PotteryBarn Modular Wall Storage Open Cubby User manual

Modular Wall Storage Open Cubby
Page 1of 3
Note: Professional installation required
Important safety instructions:
Please read all instructions carefully before assembling. For your safety, assembly by two people is recommended.
The maximum individual shelf weight capacity is 10lbs. Do not exceed the load capacity.
This hanging system is meant for drywall/stud mounting only.
If walls are concrete, brick or plaster, please consult your local hardware store for assistance.
For safety, installation by two people is recommended.
Tool Required (Not Included):
Stud Finder Phillips Screwdriver Pencil
Parts Included:
(1) Wooden Cabinet - A (1) Wall rail–B (2) Wooden Shelf –C
Hardware Included :
(3)Toggle -a (3) Toggle Screw -b (1) Wood Screw) –c(1) Wooden plug - d
(8) L-shape pegs -e
Pre-Assembly:
Remove all parts and hardware from the box and lay out on a clear workspace, along with any plastic protective
packaging. Do not dispose of any contents until assembly is complete to avoid accidentally discarding small parts or
hardware.
Use the parts and hardware lists above to identify and separate each of the pieces included.
The illustrations provided allow for easier assembly when used in conjunction with the assembly instructions.

Modular Wall Storage Open Cubby
Page 2of 3
MOUNT WALL RAIL TO THE WALL (See Figure 1)
1. Find wall studs and determine the desired placement on the wall for the product. Position the wall rail (B) on the
wall and adjust so that the rail is level. It is better to mount the wall rail to at least (1) stud. Then, use a felt-tipped
pen to mark the wall through the three pre-drilled holes of the rail to indicate the locations of the drywall toggles.
2. Drill the holes at the marked places on the wall. Then use a manual screwdriver, drive two toggle (a) into the
drywall at the marks on the left and right. To install these toggle (a) into the wall, simply rotate them at the marked
location as if they were a large screw, applying smooth even force. DO NOT HIT THEM WITH A HAMMER AND
DO NOT USE A POWER DRILL TO ROTATE THEM. These toggles are designed to bore themselves into the wall.
Continue rotating until the toggle head advances flush with the wall surface.
3. Once the toggles (a) are installed into the wall at the marked locations, reposition the wall rail (B) so that the marked
holes of the rail align with the toggles. Using the supplied toggle screw (b) secure the rail (B) to the installed toggles
(a). Note: Tighten toggle screw flush with item, the screw pops open the Toggle, this reinforces the wall and
increasing its holding power significantly.
4. Screw the wood screw(c) into the wall through the middle hole of wall rail.
5. HANG THE PRODUCT ONTO THE MOUNTED WALL RAIL
1. On the back of your product is one affixed product-mounting rail. See Figure 2.
2. Carefully position the product-mounting rail slightly above and against the wall mount rail, insuring that the two
rails are aligned. Engage the two rails.
3. Make a remark for Toggle (a) on the wall through the hole on back bottom rail with pencil. Then take off the
cabinet (A) from the wall. Drill hole on the remark and use Phillips Screwdriver to insert the Toggle (a) on the
pre-drilled hole. Do not “push” or drive the anchor into the wall. Slowly turn the Toggle clockwise while
applying pressure until the flange just touches the wall. If using a power drill, use caution as the hardware can
strip. Re-hang the cabinet (A) onto the mounted wall bracket, inseart the Toggle screw (b) through the back
panel bottom hole , screw it to the installed toggles (a). Cover the screw hole with wooden plug (d).
c
Figure 1

Modular Wall Storage Open Cubby
Page 3of 3
Assembly Instructions:
1. On the inside of the cabinet, insert the L-shape pegs (e) into the pre-drilled holes on the interior side of the wooden
cabinet (A) to set each shelf at a desired level –FOUR per shelf. Once all four pegs (e) are in position, gently place
wooden shelf (C) onto the L-shape pegs (e). Repeat for the other shelves. See Figure 3.
Care Instructions:
Wipe cabinet with a soft, dry cloth.
To protect the finish, avoid the use of all chemical and household cleaners and abrasives as they may damage finish.
thank you for your purchase
Stores/catalog/www.potterybarn.com
d
b
e
C
C
Figure 3
Figure 2
A
e
A
e
B
e
A
e
