Porta Phone The EPAK User manual

Safety
1. To prevent possible hearing damage, do not listen at high volume levels for long periods.
2. Risk of explosion if battery is replaced by an incorrect type, dispose of battery according to
the instruction.
3. Recycle your products
The WEEE logo (shown at right) appears on the product to indicate that this product must not
be disposed of or dumped with your other household wastes. You are liable to dispose of all
your electronic or electrical waste equipment by transporting to an appropriate collection
point for recycling of such hazardous waste.
FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment.
IC Warning:
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause undesired operation of
the device.
IC Radiation Exposure Statement:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled
environment. This device and its antenna(s) must not be co-located or operating in conjunction
with any other antenna or transmitter.
FCC Notice
This device complies with Part 15 of FCC rules. Operation is subject to the following 2
conditions: (1) This device may not cause harmful interference, and (2) This device must accept
any interference received, including interference that may cause undesired operation. Changes
or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
Warranty
Porta Phone items are warrantied against defects in material and/or factory
workmanship for a set period from the date of purchase. Standard repairs due to
misuse or wear and tear, as well as replacement parts including but not limited to
batteries, padding, USB cable, etc. are excluded. Shipping to Porta Phone is at
customer’s expense, Porta Phone will pay for return ground shipping if the product
warranty applies to the repair. Call for details.
Shipping
Prior to returning your headset for warranty or service you must call Porta Phone for
an RA (return authorization) number: 1 [phone].
General Service
All repair work will be performed for the cost of replacement parts and return
shipping from the Porta Phone factory.
Service / Porta Phone www.portaphone.com
145 Dean Knauss Drive 1 [phone]
Narragansett, RI. 02882
The EPAK
Coach to Catcher
Full Duplex Wireless

IMPORTANT
E-Pak intercoms include one “MAIN” transceiver.
When this MAIN unit is
turned “ON” all radios in the system will link automatically.
PAIRING WIRELESS HEADSETS
1. Slow Flash Searching for the most recently paired headset
2. Solid Blue E-Pak and wireless headset are connected
3. Rapid Flash Ready to pair with a new wireless headset
4. Blank No wireless headset connected
HEADSET INSTRUCTIONS
SET-UP
BATTERY CHARGING
Slide open battery door
Arrow/ contacts first
1. Install charged batteries.
2. Identify MAIN transceiver and press the
power button to turn ON.
3. Turn ON all REMOTE radios.
4. Flashing system/power LEDs turn
solid green indicating radios are linked.
Note: Catcher E-Paks will be specially
marked as listen only
Linking the E-Pak Radios
Individual LED Indicators:
Red -Charging
Green -Charged
Charge time appx.
3 hours
NOTE: Wireless headsets included with all new systems are
already paired to E-Pak.
Headsets are paired to
the E-Pak via the
blue programming button.
(This blue push button is also
a LED that indicates
wireless headset status.)
Microphone MUTE:
RED = Muted Mic
Unlit = Open Mic / Talk
Blue
Programming
Button
System/Power LED Power
Button
Volume
Up / Down
GAME DAY OPERATION
Visit portaphone.com/instructions-catalog/
The Lazer-Pro The T1
Mic Mute
Button
COACH:
Lazer-Pro
Headset
MAIN / COACH E-Pak
Worn on belt / on body
CATCHER:
T1 Earbuds
LISTEN-ONLY E-Pak
Snaps onto chest
protector strap
