Powdeom EN700Q User manual

22 0
HOURS
OUTPUT
AC DC USB-A USB-C
60Hz
W

1、 Cautions
1
To protect you and others from harm and the product from damage, please read
the manual carefully before using the product
1.About storage
Do not expose the product to an extreme cold or hot environment
(below -0°C or above 40°C) for storage;
Do not place the product near the vent of a heating device;
Please avoid putting the product in a rainy or wet environment;
Please keep it away from flammable liquids, gases or explosive materials;
Please keep it away from dust or a dusty environment;
Do not store the product with coins, jewelry, keys and other metal objects;
otherwise, it will damage the product, reduce the charging capacity,
shorten the service life, or even explode. The product should be stored in a
cool and dry environment.
2.About Charger
Do not use a defective charger or a charger of mismatched output voltage;
Please use the original charger, as incompatible or unqualified chargers
may cause danger or damage the product;
Do not use chargers without safety certification to charge the product.
3.About storage of leaving unused
Please make sure to charge it at least once every 6 months to extend the life
of the product (battery cells). When taking out the product after long-term
storage, please fully charge it before use. When the product charger is not
in use, the power must be disconnected at both ends.
4.About disposal of defective\old battery and charger
Please dispose of scrapped products in accordance with regulations, and
do not dispose the built-in batteries as domestic garbage to avoid explosion
and pollution.
5.Do not squeeze or pierce the product, and do not subject the product to
high external pressure, otherwise it may cause internal short-circuit,
overheating, burning or explosion.
6.Do not place this product in the reach of people with low physiology,
perception, and mentality (including children)and people without
experience and related knowledge. Avoid the above people from using
this product to avoid misuse.

2
7.The product cannot be used as a substitute for the mains AC power supply
in order to extend the cycle life of the battery cells.
8.Do not paint or paste paper on this product. Paint and stickers may block
the equipment parts and affect normal use.
9.About the environment temperature for charging.
Do not store the product in hot or cold places, please use the product in an
environment of 0~60°C;
The temperature inside a closed car in summer can be as high as 80°C
(putting the product in a car may put you or your car in danger.)
Do not directly expose the product to sunlight for a long time, since when
the heat dissipation is not started, the temperature of the battery cells will
rise sharply. When charging the product, the operating temperature should
be between 0°C~40°C.
Do not store the product near or inside water heaters, microwave ovens,
hot cooking products, or high and low pressure parts. The product may
overheat and cause fire.
10.About product cleaning
Use a dry towel or eraser to wipe the product or charger.
Do not use corrosive chemicals or cleaner.
11.Please do not disassemble, repair or modify the product, otherwise
warranty will be invalid.

3
2、 Operation Cautions
1. When using this product for the first time, due to low-power
transportation, the actual power level may not match with the power
indicator, please charge and discharge the product for 2-3 recycles and
it will be back to normal.
2. When using this product, please do not cover it with towels, clothing, etc.,
and make sure to keep more than 10cm of heat dissipation space around
the product.
3. Please keep the product and electrical products dry to prevent moisture
and liquid from entering the product, otherwise it may damage the
internal parts or circuits of the device.
Do not turn on the product when it is wet, if the product is already turned
on, please turn it off immediately.(If the product cannot be shut down, let
it be and contact the after-sales service center immediately.)
4. Do not use the product in an environment where dust or dusty substances
are concentrated, which may cause product failure, fire or explosion.
5. Do not use the product in flammable and explosive environments such
as gasoline, gas, chemical agents, mines, etc., otherwise it may endanger
safety Always operate in accordance with regulations, instructions and
signs in potentially explosive environments.
6. Do not use the product in a corrosive environment, otherwise it will
cause damage to the product.
7. Do not use the product during thunderstorms. The product may
malfunction and increase the risk of lightning strikes.
8. Please place the product on a flat surface to prevent the product from
falling, otherwise it may damage the product or cause parts failure.
9. About recharging the product
Please use Yoobao original charger to charge the product.
Do not exceed the charging time of this product. Please unplug the charger
when fully charged. It is recommended to charge during the day or when
someone is present for easy inspection.
Due to energy conversion during charging, this product may heat up. This
is a normal phenomenon. Please be careful when handling.
10.About the discharge of the product
After discharging the product, when the remaining power is the last one or
the indicator flashes, stop using it immediately and fully charge it before
using it, which can extend the battery life.

