Portable Power Technology C-15L-12 User manual

Multistage Battery Charger
User Manual
Design Features:
． PFC function. – except C-15L-12 / C-7L-24.
．Sleeping mode function.
．
Wide input voltage (universal) range operation. – except C-15L-12 / C-7L-24 .
． LCD remote control.
．Battery temperature sensor function.
．Tri-LED color indicator for different charge stage.
．
Adjustable charging mode switch for different lead-acid battery types.
． Prevent the battery overcharging, and extend the battery life.
．For recovery of the aging (sulfated) battery.
C-15L-12
C-7L-24
C-15-12
C-7-24
C-30-12
C-15-24
C-60-12
C-30-24
MHON06

List of contents
Important Safety Instructions 3
Where to install 4
Installation Illustration 7
Overview 5
Charging volt graph 8
C-15-12 / C-7-24 specification 11
C-30-12 / C-15-24 specification 12
C-60-12 / C-30-24 specification 13
Charging Formula 14
Charger LCD Remote Control 9
C-15L-12 / C-7L-24 specification 10

1. Important Safety Instructions
General Safety Precaution:
A. Do not expose the charger to rain, snow, spray, or bilge water. To reduce risk
of fire hazard, do not cover or obstruct the ventilation openings. Do not install
the charger in a zero-clearance compartment. Overheating may result.
B. The charger is designed to be permanently connected to your AC and DC
electrical systems.
C. Never use chargers at a location where there is danger of gas or dust explosions.
Before installing and using the charger, read all instructions and cautionary
markings on the charger, the batteries, and all appropriate sections of this guide.
D. Use only attachments recommended or sold by the manufacturer. Doing otherwise
may result in a risk of fire, electric shock, or injury to persons.
E.
Do not disassemble the charger. Attempting to service the unit yourself may result
in a risk of electrical shock or fire. Internal capacitors remain charged after all
power is disconnected.
F.
The charger must be provided with an equipment-grounding conductor connected
to the AC input ground.
G. To reduce the risk of electrical shock, disconnect both AC and DC power from
the charger before attempting any maintenance or cleaning or working on
any circuits connected to the charger. Turning off controls will not reduce this
risk.
H.
Do not operate the charger if it has received a sharp blow, been dropped,
or otherwise damaged in any way.
I.
To avoid a risk of fire and electric shock, make sure that existing wiring is in
good condition and that wire is not undersized. Do not operate the charger
with damaged or substandard wiring.
3

2. Installation Location:
Physical requirements for installation
Condition Description
The unit is intended for use in a dry location. Do not allow water
or other fluids to drip or splash on the charger. Do not mount
the charger in an area subject to rain, spray or splashing bilge
water.
Do not expose the charger to metal filings or any other form
of conductive contamination. The presence of conductive
contamination can cause damage and void your warranty.
For best performance, the ambient air temperature should be
between 5°F (-15°C) and 113°F (45°C)- the cooler the better.
At higher ambient temperatures, the output current will be
automatically reduced to protect the charger from high internal
temperatures.
Dry
Clean
Cool
Ventilated
Allow at least 4 inches (10 cm) of clearance around all sides
of the charger for air flow. Ensure that the ventilation openings
on the unit are not obstructed. If mounting in a compartment,
ventilate the compartment with louvres or cut-outs to prevent
overheating.
Close to AC
junction box
Avoid the use of extended wire lengths if possible.
Close to
batteries
Avoid excessive cable lengths and use the recommended
wire lengths and sizes. Undersized or overly long cables may
affect charging accuracy.
Safe
Working in the vicinity of lead-acid batteries is dangerous.
Batteries generate explosive gases during normal operation.
It is safest not to install electrical equipment in these areas.
4
IMPORTANT
This product is best mounted in a Horizontal position.
If the unit is mounted in a vertical position,
The cooling fan must be at the bottom of the unit.

