Plus M-12 Series User guide

M-12 Series Copyboard / C-12 Series Captureboard
Assembly and Setup Manual
This is the installation and assembly manual for the M-12 series Copyboard and C-12
series Captureboard.
(The copyboard and/or captureboard are referred to as "the set" or "the main unit" in this manual.)
To the Customer
Special skills are required to install the set. Never try to assemble the
set yourself.
To the Dealer or Installation Tradesman
In the interest of the safety of the customer, please perform installation
work paying due attention to the strength of the installation location to
ensure that it can bear the load of the main unit, printer, and installation
parts.
TABLE OF CONTENTS
1. Please Read in the Interest of Safety ....................................................... 2
2. Packaging List ............................................................................................ 3
3. Installation Procedure ............................................................................... 4
4. Assembly of the stand ................................................................................ 4
5. Wall Mounting ............................................................................................. 7
6. Assembly of the Printer Table ................................................................. 10
7. Connection to the set .............................................................................. 12
8. Test Print ................................................................................................... 17
9. Changing the Height of the Unit ............................................................. 18

2
1. PLEASE READ IN THE INTEREST OF SAFETY
Warning
• If you are not a qualified assembly serviceperson, do not perform installation procedures.
• Please be sure to perform the installation and assembly based on this manual. Incorrect installation
or assembly will be the cause of injury.
• Please have 2 or more persons lift the main unit when installing or removing it.
Also, be sure to lock the stand's casters before installing or removing. If not, the stand could slip un-
expectedly, resulting in accidents.
• To prevent dropping the strength of the installation location and the anchoring method must fully bear
over a long period the load of the main unit, printer, and installation parts. The installation should also
be performed to fully withstand an earthquake. Incorrect installation can result in the main unit falling
and causing injury.
• Please use M6 or equivalent screws for the wall mounting portion. Use of screws other than M6 or
equivalent can result in the main unit falling and causing injury.
• Please mount to a post in the wall or a sturdy wall stud. When the mounting positions of the main unit
are not reached, please use optional wall support fittings.
• Please use hardware like anchor nuts and anchor bolts for mounting on a concrete wall.
• Be sure to install the stabilizers supplied with the stand at each of the 4 locations (to prevent top-
pling).
• The AC adapter box is for storing the AC power adapters of the main unit and printer. The AC power
adapters and the power cords heat up. Read the "Important Safety Information" in the main unit's
"User's Manual" carefully and store them properly.
CAUTION
• When a printer is mounted on the set, attach the Velcro and printer guides so that the printer does not
slip off. If not, the printer could fall when moving the set, resulting in damage or injury.
* The Velcro is meant to prevent slipping, not to fasten the printer in place.
* Velcro is a registered trademark of Velcro Industries.

3
The packaged contents will differ depending on the purchased Series.
Please open the carton and check the parts.
In the rare event that something is missing, please contact your store of purchase.
■List of Items in Package
Main unit: 1 unit (standard type or wide type)
Wall mounting brackets: × 4, M4×8 screws × 16 (for wall mounting)
Printer table (1 set): Printer table × 1, Brackets × 2, M4×8 screws × 4, M3×6 screws × 10, Cushions × 2, Printer guides × 2,
Velcro× 2 sets
AC adapter box (1 set): With 2 masking screws
Cable covers for copyboard: Standard type×1, Wide type ×2
AC power adapter (with power code): × 1 (HEC-AP065-24V)
Markers: × 4 (One each of black, red, blue, and green)
Eraser: × 1
USB cable: × 1
Documentation: Instruction manual × 1, CD-ROM × 1, Quick Guide × 1, Assembly and Setup Manual (this manual) × 1
TOOL BOX Software Operation Manual × 1
■Printer package*: One unit
Please check the user’s manual of the printer for a list of contents for the printer package.
2. PACKAGING LIST
■Stand packaging list*
T-shape legs (with casters) × 2, Hexagonal socket screws × 8, Flat washers × 8, Horizontal bars × 2, Hexagonal
wrench × 1, Stay × 1, Nylon bushing × 1, M3×6 screws × 2, Stabilizers × 4, Frame caps × 2, Pipe caps × 4, Lock-
screws × 2, Cable covers for stand × 2 (Standard type × 1, Wide type × 1)
* The printer and stand may be options.

4
3
4
1
2
3
4
1
2
* The stand may be an option.
(Please consult with a dealer or installation tr adesman.Installation work should not be done by the customer.)
4. Assembly of the stand See Page 4
6. Assembly of the printer table See Page 10
7. Connection to the set See Page 12
8. Test print See Page 17
6. Assembly of the printer table See Page 10
7. Connection to the set See Page 12
8. Test print See Page 17
5. Wall mounting See Page 7
The installation method will change depending on the type of installation. Please perform installation and
assembly according to the following procedures.
4. ASSEMBLY OF THE STAND
Frame Cap
Stabilizer
T-shape leg
• Diagrams of printers that appear in this manual are representative illustrations.
The illustration will differ from the actual printer. Check the owner's manual of your printer for information about the names of
the connectors and their locations and use.
Caster
Stabilizer
Use the same method to assemble the left and
right sides of the stand.
(1) Press-fit the frame cap onto the top
of the T-shaped legs.
(2) Attach the stabilizers to the front
and back of the T-shaped legs.
Insert the stabilizers securely all the way in.
(3) Lock the caster stoppers.
Press the bottom portion of the stoppers to lock
them.
CAUTION
To prevent toppling, be sure to install the stabiliz-
ers at each of the 4 locations. The toppling of this
machine could cause bodily injury or damage the
machine.
3. INSTALLATION PROCEDURE
Note
* The printer may be sold separately.

