Precor Resolute RSL 618 User manual

ENGLISH
Resolute™ Strength Selectorized Line
Glute Extension RSL 618
Assembly Guide

©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide 2
Assembly Requirements
It takes about 90 minutes to assemble this equipment. If this is your rst time doing this, allow more time.
CAUTION
At least two people are required to assemble the equipment. DO NOT attempt to assemble this by yourself. Precor recommends that all strength equipment be bolted to the
ooring at all anchoring points.
Installation Requirements
● Unpack the boxes and assemble the equipment close to where you plan to use it.
● Locate equipment at least 40 inches (1 meter) away from any walls, furniture, or objects on all sides.
● While tightening the fasteners, be sure to leave room for adjustments. DO NOT fully tighten fasteners until instructed to do so.
● Set up and assemble the equipment on a solid, at surface, so that it remains level and stable.
● DO NOT move the equipment without assistance.
Required Tools
● Torque wrench with torque range to at least 150 ft-lb (206 N-m) and ts the following hex bits: 6, 8, and 10 mm
● Socket wrench sets, metric and standard, plus extensions
● Open-end wrench sets, metric and standard
● Hex wrench sets, metric and standard, plus extensions
●Box cutter
●Rubber mallet
● Retaining ring pliers - large, medium, and small
● Pliers - large, medium, and small
Trademarks
Resolute is a trademark and Precor is a registered trademark of Precor, Incorporated.
All other trademarks belong to their respective owners.

©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide 3
Part # Name Quantity Part # Name Quantity
Handle assembly 1 Kick plate 1
Front frame 1 Elbow pad 1
Lower cross brace 1 Weight labels 1
Foot plate frame 1 Washers, 11 mm 8
Pivot frame 1 End cap 1
Pivot arm 1Washer, rubber, black 1
Add-on weight 5 lb (2.2 kg) 1Wave washer 1
Shroud, rear upper 1Washers, domed, silver 4
Shroud, front upper placard 1Flat head cap screw (FHCS) M12 x 35 mm 1
Weight stack tower frame 1Socket head cap screws (SHCS) M12 x 130 mm 2
Add-on weight handle 1Socket head cap screws (SHCS) M12 x 35 mm 8
Foot plate 1 Socket head cap screws (SHCS) M10 x 65 mm 2
Top plate assembly 1Socket head cap screws (SHCS) M10 x 40 mm 2
Weight plates 10 lb (4.5 kg) 15 Button head cap screw (BHCS) M6 x 15 mm 1
Weight stack spacer, 3-inch 1Button head cap screws (BHCS) M10 x 125 mm 2
Bumpers 4 Button head cap screws (BHCS) M10 x 30 mm 5
Guide rod with cap 1Hex head screws 5/16-inch x 1½-inch 2
Guide rods 2 Nylon lock nuts, M12 2
Shroud, front lower 1Nylon lock nuts, M10 2
Shroud, rear middle 1Washer, silver, 13.5 mm ID x 35 mm OD 1
Shroud, front middle (left and right) 2Washers, 9 mm 2
Shroud, crown 1Washers, 13 mm 8
Top tray 1Washers, 11 mm, black (for foot plate) 5
Shroud, rear lower 1
Shroud, lower pulley cover 1
1
10
11
12
13
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
3
30
31
32
33
34
35
36
37
39
4
40
42
43
44
45
46
47
6
7
8
9
2
5
14
Parts List
38
41
48

©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide 4
Frame Assembly
DO NOT tighten fasteners until instructed to do so.
Have your assistant hold frame parts in place during assembly.
Image Hardware Instructions
12 M12 x 130 mm SHCS
4 washers, 13 mm
2 M12 nylon lock nuts
Tools: Hex wrench, 10 mm
Socket wrench, 19 mm
2 M10 x 125 mm BHCS
2 washers, 11 mm
Connect lower cross brace to weight stack tower and kick
plate .
Align to far left hole.
Insert both guide rod fasteners from user side to align kick plate.
Hand tighten only. These will be removed temporarily in a later
step.
22 M12 x 35 mm SHCS
2 washers, domed
Tool: Hex wrench, 10 mm
Connect pivot frame to weight stack tower .
40
29
10
26
47
43
49 35
3
5
33
36
10
10
3
5
10
33
40
36
35
43
47
29
26
10
26
3
1
2
5
4

