Power Electronics Ford Pro Standalone NB 240 User manual

NB 240
EV CHARGING SOLUTIONS
Hardware and Installation Manual
Edition: May 2022
NB240HW01BI Rev. B

NB 240
POWER ELECTRONICS
2
ABOUT
ABOUT THIS MANUAL
PURPOSE
This manual contains important instructions for the installation, configuration and use of the electric vehicle
charger Standalone NB 240, which manages the power transformation and main control for the charge.
From now on, this manual refers to Standalone NB 240 with the term “equipment” or “charger”.
Please notice the NB 240 range includes the chargers NB 150 / NB 180 / NB 210.
Power Electronics reserves the right to modify product features.
TARGET AUDIENCE
This manual is intended for qualified customers who will install, configure and operate the NB 240
chargers.
Only qualified technical personnel validated by Power Electronics may install and start up the equipment.
POWER ELECTRONICS CONTACT INFORMATION
Power Electronics USA Inc.
1510 N. Hobson Street, Gilbert,
Phoenix
AZ 85233
UNITED STATES OF AMERICA
US Sales: 602-354-4890 / [phone]
Power Electronics España, S.L.
Polígono Industrial Carrases
Ronda del Camp d’Aviació nº 4
46160, Llíria (Valencia)
SPAIN
Tel: [phone] / Fax: [phone]
Website: www.power-electronics.com

POWER ELECTRONICS
NB 240
REVISIONS
3
REVISIONS CONTROL
DATE (DD/MM/YYYY)
REVISION
DESCRIPTION
17 / 01 / 2022
A
First edition.
26 / 05 / 2022
B
Technical characteristics. Handling and transportation. Preparation for
installing the equipment. Cable access and connections.
Communications. Maintenance. Misprints correction.
The equipment and technical documentation are periodically updated. Power Electronics reserves the right to modify all or part of the
contents of this manual without previous notice. To consult the most updated information on this product, you may access our website
www.power-electronics.com, where the latest version of this manual can be downloaded. The reproduction or distribution of the
present manual is strictly forbidden unless express authorization from Power Electronics.

NB 240
POWER ELECTRONICS
4
TABLE OF CONTENTS
TABLE OF CONTENTS
ABOUT THIS MANUAL ...............................................................................................................................2
ACRONYMS.................................................................................................................................................6
SAFETY SYMBOLS.....................................................................................................................................8
SAFETY INSTRUCTIONS............................................................................................................................9
TORQUE AND SCREW SIZING.................................................................................................................15
INTRODUCTION...................................................................................................................................16
Equipment overview...........................................................................................................................17
Charging process ...............................................................................................................................19
Advanced charge functionality............................................................................................................20
Open door detection...........................................................................................................................20
Power retrofit (optional)......................................................................................................................21
Regulatory framework ........................................................................................................................21
TECHNICAL CHARACTERISTICS ......................................................................................................22
Standalone NB 240 –IEC / UL...........................................................................................................22
Standalone NB 240 –IEC / UL Slim and Cooled additional Dispenser ..............................................24
DIMENSIONS AND WEIGHT................................................................................................................25
HANDLING AND TRANSPORTATION ................................................................................................27
Reception...........................................................................................................................................27
Standard storage................................................................................................................................27
Extended storage ...............................................................................................................................28
Unpackaging ......................................................................................................................................28
Handling and transportation ...............................................................................................................28
PREPARATION FOR INSTALLING THE EQUIPMENT.......................................................................31
Site recommendations........................................................................................................................31
Minimum working distances ...............................................................................................................33
Hose maneuverability.........................................................................................................................34
Anchoring of the equipment................................................................................................................35
Ventilation system ..............................................................................................................................36
CABLE ACCESS AND CONNECTIONS..............................................................................................37
Access................................................................................................................................................38
Connections .......................................................................................................................................40
PROTECTIONS ....................................................................................................................................49
Insulation monitoring ..........................................................................................................................49
Overcurrent and short circuit protection..............................................................................................49
Overvoltage protection (optional)........................................................................................................49
Residual current protections (RCD) (optional)....................................................................................49

POWER ELECTRONICS
NB 240
TABLE OF CONTENTS
5
INTERFACE..........................................................................................................................................51
Controls..............................................................................................................................................51
LED indicators....................................................................................................................................51
COMMUNICATIONS.............................................................................................................................52
Ethernet communication.....................................................................................................................53
Optical fiber communication ...............................................................................................................53
Wi-Fi communication..........................................................................................................................53
3G / 4G communication......................................................................................................................54
LOTO PROCEDURE ............................................................................................................................55
Equipment statuses............................................................................................................................56
LOTO actions .....................................................................................................................................57
Check points for absence of voltage...................................................................................................59
COMMISSIONING ................................................................................................................................60
SAFE STOP..........................................................................................................................................62
EMERGENCY STOP AND RESTART..................................................................................................63
MAINTENANCE....................................................................................................................................64
Equipment statuses............................................................................................................................64
Checklist.............................................................................................................................................65
Power revision (status 1)....................................................................................................................66
Dead revision (status 2)......................................................................................................................67

