PLH Products Neo Lighter User manual

!
Neo Lighter - NA.LT.4_A01
rev. 1.0_01/01/2019

www.plhitalia.com
Neo Lighter
cod. NA.LT.4_A01
© 2019 - epic srl - All rights reserved
Page | 51
Technical specifications
Programmable push buttons
3 + 1
Type of inputs
Tact, rotative push buttons (30° , -30°) and Shake
Operating life
15.000 cycles
Feedback
Led blue on board
Battery type
3V CR2032 lithium coin cell
Lyfetime
10.000 click
Maximum output radio transceiver power:
2,4...2,483 Ghz +4 dBm
Range (depending on the surrondings)
up to 10 m
Contains FCC ID:
2ALA3-CBM002A
Contains IC
22496-CBM002A
Dimensions:
ø 29 mm x 49,5 mm (1,14 x 19,5 inches)
Case
Polycarbonate body and top in aluminium
Weight:
50 g
Degree of protection:
IP44
Ambient temperature, ta:
- 20 … + 45 °C
Max. case temperature, tc:
+ 65 °C
Max. relative humidity:
0...80%, non-cond.
Mark and regulations
General description
Bluetooth controllable, keypad for operation control with feedback led. The buttons can control a
scene or an animation of the user's choice or simply one luminaire, one luminaire group or all lamps
together if so desired if used with PLH Aria dimmers or any lighting fixture powered by Casambi or a
PLH Aria Jellyfish output interface.
To be configured with Casambi app available for iOs (iPhone 4S or later, iPad 3 or later, iPod Touch
5th gen or later) and Android devices (Android 4.4 KitKat or later devices produced after 2013 with
full Bluetooth 4.0 support).
Casambi Profile
3663
Neo 2 P : Neo Encoder 2 push buttons CW
8452
Neo 2 P Inv: Neo Encoder 2 push buttons CCW
3660
Neo 4 P: Neo Encoder 4 push buttons

www.plhitalia.com
Neo Lighter
cod. NA.LT.4_A01
How to use it
Check the instructions below for the configuration.
PLH Neo Lighter is provided with 4 functions: click, rotate 30° CW, rotate 30° CCW and shake (strong)
How to change the battery
Upside down the Neo Lighter and open the bottom rubber cover. Take out gently the battery holder.
Release the old battery sliding it, and change with the new one CR2032.
Respect the + symbol on the top.
Click the push button and check the functionality and the blue led on.
Reinsert the battery holder in the housing and close again the rubber cover and be sure it’s all well fixed
on the bottom.
The PLH Neo Lighter is supplyed with the 8452 firmware preinstalled!
© 2019 - epic srl - All rights reserved
Page | 52
neolighter
Battery holder
Rubber cover

