Plasma Ions PS-500T1 User manual

PS-500T1
Plasma Ions
Warranty Card
（Please keep it properly）
Product
Name
Purchase
Time
Product
Number
Contact
Number
Customer
information
Name/company
contact address
Sales company stamp：
（2）Punching Installation Steps:：
1.Mounting tape 2. Stick it on the back
of the product.
3.More than 3 PCS.
4.Aim horizontally at the wall
and press firmly
5.Plug in the power adapter
and connect the plug to the
power input.
6.The working light is on
and the machine is working
to sterilization
1.Mark the location of the
hole before installation.
2.Drill aperture of 6mm
holes at the marked
position.
3.Put the expansion plug
into the hole position.
Label position Punch Expansion rubber plug
4.Using the key open the
machine then you’ll see
the mounting screw hole
5.Using the screwdriver tool,
attach the product to the wall.
6.Plug in the power adapter
and connect the power input.
Open the front cover
打开
Power on
Screw on
There are two ways of installation: perforation installation and no hole installation.
Perforation installation is suitable for the walls can make screw holes.
and no hole installation for smooth metal walls.(Like in the elevator, most of them belong
to the non-punching installation mode, this is be selected by the user according to the
installation environment)
（1）No punching steps：
Installation Notes
Plasma air disinfection purifier
Please read the instructions before use
120 mm
225 mm

Apply in hotels,residential,hospitals,nursing houses,schools,internet cafe,supermarket,restaurants,
airports,office buildings,casinos,public toilets,transportation,underground parking lot,food
processing,animal slaughterhouse,dry goods storage, warehouses,sewage treatment factories,
garbage transfer stations and some commercial and industrial facilities.
Plasma ions generator play a long-lasting and active positive and negative ion purification effect.
Shell is metal material
This product can be used for a long-term.(Suggest clean the ion tube about 12 months later,
clean or change the filter)
Use and characteristics
Plasma generator
Power and other
indicator signals
are not lit
Check if the power cords securely inserted into the unit and
it is loose. Check the power outlet for power supply and check
the 1.0 mA standard (certified) fuse
Under normal circumstances, there is a slight current sound
and black There is a faint blue light in the dark. If found.The
ion tube bursts and the ion tube needs to be replaced.0.5 mA
standard (with certified) fuse.
Please send the following to the company's designated
maintenance department for repairs.
1. The problem cannot be solved as described above.
2. Foreign matter or moisture enters, and abnormal conditions occur.
Fault condition Processing check
Fault check
Air inlet
Air outlet
Power socket
Fuse
Power switch
Work lights
Safe Lock
Composition unit
Model
Voltage
Area
Power
Air volume
Weight
Noise Ion tube
quantity
Size Ion tube size
PS-500T1
DC12V
20-30㎡
≤50dB
260*175*60mm
10W
0-35CFM/0-60m³/h
1Kg
1（Standard）
80mm(3inch）
Filter type Ion tube lifePre-filter ≤2 years
Technical specification
Precautions
This machine is designed for only indoor general using. Do not place it open-air or high
temperature place.
Before operating the machine, make sure the power cord is firmly plugged into the power
outlet, and place the power cord in a safe position. Do not touch, install or unplug the
power cord with wet hands to avoid electric shock accidents.
Before unplugging the power cord, please turn off the machine power in the correct
procedure, otherwise it may cause damage to the machine.
If don't use the machine for a long time, please unplug the power supply.
Before operation, please check whether the air inlet and outlet positions of the machine
are blocked.
Do not put debris at the air inlet or outlet, because there is the fan installed inside with
high-speed rotation, it may caused injured if touch it.
In order to ensure the best performance of the machine, do not place any obstacles within
1 meter nearby of the air outlet position and air introduction position.
The machine has precision components built inside. Don't open the case by yourself to
avoid damage to the machine parts and may happen dangerous.
Do not dismantle the front wind panel or the chassis during machine is operating to avoid
dangerous.
Pay attention to ventilation when using it together with fuel appliances. Please do not use
machine in the kitchen.
Before cleaning the chassis of the machine, make sure turn off the power and unplug it of
the machine.Only use cloth with a little clean water and clean it softly,don't use volatile
cleaners.
Forbidding to place and using in the bathroom, otherwise it may cause electric shock.
There are electronic devices installed inside, do not open the case to avoid the risk of electric shock.
Please read this [user manual] carefully before using the machine and follow the below points of
operation base on the manual.Otherwise It may cause damage to product, or even cause injury
to yourself or others at varying degrees.
1.Please read this manual carefully before use.
2.Free services can be provided with warranty card and invoice,welcome to contact us
if you need technical support.
3.Customers can get 1 year warranty service from us with product related invoice and
documents.
4.Please keep the warranty card properly so that the warranty can be obtained when
the product needs repair.
5.The company is not responsible for the following repair services beyond the product,
but we can still provide you with paid services.
Products due to improper use or storage.
Products without warranty card or other valid documents.
Products due to unstable power supply voltage or beyond the normal voltage
range or power supply and installation does not meet the electrical installation
requirements.
Promotional products.
Products damaged caused by irresistible natural disasters.
Products beyond maintenance period,damaged due to not follow the rules and
methods of application.
Maintenance notice
