Resolute™ Strength Selectorized Line
Converging Chest Press RSL 414
Assembly Guide

©2019 Precor Inc. | Converging Chest Press RSL 414 | Assembly Guide 3
Assembly Requirements
It takes about 90 minutes to assemble this equipment. If this is your rst time doing this, allow more time.
CAUTION
At least two people are required to assemble the equipment. DO NOT attempt to assemble this by yourself. Precor recommends that all strength equipment be bolted to the
ooring at all anchoring points.
Installation Requirements
● Unpack the boxes and assemble the equipment close to where you plan to use it.
● Locate equipment at least 40 inches (1 meter) away from any walls, furniture, or objects on all sides.
● While tightening the fasteners, be sure to leave room for adjustments. DO NOT fully tighten fasteners until instructed to do so.
● Set up and assemble the equipment on a solid, at surface, so that it remains level and stable.
● DO NOT move the equipment without assistance.
Required Tools
● Torque wrench with torque range to at least 150 ft-lb (206 N-m) and ts the following hex bits: 6, 8, and 10 mm
● Socket wrench sets, metric and standard, plus extensions
● Open-end wrench sets, metric and standard
● Hex wrench sets, metric and standard, plus extensions
●Box cutter
●Rubber mallet
● Retaining ring pliers - large, medium, and small
● Pliers - large, medium, and small
Trademarks
Resolute is a trademark and Precor is a registered trademark of Precor, Incorporated.
All other trademarks belong to their respective owners.

©2019 Precor Inc. | Converging Chest Press RSL 414 | Assembly Guide 4
Part # Name Quantity Part # Name Quantity
Main frame 1 Weight plates 10 lb (4.5 kg) 23
Side arm, left 1 Collars 2
Side arm, right 1End plugs with sleeves 2
Upper cross brace 1 Washers, 12.2 mm ID x 35 mm OD 2
Lower cross brace 1Washers, domed, silver 2
Seat assembly 1 Washers, rubber, black 3
Shaft 1 Washer, silver 13.5 mm ID x 35 mm OD 1
Roller assembly 1 Retaining rings, 3/4-inch 2
Gas spring 1 Hole plugs 2
Bumpers 4 Button head cap screw (BHCS) M6 x 15 mm 1
Weight stack spacer, 1-inch 1Socket head cap screws (SHCS) M12 x 25 mm 2
Add-on weight 5 lb (2.2 kg) 1Washers, 9 mm 6
Weight stack tower frame 1Washers, 13 mm 8
Kick plate 1 Hex head screws 5/16-inch x 1½-inch 6
Add-on weight handle 1Socket head cap screws (SHCS) M12 x 35 mm 6
Top plate assembly 1Socket head cap screws (SHCS) M12 x 130 mm 2
Shroud, crown 1Nylon lock nuts, M12 2
Guide rods 2 Socket head cap screws (SHCS) M10 x 65 mm 2
Guide rod with cap 1Nylon lock nuts, M10 2
Add-on weight spacer, 3-inch 1Button head cap screws (BHCS) M10 x 125 mm 2
Shroud, rear middle 1Socket head cap screws (SHCS) M10 x 40 mm 2
Shroud, rear lower 1Washers, 11 mm 5
Shroud, rear upper 1 Back pad 1
Shroud, top tray 1 Seat pad 1
Shroud, front middle (left and right) 2 Weight labels 1
Shroud, front lower 1Roller adjustment tool (attached to Seat assembly) 1
Shroud, front upper placard 1
Shroud, pulley cover 1
1
10
11
12
13
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
3
30
31
32
33
34
35
36
37
39
4
40
42
43
44
45
46
47
48
49
6
7
8
9
2
5
14
Parts List
38
41
50
51
52
53
54
6

