PowerTech HS-9062 User manual

Phone Cradle with
15W Wireless Charger
User Manual
HS-9062

Box Contents:
1 x Wireless Charger 1 x Suction
Cup Mount
1 x Air Vent Mount 1 x USB-C
Power Cable

Product Diagram:

Installation:
Suction Cup Mount:
1. Unscrew the adjustable
mounting ring knob from the
phone cradle. Place it over the
end of the suction cup mount.
2. Attach the phone cradle to the
suction cup mount and tighten the
adjustable mounting ring knob so
the cradle and suction cup mount
are secured tightly.

3. Peel the plastic from the
bottom of the suction cup mount
and place it on the windscreen of
your car or dashboard.

Air Vent Mount:
1. Screw the adjustable vent
mount clockwise to loosen the
adjustment and the hook will
slowly come out.
2. Place the hook and latch it on
to your air vent. Screw the
adjustment anti clockwise to

tighten the adjustment and fix the
mount securely to your air vent.
3. Unscrew the adjustable
mounting ring knob from the
phone cradle. Place it over the
end of the air vent mount and
tighten the adjustable mounting
ring knob securely.

Power:
1. Insert the USB power cable in
a 5VDC/9VDC USB car charger
(not included).
2. Insert the USB-C plug in to the
USB power socket of the phone
cradle.
3. The LED status indicator will
turn green once it has been
powered on.

Note: It is suggested to use a
Qualcomm®Quick Charge™3.0
USB car charger for fast
charging. Please check to see
if your device supports quick
charge otherwise it will charge
at 5W.

Operation:
Charging:
1. Press the lock/release button
to open the phone clamps.
2. Slide down the adjustable
holder located at the bottom of
the cradle and slide your smart
phone into the cradle.

3. The LED status indicator will
turn blue once charging has
started.
Note: You may need to change
the position of the adjustable
holder at the bottom of the
cradle. The wireless charging
pads are in a different location
depending on the type of
smartphone.

Troubleshooting:
Problem:
Solution:
Will not charge
device
Ensure your
smartphone supports
Qi wireless charging
Ensure the mobile
device is placed on
the charging pad
correctly and adjust
the adjustable foot
holder accordingly
Restart your mobile
device and wireless
charger

Will not charge
device
Take off your phone
case as it may be
interfering with the
wireless charger
Will not power on
Ensure the USB
cable is connected
properly to a suitable
USB car charger

Safety:
1. Do not place any metal objects,
magnets, magnetic stripe cards or
metal phone cases between the
mobile device and the charger as
it may not work properly.
2. Keep the wireless charger at
least 20cm away from any
implantable medical devices such
as a pacemakers or cochlear, etc.
to avoid interference with the
medical device.
3. Do not open the case of the
wireless charger to avoid damage
and injury.

4. Keep the wireless charger
away from high temperatures as it
may cause damage to the
speaker and battery.
5. Do not expose the wireless
charger to water, moisture or
liquids to prevent the unit from
damage.

Specifications:
Input: 5VDC @ 2A, 9VDC @ 1.7A
Voltage Output: 5VDC, 9VDC
Current Output: 5V @ 1A(5W)
9V @ 0.8A (7.5W)
9V @ 1.1A (10W)
9V @ 1.66A 15W)
Output Power:
5W/7.5W/10W/15W
Charging Efficiency: 73% (Max)
Charging Distance: ≤7mm
Battery: 3.7V Li-ion, 60mA
Battery Standby Time: Up to 30
Days
Dimensions: 119(H) x 75(W) x
34(D)mm

Distributed by:
Electus Distribution Pty. Ltd.
46 Eastern Creek Drive, Eastern Creek
NSW 2766 Australia
Ph: 1300 738 555
Int’l: [phone]
Fax: [phone]
www.electusdistribution.com.au
