Powerflex Pf-jt48 User manual

PF-JT48 Charger

Installation Guide

PF-JT48 Charger Installation Guide

VERSION HISTORY

February 17, 2023 V1.01 Updated release

PRODUCT SPECIFICATIONS

All specifications and descriptions contained in this document are verified to be accurate at the time of

printing. However, because continuous improvement is a goal at PowerFlex, we reserve the right to

make product modifications at any time. To communicate any inaccuracies or omissions in this manual,

send an e-mail to: si[email protected].

SAFETY CONCERNS

This manual contains important instructions that should be followed for the safe installation, operation,

and maintenance of PF-JT48 chargers.

This guide contains important instructions for the PF-JT48 that must be followed during installation and

maintenance. Special symbols are used throughout the guide:

Warning: Indicates a hazardous situation that could result in injury or

death.

Risk of electric shock: Indicates components or a procedure that risks

electric shock or injury.

Caution: Indicates a hazardous situation that could result in minor injury

equipment damage.

Note:

Note: A best practice alert, tip, or technique that results in successful

results.

The unauthorized use of any trademark displayed in this document or on the product is strictly

prohibited. All other trademarks contained in this document are the property of their respective owners,

and any use does not imply sponsorship or endorsement of their products or services by PowerFlex

Systems, Inc.

Getting technical assistance

To get assistance for PF-JT48 installation or commissioning, please contact

PowerFlex support at site-support@Powerflex.com during the hours of 9 am to 5

pm (PST).

Risk of Electric Shock. Always follow basic electrical safety precautions when installing and

using this product, including wearing appropriate personal protection equipment. This product

should only be installed by a trained electrical professional.

Follow these safety instructions when installing this product:

▪Always follow local building and electrical codes when installing the charger.

▪The charger should be installed by a qualified technician.

▪Use appropriate personal electrical protection throughout the installation and especially when

installing or connecting the power distribution cable.

▪Type B, C, or D breaker should be installed in the upstream AC distribution box, with the current

rating corresponding to the desired charger max output current (see specifications in this guide).

▪Disconnect switch for each ungrounded conductor of AC input shall be provided by others in

accordance with the National Electric Code, ANSI/NFPA 70.

In addition, be sure to follow these safety instructions when using this product:

▪Read these instructions completely before using this product.

▪This device should be supervised when used around children.

▪Do not put your fingers into the electric vehicle connector.

▪Do not use this product if the flexible power cord or EV cable is frayed, has broken insulation, or

shows any other signs of damage.

▪Do not use this product if the enclosure or the EV connector is broken, cracked, open, or shows any

other signs of damage.

▪To reduce the risk of fire, connect only to a circuit provided with branch circuit over-current

protection in accordance with CSA C22.1–15 Canadian Electrical Code, Part 1 (Canada); NOM-001-

SEDE Electrical installations (utility) (Mexico); or ANSI / NFPA 70 National Electrical Code (USA).

▪To avoid the risk of fire or electric shock, do not use this device with an extension cord.

▪The suitability of the use of a flexible cord in accordance with CE Code, Part I, Rule 4-012, is to be

determined by the local inspection authority.

▪Do not remove the cover of the device or attempt to open the enclosure, as there is a risk of electric

shock. There are no user serviceable parts inside. Refer servicing to a qualified service personnel.

▪Do not install the charger near flammable, explosive, or combustible material.

FCC Part 15 Compliance

This device complies with FCC Part 15, which stipulates that radio frequency devices comply with

specific radio emission limits.

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful interference to radio communications.

To satisfy FCC radio frequency exposure requirements, a distance of 20 cm (7.9 inches) or more should

be maintained between the antenna of this device and persons during device operation.

Caution: Changes or modifications to this unit not expressly approved by the party responsible for

compliance could void the equipment's warranty.


Copyright © 2022-2023 PowerFlex Systems, Inc. All Rights Reserved. iv


Contents
Getting technical assistance ii
Getting Started 1
Welcome 1
An overview of the PowerFlex PF-JT48 1
How to use this guide 2
Setting up the PF-JT48 3
Step 1: Planning 3
What’s in the box 3
What you’ll need 3
Step 2: Installation 4
Mounting the PF-JT48 on a wall 4
Mounting the PF-JT48 on a pedestal 7
Finishing up with cable management 9
Step 3: Inspection 14
Step 4: Validation 15
Installation checklist 16
Appendix A: Technical Specifications 17
Index 19




Getting Started

Welcome

This guide instructs how to install the PF-JT48 in preparation of energizing and commissioning with the

PowerFlex system.