4
NO Packaging List Type
EN700Q Standard
Standard
1
2Adapter
Standard
3
4
Car charge connetor to DC cable
Standard
Manual
The contents will be different according to the needs of different
regions. Please contact with Yoobao service center if you have any
question.
3、 Package contents
EN700Q is a multi-functional emergency energy storage power
supply. It adopts UL authorized automobile power cell and efficient
SPWM inverter conversion technology. It is more durable and has
longer cycle life than ordinary battery cell. It enjoys the reputation
of "outdoor mobile power station". It is widely used in outdoor party
and camping, household emergency, outdoor live broadcasting,
mobile office, medical rescue, emergency rescue, power equipment
repair, communication emergency and other fields. It is compatible
with most of digital appliances and household appliance of power
rate under 700W.
4、 Product Introduction
22
0
HOURS
OUTPUT
AC DC USB-A USB-C
60Hz
W

5
5、 Specification
6、 Structure and functions
Power Button
DC Input
DC Output DC2
LED Light
USB Output A1
Car Charger Socket
USB Output A2
LED Screen Display AC Power
Indicator Light
DC Power
Indicator Light
DC Output DC1
AC Output Socket
AC Output Socket
Type-C Output C1
LED Button
Specification
Model
AC Output*2
Battery Capacity
AC Input
Type-C1 Output
DC5521 Input
USB-A1 Output
USB-A2 Output
DC5521+Car Charger
Socket
Charging Temperature
EN700Q
AC 700W 220V-240V~50Hz /100V-120V~60Hz（Pure Sine Wave）
192000mAh/25.6V（Lithium Iron Phosphate）
500W（ 220V-240V~50Hz /100V-110V~60Hz ）
DC 5V3A/9V3A/12V3A/15V3A/20V5A (PD 100W)
12V-28V5A（Max 120W）
DC 5V2.4A
DC 5V2.4A
DC 12V10A
0℃-50℃
USB A1+A2 Output
Power of Light
Standard
Dimension
Weight
Discharging Temperature
DC 5V3A （Max）
3W
GB 31241-2014
305x200x210mm (About)
8.1Kg (About)
-5℃-65℃
Battery Power 614.4Wh
5
5、 Specification
6、 Structure and functions
Power Button
DC Input
DC Output DC2
LED Light
USB Output A1
Car Charger Socket
USB Output A2
LED Screen Display AC Power
Indicator Light
DC Power
Indicator Light
DC Output DC1
AC Output Socket
AC Output Socket
Type-C Output C1
LED Button
Specification
Model
AC Output*2
Battery Capacity
AC Input
Type-C1 Output
DC5521 Input
USB-A1 Output
USB-A2 Output
DC5521+Car Charger
Socket
Charging Temperature
EN700Q
AC 700W 220V-240V~50Hz /100V-120V~60Hz（Pure Sine Wave）
192000mAh/25.6V（Lithium Iron Phosphate）
500W（ 220V-240V~50Hz /100V-120V~60Hz ）
DC 5V3A/9V3A/12V3A/15V3A/20V5A (PD 100W)
12V-28V5A（Max 120W）
DC 5V2.4A
DC 5V2.4A
DC 12V10A
0℃-50℃
USB A1+A2 Output
Power of Light
Standard
Dimension
Weight
Discharging Temperature
DC 5V3A （Max）
3W
GB 31241-2014
305x200x210mm (About)
8.1Kg (About)
-5℃-65℃
Battery Power 614.4Wh

Battery Symbol
Remaining Power
Percentage
Remaining Usage Time
Only for reference
(hours, minutes)
Long-range Light is on
(short press to turn on)
Real-time DC Output
Power Rate(W)
Real-time USB Output
Power Rate(W)
Real-time AC Output
Power Rate(W)
EN700P Screen
6
22 0
HOURS
OUTPUT
AC DC USB-A USB-C
60Hz
W
AC Input Heat Dissipation Vent

7
7、 How to charge the product
Please read the following notes first:
Accessories are only equipped. When using solor panel to charge, it is
advised to use 100W to achieve higher charging efficiency. with this product.
It is forbidden to use on other electrical appliances.The product is fully
charged when the power indicator stop flashing and stay on. Please stop
charging and unplug the power cord from the AC socket.
We can charge the product in the following four ways:
1. Use the adapter to charge. Plug the adapter pin to the AC power
and connect the other end of the cable to the "DC5521 IN" to charge
the product.
2. Charging with solar panel. Connect one end of the cable to the solar
panel (solar panel needs to be purchased separately), and insert the
other end into the DC input "DC5521 IN" interface of the product to
charge the product (It is recommended to buy solar panels specially
designed for this product).
22
0
HOURS
OUTPUT
AC DC USB-A USB-C
60Hz
W
22
0
HOURS
OUTPUT
AC DC USB-A USB-C
60Hz
W