C-60-12 ; C-30-24
5
Charging Status
Battery Temp. Sensor
Charging Mode Selection (Please refer to page 8)
Sleeping Mode Normal Mode
Warning :
Don't reverse the (+) and (-) of the
battery! Or internal damage will result!
Remote control-LCD
Fault
ON / OFF
Mode
-Black
+Red
DC OUTPUT
( Note 1 / Note 2 )
Charging Status
Battery Temp. Sensor
Charging Mode Selection (Please refer to page 8)
Sleeping Mode Normal Mode
Warning :
Don't reverse the (+) and (-) of the
battery! Or internal damage will result!
Main Switch
-Black
+Red
Slave Switch
DC OUTPUT
Remote control-LCD
Fault
ON / OFF
Mode ( Note 1 / Note 2 )
3. Overview
C-15L-12 ; C-7L-24 / C-15-12 ; C-7-24 / C-30-12 ; C-15-24
AC Input
Fan
A. Product Introduction
( Note 4 )
( Note 3 )
( Note 4 )
Slave Switch
Main Switch
AC Input
Fan
(2nd)
(Main)
Note 1:
Sleeping Mode: The fan would stop, and the charger working sound would be smaller,
so the output current would be 5A (12V spec.) and 2.5A (24V spec.) only.
Note 2:
Normal Mode: The charger would work as its max. capacity according to its spec.,
the fan would run if it's necessary.
( Note 3 )
Warning!
1.
Connecttothe battery Negative (-)
terminal only.
2.Positive(+) terminal may damage
Sensor & Charger.
Warning!
1.
Connecttothe battery Negative (-)
terminal only.
2.Positive(+) terminal may damage
Sensor & Charger.
Warning: Damage caused by wrong positive (+) and negative (-) connection
is not covered by the warranty.

Note 3:
Note 4:
The slave switch of the remote control just cuts out the output. If you want to turn
off the charger completely, please switch off main switch of charger body.
※Note 3
Warning:
Don'treverse the (+) and (-) of the battery!
Orinternal damage will result!
black
red
Battery
bracket - 2 parts : rear and frame.
B. Accessory
FRONT VIEW FrameRear
Battery Temp. Sensor: To detect the battery temp. While charging, please connect
the wire sensor to the battery Negative (-) terminal.
DON'T connect the sensor to the battery Positive (+) terminal. It may
damage
the sensor & charger.
Warning: Damage caused by wrong sensor cable connection is not
covered by the warranty.
6
How to instal?
 
C . Isolated Design
The DC battery charging circuits of this charger are galvanically isolated
by a transformer from the AC power circuits. This feature reduces the risk
of electric shock .

① With the frame only, if there’s the hole on the wall for phone jack.
②
With the frame and rear both, if the user just can screw the bracket on the
wall, no hole for phone jack.
or
When the battery (-) pole temp. reaches 65°C (+/-5°C) / 149°F (+/-41°F), the charger
would stop output.

(1). The chargers have been approved as Ignition Protected. They may be installed
in areas containing gasoline tanks and fittings which require Ignition Protected
equipment. It is safest not to install electrical equipment in these areas.
WARNING
Explosive gases; Prevent flames and sparks; Provide adequate ventilation during
charging. Include a warning against recharging non-rechargeable batteries.
If the supply cord is damaged, it must be replaced by a special cord or assembly
available from the manufacturer or its service agent.
Explosive gas precautions
7
Warning:
Don't reverse the (+) and (-) of the battery!
Or internal damage will result!
black (negative)
red (positive)
Battery
C-15L-12 ; C-7L-24 / C-15-14 ; C-7-24 / C-30-12 ; C-15-24
4. Installation Illustration
Before charging, read the instructions; for indoor use only. Disconnect the supply
before making or breaking the connections to the battery.
(2). To reduce the risk of battery explosion, follow these instructions and those
published by the battery manufacturer and the manufacturer of the equipment
in which the battery is installed.
C-60-12 ; C-30-24
Battery
Warning:
Don't reverse the (+) and (-) of the battery!
Or internal damage will result!
Battery
DC Negative Bus
black (negative)
red (positive)
red (positive)
Main battery
(the red Cable)
2nd battery
(the red terminal)
( Note 5 )
Note 5:
Please connect the main battery cable prior to 2nd battery terminal if you just have 1 battery.

8
5. Charging volt graph (0:OFF )
1 2 3
O N
1 2 3
O N
1 2 3
O N
1 2 3
O N
Mode 3
(003)
Mode 4
(020)
Mode 5
(023)
Mode 6
(123)
DC power supply.
[12.2V (for 12V spec.) /
24.5V (for 24V spec.) ]
1 2 3
O N
Mode 7
(000)
DC power supply.
[13.5V (for 12V spec.) /
27V (for 24V spec.) ]
Suitable for re-charging lead
storage battery, which is in good
condition battery (no any sulfated
situation),and completely
disconnected from the devices
it runs.because this mode has
the additional stage, the battery
may reach voltage too high for
them, and the limited current
delivered by the battery charger.
This is not able to provide power
for the devices, and stimultaneously
charge the battery.
Suitable for recovery of sulfated
gel battery, i.e.discharged batteries
unused for long periods or the battery
that never re-charges completely.
This mode should be applied with
the battery completely disconnected
from the devices it runs.
Suitable for recovery sulfated lead
storage battery, i.e. discharged
batteries unused for long periods or
the battery that never re-charges
completely.This mode should be
applied with the battery completely
disconnected from the devices it runs.
standby
orange orange
LED color
red green
standby
LED color
redred green
standby
LED color
green green
1 2 3
ON
1 2 3
ON
Mode 1
(100)
Mode 2
(120)
Suitable for re-charging
lead storage battery.
Suitable for re-charging
gel battery.
standby
orange orange
LED color
red green