An overview of the PowerFlex PF-JT48

PF-JT48 is an EV charger designed and manufactured by PowerFlex. It has a LCD display and two

preinstalled cables: a connection cable and a charging cable (with a charging connector to charge an

electric vehicle).

The PF-JT48 offers the following features:

▪Durable design with corrosion protection

▪Multiple installation configurations: wall, single pedestal, back-to-back pedestal, or side-to-side

pedestal

▪Up to 48A at 240VAC, maximum output power: 11.5kW

▪Waterproof LAN interface

▪OCPP 1.6 JSON (OCPP 2.0 compatible) internal network connectivity

▪Optional LAN+4G or Wi-Fi external connectivity

▪Standard LED indicator with optional 4.3 LCD screen

▪18-foot or 25-foot charging cable

▪Junction box (to connect cables from the charger to power and connectivity at the site)

How to use this guide

To complete the installation of a PF-JT48 EV charger to a wall or pedestal, there are four steps:

1. Planning: Inspect the PF-JT48 box contents and gather the tools necessary to install the EV charger.

2. Installation: Mount the PF-JT48’s enclosure and connect wiring as required at your site.

3. Inspection: Record site information and start the commissioning process.

4. Validation: Energize the PF-JT48 and confirm that everything is up and running.

Although these steps appear to be a sequence of steps, some activities may be performed in parallel (or

in a slightly different order). To further assist in PF-JT48 installation, refer to the following information in

this guide:

▪Checklist of things to do during the installation

▪Technical specifications

Other guides that will help with site installation:

▪Nexus Core Installation Guide —includes download and instructions for how to use the FastField

Forms (FFF) app and how to energize and commission the PowerFlex system.

Setting up the PF-JT48

Step 1: Planning

What’s in the box

PF-JT48 chargers are shipped with the following components. Carefully remove from the shipping box.

PF-JT48 Charger (with the

connection and charging

cables)

Mounting bracket and 2x M5

teeth screws (to be mounted on

back of charger)

4x M6 hexagonal expansion

anchor screws

What you’ll need

You can install the PF-JT48 charger to a wall or pedestal. Check your site plan and before installing the

wall-mounted charger, gather the following tools and equipment:

▪Phillips screwdriver

▪Drill and drill-bit (¼") for expansion anchor screws for wall installation

▪Drill and 1 1/8" (29 mm) drill-bit for pedestal installation

▪Drill and 3/8" drill bit for cable retractor

▪Voltmeter or digital multimeter for measuring AC voltage at the installation site

▪AWG #6 wire nuts for connecting wiring in the junction box

▪Level (any 9-inch torpedo level will do) to make sure that brackets are installed correctly

▪Pencil (or magic marker) to mark where drilling should occur

▪Wrench (or wrench socket) that can work with 3/8" bolt (for cable retractor)

Step 2: Installation

To install the PF-JT48, you’ll do the following:

▪Mount the EV charger to a concrete wall

▪Mount the EV charger to a pedestal

▪Install cable management

Before continuing with any installation, practice this safety measure:

Make sure that electrical breakers are switched off so that no electricity is flowing during installation.

Mounting the PF-JT48 on a wall

This picture shows how the EV charger would look like once installed on the wall (with a junction box):

1. Identify where the charger is to be installed on the wall.

Installation notes:

▪PowerFlex recommends that the base of the station should be between 48" and 58" (1.219 m

to 1.473 m) from the ground.

▪For ADA compliance, the station’s QR code should be no higher than 48" (1.2 m), which means

that the bottom of the station should be no higher than 45" (1.14 m) from the ground.

▪Make sure that the location of the charger is compatible with the location (or expected

location) of a mounted junction box where the wires from the electrical panel will terminate.

2. Remove the mounting bracket from the back of the charger by removing the two screws on the side

of the charger.

3. Place the mounting bracket on the wall at a location no higher than 45" from the ground.

4. Use a level to ensure the plate is level (L) and mark the positions for the four screws on the wall (R):

5. Place the mounting bracket to the side and pre-drill four ¼"holes into the wall:

6. Using the provided anchors and screws, attach the mounting bracket onto the wall:

7. Remove the two screws on the side of the charger. Carefully slide the charger onto the mounting

bracket (L) and lock it into place with the screws (R). Verify that the charger is securely fastened on

the wall.

