PotteryBarn LOGAN DESK User manual


Date:22‐Oct‐15www.potterybarn.com  Page1of8
Rev:  














(NOTE: This product comes with only 1 shelf that is adjustable – please refer
to Assembly Instruction)
LOGAN DESK


Date:22‐Oct‐15www.potterybarn.com  Page2of8
Rev:  


Important Safety Instructions:
Please read all instructions carefully before assembling.
For your safety, assembly by two or more adults is strongly recommended.
Keep instructions for future use.
Use only vendor supplied hardware to assemble. Using unauthorized hardware could jeopardize the structural
integrity of the item.
Pre-assembly:
Remove all parts and hardware from the box and lay out on a clear carpeted or scratch-free work surface, as
this will avoid damaging parts during assembly. The shipping box provides an ideal work surface.
Do not dispose of any packaging or contents of the shipping carton until assembly is completed to avoid
accidentally discarding small parts or hardware.
Use the parts and hardware lists below to identify and separate each of the pieces included.
The illustrations provided allow for easier assembly when used in conjunction with the assembly instructions.
The use of power tools to aid in assembly is not recommended. Power tools can damage hardware and split
wood.
This Logan desk can be assembled with other Logan components to setup as the Home Office Suite.
Parts Included:
Box 1
(1) Desktop
Box 2
(1) Left pedestal (with 2 drawers)
Box 3
(1) Right pedestal (with a drawer and a door)
Hardware Included:
Box 1 (a)
Bolt
Dia. 8mm x 38mm
(b)
Lock Washer
diam 8mm x 1.8mm
(c)
Flat Washer
diam 8mm x 2mm
(d)
Allen key
5mm thick
4x4x4x1x
Box 2 (e)
Allen key
4mm thick
1x
Box 3 (e)
Allen key
4mm thick
1x
(1) Anti-tip kit
Tools Required (not included):
Phillips head screwdrivers
Flat head screwdriver
Drill


Date:22‐Oct‐15www.potterybarn.com  Page3of8
Rev:  


Assembly Instruction Steps:
1. Set the file cabinet on the left and the CPU cabinet on the right. Remove the drawers of both cabinets by
pressing the plastic locks on the side drawer slides upwards and downwards as shown while pulling drawers
out.

2. Gently rest the desktop onto the base cabinets. Align the pre-drilled holes in top rails of the bases with the
pre-drilled holes underneath the desktop. Secure them with the bolts (a), lock washers (b) and flat washers (c)
and tighten with the enclosedAllen key 5mm (d).
c
b
a
d
File
Cabinet
CPU
Cabinet


Date:22‐Oct‐15www.potterybarn.com  Page4of8
Rev:  


3. Adjusting the levelers:
Due to an uneven floor, the furniture may not sit level due causing it to wobble. If the furniture wobbles, determine
which corner does not touch the ground correctly. With two people follow these steps:
1) Adjust the levelers using the Allen key 4mm (e) on the interior holes of the bases until adequate contact will
be made with the floor. Gently set down the piece and check stability and door alignment.
2) Repeat steps until furniture sits firmly and the doors are properly aligned.
4. Desk assembly is complete.
To setup as the Full Office Suite, follow the steps 5-7:
5. Bore holes should be made on the exterior side panels of the desk. Using the pilot holes as a guide, bore holes
on the sides using a drill with the 5mm drill bit (enclosed in the hardware pack of the base, see separate base
instructions).
Drill
Drill
d
e


Date:22‐Oct‐15www.potterybarn.com  Page5of8
Rev:  


6. Align the holes on the side panels of the desk with the bored holes on the sides of the bases. Insert the sleeves
(enclosed in the hardware pack of the base) into the hole and secure with the connecting screws (enclosed in
the hardware pack of the base) on the other end by tightening and threading the sleeve using Phillips head
screwdrivers.
7. Set the hutches and bridge onto the bases using the hutch and bridge assembly instructions.
8. Fully extend the slides on the cabinet cases. Align these with the slides on the drawer boxes and install the
drawers back onto the desk.
Side
panels
! WARNING
These drawers are equipped with Anti-Tilt
guards which prevent both drawers being
pulled out at the same time. Only one
drawer can be open at a time to prevent
the cabinet from tipping over.
DO NOT REMOVE THIS LABEL


Date:22‐Oct‐15www.potterybarn.com  Page6of8
Rev:  


9. The wooden adjustable shelves were attached to the shelf supports to prevent damage during shipping. To
change the position of a shelf, first remove the screws from the bottom of the shelf supports. Remove the shelf
and relocate the shelf supports to another set of pre-bored holes. Gently rest the shelf on to the shelf pin and
re-insert screws.
10. Once the assembled unit is moved into its final location, install included anti-tip kit (see separate instructions).
11. If the furniture still wobbles, adjust the levelers through the holes at the four corners of the base with the Allen
key 4mm (e).
d
e


Date:22‐Oct‐15www.potterybarn.com  Page7of8
Rev:  


12. Assembly is complete.
NOTE: USE THE ANTI-TIP KIT PROVIDED TO SAFELY SECURE YOUR PRODUCT(S). FOLLOW THE
INSTRUCTIONS PROVIDED TO PREVENT SERIOUS INJURY FROM TIPPING FURNITURE.
Care Instructions:
Dust often using a clean, soft, dry and lint-free cloth.
Blot spills immediately and wipe with a clean, damp, cloth.
We do not recommend the use of chemical cleansers, abrasives or furniture polish on our lacquered finish.
Hardware may loosen over time. Periodically check to make sure all connections are tight.
Re-tighten if necessary.