5
(4) Attach the two horizontal bars to the
T-shape legs.
Use hexagonal socket screws (M5) and flat wash-
ers (M5) to attach.
Partially fasten using the hexagonal wrench (M5), then
tighten securely after the upper and lower horizontal
bars have been attached.
(5) Place the stand’s hooks in the
mounting holes in the support fit-
tings and insert the grooves in the
hooks securely.
There are 3 hole positions. By changing the position,
the installation height can be changed among 3 lev-
els in 100 mm units (1770, 1870, and 1970 mm (the
maximum height)).
(6) Mount the printer table to the main
unit.
See Page 10 for information about the assembly and
installation of the printer table.
* Installation of the printer table is not required when
the main unit is used only for USB memory stor-
age.
Hexagonal wrench (M5)
T-shaped leg
Horizontal bar
Hexagonal socket screw (M5)
Flat washer (M5)
CAUTION
Please have 2 or more persons lift the main unit
when installing it or making a height adjustment. If
the unit is dropped or falls over, this could cause
unforeseen injury.
Check that the hook is securely inserted into the
installation hole. Insecure installation could result
in the unit falling and causing bodily injury or dam-
age to the unit.
Mounting hole
Hook
The rear
frame
4. ASSEMBLY OF THE STAND

6
(7) Install the stay to the printer table.
Insert the nylon bushing into the stay.
Insert the stay into the pipe of the stand.
Mount the stay to the printer table using two M3 screws.
Check again that the grooves in the stand’s hooks are se-
curely inserted in the mounting holes in the support fittings.
(8) Lock the main unit and stand with the two
locking knobs.
3
2
Stay Pipe
M3 screws
Locking knobs
Stay
Nylon bushing
Notice
4. ASSEMBLY OF THE STAND

7
1077 mm
1200 mm
1077 mm
1200 mm


(1) Determining the installation location
The diagram indicates the dimensions of the installa-
tion positions. The installation position is the same for
both the standard type and the wide type.
The installation of the main unit to the wall is per-
formed after the printer table is assembled and at-
tached to the main unit. See Page 10.
• When the Wall Is Concrete
Embed the commercially available anchor bolts or
anchor nuts for M6 at the installation positions. (See
below)
• When the Wall Structure Is Plywood or
Plaster Board, etc.
Please check that a post or stud is located at the
installation position indicated by the dimensions.
When a post is not located at the target installation
position, please use a wall support fitting that is
available separately. Attach a wall support fitting to
the post or stud.
• When the building does not have posts, please
use the stand.
• Separate optional items are available when the
standard wall mounting is not possible, or when
installation will be made to a partition.
Stud, etc.
Wooden Walls Wood screws
Make a suitable hole with an auger and
 attach the Copyboard with wood screws.
Concrete Walls Anchors
Make a base hole in the wall with a drill. Insert the anchor. Fasten the main
unit with screws.
Please use a drill of the hole diameter specified for the anchor.
Steel Walls Phillips head tapping screws (Pan head)
Check that the steel wall is reinforced and use a drill a hole of suit-
able diameter, then attach the main unit with tapping screws.
Reference: Installation Method for Various Wall Materials
Please perform an installation that suits the wall material.
Please install the main unit to posts or studs when the wall surface is of insufficient strength.
Installation Wall Material Installation Method


5. WALL MOUNTING
Note


8
(3) Attach the 4 supplied wall-mount brackets to the main unit using M4×8 screws.
Four screws for each bracket. (Total 16 screws.)
(2) Stick the cushions on the printer table, then mount the printer table on the main
unit.
 Peel off the protective sheets from the cushions’ adhesive surfaces.
Stick the cushions (2) on the back of the bracket.
See page 10 for instructions on assembling and mounting the printer table.
When mounting the printer table after installing the main unit on a wall, see page 10.
* There is no need to mount the printer table when only storing data in the USB memory storage.
Protective sheet on
adhesive surface
Cushion
Cushions
Back of bracket


Wall-mount bracket
M4 x 8 screw
5. WALL MOUNTING

9
(4) Attaching and anchoring the main unit to a wall or wall support fitting.
(The anchoring method will differ depending on the wall mounting method.)
Installing on a Concrete Wall
Anchor nut, etc.
M6 screw
Mounting to a Post
M6 wood screw
5. WALL MOUNTING

10
Printer Table Right-side Installation Printer Table Left-side Installa-
The printer table can be installed at either the left or right side. The installation method is the same.
Determine whether to install the printer table on the left or right side in consideration of the position of the
power outlet in the wall, etc.
The method of assembling the printer table is the same for stand placement and for wall mounting. The assembly diagrams
omit the stand.
M4 X 8 screws
(1) Temporarily fasten the right and left brackets to the main unit using four M4×8
screws in the order of Steps to .
Right bracket
Left bracket
M4x8
screws
Front screw
hole
Front screw
hole
When mounting the printer table after
installing the main unit on a wall
Use four M4×8 screws to temporarily fasten the
left and right brackets to the four holes in the
bottom of the main unit.
Screws hole
Screws hole Screws hole
Screws hole
2
4
1
3
(2) Temporarily fasten the printer table to the
brackets with six M3 x 6 screws.
M3 x 6 screw
Printer table
M3 x 6 screw
6. ASSEMBLY OF THE PRINTER TABLE
If the printer touches the wall, move the printer
table forward, then fasten it in place using four
M3x6 screws.
* When installing using a stand, do not move the printer table
forward and fasten it in place. Doing so could result in the
printer table falling.