8. Connect the chargers’ wires to the circuit branch wires in a junction box, using AWG #6 wire nuts:

Use cable gland waterproof connectors,

if necessary.

You can use a single junction box with

two PF-JT48 chargers.

For safety reasons, make sure that the front opening of the junction box is covered.

The PF-JT48 is now mounted on the wall. To complete the installation, you’ll need to spend a few more

minutes doing cable management.

Mounting the PF-JT48 on a pedestal

Note: The initial mounting instructions for the PF-JT48 charger on a pedestal is similar to mounting

the charger onto a wall.

1. Identify where the charger is to be installed on a pedestal.

Installation notes:

▪PowerFlex recommends that the base of the station should be between 48" and 58" (1.219 m

to 1.473 m) from the ground.

▪For ADA compliance, the station’s QR code should be no higher than 48" (1.2 m), which means

that the bottom of the station should be no higher than 45" (1.14 m) from the ground.

▪Make sure that the location of the charger is compatible with the location (or expected

location) of a mounted junction box where the wires from the electrical panel will terminate.

2. Remove the mounting bracket from the back of the charger by removing the two screws on the side

of the charger.

3. Place the mounting bracket on the pedestal at a location no higher than 45" from the ground.

4. Use a level to ensure the plate is level and mark the positions for the four screws on the pedestal.

5. Place the mounting bracket to the side and pre-drill four ¼"holes into the pedestal.

6. Attach the mounting bracket onto the pedestal using M6 screws (not provided).

7. If no wire management hole exists in the pedestal, use a 1 1/8" (29 mm) drill-bit to drill a hole

between 6-12 inches under the location of the charger, directly under the left cable. Use a 1" cable

gland to waterproof the cable opening:

8. Pass the charger wiring cable through the hole and connect to the circuit branch opening in the

pedestal. Connect the cables with wire nuts inside the pedestal to the junction box:

For safety reasons, make sure that the wiring opening is covered. To complete the installation, you’ll

spend a few more minutes to perform cable management (in the next section).

Finishing up with cable management

Cable management is important to complete for every EV charger installation. This includes the

installation of the following:

▪A charging connector holster

▪A cable retractor or a high-point anchor

Install a charging connector holster

At the end of a charging cable is a charging connector that is inserted into a vehicle for charging. For

safety reasons, the charging connector should be hung up when not in use. Two holsters are offered:

Direct holster

Z holster

Both holsters come with two sets of screws to be used depending on where it will be installed. For

pedestal installation, install the holster underneath the station using the four screws. For wall

installation, install the holster on a nearby wall using the four anchor screws.

Install a cable retractor or a high-point anchor

Another key cable management feature improves safety by keeping the charging cable off the ground,

avoiding the risk of tripping, and reduces cable wear.

PowerFlex offers a cable retractor provides spring-loaded tethered support and suspends a charging

cable above the mounted charger when not in use. A cable retractor releases the charging cable when a

vehicle is being charged.

A cable retractor can be installed for either wall or pedestal installations with two simple steps:

1. Mount the retractor to the wall or pedestal

2. Mount the charging cable to the cable retractor

The cable retractor provided by PowerFlex has the following components:

Item

Description

Mounting holes on the cable retractor

Cable retractor rope (on the cable retractor)

Cable clamp (on the cable retractor)

4x 3/8" wall anchor bolt for mounting on the wall (with washer and nut)

4x 3/8" short bolts for mounting on a pedestal (with washer and nut)

To mount the retractor to the wall or pedestal:

1. Identify the best location for the cable retractor. We recommend 2-3 FT above the mounted

charger.

2. Place the retractor on the surface, use a level to make sure it is straight, and mark the four screw

locations on the wall or pedestal.

3. Place the retractor to the side. Using a 3/8" drill bit, drill holes at the four marked screw locations.

4. Remove the nut and washer from the wall-mounting nuts and bolts.

5. Insert each bolt with a wall anchor in the drilled holes.

6. Place the retractor and the washers on the bolts and secure by tightening the nuts with a wrench

socket.

Note: If mounting on a pedestal, use the four short bolts to secure the cable retractor.

