1. Aboutcamera

1.1Productintroductionandmainfeatures:

PNIIP652W/IP655Bproductisa2MP/5MPIPcameraforvideosurveillanceandremotemonitoring.It

connectstotheInternettosendandreceivedataandyoucanuseittoremotelyviewreal‐timeimages

fromyourmobilephone,computerorotherdeviceanytimeandanywhere.Itcansavesurveillancevideos

onmicroSDcard,computerorotherdevicelikecompatibleNVR.Thecameraalsosupportsalarmfunctions

suchassendingalarmemails,alarmingphonemessagepushandotherfunctions.

WiFisupportandAPmodesupport;

Supportupto128GTF/microSDcardstorage;

2.7‐13.5mm5Xopticalzoomautofocuslens;

Supporttwowayaudio(built‐inMICandspeakers);

PTZ‐Pantiltrotation,horizontal:355°&vertical:120°;

WaterproofprotectionlevelIP66;

6pcsarrayinfraredLEDsprovidenightvisionupto50mdistance;

SupportP2Pconnection,remotemonitoringfromanywhere&anytime;

Elegantoutlineandeasyinstallation;

Providesandroid&iOSAPPandprofessionalPCclientsoftwareforWindows;



1.2Productboxcontains:

①IPCamera

②Poweradapter

③Usermanual

④Networkcable

⑤WIFIAntenna

⑥Screwsbag



1.3Productinterface:



ResetButton

Power

RJ45Interface

English

üzembehelyezésiútmutató/GuidaRapida/Skróconainstrukcjaobsługi/Ghidrapiddeconfigurare

3/79

2. Connectcamera

2.1Connectnetworkcabletorouterandplugincamerapoweradapter



2.2Connectnetworkcableandpowertothecamera,itneedsaboutafewminutestoselfcheckingand

thenstartworking



Networkindicatorlight(green):alwaysflashingmeansnetworkdatatransmissionisnormal



3. Viewviamobilephone

3.1Download“CamHi”fromGooglePlayStore/AppleAppStoreorscantheQRcodebelowtogetAPP

information



AndroidIOS

ThecamerawillturnonAPmodewhenthecameraisonlyconnectedtothepowersupply.Youcan

connecttocameraviatheAPmode.Fordetails,pleasefindhelpdocumentation“Howtousethe

APmodeofthecamera”intheCDinformation.

TheroutermustbeabletoconnecttotheInternet!

Pleaseusethestandardpowersupply.

English

üzembehelyezésiútmutató/GuidaRapida/Skróconainstrukcjaobsługi/Ghidrapiddeconfigurare

4/79

3.2 RunAPPandAddCamerafolowingtheprocedurebelow.Afterthisstep,renameyourcamera,

andfinishprocedure

 

CheckandenterDefaultUsernameandPassword:admin/admin



3.3 Afteraddingthecamera,clickonlinecameratoviewreal‐timeimage





1.click“Add

Camera”

2.Click”Search

camerafromLAN”

clickhereto

monitor.

OryoucanentertheUIDby

scanningtheQRcodeonthe

camera'slabel,asshown

below(ifavailable)orinput

camera’sUIDmanuallyfrom

cameralabel(ifavailable)

DetailedinstructionsforCamHiappare

availableintheCD,andontheproduct’s

webpagewww.pni.ro

English

üzembehelyezésiútmutató/GuidaRapida/Skróconainstrukcjaobsługi/Ghidrapiddeconfigurare

5/79

4. ViewcamerafromPC

4.1Forproductconfigurationinstall“Searchtool”softwarefromtheCD.Runsoftwareandsearch

camerainLAN(CameraandPCmustbeconnectedinthesamenetwork/router)



Click“Next”andyoucanmodifynetworkparametersofthecamera,acordingtoyournetworksettings.

YoucanuseDHCPsettingforfasterconfiguration.



4.2 InordertoaccessremotelyIPcamerathroughInternetinstallanduse"HiP2PClient"softwarefrom

CD(forPC/LaptopwithWindows).Thesoftwareallowstheinitialsearchandconfigurationof

camerainthelocalnetworkandtheadvancedconfigurationofthecamera’sparameters.



Note:ThecameracanalsobeaccessedfromIEbrowserbyenteringIPandportofcamera:

http://XXX.XXX.XXX.XXX:80wherexxistheIPaddressfoundinSearchTool.

Defaultusername:

admin

Defaultpassword:

admin

2.doubleclickcamera

informationtoaccesscamera

inInternetExplorerBrowser

1.Click"Refresh"to

findthecamera

HiP2PClientsoftwareinstallationpackagesandinstructionsareavailableonCDoronseller’s

webpagewww.pni.ro

English

üzembehelyezésiútmutató/GuidaRapida/Skróconainstrukcjaobsługi/Ghidrapiddeconfigurare

6/79



5. SetWIFI

5.1SetWIFIonphone

  



1.clickhereto

entersettingpage

2.click“WI‐FI

Setting”

3.selectWIFI

andenter

password

English

üzembehelyezésiútmutató/GuidaRapida/Skróconainstrukcjaobsługi/Ghidrapiddeconfigurare

7/79

5.2SetWIFIviabrowseronPC



6. SetMicroSDcardrecord



6.1FindthecameraMicroSDcardinstallationtutorialsfromCDandinstalltheMicroSDcard(128Gb

maximum)intothecamera



6.2Setmotiondetectionalarmrecordingfromphoneapp

TheWIFIRoutermusthaveasignalvaluegreaterthen50%andWIFInamemustbeEnglishandcan

notcontainspecialcharacters.