©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide 5
32 M12 x 35 mm SHCS
2 washers, 13 mm
Tool: Hex wrench, 10 mm
Connect front frame to lower cross brace .
42 M12 x 35 mm SHCS
2 washers, domed
Tool: Hex wrench, 10 mm
Connect handle assembly to weight stack tower .
5 2 M12 x 35 mm SHCS
2 washers, 13 mm
Tool: Hex wrench, 10 mm
Connect handle assembly to front frame .
2
47
36
3
2
10
33
1
36
1
3
33
36
47
36
10
1
2
36
47
1
36
47
2

©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide 6
Moving Parts
Image Hardware Instructions
11 wave washer Slide wave washer onto shaft on pivot arm .
2 1 end cap
1 M12 x 35 mm FHCS
Tool: Hex wrench, 8 mm
Slide shaft of pivot arm into pivot frame and secure.
62 M10 x 40 mm SHCS
2 washers, 11 mm
Tool: Hex wrench, 8 mm
Connect foot plate frame to lower cross brace and pivot frame .
75 M10 x 30 mm BHCS
5 washers, 11 mm, black
Tool: Hex wrench, 9 mm
Attach foot plate to frame.
8Tools: Hex wrench, 10 mm
Socket wrench, 19 mm
Torque wrench
Gently rock the frame to align. Tighten all M12 fasteners to a torque of 55
ft-lb (75 N-m).
Do not tighten the M10 screws installed in step 1 at this time. They will be
removed temporarily in a later step.
38
3
5
4
29
5
48
41
12
4
3
12
3
4
5
41
48
38
29
5
30
34
32
6
30
32
34
6
5

©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide 7
Route the Cable
Image Hardware Instructions
1Tools: Two open end wrenches, 19 mm Attach cable to pivot arm . Hold the rod end and tighten the
nut. Maximum distance is 25 mm.
2Tools: Hex wrench, 8 mm
Hex wrench, 4 mm
To route the cable around the lower pulley on the weight stack
tower, remove the cable retainer. Route the cable around the
pulley and then replace the cable retainer.
3Tools: Hex wrench, 10 mm
Open-end wrench, 19 mm
Torque wrench
To route the cable to the upper pulleys of weight stack tower,
remove the cable retainers, route the cables, and replace the
retainers. Tighten to 50 ft-lb (67 N-m) of torque.
32 hex head screws 5/16 x 1½-inch
2 washers, 9 mm
Tool: Socket wrench, ½-inch
Attach elbow pad (wide side towards user) to handle assembly .
1
27
46
42
1
27
42
46
5
5

©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide 8
Finish the Weight Stack Tower
Image Hardware Instructions
12 M10 x 125 mm BHCS
2 washers, 11 mm
Tool: Hex wrench, 6 mm
Remove the guide rod fasteners installed in step 1 of the Frame Assembly.
2 2 guide rods
1 weight stack spacer, 3-inch
Align the weight stack spacer over the holes on the base of the tower. Insert two
weight guide rods and lean outwards about 6 inches (15 cm), enough clearance
for the weights. Flat side of weight stack spacer should face user side.
3 2 bumpers
15 10 lb (4.5 kg) weight plates
1 top plate assembly
Slide one bumper on to each rod. Place the weight plates on the rods. Ensure the
side with three holes face the user side and single hole to the back. Place the top
plate over the weight plates. The plates and top plate should align ush on the
user side.
40
49
15
18
14
13
16
13
16
18
40
14
49
15

©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide 9
4Straighten the guide rods to a vertical position. Have your assistant lift the guide
rods into the upper part of the frame.
5 Tools: Hex wrench, 6 mm
Torque wrench
While the assistant is holding the rods into the upper frame, replace the two
guide rod bolts, removed in step 1, underneath the guide rods in the bottom
frame. Secure them to the kick plate. Let the guide rods drop onto the bolts and
fully tighten the bolts. Tighten M10 screws to 32 ft-lb (43 N-m) of torque.
61 M10 x 65 mm SHCS
2 washers, 11 mm
1 M10 nylon lock nut
Tools: Hex wrench, 8 mm
Socket wrench, 17 mm
1 guide rod with cap
Prepare the lower base for the add-on weight assembly. Place the retaining
screw through the bracket on the weight stack spacer.
Remove the cap from the guide rod and place the rod into bracket opening se-
cured by the screw.
7 2 bumpers
1 add-on weight
1 add-on weight handle
Place one bumper onto the third guide rod, followed by another bumper (wide
sides together), the add-on weight, and the add-on weight handle.
81 M10 x 65 mm SHCS
2 washers, 11 mm
1 M10 nylon lock nut
Tools: Hex wrench, 8 mm
Socket wrench, 17 mm
Replace the cap to the top of the rod and secure top of rod to weight stack tower
frame.
7
44
44
44
17
37
29
7
11
16
29
37 44
11
16
17
37
29
37
29
40
49

