Plejd LED-75 User manual

LED-75
Mains electricity
230 V/50 Hz, max 0.5 A
Standby power
Pno: N/A Psb: 0.35 W Pnet: 0.35 W
Efficiency at full-load
90 %
Operating temperature
-25 to +40 °C
Non-condensing
Dimensions
162x62x34 mm
Cable area
Connections: 0.5–2.5 mm2
Protection
Overtemperature software
Short circuit protection
IP rating
IP20
Radio
2.4 GHz mesh
Bluetooth®
<10 dBm
Radio range
Approx. 10 m indoors
The Plejd mesh technology extends the range by
allowing the units to communicate with each other.
0419.2.6
RISK OF INJURY TO PERSON OR PROPERTY
All work on the appliance must be carried out by
an authorized electrician. National laws and
regulations must be followed.
Compliant to standards
Hereby, Plejd AB declares that the radio
equipment type LED-75 is in compliance
with Directive 2014/53/EU.
The full text of the EU declaration of
conformity is available at the following
internet address: plejd.com/compliance
EN
INSTALLATION MANUAL
Further information can be found
in the Plejd app or at plejd.com
Plejd AB, Krokslätts Fabriker 27A
431 37 Mölndal, Sweden
Disposal and recycling
This electrical product should not be disposed
of together with other household waste. Contact
your local recycling center for guidance on
electrical and electronic equipment disposal.
Important information
Do not use the product if it has visible signs
of damage.

LED-75 is a LED Driver for 12/24 V DC up to 75 W load. It
has a built-in dimmer and tunable white support for
LED-strips with common anode. The load output is isolated
from the mains voltage (SELV).
The product can be installed on a wall with two screws
(not included).
Connect the product
NOTE!
During installation the product is non-dimmable.
Use the app to configure before use.
If the load isn’t tunable, you may connect it to
either of the negative (-) terminals.
LED-75
N
N
L
L
1
Cold
Warm
+––
Load (CV)
12 V DC 1–40 W
24 V DC 1–75 W
Control input
Control input 1 can be used for control with:
· push button (preset)
· light switch
· motion sensor (with neutral conductor).
The input can also be used to wirelessly control one
or more products from Plejd. Additionally, double click
on a push button can be used to activate scenes.
1
Support
Follow the instructions in the app
Hand over the Plejd system
Once you have completed the installation, you will
find the system code in the app. Write the code on
the included sticker . Place the sticker in the
distribution box and give the welcome folder HI!
to the customer.
In the event of any technical questions,
please contact our customer service:
[email protected] | [phone]
Download the Plejd app on the App Store or Google
Play. After supplying power to the unit by following
the wiring diagram, use the app to complete the
installation. Setup requires Bluetooth®and an
internet connection.
