Polycom®SoundStation2™
Avaya 2490
Setting the Standard. Again.
Benefits
More productive calls –
Polycom’s patented Acoustic
Clarity Technology allows
simultaneous, natural,
freeflowing conversation
Hear and be heard clearly
– Twice the loudness and
microphone sensitivity of
the original SoundStation
– eliminates ear strain and
repetition
Resists interference from
mobile phones – Clearer calls
with no distracting noise from
wireless devices
Backlit display provides
important information –
Displays console phone number,
number called, duration/
progress of call
Ability to increase coverage –
Optional extension microphones
expand coverage for larger
conference rooms
DEFINITY ECS conferencing
feature – Direct access to your
Avaya DEFINITY’sconferencing
feature allows quick and easy
connections of up to six*
locations in a singleconference
call without using a conference
bridging service
*Dependent upon DEFINITY ECS configuration
Remarkable Voice Quality. Avaya®DEFINITY®Compatibility.
For Avaya DEFINITY users, communicating with crystal clarity couldn’t be
easier. Just connect a SoundStation2 Avaya conference phone directly into
a DEFINITY ECS digital wall jack. You don’t need an analog port, analog
adapter, or complicated connections to take advantage of natural two-way
conversations with Polycom’s breakthrough Acoustic Clarity Technology.
Polycom’s SoundStation2 product line has redefined the standard for
business-quality voice conferencing. With industry-leading full duplex for
natural, simultaneous two-way conversation, the SoundStation2 Avaya
conference phone will exceed your expectations in medium to small
conference rooms. Delivering remarkable voice quality equal to the original
SoundStation Premier® 500D/550D conference phone and a 50% increase
in microphone sensitivity over the award-winning SoundStation, users can
speak in a normal voice and be heard clearly up to ten feet away – making
every call a more productive call.
SoundStation2 Avaya conference phone provides users with advanced
features, including a large backlit display that offers easily visible call
information and telephone functions. Smart technology, such as Dynamic
Noise Reduction (DNR), provides maximum microphone sensitivity, while
reducing distracting room and background noise. And the SoundStation2
Avaya conference phone offers 360-degree microphone coverage with
intelligent mixing – so only the microphone closest to the speaker is on
for crystal clear conferencing. It also features technology that resists
interference from mobile phones and other wireless devices, delivering
clear communications with no distractions. Plus, the SoundStation2 Avaya
conference phone provides direct access to your Avaya DEFINITY’s
conferencing feature, allowing quick and easy connections of up to six*
locations in a single conference call without using a conference bridging
service.

Architecture
Tabletop console contains audio processing•
functions and keypad. Wall module contains power
and PBX line interfaces.
Cables consist of 21 ft (6.4 m) single-cord•
connection to tabletop console and 6 ft (1.8 m)
connection to RJ-11 telephone jack. Optional
Extended microphone modules connect to console
via 7 ft. (2.1 m) cables
Console
Size (L x W x H)
14.5 x 12.25 x 2.5 in•
(36.8 x 31.1 x 6.4 cm)•
Weight
1.75 lb. (0.8 kg)•
Power
110V 60Hz AC / 220V 50 Hz AC (depending on•
country-specific SKU)
Network interface
Avaya DEFINITY ECS•
PBX Compatibility
Compatible with any DEFINITY voice port that•
supports the 6400, 7400 or 8400 series phones
(except the Callmaster series)
Display
132x65 pixel backlit graphical LCD•
User interface*
User selectable ring tones•
Configurable soft keys for easy dialing of voice•
conferencing services
Multi-lingual support: English, German, French,•
Italian, Spanish, Portuguese, Norwegian
Password protected configuration settings for•
administrators
Caller ID and phone book
Phone book/speed dial list – up to 25 entries•
Keypad
12-key telephone keypad•
On-hook/off-hook, conference, mute, volume up/•
down keys, menu, navigation keys*
3 context sensitive soft keys* including redial, hold,•
programmable conference key
Console loudspeaker
Frequency response: 300 to 3300 Hz•
Volume: adjustable to 94 dBA SPL (peak) volume•
at 0.5 meters
Console microphones
3 cardioid microphones 300 to 3500 Hz•
Audio
Polycom Acoustic Clarity full duplex – IEEE 1329•
Type 1•
Up to 10 ft. microphone pick-up range•
Gated microphones with intelligent microphone•
mixing
Dynamic noise reduction•
Interfaces
2 EX microphone connections*•
Applications Port* for connection to other•
communication devices such as mobile phones†
and computers
RCA Auxiliary audio jack•
Accessories
2 cardioid extension microphones 300 – 3500 Hz•
(for EX model only)
Regulatory compliance
NA Cl/C-UL•
FCC Part 68•
FCC Part 15 Class B•
Canadian ICES-003•
CE Mark (R & TTE Directive)•
Environmental requirements
Operating temperature: 40° - 104°F (5° - 40°C)•
Relative humidity: 20% - 85% (noncondensing)•
Storage temperature: -22° - 131°F (-30° - 55°C)•
Recommended room conditions
Reverberation time: <0.5 seconds•
Noise level: <48 dBa•
SoundStation2 ships with:
Tabletop phone console•
21 ft. (6.4 m) cord to console•
6 ft. (1.8 m) telco cable to RJ-11 telephone jack•
User documentation (user guide CD, quick•
installation guide, registration card)
Warranty
1 year•
Part Numbers (North America)
2305-16375-001: SoundStation2 Avaya 2490•
2200-16155-001: Extension microphone kit•
† SoundStation2 uses a cable that connects to
a standard 2.5mm headset connector. If your
mobile phone model does not support this type of
connection you will need an adapter (not included).
Connecting the SoundStation2 to a mobile phone
is analogous to connecting a headset to a mobile
phone. Not all mobile phone models recognize the
SoundStation2 as a headset. For a list of mobile
phones that are known to work with SoundStation2,
please consult www.polycom.com.
Polycom®SoundStation2®Avaya2490 Specifications
Part No. 3726-17475-001 Rev 082409
Users receive the same great quality and features as the Polycom SoundStation2 conference phone, including:
Polycom Acoustic Clarity Full Duplex
3 Cardiod microphones
10ft Microphone Pickup range
Intelligent microphone mixing
Dynamic Noise Reduction
Volume (adjustable up to 94 dBA @ 0.5m)
User selectable ring tones
12-key telephone keypad
Mute, Volume up/down keys
Mute, Conference keys
Graphical Backlit LCD
Configurable conference Speed Dial Key
3 Context sensitive soft-keys
Multi-lingual User Interface
CallerID
25 Entry Phone Book
RCA Auxiliary Audio Jack
Applications Port
EX microphone jacks