AftertheWIFIsettingiscompleted,thecamerawillautomaticallyswitchtotheWIFIconnection

whenthenetworkcableisunplugged.

MotiondetectionalarmrecordingisrecommendedwhentheMicroSDcardissmall.

Thisway,thecamerawillonlyrecordvideoonSDCardwhenmotionisdetectedinthe

viewfieldofthecamera.

1.Enter

“wireless”page2.SelectWIFI

3.Enterpassword

4.WIFItest

5.Savesettings

English

üzembehelyezésiútmutató/GuidaRapida/Skróconainstrukcjaobsługi/Ghidrapiddeconfigurare

8/79

  



6.3Setschedulerecordingonphone



 



1.open“Enable

Record”inRecording

Schedulemenu

1.TurnOn“Motion

Detection”inAlarm

Settingsmenu

2.TurnOn“Alarm

SDREC”inAction

withAlarmMenu

3.checkiftheSD

cardisavailable

2.checkiftheSD

cardisavailable

English

üzembehelyezésiútmutató/GuidaRapida/Skróconainstrukcjaobsługi/Ghidrapiddeconfigurare

9/79

6.4Playbackrecordonphone

  



7. Rebootandrestorefactorysettings

7.1Reconnectthepowertorestartthecamera



7.2Pressandholdtheresetbuttonfor15secondsandthecamerawillrestoretofactorysettings



1.clickhereto

enterrecordpage

2.clickonline

camera

3.Playordownload

videofiles

TheseparameterscanbesetinmoredetailviaHiP2PClientSoftwareorIEbrowseronthePC!

AlsoyoucanrestartorresetthecameraviamobilephoneorPC.

English

üzembehelyezésiútmutató/GuidaRapida/Skróconainstrukcjaobsługi/Ghidrapiddeconfigurare

10/79

8. Specifications

ModelPNIIP652WPNIIP655B

VideoSensor2.0megapixel1/2.8"SONY307CMOS5.0megapixel1/2.8"SONY335lowluxCMOS

Videoresolution

Mainstream:1920x1080@18fps/

Substream:640x352@25fps,320x176@25fps

Mainstream:2560x1920@15fps,2560x1440@15fps

Substream:800x600/800x448@25fps,

640x480/640x352@25f

s

VideocompressionH.264 H.265

Lens2.7‐13.5mm5Xopticalzoomautofocuslens2.7‐13.5mm5Xopticalzoomautofocuslens

Viewangle96°~26.2°96°~26.2°

Nightvision 6pcsarrayinfraredLEDs,nightvisiondistance6pcsarrayinfraredLEDs,nightvisiondistance50m

Audio

AudiocompressionG.726/G.711G.726/G.711

Audiocoderate8Kbps,16bit8Kbps,16bit

Audioinput/outputBuilt‐inMICandspeakers,supporttwowayBuilt‐inMICandspeakers,supporttwowayaudio

Alarm

Motiondetecting

alarm

Canset4independentdetectionregion(1‐100

sensitivitycanbeset)

Canset4independentdetectionregion(1‐100

sensitivitycanbeset)

Alarmlinkage

Alarmsendpicturestothemailbox,

AlarmuploadpicturesandvideostoFTPserver,

Alarmrecordpictures,videostoMicroSDcard

Alarmmobilephonemessagepush,

Alarmtriggersoundalarm

Alarmsendpicturestothemailbox,

AlarmuploadpicturesandvideostotheFTPserver,

AlarmrecordpicturesandvideostoMicroSDcard,

Alarmmobilephonemessagepush,

Alarmtriggersoundalarm

AlarmrecordingSupportMicroSDcardandPCclientlinkageSupportMicroSDcardandPCclientlinkagealarm

Network

WirelessIEEE802.11b/g/nIEEE802.11b/g/n

EthernetRJ45EthernetRJ45Ethernet

OnvifprotocolSupportONVIF2.4(backwardcompatible)SupportONVIF2.4(backwardcompatible)

Storage

MicroSDcardSupportupto128GmicroSDcardSupportupto128GmicroSDcard

RecordingmodeAlarmrecord,timingrecord, Alarmrecord,timingrecord,

VideoplaybackSupportAPP,IEbrowser,remoteclientplayand

downloadthevideo

SupportAPP,IEbrowser,remoteclientplayand

downloadthevideo

PTZ

RotationangleHorizon:0°～355°,Vertical:0°～120°Horizon:0°～355°,Vertical:0°～120°

Horizontalspeed10°～30°/S10°～30°/S

Verticalspeed8°～25°/S8°～25°/S

Preset8presetpoints,supportscruisefunction8presetpoints,supportscruisefunction

General

specification

PowerDC12V2ADC12V2A

Operating

environment

Environment‐20Ԩ~+60Ԩ(‐4Ԭ~+140Ԭ),

Humidity10%～90%,non‐condensing

Environment‐20Ԩ~+60Ԩ(‐4Ԭ~+140Ԭ),

Humidity10%～90%,non‐condensing

ShellmaterialAllmetalshellAllmetalshell

WaterprooflevelIP66IP66

Productsize160mm×100mm×175mm(L×W×H)160mm×100mm×175mm(L×W×H)

Productweight0.9kg0.9kg

Packagesize225mmx205mmx120mm(L×W×H)225mmx205mmx120mm(L×W×H)

Packageweight1.2kg1.2kg

ResetbuttonSupportSupport

English