8
3. Charge with a cable with car charger plug connect the car charger plug to
the cigarette lighter and the other end to DC input “DC5521 IN” interface of
the power station.
22
0
HOURS
OUTPUT
AC DC USB-A USB-C
60Hz
W

AC Output Socket 9
Please read following cautions before use:
Please ensure that the input voltage and frequency of electrical equipment
are consistent with the parameters of this product.
Please ensure that the rated power of electrical equipment is less than
700W, preferably within 80% power range.
If the rated power of electrical equipment is higher than 700W, the overload
protection may be activated.
If the power of electrical equipment is higher than the rated power of 700W,
please choose Yoobao portable power supply with higher power.
The instantaneous power of some electrical equipment is greater than its
rated power. For example, the starting power of inductive load equipment
is generally 3-8 times of a certain rated power, and the starting power of
energy-saving lamp is dozens of times of its rated power. The above
situation does not rule out the possibility of activating the overload
protection of this product and turning off the power supply.
Steps of using the AC output
Step 1: Turn it on with the AC button and the indictor will be on. Remaining power
can be seen on LED screen.
8、 How to use the AC output
Step 2: Check whether the input voltage and frequency is compatible with
the product.
Step 3: Make sure the power rate is under the rated power rate of this product.
Step 4: Connect the appliance to the AC output.
AC Power Button
AC

10
Step 5: Turn it o with the AC button and pull out the appliance plug when stop using.
Step 6: Please recharge it if it is of low battery or out of battery.
Note:
To avoid power loss, please turn it off with the AC button when you are not
using AC port.
Since different countries have different plug type and voltage standards, to
avoid danger, please carefully check if the appliance is compatible with the
product.
9、 How to use the DC output
When using DC output(include USB-A output, DC output, Type-C PD 100W
output), please ensure that the digital device support the current of the
corresponding output port, so as to prevent the interface from overheating
and causing damage to the device.
1. Use USB ports to charge digital devices
2 ways to use USB output:
USB-A QC3.0: the orange USB-A can provide QC3.0 quick charge, it will need a cable
supporting QC3.0 protocol to connect power station and the digital
devices. Long press the DC button and the power station will charge
the digital devices quickly.
USB-C: USB-C output interface, also known as Type-C, can provide PD fast charging
and the output power is 100W. It will need a cable supporting PD protocol to
connect power station and the digital devices. Long press the DC button and
the power station will charge the digital devices quickly.
2. Use DC output to power appliances
Long press DC button, the DC indicator light will be on and two DC ports start to
provide power at voltage 12V and total current 6A. Connect to the DC output
to power appliances. Long press the DC button again, the DC indicator will be o
and the power will be cut. This DC output can provide power to DC fan and LED
lights etc.
When you are not using DC output, please turn it off with the DC button,
otherwise the remaining power will be consumed by itself.

Long-range
Lamp Button
11
11、 After-sales services
The product has a built-in flashlight.
1. Strong LED reading light, short-press the switch to turn it on and switch
the modes of luminance: soft→normal→strong
2. Outddor searchlight, short-press the switch to turn it on and switch the
modes: lighting mode→SOS signal mode→OFF
Please don't use the flashlight directly point to eyes to avoid the damage
from strong light.
To ensure your legal right, please pay attention to:
1. The warranty card must be sealed by the seller before it can take effect.
2. The warranty card shall be properly kept by the user. If it is lost or altered,
it will be invalid.
3. In case of any failure caused by non-human reasons, you can take the
warranty card to the designated repair center for free repair within the
warranty period.
4. Free maintenance service will be unavailable under the following
circumstances even within the warranty period:
You will no longer enjoy the warranty if you disassemble, refit or repair the product
without permission;
Damage of surface coating and appearance is not within the scope of warranty;
Failure caused by incorrect installation, packaging and use which is not in
accordance with the requirements of the user manual;
Failure or damage caused by accidental, man-made reasons or environment and
other factors (wrong operation, collision, unreasonable voltage, damp, etc.);
10、Steps to use flashlight

12
Toxic and hazardous substances or elements
Polybrominated
Diphenyl Ether
Polybrominated
biphenyls
chromium
cadmium
mercuryLead
0:means that the content of the hazardous substance in all
homogeneous materials of the component is below the limit
requirement specified in the 2002/95/EC (ROHS) standard
0 0 0 0 0 0
12、 Name and content of toxic and hazardous
substances or elements in the product
Failure or damage caused by force majeure like earthquake, fire disaster, tsunami
Product packaging box and accessories are not within the scope of warranty
If your product has expired the warranty period, we oer compensated
repair service.
Warning
AC socket is for output only, no input!
Do not disassemble, soak in water or
leave in fire!