©2019 Precor Inc. | Converging Chest Press RSL 414 | Assembly Guide 5
Frame Assembly
DO NOT tighten fasteners until instructed to do so.
Have your assistant hold frame parts in place during assembly.
Image Hardware Instructions
12 M12 x 130 mm SHCS
4 washers, 13 mm
2 M12 nylon lock nuts
Tools: Hex wrench, 10 mm
Socket wrench, 19 mm
2 M10 x 125 mm BHCS
1 washer, 11 mm
Connect lower cross brace to weight stack tower and
kick plate .
Align to second hole from right.
Insert guide rod fasteners, one from each side, to align the
kick plate. Hand tighten only. These will be removed tem-
porarily in a later step.
13
4
1
5
14
13
45
48
5
14
44
41
50
5
41
14
44
13
50 48
48
45
41

©2019 Precor Inc. | Converging Chest Press RSL 414 | Assembly Guide 6
2 2 M12 x 35 mm SHCS
2 washers, 13 mm
Tool: Hex wrench, 10 mm
Connect lower cross brace to main frame .
32 M12 x 35 mm SHCS
2 washers, domed, silver
Tool: Hex wrench, 10 mm
Connect upper cross brace to weight stack tower .
1
5
13
4
33
43
41
43
41
1
43
5
33
43
13
4

©2019 Precor Inc. | Converging Chest Press RSL 414 | Assembly Guide 7
42 M12 x 35 mm SHCS
2 washers, 13 mm
Tool: Hex wrench, 10 mm
Connect upper cross brace to main frame .
5 Tools: Hex wrench, 10 mm
Socket wrench, 19 mm
Torque wrench
Gently rock the frame to align. Tighten all M12 fasteners to
55 ft-lb (75 N-m) of torque.
Do not tighten the M10 screws installed in step 1 at this
time. They will be removed temporarily in a later step.
1
4
41
43
41
1
43
4

©2019 Precor Inc. | Converging Chest Press RSL 414 | Assembly Guide 8
Moving Parts
Image Hardware Instructions
12 collars Slide collars onto arm shafts on main frame. Ensure at sides of
collars are towards main frame.
2Slide left arm and right arm onto shafts at top of main
frame . Each arm is labeled with and . Match the arm
labels with the labels at the top of the main frame to ensure prop-
er placement.
32 washers, rubber
2 washers, 12.2 mm ID x 35 mm OD
2 M12 x 25 mm SHCS
Tools: Hex wrench, 10 mm
Torque wrench
Slide washers on to each arm in order shown. Hold washers
centered in arms and secure. Tighten to a torque of 55 ft-lb (75
N-m).
42 end plugs with sleeves
Tool: Mallet
Slide end plugs with sleeves onto ends of arms. Tap gently with
mallet if needed.
Remove all and labels.
30
30
3
2
31
L
R
1
32
34
39
3
12
34 32
31
39
L
R
L
R
L
R

©2019 Precor Inc. | Converging Chest Press RSL 414 | Assembly Guide 9
Seat Assembly
Image Hardware Instructions
1 1 roller assembly
1 shaft
2 retaining rings, 3/4-inch
Tool: Pliers
Attach the seat assembly to the main frame . Place the roller assembly
between the seat assembly brackets and insert the shaft. Secure each side with
retaining rings.
21 gas spring Snap gas spring into place under seat and at base of main frame . The larg-
er body of the gas spring attaches to the seat.
3To adjust the roller clearance on the seat assembly, have your assistant apply
downward force on seat.
4Tools: Two hex wrenches, 8 mm Preinstalled on the front roller of the seat assembly is a roller adjustment tool .
Continue to apply force to the seat assembly and press the adjustment tool down-
ward to turn the roller. Turn until it just contacts the plastic ratchet plate and no
more than 180 degrees. Tighten the socket head screws on the sides of the front
roller (ensure the position of the roller tool does not change). Remove tool.
5 4 hex head screws 5/16 x 1½-inch
4 washers, 9 mm
Tool: Socket wrench, ½-inch with extension
Attach seat pad to seat assembly .
1
6
7
8
9
6
1
6
36
40
42
52
54
54
52
6
40
42
1
8
7
36
9
6

