HAMPTON WALL SHELF
Mounting Instructions
Note:
For safe mounting, it is essential to use the proper hardware for your wall type.
Contact your local hardware store for assistance if necessary. For your safety and
ease, installation by two people is strongly recommended.
Mount to wood studs whenever possible. Use a stud finder to locate stud in mounting
positions. If mounting locations align with stud, use stud mounting screws. If there
is no stud, toggle anchors and toggle screws should be used.
Mounting Instructions: (Illustration 1)
1. Hold cabinet at desired location. With a pencil, mark on the wall the top outside
corners. These marks will be used to determine the location of the mounting
hardware.
2. Measure down from the top of the cabinet to the top of both keyhole notches. Record
these measurements on the wall, using the marks in step one as guide.
3. Measure in from the side of the cabinet to the top of both keyhole notches. Again,
record these measurements on the wall. Align the two measurements until they
intersect. This is the insertion point of your mounting hardware. Use a carpenter’s
level to ensure the cabinet will be level.
Dry Wall Mounting
4. Place a #2 Phillips screwdriver into recess of the toggle anchor. Do not “push”
the anchor. It is designed to bore into the wall like a drill bit. Slowly turn
the anchor clockwise while applying pressure until the flange just touches the
wall. Keep turning clockwise until one arrow on head is pointing to the 12 o’clock
position. Insert toggle screw into toggle anchor turning clockwise. You will feel
a slight resistance. Continue turning screw until the screw head touches the
anchors flange. Tighten screw until it becomes difficult to turn. At this point
the internal pivot will have engaged the backside of the dry wall. Leave
approximately ½” between the back of the screw head and the wall.
5. Mount cabinet by fitting the lower hole of keyhole slots over screw heads and down
until the top of the keyhole slots rest on the screws. You may need to tighten
or loosen screws slightly to allow cabinet to fit snugly against wall.
Stud Mounting
6. Insert stud mounting screws into wall using Phillips screwdriver or drill. Leave
approximately ½” between the back of the screw head and the wall. Mount cabinet
as in step 5 above.
Plastic Plugs Installation: (Illustration 2)
7. Insert plastic plugs (D) into screw holes on the cabinet. Push in with index finger.

Illustration
Hardware Included:
(2) Toggle Anchor (A) (2) Toggle Screw
(B)
for dry wall mounting
(2) Stud Mounting Screw (C) (2) Plastic Plugs
(D)
Care Instructions:
Wipe with a soft, dry cloth. To protect the
finish, do not apply household cleaners or
abrasives.
Illustration
1