6. Charger LCD Remote Control :
Fault
ON / OFF
Mode
Fault
ON / OFF
Mode
1. OFF
2. Mode 1 ~ 5, no battery connected.
4. Mode 1~ 5, float stage display. 3. Mode 1 ~ 5 while charging.
5. Mode 6 ~ 7: power supply mode.
6. Over temperature protection.
7. High battery volt protection.
Fault
ON / OFF
Mode
power supply DC output volt
output current ON/OFF switch
Fault
ON / OFF
Mode
battery volt
charging currentcharging mode
ON/OFF switchbattery capacity
Fault
ON / OFF
Mode
fault indicator (red lighting)
Fault
ON / OFF
Mode
fault indicator (red lighting)
Fault
ON / OFF
Mode
9
fault indicator
** If overload, the output volt would go down
gradually, according to the load current. **
mode

Model C-15L-12 C-7L-24
Voltage range
Frequency range
Efficiency
Power factor
Input socket
Mode Selection
Bulk Stage
Absorption stage (I)
Absorption stage (II)
Float stage
Max. current output
Continuous current output
Recommended battery capacity
Leakage current from battery
Over temperature
Overload
Output short circuit
Microprocessor check
WORKING TEMP.
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
Remote Control
Dimension (L x W x H)
Weight
Sleeping Mode Function
INPUT
OUTPUT
PROTECTION
ENVIRONMENT
OTHER
120Vac (100~130Vac) / 230Vac (180~240Vac).
45 ~ 65Hz
>=85%
0.5 at full load (±5％)
IEC plug
55°C±5°C (131°F±41°F)
YES
YES
YES
-15°C ~ +45°C (5°F ~ 113°F)
20 ~ 90% RH non-condensing
-30°C ~ +70°C (-22°F ~ +158°F) , 10 ~ 95% RH
±0.05%°C (0°C ~ 50°C/32°F ~122°F)
YES
213 x 142 x 72mm
1.9kgs
13.5V, 1A max
45 ~ 150Ah (12V)
<1mA
YES ( 5A current output only)
27V, 0.5A max
30 ~ 90Ah (24V)
<1mA
YES ( 2.5A current output only)
Mode 1
14.7V,
15A max
/
Mode 2
14.1V,
15A max
/
Mode 3
14.1V,
15A max
14.7V,
1A max
Mode 4
14.1V,
1A
14.1V,
1A
max
/
Mode 5
14.7V,
1A
14.7V,
1A
max
/
Mode 6
12.2V,
15A
12.2V,
15A
/
12.2V, 15A
Mode 7
13.5V,
15A
13.5V,
15A
/
13.5V, 15A
Mode 1
29.4V,
7A max
/
Mode 2
28.2V,
7A max
/
Mode 3
28.2V,
7A max
29.4V,
0.5A max
Mode 4
28.2V,
0.5A
28.2V,
0.5A max
/
Mode 5
29.4V,
0.5A
29.4V,
0.5A max
/
Mode 6
24.5V,
7A
24.5V,
7A
/
24.5V, 7A
Mode 7
27V,
7A
27V,
7A
/
27V, 7A
14.7V, 15A 29.4V, 7A
15A
15A
7A
7A
/
/
/
/
/
/
Note: Specifications subject to change without notice.
**The above spec. ±0.5V for 12V spec.; ±1.0V for 24V spec.; Amp. ±10% is acceptable.
C-15L-12 / C-7L-24 specification
10

