POWERhandle PH-SG01 User manual

POWERhandle
Charger
User Manual
PH-SG0
Technical Specifications
If you experience any problems with the product please contact
email: [email protected]
phone UK: [phone]
www.cel-global.com
READ INSTRUCTION MANUAL
KEEP DRY
GENERAL HAZARD
SAFETY ALERT
KEEP BYSTANDERS AWAY
© Copyright C Enterprise Limited 2012
C Enterprise Limited www.cel-global.com [email protected]
UK • HK • USA • China • Europe • Australia • Japan
C Enterprise Ltd
Product Code
Charger Input
Charger Output
Boxed Dimensions
Weight
Currently compatible with
- PH-SG01
- 240v AC 50Hz
- 23V DC 500mA
- 155x77x55mm
- approx (6x3x2")
- 0.45Kg (1lb)
- PH01, PH02, PH03, PH04,
PH09, PH10, PH11, PH12
FAQ
POWERhandle refers to the battery pack and handle used to
power compatible CEL products, use of the word battery or
batteries refers to the non-removable cells contained within the
POWERhandle.
General inspection
Regularly check that all wires and fittings are present and
correct. Any damage increases the risk of electric shock, fire or
damage to person and property.
Dust
Keep the products air vents unclogged and clean at all
times. Remove dust and dirt regularly. Cleaning is best
done with compressed air or a rag.
Never use caustic agents to clean plastic parts.
CAUTION, Do not use cleaning agents to clean the plastic
parts of this product. A mild detergent on a damp cloth is
recommended. Water must never come into contact with
the charger or POWERhandle.
WARNING, Do not use an extension cord to charge.
WARNING, Charge indoors only.
WARNING, Do not use in wet or damp areas.
Store the product, instruction manual and accessories in a
secure, dry place. In this way you will always have all the
information and parts ready to hand.
This product contains no user serviceable parts. Repairs should
only be carried out by a CEL authorised repairer.
18V
My battery is not charging, what’s wrong?
Check to make sure the electrical outlet is "live" and that
the air surrounding the battery and charger is between
10ºC and 24ºC (50ºF) and (75ºF). Make sure the
POWERhandle is correctly fitted.
If a Li-ion battery has been subject to an impact, such as being
dropped, the circuit which prevents over discharge can become
damaged, contact your retailer. Extreme impact can cause the
chemicals within the battery to leak, these chemicals are
harmful and should not be touched. Do not charge or attempt to
use the battery. Dispose of appropriately.
What is the best way to care for the batteries in my
POWERhandle?
CEL uses several types of battery in its range of
POWERhandles, these require different care. NiCD batteries
will perform best if completely discharged before charging, at
least once every five cycles (charge/discharge cycles). NiMh
batteries should be cared for in a similar way but are more
resilient to the “memory effect” than NiCD, Li-ion batteries have
no memory effect so you can charge them at any time. The
charge will be retained in storage for much longer than other
battery technology but should be topped up occasionally as
over discharge can permanently damage the battery.
Always charge POWERhandles before storage. For more
information see www.cel-global.com
How can I get my charger repaired if it is damaged?
Contact your retailer or visit www.cel-global.com
Where can I get replacement parts, advice or help?
Ask at your retailer or visit www.cel-global.com
Maintenance
Manual Version: 120816 - Designed and edited in the UK - Printed in China

This charger is designed to charge 18 volt
POWERhandles only, using any other battery with
this charger could cause serious harm to persons
and property.
Charge only within a temperature range of 0 °C to 45
°C if the battery goes outside this range while charging
it may be damaged or not reach full capacity.v
Always remove the battery from the tool/charger
and store it in a dry, secure place between 10ºC
and 24ºC (50ºF) and (75ºF) when not in use.
NEVER pull the charger out by the cord or use if the
cord is damaged in any way.
NEVER leave the battery on charge for longer than 24
hours to reduce fire risk.
NEVER use or charge a battery that is damaged or
leaking fluid has corrosion on the metal contacts. In
case of leak dispose of safely and clean thoroughly.
Features ChargingSafety Notes
To use this product properly, you must observe the safety limitations, the
assembly instructions and the operating instructions to be found in this
manual. All persons who use and service this product must be acquainted
with this manual and must be informed about potential hazards. Children
and infirm people must not use this product. Children should be
supervised at all times if they are in the area in which the product is being
used. It is also imperative that you observe the accident prevention
regulations in force in your area. The same applies for general rules of
occupational health and safety.
The manufacturer shall not be liable for any changes
made to this product nor for any damage resulting from
such changes.
Do not use the product in the rain or in a damp area.
Check for damaged parts. Before using this product,
check that there are no damaged parts or wires.
Defective or damaged parts must be replaced by an
authorised service facility.
Guard against electric shock. Prevent contact with
grounded objects such as water pipes.
WARNING. The use of an accessory or attachment, other
than those recommended in this Instruction Manual, may
present a risk of personal injury.
This product has been designed to charge specific batteries, any use
not specified in this manual will be considered misuse.
The product must be used only for its prescribed purpose. Any use other
than those mentioned in this Manual will be considered a case of misuse.
The user and not the manufacturer shall be liable for any damage or injury
resulting from such cases of misuse.
If the product appears to have any fault or makes any unusual
sounds please consult the manual, a service centre or your retailer
before using.
Conforms to relevant standards for electromagnetic compatibility.
General
Hazard
Keep Dry
Only use supplied battery
and charger or CEL
recommended
replacements.
1. Plug the charger unit into
a safe and suitable power
outlet. Green light will
come on.
2. Place the POWERhandle to be charged in a safe,
secure position and grip firmly.
3. Slide the rails on the adaptor plate into the top of the
POWERhandle, check alignment and press in firmly,
check the parts are connected and cannot be pulled
apart without operating the release catches.
The green light will go off and the red light will come on
while the unit is charging.
Charging time for a 1.3 Ah POWERhandle is typically 5
hours but the charger will indicate when the battery is
ready for use batteries with higher capacity may take
longer to charge.
If the battery was not fully discharged in the previous
use a faster charge will be possible.
4. Once the battery is charged the green light on the
charger will come on again, slide the release catches
and disconnect the adaptor plate from the
POWERhandle, remove the charger from the power
outlet and store safely.
When charging some POWERhandles
their LED display will flash RED then
RED+YELLOW then
RED+YELLOW+GREEN and loop until
the POWERhandle is fully charged.
loop
RED YELLOW GREEN
Indicator Lights
Adaptor Plate
Rails
Charger
If there is any doubt of normal
operation of any part of this tool or
the charger, de-activate and remove
from any source of power
immediately. Consult your retailer.
Your product
may differ from
the images and
descriptions in
this manual.
POWERhandle
(sold separately)
Release catches
(both sides or on rear
of some models)
Before charging,
read the
instructions.
For 18v
POWERhandles
only.
Indoor use only.
www.CEL-global.com
Green =
AC Power/Full
Red =
Charging
PH-SG01