To mount the cable to the retractor:

1. Pull the cable retractor rope so that the cable

clamp touches the floor and ls firmly in

position. The cable clamp is shown below:

2. Unscrew the two screws on the retractor’s

cable clamp:

3. Insert the charging cable in the cable clamp

(both front and back view shown):

4. Put the cable clamp pieces back together and

then reinsert the nuts and bolts (back view

shown):

Installation notes:

▪Place the cable clamp along the charging cable, at least 2 feet to the top of the charger. Also,

Give the cable slack to the bottom of the charger as shown in the picture:

Ensure the cable is not twisted between the

charger and the cable clamp.

The high-point anchor is an alternative to the cable retractor that is not provided by PowerFlex. This

simple assembly can be mounted on a wall or onto a pedestal.

1. Using a ¾" metal cable clamp with

rubberized cushions, route the charging cable

2-3 FT above the charger. Make sure there

are no twists in the cable.

2. Install a cable clamp to hold the cable.

3. Use a ¼" diameter screw with a wall anchor

as appropriate for the wall material to secure

the cable clamp to the wall.

Before proceeding to the next step …

1. Confirm that the PF-JT48 charger is securely mounted to a wall or pedestal.

2. Perform a quick verification that all cables to the charger enclosure are fully connected.

Step 3: Inspection

Inspection is performed once the entire PowerFlex system is ready to be energized, commissioned, and

validated. Inspection is where installation information is recorded and a request for commissioning with

PowerFlex is initiated.

PowerFlex uses a customized mobile app, available from either the Google Play store or the Apple

Store, called FastField Forms (FFF). This app enables installers to gather important installation

information and photographs for each PF-JT48 charger being installed:

More about using the FFF app …

▪Nexus Core Installation Guide —includes download and instructions for how to use the FastField

Forms (FFF) app and how to energize and commission the PowerFlex system.

Step 4: Validation

Once the PF-JT48 charger information is entered and the rest of the PowerFlex stations are recorded in

the app, the installer submits the forms to PowerFlex for review and commissioning. After the go-ahead

from PowerFlex, the final validation step is performed.

To perform an end-to-end validation, you’ll energize with power and confirm each PF-JT48 works as

expected. There are three LED light indicators on the front of the charger that indicate its status:

Display

LED light

Description

READY

If solid blue, the charger is in standby mode.

CHARGE

If solid green, the vehicle connector is inserted in the

vehicle’s charging inlet and is waiting to charge.

CHARGE

If flashing green, a vehicle is currently being charged.

FAULT

If solid red, there is a problem (more information is in the

user guide).

To learn more about …

▪Inspection and validation for PowerFlex systems, read the Nexus Core Installation Guide.

Installation checklist

Done

Task

Step 1: Planning



Identify the location where the PF-JT48 EV charger will be installed at the site



Unbox the PF-JT48 and verify everything is included



Gather all the required tools before going onsite for the installation

Step 2: Installation



Install the PF-JT48 securely to a wall or pedestal



Attach power, communications, and ground bond cables to the enclosure



Ensure all external connections are properly sealed and junction box (and any wires) are

not exposed



Install the charging connector holster (one of two types available from PowerFlex for

cable management)



Install a cable retractor or a high-point anchor (cable management)

Step 3 and 4: Inspection and Validation (usually performed later)



Gather information from the site using the app



Submit site information to PowerFlex with FFF



Get OK to energize and finalize the installation from PowerFlex support



Energize power to the PF-JT48



Collaborate with PowerFlex that end-to-end diagnostics run successfully

Table of contents

Popular Batteries Charger manuals by other brands

ProMariner

ProMariner ProNautic1210P instruction manual

Licorne

Licorne DN49 user manual

Manhattan

Manhattan Popcharge Auto USB Charger instructions

EG4

EG4 PDP-120A-240 user manual

Bticino

Bticino H4285CW2 quick guide

Eagle

Eagle Power II Installation & owner's manual

Flux

Flux BCH-3100 Original operating instructions

Ozito

Ozito Xilinx instruction manual

VOLTCRAFT

VOLTCRAFT 20 15 40 Directions for use

Aptiv

Aptiv 74T0 user manual

DigiPower

DigiPower TC-U400 user guide

Sears

Sears 200.71210 owner's manual

SLAT

SLAT TITAN Series installation guide

RAMSET

RAMSET CBCHR18 owner's manual

Motorola

Motorola GMLN5075 installation manual

Lectron

Lectron 16/32A EV Charger user manual

ABB

ABB HT605310 Operation manual

Innogy

Innogy eBox professional Instructions for use

PowerFlex PF-JT48 User manual

Popular Batteries Charger manuals by other brands
