Plantronics SHR2083-01 User manual

Ruggedized
Headsets
USER GUIDE

Welcome to Hands-Free
Communications from
Plantronics
To obtain the maximum performance from your headset, please
read the important information contained in this manual. It will help
you become more familiar with the features and functions of the
headset and its usage.
All SHR headset models are equipped with either electret or
dynamic noise cancelling microphones. They provide a reduction in
transmitted background noise of approximately 80% (about 18 dB).
On the circumaural models, the earcups provide approximately
22 dB of noise reduction on the covered ear.
IF YOU HAVE ANY QUESTIONS, PLEASE CALL PLANTRONICS:
1-800-544-4660

Figure A
1. Position the foam cushion(s)
over the center(s) of your
ear(s).
To adjust the headband,
lengthen or shorten the band
until it is most comfortable for
you. The “clickstop” adjustment
will keep the headband in that
position. (Refer to Figure A)
2. On models with a stabilizer
T-bar (only one ear cushion),
position the T-bar above your
ear.
3. On Behind-the-Head models,
gently bend the earhooks until
it is most comfortable for you.
Adjust rubber headband strap
to fit.
Adjusting the Headband

1. To adjust the boom, carefully
shape it with both hands as
shown. (Refer to Figure B)
2. Do not bend or twist the boom
within 1/2” of the microphone
or capsule.
3. Avoid repeated twisting of
the boom.
4. Position the microphone
approximately 1/2” from your
face at the front corner of your
mouth.
5. The microphone is covered by
a protective windscreen which
enhances the performance of
the microphone.
Figure B
Adjusting the Microphone

Figure C
6. Make certain to speak into
the front of the microphone.
You may need to rotate the
microphone in order to position
the front of the microphone
toward your lips. Speak into
the side marked TALK. If
this marking is obscured by
the windscreen, temporarily
remove it in order to determine
which side is the front of the
microphone. (Refer to Figure C)
7. Do not force the microphone
arm beyond its limits.

Many models are fitted with
Plantronics Quick Disconnect (QD)
cables which allow the user to
easily detach the headset from the
interface cable and/or amplifier
assembly. (Other terminations are
available upon request).
1. Before attempting to use your
headset, be sure that the two
Quick Disconnect cables are
connected.
2. To disconnect, grasp the Quick
Disconnect as shown and pull
straight apart. (Refer to Figure D)
Figure D
Quick Disconnect™

Windscreens, Microphone,
for BTH Headsets
(SHR 2379 and similar)
P/N: 90227-01
Ear Cushions
for Ear Cup Headsets
(SHR 2083 and similar)
P/N: 90216-01
Cushion, Speaker Cover,
for BTH Headsets
(SHR 2379 and similar)
P/N: 90228-01
Windscreens, Microphone,
for Ear Cup Headsets
(SHR 2083 and similar)
P/N: 90227-02
Headband, Binaural,
for Ear Cup Headsets
(SHR 2083 and similar)
P/N: 90185-03
Headband Arm Pad,
for Monaural
Ear Cup Headsets
(SHR 2082 and similar)
P/N: 90185-06
Headband, Monaural,
for Ear Cup Headsets
(SHR 2082 and similar)
P/N: 90185-02
Supplies & Accessories sold separately

LIMITED WARRANTY
This warranty covers defects in materials and workmanship of Commercial
Products manufactured, sold or certified by Plantronics which were
purchased and used in the United States and Canada.
This warranty lasts for one year from the date of purchase of the Products.
This warranty extends to you only if you are the end user with the original
purchase receipt.
We will, at our option, repair or replace the Products that do not conform to
the warranty. We may use functionally equivalent reconditioned/refurbished/
remanufactured/pre-owned or new Products or parts.
To obtain service in the U.S. contact Plantronics at 800-544-4660 and in
Canada call 800-540-8363. If you need additional information, please contact
our service centers at the numbers provided.
THIS IS PLANTRONICS COMPLETE WARRANTY FOR THE PRODUCTS.
This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state or province to province. Please contact
your dealer or our service center for the full details of our limited warranty,
including items not covered by this limited warranty.
Plantronics, Inc.
345 Encinal
Santa Cruz, CA 95060
United States
Tel: [phone]
Tel: [phone]
www.plantronics.com
© 2008 Plantronics, Inc. All rights reserved.