Model C-15-12 C-7-24
Sleeping Mode Function
INPUT
OUTPUT
PROTECTION
ENVIRONMENT
OTHER
100~240Vac
45 ~ 65Hz
>=85%
1.0 at full load (+/-5%)
IEC plug
55°C±5°C (131°F±41°F)
YES
YES
YES
-15°C ~ +45°C (5°F ~ 113°F)
20 ~ 90% RH non-condensing
-30°C ~ +70°C (-22°F ~ +158°F) , 10 ~ 95% RH
±0.05%°C (0 ~ 50°C)
YES
213 x 142 x 72mm
1.9kgs
13.5V, 1A max
45 ~ 150Ah (12V)
<1mA
YES ( 5A current output only)
27V, 0.5A max
30 ~ 90Ah (24V)
<1mA
YES ( 2.5A current output only)
Mode 1
14.7V,
15A max
/
Mode 2
14.1V,
15A max
/
Mode 3
14.1V,
15A max
14.7V,
1A max
Mode 4
14.1V,
1A
14.1V,
1A max
/
Mode 5
14.7V,
1A
14.7V,
1A max
/
Mode 6
12.2V,
15A
12.2V,
15A
/
12.2V, 15A
Mode 7
13.5V,
15A
13.5V,
15A
/
13.5V, 15A
Mode 1
29.4V,
7A
max
/
Mode 2
28.2V,
7A
max
/
Mode 3
28.2V,
7A
max
29.4V,
0.5A max
Mode 4
28.2V,
0.5A
28.2V,
0.5A max
/
Mode 5
29.4V,
0.5A
29.4V,
0.5A max
/
Mode 6
24.5V,
7A
24.5V,
7A
/
24.5V, 7A
Mode 7
27V,
7A
27V,
7A
/
27V, 7A
14.7V, 15A 29.4V, 7A
15A
15A
7A
7A
/
/
/
/
/
/
Over temperature
Overload
Output short circuit
Microprocessor check
WORKING TEMP.
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
Remote Control
Dimension (L x W x H)
Weight
Note: Specifications subject to change without notice.
C-15-12 / C-7-24 specification
**The above spec. ±0.5V for 12V spec.; ±1.0V for 24V spec.; Amp. ±10% is acceptable.
11
Voltage range
Frequency range
Efficiency
Power factor
Input socket
Mode Selection
Bulk Stage
Absorption stage (I)
Absorption stage (II)
Float stage
Max. current output
Continuous current output
Recommended battery capacity
Leakage current from battery

Note: Specifications subject to change without notice.
Model C-30-12
C-15-24
Voltage range
Frequency range
Efficiency
Power factor
Input socket
Mode Selection
Bulk Stage
Absorption stage (I)
Absorption stage (II)
Float stage
Max. current output
Continuous current output
Recommended battery capacity
Leakage current from battery
Over temperature
Overload
Output short circuit
Microprocessor check
WORKING TEMP.
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
Remote Control
Dimension (L x W x H)
Weight
Sleeping Mode Function
INPUT
OUTPUT
PROTECTION
ENVIRONMENT
OTHER
100 ~ 240VAC
45 ~ 65Hz
>=85%
1.0 at full load (+/-5%)
IEC plug
55°C±5°C (131°F±41°F)
YES
YES
YES
-15°C ~ +45°C (5°F ~ 113°F)
20 ~ 90% RH non-condensing
-30°C ~ +70°C (-22°F ~ +158°F) , 10 ~ 95% RH
±0.05%°C
(0°C ~ 50°C/32°F ~122°F)
YES
252 x 142 x 72mm
2.5kgs
13.5V, 2A max
75 ~ 250Ah (12V)
<1mA
YES ( 5A current output only)
27V, 1A max
45 ~ 150Ah (24V)
<1mA
YES ( 2.5A current output only)
Mode 1
14.7V,
30A max
/
Mode 2
14.1V,
30A max
/
Mode 3
14.1V,
30A max
14.7V,
2A max
Mode 4
14.1V,
2A
14.1V,
2A max
/
Mode 5
14.7,
2A
14.7V,
2A max
/
Mode 6
12.2V,
30A
12.2V,
30A
/
12.2V, 30A
Mode 7
13.5V,
30A
13.5V,
30A
/
13.5V, 30A
Mode 1
29.4V,
15A max
/
Mode 2
28.2V,
15A max
/
Mode 3
28.2V,
15A max
29.4V,
1A max
Mode 4
28.2V,
1A
28.2V,
1A max
/
Mode 5
29.4V,
1A
29.4V,
1A max
/
Mode 6
24.5V,
15A
24.5V,
15A
/
24.5V, 15A
Mode 7
27V,
15A
27V,
15A
/
27V, 15A
14.7V, 30A 29.4V, 15A
30A
30A
15A
15A
/
/
/
/
/
/
**The above spec. ±0.5V for 12V spec.; ±1.0V for 24V spec.; Amp. ±10% is acceptable.
C-30-12 / C-15-24 specification
12