www.plhitalia.com
Neo Lighter
cod. NA.LT.4_A01
Warranty
We reserve the right to make technical and formal changes to the product in the interest of technical
progress. Our products are under guarantee within the scope of the statutory provisions.
If you have a warranty claim, please contact PLH by e@mail ([email protected]) or the Local Reseller.
!
© 2019 - epic srl - All rights reserved
Page | 53
This product should not be disposed of with household waste."
Please recycle the products where facilities
for electronic waste exist. Check with your local authorities for recycling advice.
Please note!
•The device may only be opened and installed according to
the circuit diagram on the device or these instructions by a
qualified electrician. The existing safety regulations must be
observed.
•Appropriate installation measures must be taken to achieve
the requirements of protection class II.
•This independently mountable electromechani-
cal or electronic device is designed for controlling the
temperature in dry and enclosed rooms only under normal
conditions.
•The device confirms to EN 60730, it works according opera-
ting principle 1C.
•The permissible relative humidity of max. 95% must not be
exceeded. Condensation is to be avoided.
•When starting up the room temperature controller, it
must be noted that the thermo-bimetal requires a certain
period of time to adapt itself to the room temperature. The
switching point will therefore deviate from the room tem-
perature immediately after installation or after switching off
the night set-back. The switching point accuracy is ensured
after approx. 1 to 2 hours of operation.
To heat up faster in the beginning and shorten the com-
pensation time in the beginning, we recommend setting
the room temperature higher than actually desired. After
attaining the temperature, the temperature setting can be
set back to the desired setpoint value.
Applications
•The room temperature controller controls the temperature
in closed rooms, such as apartments, schools, halls, work-
shops, etc. subject to normal ambient conditions.
Installation location
•Preferably opposite the heating source on an inside wall.
radiator
radiator
Room
Temperature Controller
•Installation height: approx. 1.5 m above the floor
•Avoid outside walls and air drafts originating from windows
and doors.
•Please observe that the normal convection air of the room
must be able to reach the controller without hindrance.
The controller should therefore not be installed between
shelves, behind curtains or be covered in any way.
•Heat from other sources has a negative influence on cont-
roller accuracy.
Therefore you should avoid:
direct sunlight, installation in the vicinity of TVs, radios,
heaters, lamps, chimneys, and heating ducts.
•Even a dimmer creates heat!
If the controller and a dimmer are installed in a shared
switch frame, the devices should be placed as far apart from
each other as possible. If the devices are installed above
each other, the controller must be below the dimmer on the
bottom.
Installation on 58mm flush-type box (DIN 49 073)
a) Remove casing cover:
- Pull off the adjustment knob
- Loosen the cover screw
- Pull off the cover
b) Electrical connection according to circuit diagram
(see below).
c) Mount the device onto the socket using the thread-forming
tapping screws for flush-type boxes.
d) Mount the casing cover with switch frame.
The cover must latch into the bottom part of the casing before
tightening the screw.
- Push the adjustment knob back on
To facilitate dismantling, the casing cover and switch frame
should be removed together.
Electrical connection
Connect all lines exactly as shown in the relevant circuit
diagram.
Please observe that the neutral conductor N is connected to
terminal N. If this is not the case, large temperature deviations
will result since the controller will not be able to function
properly.
Conductor cross-section: 1 mm2 to 2.5 mm2solid conductor
No protective-conductor terminal is required since the device
is completely insulated.
Brief description in the circuit diagram
L = outer conductor (phase)
N = neutral conductor (previously Mp)
>= terminal for clock signal for
temperature set-back
U= heating load terminal
P= cooling load terminal
RF = resistance for thermal feedback
TA = resistance for night set-back of room temperature
Technical data
Type 2026.. 2030.. 2031..
Temperature range 5…30°C 5…30°C 5…30°C
Rated voltage AC 250V AC 250V AC 24V
Rated current (cos ϕ
= 0,6)
Uheating
Pcooling
10 (4) A
5 (2) A
10 (4) A
–
(DC 24V)
10 (4) A
–
Switching capacity
Uheating
Pcooling
2,2kW
1,1kW
2,2kW
–
240 W*
–
Switching temp. diff. app. 0,5K app. 0,5K app. 0,5K
Night set-back – app. 4K app. 4K
*At DC max. 100 W
For all devices:
Degree of pollution 2
Calculation impulse voltage 4 kV
Temperature for the Ball compression test 75 ± 2°C
Voltage and Current for the for purposes
of interfernce measurements
230 V, 10 A
Order No.: 2030.. Room temperature controller 250 V
with NC contact, On/Off switch and
LED
Order No.: 2031.. Room temperature controller 24 V
with NC contact, On/Off switch and
LED
Note:
LED On = controller active
Order No.: 2026 .. Room temperature controller 250 V with
changeover contact
Narrowing down the temperature setting range
The controller is factory-set to a maximum setting range of
5 °C to 30 °C (see Fig. 1).
There are 2 ring gauges in the adjustment knob. These ring
gauges can be used to narrow down the temperature setting
range as required, for example to a range of 8 °C to 23 °C.
Setting procedure:
1. Select the temperature limits:
Example: max. 23°C min. 8°C
2. Note! First turn the adjustment knob to the approximate
average value in the middle of the desired setting range.
Example: The average value between 8°C and 23°C is
approx. 15°C
3. Then pull off the adjustment knob.
4. Set the red ring gauge to the max. temperature limit.
Example: 23°C
Rotate counter-clockwise. The numbers on the outside of the
scale are valid! Place the tip of a pen into the hole and rotate
the red ring counter-clockwise to 23°C (max. scale Fig. 2).
5. Set the blue ring gauge to the minimum temperature limit.
Example: 8°C
Rotate clockwise. The numbers on the inside of the scale are
valid! Place the tip of a pen into the hole and rotate the blue
ring to 8°C (min. scale Fig. 3).
6. Push the adjustment knob back on:
The indicator must be approximately in the center of the new
setting range; see 2.
Example: approx. 15°C
Fig. 1
The controller is supplied
with this setting
Full range:
5°C to 30°C
Fig. 2
Red gauge ring (max.)
set in direction of arrow
to 23°C
Fig. 3
Blue gauge ring (min.)
set in direction of arrow
to 8°C
Temperature setting scales
with flag digits
P= approx. 5°C = approx. 20°C
2= approx. 10°C 5= approx. 25°C
3= approx. 15°C 6= approx. 30°C
Symbols
OFF
ON
êpermanently set temperature
ëpermanently set set-back temperature
Nswitch-over between day and night temperature
controlled by time switch
Warranty
We reserve the right to make technical and formal changes to
the product in the interest of technical progress.
Our products are under guarantee within the scope of the
statutory provisions.
If you have a warranty claim, please contact the point of sale or
ship the device postage free with a description of the fault to
the appropriate regional representative.
Operating Instructions
Room
Temperature Controller
Order No. 2026 .., 2030 ..,
2031 ..
U 468 931 022 976-2 9709182000
This product should not be disposed of with
household waste.
Please recycle the products where facilities
for electronic waste exist. Check with your
local authorities for recycling advice.