NB 240
POWER ELECTRONICS
6
ACRONYMS
ACRONYMS
The terms commonly used in the documentation of Power Electronics’ products are listed in the table
below.
Please notice this is a general series of terms and it encompasses all our product divisions (industrial,
solar, storage, and electric mobility), thus, some of the following expressions may not apply to this
particular manual.
ACRONYM
MEANING
AASS
Auxiliary Services
AC
Alternating Current
AI
Analogue Input
AO
Analogue Output
BESS
Battery Energy Storage System
BMS
Battery Manager Solution
CCID
Charge circuit interrupting device
CCL
Charge Current Limit.
CCS
Combined charging system –charging and communications protocol following the standard IEC
61851-23 Annex CC
CHAdeMO
Charging and communications protocol following the standard IEC 61851-23 Annex AA
CPU
Central Processing Unit
DC
Direct Current
DCL
Discharge Current Limit
DI
Digital Input
DSP
Digital Signal Processor
DO
Digital Output
EMS
Energy Management System
EV
Electric Vehicle
FPGA
Programmable device (Field-Programmable Gate Array)
FRU
Field Replaceable Unit
GFDI
Ground Fault Detector Interrupter
GPRS
General Packet Radio Services, a data transmission system
HVAC
Heating, Ventilation, and Air Conditioning
IGBT
Insulated Gate Bipolar Transistor
IMI
Insulation monitoring device
IT
Grid system where the power supply is kept isolated and the electrical equipment system is
grounded.
LOTO
Lock Out –Tag Out
MCB
Miniature Circuit Breaker
MCCB
Moulded Case Circuit Braker
MPCS
Multi Power Conversion System
MID
Measuring Instrument Directive
MV
Medium Voltage. This term is used to refer to high voltage in general
PE
Ground connection
PI
Proportional and Integral
POI
Point Of Interconnection
PPE
Personal Protection Equipment

POWER ELECTRONICS
NB 240
ACRONYMS
7
ACRONYM
MEANING
PV
Photovoltaic energy
RCD
Residual Current Device
RCM
Residual Current Monitor
RFID
Radio Frequency Identification
SOC
State Of Charge –referred to battery
SOH
State Of Health –referred to battery. It compares the actual state of the battery to its initial
conditions. It is measured in percentage
STO
Safe Torque Off
TN
Grid system where the power supply is grounded, and the electrical equipment system is brought
to the same ground through the neutral connector.
TT
Grid system where both the power supply and the electrical devices are connected to the ground
via separate connections
UPS
Uninterruptible Power Supply
VSD / VFD
Variable Speed Drive, Variable Frequency Drive. Both terms are used

NB 240
POWER ELECTRONICS
8
SAFETY SYMBOLS
SAFETY SYMBOLS
Always follow safety instructions to prevent accidents and potential hazards from occurring.
In this manual, safety messages are classified as follows:
Other symbols used in this manual for safety messages are the following:
WARNING
Identifies potentially hazardous situations where dangerous voltage may be
present, which if not avoided, could result in minor personal injury, serious
injury or death.
Be extremely careful and follow the instructions to avoid the risk of electrical
shocks.
CAUTION
Identifies potentially hazardous situations, which if not avoided, could result
in product damage, or minor or moderate personal injury.
Read the message and follow the instructions carefully.
NOTICE
Identifies important measures to take in order to prevent damage equipment
and warranty lost, as well as encouraging good use and environmental
practices.
Hot surface. Be careful and follow the instructions to avoid burns and personal injuries.
Risk of fire. Be careful and follow the instructions to prevent causing an unintentional fire.
Caution, risk of electric shock. Energy storage timed discharge. Wait for the indicated
time to avoid electrical hazards.

POWER ELECTRONICS
NB 240
SAFETY INSTRUCTIONS
9
SAFETY INSTRUCTIONS
IMPORTANT!
Read carefully all documentation before handling the equipment and pay special attention to safety
recommendations to maximize the performance of this product and ensure its safe use and installation.
This document covers the most important and frequent potential causes of damage to equipment or
personnel. It is the responsibility of the installer to follow the instructions provided in this manual, follow
good electrical practices and identify all warnings and recommendations before starting up and operating
the electric vehicle chargers.
WARNING
FIRST CONSIDERATIONS
The operations detailed in this manual can only be performed by qualified personnel.
The condition of qualified personnel referred to in this manual shall be at least the condition that meets
the standards, regulations and safety laws applied to the installation and operation of this equipment.
Read and retain the Hardware and Installation Manual for future reference.
Before assembling the equipment, read all instructions, caution signs and other sections of this manual.
Failure to follow these warnings can result in severe electrical shock or death. Pay attention at all times
to prevent possible accidents.
In addition to the recommendations in this manual, local and site-specific safety procedures should
be observed. Additionally, local and national electrical regulations must be followed to avoid personal
injury and/or equipment damage.
The electric vehicle charging system may cause an ELECTRICAL DISCHARGE if the warnings
indicated in this manual are not followed.
Make sure the equipment is completely disconnected from the power supply and grounded before
handling or servicing. Otherwise, there is a risk of electric shock. To avoid electrical hazards,
disconnect the input supply, ground the equipment, remove control voltages before performing any tasks,
and ensure that busbars are completely discharged. Warning and safety labels must be properly affixed
to terminals, cabinets and control panels in accordance with local regulations.
When working on electrical installations, always remember to apply the FIVE GOLDEN RULES:
1. Visible shutdown of all live sources.
2. Mechanical locking of all cutting elements.
3. Verify the absence of voltage by using the appropriate tools for the voltage of the installation.
4. Ground and short-circuit all possible voltage sources.
5. Delimit and mark the work area.
Do not modify the equipment. If you fail to do so, Power Electronics will not assume any liability, and
the product warranty will be voided.