Model C-60-12 C-30-24
INPUT
OUTPUT
PROTECTION
ENVIRONMENT
SIZE
100 ~ 240VAC
45 ~ 65Hz
>=85%
1.0 at full load (+/-5%)
IEC plug
55°C±5°C (131°F±41°F)
YES
YES
YES
-15°C ~ +45°C (5°F ~ 113°F)
20 ~ 90% RH non-condensing
-30°C ~ +70°C (-22°F ~ +158°F) , 10 ~ 95% RH
±0.05%°C (0°C ~ 50°C/32°F ~122°F)
335 x 142 x 72mm
3.5kgs
13.5V, 2A max
180 ~ 600Ah (12V)
<1mA
YES ( 5A current output only)
27V, 1A max
90 ~ 300Ah (24V)
<1mA
YES ( 2.5A current output only)
Mode 1
14.7V,
60A max
/
Mode 2
14.1V,
60A max
/
Mode 3
14.1V,
60A max
14.7V,
2A max
Mode 4
14.1V,
2A
14.1V,
2A
max
/
Mode 5
14.7V,
2A
14.7V,
2A
max
/
Mode 6
12.2V,
60A
12.2V,
60A
/
12.2V, 60A
Mode 7
13.5V,
60A
13.5V,
60A
/
13.5V, 60A
Mode 1
29.4V,
30A max
/
Mode 2
28.2V,
30A max
/
Mode 3
28.2V,
30A max
29.4V,
1A max
Mode 4
28.2V,
1A
28.2V,
1A max
/
Mode 5
29.4V,
1A
29.4V,
1A max
/
Mode 6
24.5V,
30A
24.5V,
30A
/
24.5V, 30A
Mode 7
27V,
30A
27V,
30A
/
27V, 30A
14.7V, 60A 29.4V, 30A
60A
60A
30A
30A
/
/
/
/
/
/
Voltage range
Frequency range
Efficiency
Power factor
Input socket
Mode Selection
Bulk Stage
Absorption stage (I)
Absorption stage (II)
Float stage
Max. current output
Continuous current output
Recommended battery capacity
Leakage current from battery
Over temperature
Overload
Output short circuit
Microprocessor check
WORKING TEMP.
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
Dimension (L x W x H)
Weight
Sleeping Mode Function
13
Note: Specifications subject to change without notice.
**The above spec. ±0.5V for 12V spec.; ±1.0V for 24V spec.; Amp. ±10% is acceptable.
C-60-12 / C-30-24 specification

7.Charging Formula
( A ) . Charging Time
Formula
Example
Charging time will depend on the capacity of your battery and on how
deeply it is discharged. The following equation calculates an approximate
charging time.
Charging time =
where:
Charging Time: Battery recharge time in hours
CAP:
Battery capacity in amp-hours
DOD: Battery depth of discharge in per cent. A fully
discharged battery has 100% DOD
CC:
Charge current, the rated current output of the
charger in amperes
80%:
Typical charging efficiency forlead-acid batteries
A Group size battery rated at 100 amp-hours is 40% discharged, that is,
it has a DOD = 40. Charging time with a C-15L-12 unit is
calculated as follows:
Charging time = = 3.3 hours
CC x 80%
15A x 80%
100Ah x 40%
CAP x DOD
( B ) . Discharging Time
To achieve 50% cycling you should calculate your Amp-hour consumption between
charging cycles and use a battery bank with twice that capacity. To calculate Amp hour
consumption, first look at the rating plate on your AC appliance or tools.
Each appliance or tool will be rated in either AC Amps or AC watts or AC VA(Volts-Amps)
apparent power.
Use one of the following to calculate the DC Amp-hour draw for a 12 Volt system:
(AC Amps x 10) x 1.1 x hours of operation = DC Amp-hours
(AC watts/12) x 1.1 x hours of operation = DC Amp-hours
(AC VA/12) x 1.1 x hours of operation = DC Amp-hours
In all formulas, 1.1 is the factor for inverter/charger efficiency.
Calculate the above for every AC appliance or tool you intend to use on your inverter.
This will give you the total number of Amp-hours used between recharges. Size your battery
bank using this number as a guideline. A good rule to follow is to size the battery bank about
2 times larger than your total Amp-hour load requirement. Plan on recharging when 50% discharged.
Many electric motors have momentary starting requirements well above their operational rating.
Start up watts are listed where appropriate. Individual styles and brands of appliances may vary.
NOTICE: Lead-acid battery is recommended for inverter/charger models, also the LiFePO4 battery.
14