Neo Lighter
cod. NA.LT.4_A01
1. Download the app
Download the free Casambi App directly from
the AppStore or the Google Play
 "
For all the functionality of the Casambi App
download the Short User Guide from the
Casambi website
https://casambi.com/static/datasheets/Short-
user-guide.pdf
2. Open the App
Before you open the app be carefull about this
points:
-the Bluetooth need to be ON on your
smartphone or tablet
-have done all the updates of the operating
system;
-have installed and configured a Casambi
device or a PLH Dimmer or PLH Jellyfish
-have created a ‘Network’
3. Add the device
To add the Neo Lighter on your network you need
to have installed a Casambi enabled lighting
fixture, a PLH Dimmer or a PLH Jellyfish.
Refer to the specific manual for the installation of
those devices.
After you open the Casambi App on your
Smartphone, take pressed the main button
of the Neo Lighter and a window ‘Found a new
device’ will appear.
Then click on Add individually to… , change
the Name of your Neo Lighter, and add to your
new network.
Release the button only at the end of the
process.
Take in mind that by default the profile is
provided with the Neo 2 P Inv.
But are available 3 different profile:
-Neo 2 P"
Will be possible to set up only the click and
the shake to different functions or scenario:
rotation clockwise will dimm UP and counter
clockwise will dimm DOWN the main
scenario or light associated to the main
push button
-Neo 2 P Inv "
Will be possible to set up only the click and
the shake to different functions or scenario:
rotation clockwise will dimm DOWN and
counter clockwise will dimm UP the main
scenario or light associated to the main
push button
-Neo 4 P"
Will be possible to set up 4 different
functions or scenario for every command,
main push button, rotate clockwise and
counter clockwise and shake
If you want to change it, select the new profile
from the ‘Change profile’ option. Will be
possible to change it again later following the
steps at point 5
Don’t forget to always press the main
button or the Neo Lighter will fall in sleep
and break the communication.
4. Assign input functionality
To assign and change the preferences of the
Neo Lighter go on More / Switches and select
your Neo Lighter
Depending to the profile you choose you will
have 2 or 4 presets.
From the beginning all the input will be ‘Not in
use’.
Tap to select to change the functionality.
You can control any Casambi devices or
scenarios.
To control the Jellyfish output click on ‘Control
an element’ and select then the right output
To control a PLH Dimmer click on ‘Control a
Luminaire’.
Refer to the Casambi App Manual for any
further study.
© 2019 - epic srl - All rights reserved
Page | 54

Neo Lighter
cod. NA.LT.4_A01
!
5. Change the profile of a Neo Lighter
When the Neo Lighter is added, it will be visibile
from the menu More / Switches.
Remember that after 6 second the Neo Lighter fall
in sleep. During the process of the upgrade of the
Profile always click the main push button. Release
only at the end of the process.
To change the profile of a Neo Lighter go to
the Menù More / Switches.
The Neo 2 P Inv, or the other profile changed,
will be greyed.
Click on it and scroll bottom the menù.
Then to show the Unpair device you need to:
-click the main push button and shake
strongly the Neo Lighter (for the profile Neo
2 P Inv and Neo 2 P)
-click the main push button and rotate at the
same time the same button (for the profile
Neo 4 P)
After the device is unpaired click again the
main push button, and continue press it, and
go on the More…/Nearby menu’ .
Click on the Neo Lighter icon.
When you click on it the app will ask to ‘Change
profile’ too.
Change profile give you the chance to change
the firmware, then the settings of the push
buttons. Check the list on first page then
select the desired profile
Add again the Neo Lighter to your Network.
Don’t forget. Every time you perform this
operation you will discards all the setups.
Only when you end the process release the
push button and continue from the step 5
6. Update the firmware
Time to time the firmware update window will
appear for some maintanance stuff.
Then perform the update clicking on Start
update.
Don’t forget to take pressed the main push
button till the update is not ended.
7. Troubleshooting
1) The Neo Lighter is a battery device. If not
function check the blue light turn on when
you click the main push button. If not,
change the battery following the
instructions.
2) The Neo Lighter use the bluetooth signal,
for communicate between the devices.
Refer to the Casambi website to discuss all
aspects related to this technology.
3) You can control devices in a range up to
10m but it strongly depends by the
surrondings. If the ‘receiver’ device like a
Casambi Dimmer, is inside of a metal box
this range can reduce significatevely.!
© 2019 - epic srl - All rights reserved
Page | 55

www.plhitalia.com
[e-mail]
plhitalia
#plhitalia
PLH Italia
@plhitalia
