes in line) (3). Make sure that the gap between the column edge and column holder is approx.
3mm (0.12 in.) so that the column is firmly attached to the base plate. Attach the base plate to the col-
umn with four M10x40 DIN 912 screws (4) using the 8mm Allen key. Lift the mobile base up.
mobile_intra2.eps
1
3
2
4
2
3 mm
Column
Column holder
Wheel assembly
Base plate
Mobile base package
Generator back plate
Make sure that the gap between the column edge and column holder is
approx. 3mm (0.12 in.) so that the column is firmly attached to the base plate.

Planmeca Intra Mobile base 3/8
Installation instructions
PLANMECA INTRA X-RAY UNIT
3. Position the cylindrical pins to the bearing housing according to the figure below. Route the Intra cables
through the horizontal arm and column. Attach the horizontal arm to the column with two attachment
screws (1) and larger (2) and smaller (3) washers.
1
2
3
mobile_intra7.eps
5x18 pin
Pin
5x14 pin
5x18 pin
5x14 pin
5x14 pin
5x14 pin
Gap
Place the cylindrical pins
to the bearing housing
according to figure beside.
Horizontal arm
Intra cables

PLANMECA INTRA X-RAY UNIT
4/8 Planmeca Intra Mobile base Installation instructions
4. Attach the bracket arm to the horizontal arm by pushing the bracket arm shaft into the bearing housing.
Secure the bracket arm with the locking plate.
5. Carefully pull the Intra cables out from the column so that they can be connected to the generator PCB.
Leave the extra length of the cables into the column. Attach the generator assembly to the generator
back plate with four attachment screws.
mobile_intra8.eps
Locking plate
M5x6 DIN 912 screw
Use 4mm Allen key.
mobile_intra5.eps
Generator assembly
Intra cables

Planmeca Intra Mobile base 5/8
Installation instructions
PLANMECA INTRA X-RAY UNIT
6. Connect the Intra cables to the Generator PCB according to the figure below.
7. Attach the generator housing to the generator assembly with three M4x6 ULS screws.
mobile_intr
a
P1
P8
mobile_intra11.eps

PLANMECA INTRA X-RAY UNIT
6/8 Planmeca Intra Mobile base Installation instructions
8. Place the cover plugs to the end of wheel assemblies, horizontal arm and column top. Insert the plugs
into the attachment screw openings on the column (see figure below). Secure the bracket arm to the
transport position with the strap supplied with the base.
CAUTION NEVER MOVE THE INTRA MOBILE X-RAY UNIT WITHOUT FIRST SECURING THE
BRACKET ARM TO THE TRANSPORT POSITION.
mobile_intra10.eps
Strap

Planmeca Intra Mobile base 7/8
Installation instructions
PLANMECA INTRA X-RAY UNIT
TRANSPORTING THE MOBILE INTRA X-RAY UNIT
CAUTION NEVER MOVE THE INTRA MOBILE X-RAY UNIT WITHOUT FIRST SECURING THE
BRACKET ARM TO THE TRANSPORT POSITION.
Secure the bracket arm to the transport position with the strap. Disconnect the Planmeca Intra from
the power supply and hang the power supply cable on the handle. Transport the x-ray unit with care.
Do not bump the unit down steps or allow the tube head to hit anything.
The mobile base has mechanical locking levers on the back wheels. Press the locking levers down
to lock the wheels. This will prevent the mobile base from moving.
If you have to move the mobile base over a low obstacle, tilt the base slightly by pressing the back
end of the wheel assembly with your foot.
mobile_intra12.eps
Brake ON
Strap
Power supply cable
mobile_intra14.eps