©2019 Precor Inc. | Converging Chest Press RSL 414 | Assembly Guide 10
Route the Cable
Image Hardware Instructions
1Tools: Two open end wrenches, 19 mm
Torque wrench
Attach cable to arms. Thread cable end into rod end as shown. Hold rod end with
wrench and fully tighten lock nut. Maximum distance is 25 mm.
Tighten to 50 ft-lb (67.7 N-m).
2 Tools: Socket wrench, 8 mm
Socket wrench, 4 mm
To route the cable around the lower pulley on the weight stack tower, remove
the cable retainer. Route the cable around the pulley and then replace the cable
retainer.
3Tools: Hex wrench, 8 mm
Open-end wrench, 19 mm
Torque wrench
To route the cable to the upper pulleys of weight stack tower, remove the cable
retainers, route the cables, and replace the retainers. Tighten to 50 ft-lb (67
N-m) of torque.
6 2 hex head screws 5/16 x 1½-inch
2 washers, 9 mm
2 hole plugs
Tool: Socket wrench, ½-inch with extension
Attach back pad to main frame .
1
37
40
42
51
51
1
37
42
40

©2019 Precor Inc. | Converging Chest Press RSL 414 | Assembly Guide 11
Finish the Weight Stack Tower
Image Hardware Instructions
12 M10 x 125 mm BHCS
1 washer, 11 mm
Tool: Hex wrench, 6 mm
Remove the guide rod fasteners installed in step 1 of the Frame Assembly.
2 1 weight stack spacer, 1-inch
2 guide rods
Align the weight stack spacer over the holes on the base of the tower. Insert two
weight guide rods and lean outwards about 6 inches (15 cm), enough clearance
for the weights. Flat side of weight stack spacer should face user side.
32 bumpers
23 10 lb (4.5 kg) weight plates
1 top plate assembly
Slide one bumper on to each rod. Place the weight plates on the rods. Ensure the
side with three holes face the user side and single hole to the back. Place the top
plate over the weight plates. The plates and top plate should align ush on the
user side.
10
16
18
29
11
18
11
16
10
29
50 48
48
48
50

©2019 Precor Inc. | Converging Chest Press RSL 414 | Assembly Guide 12
4Straighten the front two guide rods to a vertical position. Have your assistant lift
the guide rods up into the upper part of the frame.
5 Tools: Hex wrench, 6 mm
Torque wrench
While the assistant is holding the rods into the upper frame, reinsert the two
bolts underneath the guide rods removed in Step 1 above. Let the guide rods
drop onto the bolts and fully tighten the bolts. Tighten M10 screws to 32 ft-lb
(43 N-m) of torque.
6 1 M10 x 65 mm SHCS
2 washers, 11 mm
1 M10 nylon lock nut
Tools: Hex wrench, 8 mm
Socket wrench, 17 mm
1 guide rod with cap
Prepare the lower base for the add-on weight assembly. Place the retaining
screw through the bracket on the weight stack spacer.
Remove the cap from the guide rod and place the rod into bracket opening se-
cured by the screw.
72 bumpers
1 add-on weight spacer, 3-inch
1 add-on weight
1 add-on weight handle
Place one bumper onto third rod, followed by the add-on weight spacer, another
bumper, the add-on weight, and the add-on weight handle.
19
10
12
15
20
15
12
10
20
10
46
47
50
19
46 47
50
50
48
48

