Polaris NRX-4 User manual

User Guide
NRX-4
TThheeTTwwooLLiinnee
TTeelleepphhoonneewwiitthh
CCoonnffeerreenncceeFFaacciilliittyy
TTeelleepphhoonneessooffDDiissttiinnccttiioonn
BBuussiinneessssTTeelleepphhoonneeRRaannggee

2
NRX --Display Feature Phone
INDEX
TTEELLEEPPHHOONNEELLAAYYOOUUTT
11..IINNSSTTAALLLLAATTIIOONN
22..OOPPEERRAATTIIOONN
2.1 Dialing
2.2 Two Line Facility
2.3 Hold
2.4 Incoming Calls
2.5 Conference Calls
2.6 Programming Memory Buttons
2.7 Memory Dialling
2.8 Privacy (Muting the Microphone during Conversation)
2.9 Modem/Data Connection Socket
2.10 Message Waiting
2.11 Last Number Redial
2.12 Adjustable Ringing Volume
2.13 Adjustable Ringing Tone Pitch
2.14 Speakerphone Facility
2.15 Hearing Aid Compatibility
33..WWAALLLLMMOOUUNNTTIINNGGTTHHEEUUNNIITT
NRX The Two Line Telephone with Conference Facility

3
NRX-3 --Display Feature Phone
TELEPHONE LAYOUT
NRX-4
-The Two Line Telephone with Conference Facility
Tel No:
EXT:
0
4
7
1
65
89
2 3
ABC DEF
MNOJKLGHI
TUV
PQRS WXYZ
LINE 1
REDIAL
0
VOLUME CONTROL
SPEAKERPHONE
LINE 2
HOLD
CONF
FLASH
Volume Step Up/Step Down
Control Buttons
Last Number Redial
Speakerphone
Button
Line 1
Line 2
Conference Call
Button
Hold Button
Flash Button
Number Keypad
Memory Buttons
Message Waiting/
Ring Indicator
Wall Mount Tab
6.
2. 3. 4. 5.
7. 8. 9. 10
1.

1. INSTALLATION
The Model NRX-4 telephone requires no batteries to be fitted as the memories are
stored in EEPROM solid state memory which does not require battery backup.
Connect one end of the coiled cord to the handset and the other end to the socket
at the left of the base unit. Replace the handset on the cradle.
Connect one end of the telephone line cored to the socket at the back of the unit
and connect the other end to the telephone socket at the wall.
2. OPERATION
22..11DDiiaalllliinngg
Lift the handset or press speaker button. The telephone will automatically seize the
first free line.
Dial the number.
To terminate a phone call, simply replace the handset or press the speaker button again.
22..22TTwwooLLiinneeFFaacciilliittyy
The telephone automatically selects the first free line when the handset is lifted or the
speaker button depressed. The line in use is indicated by a red LED on the line button.
22..33HHoolldd
During the course of a conversation the line can be put on Hold by simply pressing
the hold button. A green LED will light on the line button concerned. In this state,
a call can be answered or set up on the other line.
The call can be released from its held state by pressing the appropriate line button.
22..44IInnccoommiinnggCCaallllss
Incoming call on either of the lines is indicated by a flashing red LED on the line
button together with the ringing tone and flashing of the main ringer indicator (top
right corner of the telephone).
22..55CCoonnffeerreenncceeCCaallllss
It is possible to set up a three party conference call as follows:
●Set up or receive a call
●Put this call on hold by pressing the hold button
●Set up or receive a second call on the other line
●Press conference button to establish a three party call
●Replace the handset or press speaker button to release both lines
If you wish to release only one line from the conference, press the line button for the
line you wish to maintain. This will release third party on the other line.
NRX-4
-The Two Line Telephone with Conference Facility
4

