Polygroup TV70M3AVBL00 User manual

3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective cap before inserting into
the assembled stand. Make sure the pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out.When adjusting branches, be sure that all wires are free of branch
hinges.
7. Connect the light strings as per the color labels indicated in Fig. B and insert green label adapter into the wall outlet.Your
entire tree should now be lit.If some bulbs do not light or flickers, search for any loose plugs and/or broken, loose or missing
bulbs. Replace bulbs promptly in order to maintain the performance and life expectancy of your pre-lit tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Congratulations on purchasing your new tree from Polygroup®!
Carefully follow the instructions below on how to quickly and easily set up your new tree.
TREE ASSEMBLY INSTRUCTIONS
MODEL #: TV70M2D31L03, TV70M3AVBL00
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: 120V, 60Hz, 0.08A
Output: 28V DC 0.107A
Fig. B - Tree and Light Assembly
1
Adapter
To Be Plugged
Into Wall
Outlet
Insert Green
Label Extension
Cord into Adapter
Insert Red Label
Plugs Into Red
Labeled Extension Cord
Section 1
Section 2
Tree top
Foot Pedal
on/off Switch
Fig. A - Tree Stand Assembly
Pull apart the legs of the stand so that they
are snapped into an x-shape, place the tree
stand on a level surface.
To close the stand, press the metal button
and fold the legs together.
Click
NEED HELP?
DO NOT RETURN TO STORE. PLEASE VISIT US AT:
www.polygroupstore.com OR 1-888-919-0070

8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out one
to the right, one to the left and one at the center of the main stem. (See Fig. C)
9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform look. Shift branches to fill
any gaps.Your Christmas tree is now complete and ready to be decorated.
Top view Side view
Fig. C
2
1. Unplug adapter from the wall outlet first and then remove all ornaments and decorations.
2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to remove from section
below and fold all branches toward the pole.
3. In case of difficulty separating the tree pole (trunk), apply a small amount of lubricant at the joint and rotate the upper pole in
both directions. Lift up the upper pole again.
4. Continue by gently lifting straight up each section(s) from the section below and fold all branches toward the pole until the
bottom section is removed from the tree stand.
5. Carefully place all tree sections into shipping box and tape it shut.
6.When not in use, please store your tree in a cool, dry place away from sunlight. Exposing your tree to excessive heat or humidity
may damage your tree.
7. Keep out of reach of pets and children.
STORAGE INSTRUCTIONS
For Pre-lit Trees, If The Tree Does Not Illuminate
1. Please check to make sure that all plugs are properly connected and adapter is plugged into the wall outlet. (If the tree comes
with a foot pedal, try stepping on the on/off button).
2. Please check for loose, broken or missing light bulbs and replace as needed.
Loose Hinge Pin
1. Extra hinge pins are included for repairing the hinges.
Place the branch into the slot of the bracket.
2. Insert a new hinge pin through the hole and secure
using the retainer washer. (See Fig. E)
TROUBLESHOOTING TIPS
Each tree includes hinge pins/washers, and for pre-lit trees spare bulbs are also included.
If extra parts are needed, please contact our customer service center.
SPARE PARTS
Fig. E
CAUTION:
1.To reduce the risk of fire and electric shock:
a) Use only the power supply that was provided with this product;
b) Do not install on trees having needles, leaves or branch covering of metal or materials which look like metal, and
c) Do not mount or support strings in a manner that can cut or damage wire insulation.
2. Use only the adapter supplied with this product. Using a different adapter will damage the lights and may cause fire, or
electrical shock hazards.
For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact us at 1-888-919-0070
or visit our website at www.polygroupstore.com. One of our customer service representatives will be happy to assist you.
CUSTOMER SERVICE FOR CHRISTMAS TREES
Tree ID#:
Tree UPC#:
Store Purchased:
Specify Problem:
Customer Name:
Address(No P.O. Boxes):
City & State:
Zip Code:
Day Phone:
Date Purchased:
TREE ID# IS LOCATED ON END PANEL OF BOX.TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.