©2019 Precor Inc. | Converging Chest Press RSL 414 | Assembly Guide 13
8 1 M10 x 65 mm SHCS
2 washers, 11 mm
1 M10 nylon lock nut
Tools: Hex wrench, 8 mm
Socket wrench, 17 mm
Replace the cap to the top of the rod and secure top of rod to weight stack
tower frame.
91 washer, rubber
1 washer, silver 13.5 mm ID x 35 mm OD
Place the washers into the top of the cable connector in the add-on weight
handle.
10 Tool: Torque wrench Attach the cable to the weight stack. Thread the bolt into the top plate assem-
bly until the cable meets ALL of the following requirements.
The top weight begins to separate from the second weight.
The selector pin can be easily inserted into each of the weight plates.
The add-on weight is engaged when the latch is in the down posi-
tion.
At least six turns of the threads on the cable bolt extend into the
add-on weight selector stem.
The distance from the underside of the jam nut to the top of the washer
should be no more than 1.61 inch (41mm).
Tighten the locking bolt against the select stem to 50 ft-lb (81 N-m) of
torque.
Check and further adjust cable connections at arms if needed.
11 1 weight labels Remove back of labels. Align top holes on weights and labels and place pin
into hole. Remove pin and place into a lower hole on labels. Re-align labels as
necessary and then press rmly onto weights. Rub vigorously and thoroughly
to adhere. Peel the extra label away and rub remaining labels again.
12 Lubricate the guide rods with a Teon-based lubricant, such as Tri-Flow Supe-
rior Lubricant. Remove any excess with a clean cloth or tissue.
46
47
50
34
35
53
50
46 47
35
34
41 mm

©2019 Precor Inc. | Converging Chest Press RSL 414 | Assembly Guide 14
Install the Shroud
IMPORTANT
Before installing the shroud, ensure that cable connections are correct and cables move smooth through their paths. If they do not,
STOP and adjust cable and routing. In addition, ensure all fasteners (including those preinstalled) are tightened appropriately.
Note The location of the lower pulley cover will vary depending on the model.
Image Hardware Instructions
1Snap the lower pulley shroud onto the lower front shroud . Place
the lower front shroud with pulley cover into frame and hook onto but-
tons.
2 1 M6 x 15 mm SHCS
Tool: Hex wrench, 4 mm
Secure lower pulley shroud.
3Place the lower rear shroud onto the frame. Raise it enough to hook
over buttons.
4 Install the rear middle shroud . Slide it over the triangular tabs of the
lower shroud and hook it onto middle buttons.
Repeat for the front middle shrouds .
5Install the upper rear and front shrouds . Ensure to hook them
over the buttons and spacers.
6 2 M10 x 40 mm SHCS
Tools: Hex wrench, 8 mm
Torque wrench
Place shroud crown on top and secure. Recommended bolt torque
is 25 ft-lb (34 N-m).
7 Securely snap top tray into place.
21
22
23
24
25
26
17
27
28
49
38
17
38
28
26 22
21
25
27 23
49
24

©2019 Precor Inc. | Converging Chest Press RSL 414 | Assembly Guide 15
Complete the Assembly
IMPORTANT
As oor materials vary, it is important that you consult a licensed contractor to advise you on proper bolting techniques and appropriate fastener
types.
Standards can be changed or updated. Precor recommends that you keep apprised of your local industry standards. Precor shall not be liable for fail-
ure to properly secure and bolt strength equipment to the oor.
Precor recommends that the strength equipment be bolted down at all anchoring points. Adjust the round feet on the frame up or down by turning them left or right to help level the
equipment.
Anchor each oblong foot on the frame to the oor, including the feet on the weight stack tower. Each oblong foot has a rubber cap with slits to allow access the anchor points.
Final Checklist
• Lubricate the guide rods and chrome pad adjustment tubes with a Teon spray lubricant. Precor recommends using TriFlow brand.
• For all movable arm and pad frames, adjust and test each position. Verify that the adjustment pin fully engages and inserts freely into each position.
• Verify cables fully sit in cams (if applicable) and in pulleys. Cables should move without rubbing.
• Place the selector pin into the holder on the top plate assembly of the weight stack. Perform the exercise slowly. Verify cable moves freely without any binding. Select a
moderate weight and repeat.
• Verify the selector pin can be inserted into each weight plate.
• Verify all fasteners and the cable retention nuts are tight. Ensure they meet the torque call outs in the assembly guide.
• Refer to the Maintenance Guide that came with your product for details on maintaining the equipment.

RSL Converging Chest Press 414 | Assembly Guide | P/N CW39535-101 ENG
© Precor, Incorporated | 30 August 2019
