powersoft DigiMod IS Series Specification sheet

Tech Note’s
Number
Keep This Technical Note For Future Reference
1 Preliminary consideration
This article is related to the following products:
fDigiMod IS Series
fAll DigiMod modules with DSP-C installed
2 Tools needed
fPhillips cross-wing screwdriver
fFlathead screwdriver
fA pair of pliers for electrical uses
fOne XLR male connector
fTwo Phoenix 5 poles connector
fOne audio cable
3 Procedure
Disconnect the 3 micro-match connectors from the DSP-C.
Take the Phillips screwdriver to remove the 2 screws from the
DSP-C.
Take the athead screwdriver and push out the DSP-C from
the sim board.
With the aid of the pliers add the 2 jumpers on the pins BY22-
BY32 in the CN18 connector and pins BY31-BY21 on the CN17
connector.
TECHNICAL NOTE #16 rev. 01
Removing DSP-C from DigiMod
How to remove the DSP-C card from Digimod amp modules
FIGURE 1: Disconnecting the micro-match connectors
FIGURE 2: Removing screws from the DSP-C
FIGURE 3: Jumpers on DigiMod, overview
FIGURE 4: Removing the DSP-C
FIGURE 5: Jumpers on DigiMod, detail
FIGURE 6: Jumpers in place
© 2012 - 2013 Powersoft
powersoft_TN016_RemoveDSPC_en_v1.0

Via Enrico Conti, 5
50018 Scandicci (FI) Italy
Tel: [phone]
Fax: [phone]
General inquiries: [e-mail]
Sales: [e-mail]
Application & technical support: [e-mail]
Service & maintenance: [e-mail]
www.powersoft-audio.com
Make one cable XLR male / Phoenix 5 poles following this
schematic pin:
With the same pin conguration use the other phoenix 5 poles
connector to make the parallel input.
Connect this cable to the phoenix input connector on DigiMod
amp module
FIGURE 7: Phoenix_input.png
Pin Phoenix
1GROUND
2HOT
3COLD
XLR male Pin
GROUND 1
HOT 2
COLD 3
© 2012 - 2013 Powersoft powersoft_TN016_RemoveDSPC_en_v1.0