©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide 10
91 washer, rubber
1 washer, silver 13.5 mm ID x 35 mm OD
Place the washers into the top of the cable connector in the add-on weight han-
dle.
10 Tool: Torque wrench Attach the cable to the weight stack. Thread the bolt into the top plate assembly
until the cable meets ALL of the following requirements.
The top weight begins to separate from the second weight.
The selector pin can be easily inserted into each of the weight plates.
The add-on weight is engaged when the latch is in the down position.
At least six turns of the threads on the cable bolt extend into the add-on
weight selector stem.
The distance from the underside of the jam nut to the top of the washer should
be no more than 1.61 inch (41mm).
Tighten the locking bolt against the select stem to 50 ft-lb (81 N-m) of
torque.
Check and further adjust cable connections at arms if needed.
11 1 weight labels Remove back of labels. Align top holes on labels and top weight and place pin
into hole. Remove pin and place into a lower hole on labels. Re-align labels as
necessary and then press rmly onto weights. Rub vigorously and thoroughly to
adhere. Peel the extra label away and rub remaining labels again.
12 Lubricate the guide rods with a Teon-based lubricant, such as Tri-Flow Superior
Lubricant. Remove any excess with a clean cloth or tissue.
31
45 31
45
28
41 mm

©2019 Precor Inc. | Glute Extension RSL 618 | Assembly Guide 11
Image Hardware Instructions
1Snap the lower pulley shroud onto the lower front shroud . Place
the lower front shroud with pulley cover into frame and hook on to but-
tons.
21 M6 x 15 mm SHCS
Tool: Hex wrench, 4 mm
Secure lower pulley shroud.
3Place the lower rear shroud onto the frame. Raise it enough to hook
over buttons.
4Install the rear middle shroud . Slide it over the triangular tabs of the
lower shroud and hook it onto middle buttons.
Repeat for the front middle shrouds .
5Install the upper rear and front shrouds . Ensure to hook them
over the buttons and spacers.
62 M10 x 40 mm SHCS
Tools: Hex wrench, 8 mm
Torque wrench
Place shroud crown on top and secure. Recommended bolt torque
is 25 ft-lb (34 N-m).
7 Securely snap top tray into place.
8
19
Install the Shroud
20
39
25
19 24
20
21
22
38
23
9
8
21
22
23
24
25
9
38
39
IMPORTANT
Before installing the shroud, ensure that cable connections are correct and cables move smooth through their paths. If they do not,
STOP and adjust cable and routing. In addition, ensure all fasteners (including those preinstalled) are tightened appropriately.
Note The location of the lower pulley cover will vary depending on the model.

Complete the Assembly
IMPORTANT
As oor materials vary, it is important that you consult a licensed contractor to advise you on proper bolting techniques and appropriate fastener
types.
Standards can be changed or updated. Precor recommends that you keep apprised of your local industry standards. Precor shall not be liable for fail-
ure to properly secure and bolt strength equipment to the oor.
Precor recommends that the strength equipment be bolted down at all anchoring points. Adjust the round feet on the frame up or down by turning them left or right to help level the
equipment.
Anchor each oblong foot on the frame to the oor, including the feet on the weight stack tower. Each oblong foot has a rubber cap with slits to allow access the anchor points.
RSL Glute Extension 618 | Assembly Guide | P/N CW39563-101 ENG
© Precor, Incorporated | 30 August 2019
Final Checklist
• Lubricate the guide rods and chrome pad adjustment tubes with a Teon spray lubricant. Precor recommends using TriFlow brand.
• For all movable arm and pad frames, adjust and test each position. Verify that the adjustment pin fully engages and inserts freely into each position.
• Verify cables fully sit in cams (if applicable) and in pulleys. Cables should move without rubbing.
• Place the selector pin into the holder on the top plate assembly of the weight stack. Perform the exercise slowly. Verify cable moves freely without any binding. Select a
moderate weight and repeat.
• Verify the selector pin can be inserted into each weight plate.
• Verify all fasteners and the cable retention nut are tight. Ensure they meet the torque call outs in the assembly guide.
• Refer to the Maintenance Guide that came with your product for details on maintaining the equipment.
