Plejd DIM-02 User manual
DIM-02
0306.3.3
Mains electricity
230 V/50 Hz
Standby power
0.3 W
External operating temperature
-20 to +35 °C
Dimensions
46x46x18 mm
Load type
Trailing edge
Leading edge
Protection
Overtemperature software
Overtemperature hardware
Overload software
Radio
2.4 GHz mesh
Bluetooth®
<10 dBm
Radio range
Approx. 10 m indoors
The Plejd mesh technology extends the range by
allowing the units to communicate with each other.
RISK OF INJURY TO PERSON OR PROPERTY
All work on the appliance must be carried out by
an authorized electrician. National laws and
regulations must be followed.
Compliant to standards
Hereby, Plejd AB declares that the radio
equipment type DIM-02 is in compliance
with Directive 2014/53/EU.
The full text of the EU declaration of
conformity is available at the following
internet address: plejd.com/compliance
EN
INSTALLATION MANUAL
Further information can be found
in the Plejd app or at plejd.com
Plejd AB, Krokslätts Fabriker 27A
431 37 Mölndal, Sweden
Disposal and recycling
This electrical product should not be disposed
of together with other household waste. Contact
your local recycling center for guidance on
electrical and electronic equipment disposal.
Important information
Do not use the product if it has visible signs
of damage.
Do not use with: fluorescent lamps, conventional transformers or
low-energy lamps.
Load per output (total max. output 200 VA)
Halogen/incandescent (230 V) 0–100 W
LED light source/driver (230 V trailing edge) 0–100 VA
LED light source/driver (230 V leading edge) 0–50 VA
Electronic transformers (12 V halogen) 0–100 VA
Install the product in the appliance box behind the
push button/box lid or secure it with a Mounting clip (MNT-01, not
included) on the wall or DIN rail.
When installing in insulated or warm environments or with several
dimmers in the same box, the total power
is reduced.
DIM-02 is a universal dimmer with output for two different loads of
up to 100 VA per channel and has adjustable minimum, maximum,
and starting levels.
Connect the product
NOTE!
During installation the product is non-dimmable.
Use the app to configure before use.
Control inputs 1 and 2 can be used for control with:
· push button (preset so that inputs 1 and 2
control respective outputs 1 and 2)
· light switch
· motion sensor (with neutral conductor).
The inputs can also be used to wirelessly control one
or more products from Plejd. Additionally, double click
on a push button can be used to activate scenes.
Control inputs 1 2
L
N
N
12
L
1 2 N N
DIM-02
Support
Follow the instructions in the app
Hand over the Plejd system
Once you have completed the installation, you will
find the system code in the app. Write the code on
the included sticker . Place the sticker in the
distribution box and give the welcome folder HI!
to the customer.
In the event of any technical questions,
please contact our customer service:
Download the Plejd app on the App Store or Google
Play. After supplying power to the unit by following
the wiring diagram, use the app to complete the
installation. Setup requires Bluetooth®and an
internet connection.
