Verify the work pieces/sheet will not move on the top support
bar 8. If necessary, secure in place.
Make sure that you do not load workpieces unevenly. Otherwise,
the workpiece can become unbalanced and fall down.
Remove any excess materials on the product, e.g. wet paint, dirt, oil or snow.
Installation
Note: To begin the assembly, please be reminded to only tighten all screw con-
nection slightly, and only tighten fully the screw connection when the product is
assembled completely.
First spread the leg of side frame 5. Pull down the locking pin 10 on the leg
and lock the locking hook 12 on the other leg. Insert the hole bar 7through
the middle part of side frame 5. Use the locking pin 10 and insert through
the hole on the side frame 5in order to lock the hole bar 7in place. Please
be reminded to leave at least 3 holes to be protrude on top of the frame. Re-
peat the above steps to have 2 side frames with support bar (Fig. A).
Make sure both hole bars 7are on the same height.
Connect the middle support bar 9and use screw sets 1and 2to connect
with both side frames 5(Fig. B).
Use screw set 2on the side where is the locking hook 11 on the leg. After
you finish connect screw set 2, pull down the locking hook 11 and lock the
hooks on the screw. Use the screw sets 1on the other side. Repeat the above
steps to fix the middle support bar 9in place (Fig. C).
Connect the bottom plate 6to the leg with screw set 3. Repeat the above to
fix both bottom plates in place (Fig. D).
Place the top support bar 8onto the hole bar 7. Use screw sets 4to fix
the top support bar 8in place (Fig. E).
Align the product and tighten all the screw connections
Raise the two safety brackets 13 on the top support bar 8(Fig. F).
Use
CAUTION! RISK OF INJURY! Be sure locking hooks 11 und 12 are
secured in place. The two trestles must be set to the same working height. This
will ensure stability.
Verify the work pieces/sheet will not move on the top. If necessary, secure in
place.
Make sure that you do not load workpieces unevenly. Otherwise, the work-
piece can become unbalanced and fall down.
Always use two trestles and a board or boards together for working.
Fold the legs all the way apart.
