PNI IP65 live User manual

PNI IP65 live
5MP GSM 4G video surveillance camera/5MP GSM 4G камера за
видеонаблюдение/5 MP GSM 4G-Videoüberwachungskamera/Cámara
de videovigilancia GSM 4G de 5MP/Caméra de vidéosurveillance 5MP GSM
4G/5MP GSM 4G videó megfigyelő kamera/Telecamera di videosorveglianza
GSM 4G da 5 MP/5MP GSM 4G videobewakingscamera/Kamera do nadzoru
wideo 5MP GSM 4G/Camera supraveghere video 5MP GSM 4G
EN User manual ......................................................... 3
BG Ръководство за употреба ............................. 13
DE Benutzerhandbuch .............................................. 24
ES Manual de usuario ............................................... 34
FR Manuel utilisateur ............................................... 44
HU Használati utasítás .............................................. 54
IT Manuale utente .................................................. 64
NL Handleiding ........................................................ 74
PL Instrukcja obsługi ............................................... 84
RO Manual de utilizare ............................................. 94

3User manual
English
Basic features
• 4G and LAN connection (RJ45 connector)
• Recording on micro SD card, max. 128 GB (card not included)
• Bidirectional audio communication (built-in microphone and speaker)
• Outdoor mounting, protection class IP66, ABS housing
• 2 IR LEDs, 2 white light LEDs, 4 IR LEDs and white light
• P2P connection for remote monitoring
• Remote control through the CamHi/CamHi Pro application (Android/
iOS) and through the HiP2P Client application (PC Windows)
Technical specifications
Video
Sensor 5.0 MP 1/2.7” SC5238 CMOS
Chipset T31X
Video compression H.264/H.265
Lens 3.6mm
Viewing angle 82.5°
LED 2 IR LEDs, 2 white light LEDs, 4 IR
LEDs and white light
IR distance up to 30 meters
Digital zoom 2X
Audio Audio compression G.726/G.711
Audio Input/Output Built-in Microphone/Loudspeaker
Allarm
Motion detection Yes, adjustable sensitivity (1-100), 4
independent detection zones
Human silhouette
detection
Yes, it can work together with the
motion detection function for more
accurate detection

User manual 4
English
Allarm Actions if alarm was
triggered
Send a message in the application
Save recording or captured image on
micro SD card
Send email with image capture
Save recording or captured image on
FTP server
Interface
Power 5.5 x 2.1 mm connector
Ethernet RJ45 connector
Reset button Press for 5 seconds to reset the
camera
Micro SD card slot Maximum supported capacity 128GB
SIM slot Nano SIM (12mm x 9mm)
ONVIF Supports ONVIF 2.4 (and earlier
versions)
3G/4G
3G standard WCDMA
3G frequency B1(2100MHz), B8(900MHz)
4G standard FDD-LTE/TDD-LTE
4G frequency
B1(2100MHz), B3(1800MHz),
B7(2600MHz), B8(900MHz),
B20(800MHz), B38(2600MHz),
B40(2300MHz), B41(2500MHz)
PTZ Rotation angle Horizontal: 350°
Rotation speed Vertical: 90°
General
Power supply Horizontal: 30°/sec.
Consumption Vertical: 35°/sec.
Waterproof IP66
Housing ABS
Dimensions 105 x 100 x 170 mm
Weight 500 g

5User manual
English
Installation
Note: Before installing the camera in the final location, insert a micro SD
card and a nano SIM card into the camera, power the camera, add it to the
application and test its functionality.
Micro SD and nano SIM card installation
1. Undo the screw and remove the compartment cover from the back of the
camera.
2. Install a micro SD card (max. 128GB) and a nano SIM card inside.
Warning: the SIM card with 4G mobile data must not have the PIN code
activated. Insert the SIM card with mobile data into a mobile phone, disable
the security PIN and check if mobile data is available by accessing any web
page.
1. Reset button
2. Micro SD card slot
3. Nano SIM slot

User manual 6
English
CamHi Pro app
1. Install the CamHi or CamHi Pro application on your mobile phone by
accessing Google Play or the App Store or scan the QR codes below:
Android CamHipro iOS
Camera configuration
2. Power the camera using the power supply in the package.
3. The camera will start initializing. When the camera stops rotating, it is
ready for configuration.
4. Open the application and press the “+” icon.
5. From the displayed options, select “4G camera”.
6. Enterthecamera’sUIDmanuallyorscantheQRcode.TheUID,username,
password and QR code can be found on the label attached to the camera.
Press “Confirm add”.
7. Give the room a name. Press “Confirm”.
8. For reasons of brevity, you are advised to change the room password.
Change the password and press “Apply”.
9. After you have successfully added the camera, click on the camera in the
list to view the images taken by it in real time.
Note: The camera status must be Online. If the status is Oine, proceed as
described in the chapter “Manually adding GSM parameters”.
Note: IP65 live camera does not support WiFi connection, only LAN via
RJ45.

7User manual
English

User manual 8
English
Meaning of the red LED on the GSM card
Blinks rarely - Not connected to GSM
Blinks very often - Connected to GSM
Manually add the GSM parameters
If the status of the camera is Oine, proceed as follows:
1. Connect the camera to the router via Ethernet cable.
Note: IP65 live camera does not support WiFi connection, only LAN via
RJ45.
2. Wait for the camera status to become Online.
3. Press the icon to access the additional settings menu.

9User manual
English
4. Access the “4G setting” menu.
5. Choose the “Manual” option for “APN Mode”.
6. Manually enter the APN, Username and Password corresponding to the
GSM operator of the card inserted in the camera.
For example, for the Vodafone SIM card:
APN: live.vodafone.com
Username and Password: leave blank
7. Remove the Ethernet cable from the camera.
8. Restart the camera.

User manual 10
English
Preview interface settings
Available options:
• Start/Stop manual recording.
• Enable/Disable loudspeaker (press to listen to the sounds picked up by
the surveillance camera).
• Retrieve capture image.
• Activate/Deactivate microphone (press to talk to the person in front of
the surveillance camera).
• Camera rotation up/down, left/right.
• Image enlargement (digital zoom).
• Image mirroring (horizontally or vertically).
• Predefined camera position setting.
• Volume control.
• Image adjustments (contrast, brightness, saturation).
• Night mode setting:
Infrared mode: the 2 IR LEDs + 4 IR LEDs and white light light up.
Color mode: the 4 LEDs with IR and white light light up.
Smart mode: the 2 LEDs light up with white light only when the camera
detects movement.
A - 2 white light LEDs
B - 4 IR LEDs and white light
C - 2 IR LEDs