NRX-4
-The Two Line Telephone with Conference Facility
5
22..66PPrrooggrraammmmiinnggMMeemmoorryyBBuuttttoonnss
There are 10 memory locations in the NRX 4 telephone, which can be used to store
important telephone numbers. The following is an example of storing a number in
one of the locations:
1. Lift the handset or press the 'Speaker" button once.
2. Press the 'PROGRAM' button. (This is concealed under memory label).
3. Enter the telephone number for storing. After the number has been entered,
press the 'PROGRAM' button again.
4. Select one of the direct memory locations for storing the number at
that location.
5. Repeat steps 2 to 4 for successively storing more than one telephone
number. When all numbers have been stored replace the handset.
The programming can be enabled and disabled by means of the following key
sequence:
1.1 To disable the programming [PROGRAM] [VOL UP] [PROGRAM] [0].
1.2 To enable the programming [PROGRAM] [VOL UP] [PROGRAM] [1]
22..77MMeemmoorryyDDiiaalllliinngg
To dial a telephone number that has been stored in one of the direct memory
locations
1. Lift the handset or press the 'Speakerphone' button.
2. When you hear the dial tone, press one of the memory location buttons.
22..88PPrriivvaaccyy((MMuuttiinnggtthheeMMiiccrroopphhoonnee
dduurriinnggCCoonnvveerrssaattiioonn))
During a telephone conversation, you may switch off the microphone in the handset
by pressing the Mute button on the handset. As long as the handset Mute button
is pressed, the microphone mute function is activated. Releasing the handset Mute
button will re-enable the microphone for conversation.
22..99MMooddeemm//DDaattaaCCoonnnneeccttiioonnSSoocckkeett
The NRX4 telephone has an additional socket marked MODEM, which allows the
user to connect an extra telephone, modem or fax machine to the telephone line.
This socket is at the back panel of the base cabinet and has a removable plastic cover.

22..1100MMeessssaaggeeWWaaiittiinngg
The NRX4 has a built in LED and neon lamp for message waiting indication. This is
compatible with various PABX systems providing such features. A message waiting
switch is built inside the switch compartment located on the base bottom. This
switch enables the LED to detect two different line reversal signals by selecting switch
position 1 or 2.
For 90V DC or AC message waiting signalling PABX's the neon is used for indication.
Set the position of the switch to off, as the LED is not needed for indication.
The default switch position is OFF.
Please note the compartment door should be replaced when settings completed.
22..1111LLaassttNNuummbbeerrRReeddiiaall
If you dial a number and find it is engaged or there is no reply, replace the handset
or depress the speaker button. The number will be retained in the memory until you
dial a different number.
What
to do: Lift the handset or press ‘Speakerphone’ button
Press the 'Redial' button
22..1122AAddjjuussttaabblleeRRiinnggiinnggVVoolluummee
On the right of the unit is a switch, this adjusts the ringing volume of incoming calls.
From left to right it has three positions: off, low, high. Move the switch to the
position your require. In addition to the ringing tone there is a Ring Indicator Lamp
on the unit that will flash when the telephone is ringing as a visual indication. The
Ringer Switch does not control this Ring Indicator Lamp.
22..1133AAddjjuussttaabblleeRRiinnggiinnggTToonneePPiittcchh
On the right of the unit, there is also a switch that adjusts the ringing pitch of
incoming calls. From left to right it has three positions: low, medium and high.
Move the switch to the position you require.
22..1144SSppeeaakkeerrpphhoonneeFFaacciilliittyy
The 'Speakerphone' button enables you to use the telephone without lifting the
handset when a headset is not connected to the telephone. Pressing the
'Speakerphone' button again will disconnect the telephone line and terminate the
call.
During a speakerphone conversation, lifting the handset will switch the unit to the
handset mode. The speakerphone will be disabled and the handset should be used
for conversation instead. The speakerphone mode will be activated again by pressing
the 'Speakerphone' button and replacing the handset.
NRX-4 The Two Line Telephone with Conference Facility
6

22..1155HHeeaarriinngg--aaiiddccoommppaattiibbiilliittyy
The handset receiver is hearing aid compatible.
3. WALL-MOUNTING THE UNIT
The NRX 4 telephone can be wall mounted using the wall mount bracket installed
on the bottom of the unit.
●Dismount the wall mount bracket from the unit.
●Placing the wall mount bracket to the required position on the wall.
●
Drill two holes on the wall according to the distance as marked by two mounting holes.
●Install the two screws supplied with the unit in the wall.
●
Re-install the wall mount bracket to the bottom cabinet for the wall mount position.
●Position the wall mount slots on the bracket of the unit over the two screws on
the wall. Pull down and lock into place.
●Beneath the earpiece section of the cradle you will find a small tab. Pull this up to
form the hook for the handset.
● When you are on the telephone, you sometimes need to put the handset down for
a moment. There is a special hook at the back (top) of the unit so that you can hang
the handset on the unit when it is wall mounted, without terminating the call.
NRX-4
-The Two Line Telephone with Conference Facility
7
