POWERSHADES SQUARE CASSETTE User manual

SCREWS BRACKETSSTABILIZERSWALL SPACERS
SQUARE CASSETTE INSTALLATION GUIDE
Thank you for your purchase! This will guide you through the Square Cassette installation process.
If you ever need any help throughout, reach out to us at [phone].
INSTALLATION
REQUIRED TOOLS AND HARDWARE
Determine the correct window for the shade to be installed and whether the shade was ordered
to be inside or outside mounted. Please also consider the control side of the shade. You can
reference the packaging of the shade or you can refer to your order on the PowerShades Portal for
this information.
STEP 1
1
Before installing the Square Cassette roller shade, Please have measurements from your
order handy. Your shade will come labeled with the room name and shade name on the
outside of the box to help you correctly identify the shade.
!
Shade > 60”W = 3 Brackets.Shade > 90”W = 4 Brackets. Shade > 120”W = 5 Brackets.
!

INSIDE MOUNT
OUTSIDE MOUNT
Spacer will give 1/8” from
the back of the jamb
Mount and screw the brackets at a max of 2” from the left and right side of the window jamb. Bracket
will be screwed inside the top of the threshold with the spacer attached and facing the window. If
additional mounting brackets are needed, evenly distribute across the top inside window jamb even
with the 2 end mounting brackets.
INSIDE MOUNT
Mount and screw brackets top outside window jam, level with one another and centered to
measurements. Max 2” from each end of cassette The spacer will be screwed to the surface through
the bracket. If a third mounting bracket is needed, secure it at the top center of the window. If
additional mounting brackets are needed, evenly distribute across the top above the window even
with the 2 end mounting brackets.
OUTSIDE MOUNT
Depending on mount type, the spacer will be screwed to the surface through the bracket
(outside mount) or will simply be attached (inside mount).
!
Connection wires will come out of
the back of the cassette. Make sure
brackets clear all wiring obstructions
before mounting.
!
Before mounting your brackets, place the wall spacer on the back of the brackets, lining up the
screw holes. You will be able to snap the spacer to the back of the bracket.
STEP 2
Screw brackets onto the left and right side above the window, centered to measurements.
STEP 3
2

Attach the cassette to the mounting brackets.
Rest the groove on the top of the cassette to the top lip of the bracket.
Pivot the back end of the cassette up and lift until it clicks into the backside of the bracket.
1
1
2
2
Apply bracket stabilizer to the backof your bracket when its screwed and mounted. You will be
able to slide it in-between the spacer and the back of bracket until it clicks into place.
STEP 4
STEP 5
3
