PotteryBarn MADERA DAYBED WITH CANOPY User manual

Page 1 of 9
MADERA DAYBED WITH CANOPY
ASSEMBLY INSTRUCTIONS
Date: 2013-Dec.-03
Rev: -
www.potterybarn.com

Page 2 of 9
Important Safety Instru tions:
• Please read all instructions carefully before assembling.
• For your safety, assembly by t o or more adults is strongly recommended.
• Keep instructions for future use.
• Use only vendor supplied hard are to assemble. Using unauthorized hard are could jeopardize the structural
integrity of the item.
Pre-assembly:
• Remove all parts and hard are from the box and lay out on a clear carpeted or scratch-free ork surface, as this
ill avoid damaging parts during assembly. The shipping box provides an ideal ork surface.
• Do not dispose of any packaging or contents of the shipping carton until assembly is completed to avoid
accidentally discarding small parts or hard are.
• Use the parts and hard are lists belo to identify and separate each of the pieces included.
• The illustrations provided allo for easier assembly hen used in conjunction ith the assembly instructions.
• The use of po er tools to aid in assembly is not recommended. Po er tools can damage hard are and split ood.
Parts In luded:
(A) Top Cover Frame 1 pc
(B) Top Frame 1 pc
(C) Post 4 pcs
(D) Front & Back Frame 2 pcs
(E) Left & Right Side Frame 2 pcs
(F) Center Support 1 pc
(G) Main Frame 1 pc
(H) Finial 1 pc
(I) Canopy 1 pc
(J) Curtain 8 pcs
(K) Cushion 1 pc
A
B
E
D
F
G
H
I
J
K
C Left
C Right

Page 3 of 9
Hardware In luded:
(
L
)
Short Allen Bolt
M6 x 40 mm
(
M
)
Long Allen Bolt
M6 x 60 mm
8x
2
3
x
Tools Required :
Allen Key 1x (included)
Assembly Instru tion Steps:
1. Assemble 2 pcs of Post (C) to the ight Side Frame (E)and 2 pcs of Post (C) to the Left Side Frame(E). (See Fig. 1).
Insert 4 pcs Long Allen Bolts (M) on each side frames, and tighten ith the supplied Allen Key. (See Fig.1), Detail 1.
Fig. 1
M
Detail 1
E
E
C Left
C Left
C Right
C Right
C Left
C Left

Page 4 of 9
2. Assemble Left & Right Side Frames (E) to the Front & Back Frame (D). (See Fig. 2).
3. Insert 4 pcs Long Allen Bolts (M) to assemble the Front Frame (D) & 4 pcs Allen Bolts (M) to assemble the Back
Frame (D). Tighten ith the supplied Allen Key (See Fig. 3) Detail 1.
Fig. 2
D
M
Fig. 3
D
D
D E
E
C Left
C Left
C Right
C Right
C Right
C Right
C Left
C Left
Detail 1

Page 5 of 9
Fig.4
4. Assemble the Center Support (F) to the Left & Right Side Frames (E) as sho n on Fig. 4.
Insert 2 pcs of Long Allen Bolts (M) and tighten ith the supplied Allen Key. See Fig.4, detail 1.
5. Lay the Cushion (K) on the Main Frame (G) (See Fig. 5).
From under the Main Frame (G) secure the Velcro through the slats of the Main Frame (G). (See Fig. 5) Detail 1 &
2
F
Fig. 5
D
D E
E
M
Detail 1
C Right
C Right
C Left
C Left
K
G
Detail 1
Detail 2

Page 6 of 9
6. Lay the Main Frame (G) and the Cushion (K) as sho n on Fig. 6
7. Assemble the Top Cover Frame (A) to the Top Frame (B) as sho n on Fig. 7.
Fig. 7
A
B
K C Right
C Right
C Left
C Left
Fig. 6

Page 7 of 9
8. From underneath, insert 8 pcs Short Allen Bolts (L). Tighten ith the supplied Allen Key. (See Fig.8) Detail 1
Assemble the center pole using 1 pc Long Allen Bolt (M). Tighten ith the supplied Allen Key. (See Fig.8) Detail 2
9. Wrap the Canopy (I) to the Top Frame assembly. Pull the straps located under the canopy on all edges and secure
the Velcro through the frames. (See Fig. 9) Detail 1 & 2.
Detail 1
Detail 2
Fig. 8
Fig. 9
Detail 2
L
M
I
Detail 1

Page 8 of 9
10. Assemble the Finial (H) by turning to the center pole of the top frame. (See Fig. 10) Detail 1.
11. Assemble the top frame ith canopy to the post. (See Fig. 11). Insert 4 pcs Long Allen Bolts (M) into the holes on
the corners, and tighten ith the supplied Allen Key. (See Fig 11) Detail 1.
Detail 1
Fig. 10
Detail 1
H
M
Fig.
11

Page 9 of 9
12. Attach 8 pcs Curtains (J) to each sides of Daybed as sho n on Fig.12.
Secure the Velcro to the rail of the Top Frame (B). See Fig. 12 Detail 1
Secure the Curtain (J) to the Post (C). See Fig. 12 Detail 2.
Assembly is complete !.
Care Instru tions:
• Dust often using a clean, soft, dry and lint-free cloth.
• Blot spills immediately and ipe ith a clean, damp, cloth.
• To protect the furniture from spills, al ays use coasters.
• We do not recommend the use of chemical cleansers, abrasives or furniture polish on our lacquered finish.
• Hard are may loosen over time. Periodically check to make sure all connections are tight.
• Re-tighten if necessary.
Fig. 12
Thank you for your purchase
Stores | catalog | www.potterybarn.com
Detail 1
Detail 2
J
